Efforts to optimize the design and enhance the efficiency of standing-wave thermoacoustic refrigerators (SWTARs), particularly those with parallel plate stacks, are crucial for achieving rapid and straightforward engineering estimates. This study primarily focused on optimizing the coefficient of performance (COP) by combining linear thermoacoustic theory (LTT) with the design of experiments (DOE) approach. The investigation centered around five key parameters affecting the COP once the working gas had been selected. Then, based on LTT, the COP was estimated numerically over defined intervals of those five parameters. Moreover, through quantitative and qualitative effect analyses, these five parameters and their interactions were determined. Utilizing a transfer function, the study aimed to delineate the best COP value (1.76) over a defined interval of the parameters as well as the contribution of the thermoacoustic main parameters (55.69%) and their interactions (two-way interactions = 33.30%, three-way interactions = 7.36%, and four-way interactions = 3.35%). Furthermore, a comparison between contour and surface responses and several statistical decision approaches applying the full factorial design verified the robustness of the study’s findings. Ultimately, the COP results obtained aligned with the existing literature, underscoring the validity and relevance of the study’s methodologies and conclusions. Full article

Thin-walled connection structures are commonly used in the hot-end components of aerospace vehicles. Large deflection nonlinear responses and fatigue failure occur due to their discontinuous mass distribution and prominent cross-sectional changes under the action of complex thermal, aerodynamic, and noise loads. A thermoacoustic fatigue test was carried out to obtain the acoustic and vibration responses and fatigue life changes of the connection structure under heat flow conditions in engineering applications. The high-temperature acoustic fatigue test system of aviation thin-walled structures was used, taking the high-temperature alloy thin-walled plate-load-bearing frame bolted connection structure as the research object. As a result, the vibration response and fatigue life under different thermoacoustic loads were obtained. The contact finite element method was used to simulate the connection pre-tightening force, and the coupled finite element/boundary element method was used to calculate the acoustic and vibration response of the heat flow conditions. The changing rules of the frequency response peak value at the critical point of the thin-walled connection structure under the effects of different temperature fields, fluid fields, and sound fields were obtained through the processing and analysis of the calculation results. Considering the structural vibration fatigue damage mechanism, this study employed an improved rainflow counting method to compute the rainflow circulation matrix (RFM) and rainflow damage matrix (RFD) of the vibration stress time history at critical points within the structure framework. Said method was combined with Miner’s linear cumulative damage theory to estimate the fatigue life under various thermal-fluid-acoustic coupled loads. A comprehensive analysis validates the accuracy of the established numerical simulation calculation model in identifying critical connection points within structures subjected to pre-tightening forces. This model effectively characterizes thermal, aerodynamic, and acoustic loads on high-temperature alloy