Search Results (13)

An electromagnetic launcher is a kind of rail symmetrical distribution launcher. When a symmetrical current is passed between the rails, the strong magnetic field is symmetrically distributed between the two rails. The bore parameters affect the efficiency and accuracy of the launcher. Launching accuracy is an important evaluation content for assessing the technical index of the electromagnetic launcher. In this paper, experiments were carried out to investigate the influence factors of the launching accuracy of a small-caliber electromagnetic launcher. The experimental results show that: (1) The consistency of the muzzle velocity increases with the increase of the rail separation. When the rail separation is 16 mm, the mean deviation of the muzzle velocity is the smallest, at 16.71, 15.72, and 10.77, respectively. When the rail separation is constant, the mean deviation of the muzzle velocity is 10.77, while the convex arc height is 1 mm. Increasing the rail separation and the convex arc height is beneficial to improving the consistency of the initial velocity. (2) When the rail separation is certain, increasing the convex arc height significantly improves the firing accuracy and firing intensity, and when the convex arc height increases from 0 mm to 1 mm, the firing intensity is reduced from 9.6 to 4.41, and the firing intensity decreases from 10.34 to 5.79, which significantly reduces the firing deviation and increases the muzzle consistency of the armature under repeated firing conditions. (3) The muzzle attitude is mainly affected by the effective mass ratio. Within a certain range, adding load can make the muzzle attitude of the integrated projectile more stable. However, when the load mass is too large, it will have a negative impact on the muzzle attitude. The results show that under the two cases of the effective mass ratio of 0.43 and 0.49, the integrated projectile has a better muzzle attitude. Full article

This study presents a flywheel energy storage system utilizing a new multi-axial flux permanent magnet (MAFPM) motor–generator for coil launchers. The traditional winding structure of the flywheel is effective for energy recovery over several minutes. However, because the projectile is launched from coil launchers in less than one second, the traditional winding structure experiences insulation deterioration and winding damage due to the high current. This study proposes a winding structure made of an 8 × 0.5 mm conductor with eight turns to meet the energy requirements of coil launchers. Furthermore, the motor winding was divided into two sections, which were compared using both series and parallel connection methods as described in the literature. The proposed system produces energy that is 29.96%, 85.63%, and 81.11% lower than the A winding (where A and B are identical), the A + B winding (series connected), and A//B winding (parallel connected) at the same speed. However, as the speed increases by 258.26%, the energy output rises by 215.88%. The flywheel motor–generator’s series-parallel winding structure reaches its current carrying capacity at 1188 rpm. By utilizing a separate winding instead of the traditional motor–generator winding, a current of 38.4 A is achieved, ensuring that the winding’s current carrying capacity remains within the design parameters. Experimental data have proven that the proposed multi-wire winding structure is an innovative solution for coil launchers, surpassing various combinations of motor–generator windings found in the literature. Furthermore, the placement of the proposed winding in a single slot in the design ensures a compact structure. Full article

Recent developments in electromagnetic launchers have created potential applications in transportation, space, and defense systems. However, the total efficiency of these launchers has yet to be fully realized and optimized. Therefore, this paper introduces a new design idea based on increasing the magnetic flux lines that facilitate high output velocity without adding any excess energy. This design facilitates obtaining a mathematical equation for the launcher inductance which is difficult to analytically represent. This modification raises the launcher efficiency to 36% higher than that of the ordinary launcher at low operating voltage. The proposed design has proven its superiority to traditional launchers, which are limited in their ability to accelerate microsatellites from the ground to low Earth orbit due to altitude and velocity constraints. Therefore, an aircraft is used as a flying launchpad to carry the launcher and bring it to the required height to launch. Meanwhile, it is demonstrated experimentally that magnetic dipoles in the projectile material allow the launcher coil’s magnetic field to accelerate the projectile. This system consists of the launcher coil that must be triggered with a high amplitude current from the high DC voltage capacitor bank. In addition, a microcontroller unit controls all processes, including the capacitor bank charging, triggering, and velocity measurement. Full article

Most aircraft launchers exhibit a rapid acceleration of the launching aircraft, often exceeding ten times the acceleration due to gravity. However, only magnetic launchers offer flexible control over the propulsion force of the launcher cart, enabling precise control over the aircraft’s acceleration and speed during its movement on the launcher. Consequently, extensive research is being conducted on magnetic launchers to ensure the repeatability of launch parameters, protect against aircraft overloads, and ensure operator safety. This article describes the process of modeling and analyzing the dynamical properties of a launch cart of an innovative prototype launcher, which employs a passive magnetic suspension with high-temperature superconductors, developed under the GABRIEL project. The developed mathematical model of the magnetic catapult cart was employed to conduct numerical studies of the longitudinal and lateral movement of the cart, as well as the configuration of the UAV–cart system during UAV takeoff under variable atmospheric conditions. An essential aspect of the research involved experimentally determining the magnetic levitation force generated by the superconductors as a function of the gap. The results obtained demonstrate that the analyzed catapult design enables safe UAV takeoff. External factors and potential vibrations resulting from uneven mass distribution in the UAV–cart system are effectively balanced by the magnetic forces arising from the Meissner effect and the flux pinning phenomenon. The primary advantage of the magnetic levitation catapult, in comparison to commercial catapults, lies in its ability to provide a reduced and consistent acceleration throughout the entire takeoff process. Full article

The subject of the research is a model of a magnetic launcher, which is an innovative alternative to commercially occurring unmanned aircraft launchers (UAV). As the take-off is an energy-demanding phase of the flight; therefore, abandoning the power supply of the UAV during this phase significantly affects increasing the potential range and duration of UAV flight. The magnetic launcher offers the significant advantage of minimizing friction between the starting cart and the launcher, resulting in the higher energy efficiency of the system. Research conducted so far has shown that the possibility of accelerating the aircraft on the longer runway offered by the launcher reduces aircraft overloads occurring during take-off. As a result, the launcher, aircraft, and onboard equipment are much safer. This paper presents the system’s mathematical modeling and numerical simulation results for micro-class UAV take-off and landing using the analyzed magnetic launcher. The computer program for analyzing system dynamics was implemented in the MATLAB environment. Simulation results were visualized graphically and as animations in Virtual Reality. The VR application was implemented in Unity and ran on VR goggles Oculus Quest2. The simulations carried out show that—in the absence of control—an important factor reducing the takeoff distance and affecting the aircraft load is the adoption of a non-zero takeoff thrust of the UAV. The initial pitch angle also has a significant impact on the takeoff process. With an increase in this parameter, the length of the takeoff distance decreases and the lift-off speed decreases, but too much pitch angle may result in the aircraft descending in the first moments of flight, which could lead to a collision with the launch rails. Full article

This paper presents a servo control method for the multiple launch rocket system (MLRS) launcher during marching fire operations. The MLRS, being a complex nonlinear system, presents challenges in designing its servo controller. To address this, we introduce the fuzzy adaptive sliding mode control (FASMC) approach. The permanent magnet synchronous motor (PMSM) and controller of the MLRS were simulated in the MATLAB/Simulink environment. The dynamic model of the MLRS during marching fire was established using multi-body system theory, vehicle mechanics, and launch dynamics. The dynamic model was then integrated with the FASMC-based controller using the Adams/View module. Numerical calculations were performed to demonstrate the control performance and the effectiveness and applicability of the proposed approach were validated through a comparison experiment between FASMC and other common control methods. Full article

A simple model is presented to describe how the radio frequency electromagnetic field modifies the plasma density the antenna faces in tokamaks. Aside from “off-the-shelf” equations standardly used to describe wave-plasma interaction relying on the quasilinear approach, it invokes the ponderomotive force in presence of the confining static magnetic field. The focus is on dynamics perpendicular to the $B_o$ magnetic field. Stronger fields result in density being pushed further away from the launcher and in stronger density asymmetry along the antenna. Full article

More and more CubeSats cooperate to implement complex space exploration missions. In order to store and deploy more CubeSats in a rocket-launch mission, this paper presents a new CubeSat deployer with large-capacity storage. Different from the traditional one with the compression springs, the deployer with electromagnetic actuators is proposed to achieve the transportation and release. A new electromagnetic actuator with high thrust density was applied to adjust the release speeds of the CubeSats with different masses, and a new electromagnetic convey platform with attractive force was designed to transfer the stacked CubeSats to the release window. The equivalent magnetic circuit method was used to the establish electromagnetic force models. The simplified dynamic models of the transportation and release were built. The magnetic field, electromagnetic force, and motion characteristics were analyzed. The prototype was developed to verify the performance of the proposed configuration of the deployer with electromagnetic actuators. The experimental results show that stacked CubeSats can be transported smoothly even under constant external interference. The launcher achieved high thrust density and effectively adjusted the separation speed of the CubeSats. Full article

The ablation and wear of the four-rail electromagnetic launcher during the working process will aggravate the damage of the armature and rail, and greatly affect the service life of the launcher. To effectively alleviate rail damage, this paper applies the copper-steel composite rail to the four-rail electromagnetic launcher and proposes a new four-rail electromagnetic launcher. Based on the quadrupole magnetic field theory, the physical model of the new four-rail electromagnetic launcher is established, and the electromagnetic characteristics of the ordinary and new launchers are compared and analyzed using the finite element method. On this basis, the influence of composite layer parameters on the electromagnetic characteristics of copper-steel composite quadrupole rail is explored. The study found that the new four-rail electromagnetic launcher can provide a better launch magnetic field environment for smart loads, and the current distribution of the armature and the rail contact surface is more uniform, which can effectively improve the contact condition between the armature and the rail. The composite layer parameters of copper-based composite rail will have a certain impact on electromagnetic characteristics, and copper-steel composite rail of appropriate proportions can be selected according to different needs. The model proposed in this paper has a certain degree of scientificity and rationality. Full article

During the operation of the Quadrupole Compound Orbital electromagnetic launcher, the current is easy to gather in the armature and the rail contact surface. Serious turn and arc ablation can occur, causing damage to the rail and the armature and affecting the life of the launcher. To better solve the thermal ablation problem of the armature and the rail, three different configurations of the rail and the armature are established, and the current density, magnetic field distribution and electromagnetic force of the rail and the armature are compared and analyzed using the finite element method, and the effect of concave and convex values of the armature rail on current distribution and electromagnetic force is discussed. The results show that the planar armature can effectively reduce the maximum current density and mitigate thermal damage. The concave elliptical rail produces the largest electromagnetic thrust and the smallest radial electromagnetic force, and the armature is more stable during firing. The maximum current density and magnetic field strength are negatively correlated with the concave and convex values; the electromagnetic thrust applied to the concave elliptical armature is negatively correlated with the concave value, while the electromagnetic force applied to the convex elliptical armature is positively correlated with the convex value. Full article

Hollow core microstructures powered by infrared lasers represent a new and promising area of accelerator research, where advanced concepts of electromagnetism must be used to satisfy multiple requirements. Here, we present the design of a dielectric electromagnetic band gap (EBG) mode launcher–converter for high-power coupling in dielectric laser accelerators (DLAs). The device is based on a silicon woodpile structure, and it is composed of two perpendicularly coupled hollow-core waveguides—a transverse electric (TE)-like mode waveguide (excited from laser power) and a transverse magnetic (TM)-like mode (accelerating) waveguide—in analogy with the TE${}_{10}$-to-TM${}_{01}$ waveguide mode converters of radio frequency (RF) linear accelerators (LINACs). The structure is numerically designed and optimized, showing insertion losses (IL) $<0.5$ dB and efficient mode conversion in the operating bandwidth. The operating wavelength is 5 $\mathsf{\mu }$m, corresponding to a frequency of ≈60 THz, in a spectral region where solid-state continuous-wave (CW) lasers exist and are actively developed. The presented woodpile coupler shows an interaction impedance in the order of 10 k$\Omega$, high power handling and efficiency. Full article

Reluctance coil guns are electromagnetic launchers having a good ratio of energy transmitted to actuator volume, making them a good choice for propelling objects with a limited actuator space. In this paper, we focus on an application, which is launching real size soccer balls with a size constrained robot. As the size of the actuator cannot be increased, kicking strength can only be improved by enhancing electrical to mechanical energy conversion, compared to existing systems. For this, we propose to modify its inner structure, splitting the coil and the energy storage capacitor into several ones, and triggering the coils successively for propagating the magnetic force in order to improve efficiency. This article first presents a model of reluctance electromagnetic coil guns using a coupled electromagnetic, electrical and mechanical models. Four different coil gun structures are then simulated, concluding that splitting the kicking coil into two half size ones is the best trade-off for optimizing energy transfer, while maintaining an acceptable system complexity and controllability. This optimization results in robust enhancement and leads to an increase by $104\%$ of the energy conversion compared to a reference launcher used. This result has been validated experimentally on our RoboCup robots. This paper also proves that splitting the coil into a higher number of coils is not an interesting trade-off. Beyond results on the chosen case study, this paper presents an optimization technique based on mixed mechanic, electric and electromagnetic modelling that can be applied to any reluctance coil gun. Full article

In an electromagnetic rail launcher, a metal liquid film is created at the armature/rail (A/R) contact interface. It has a significant impact on electromagnetic launch performance. In this paper, an electromagnetic-elastic mechanics-hydrodynamics multi physics coupling model is established in consideration of the metal liquid film’s own acceleration, magnetic pressure and dynamic changes in film thickness. Based on this model, the lubricating characteristics of magnetic pressure and fluid pressure distribution, film thickness distribution and velocity distribution of the metal liquid film were studied. When the velocity of the metal liquid film is very fast, and the magnetic pressure is reduced, it may fail to maintain stability and rupture, which may be an important reason for the transition. Finally, this paper analyzes the lubrication effect of the metal liquid film, and points out that when we want strictly to control the muzzle velocity, the lubrication effect of the metal liquid film must be considered. Full article
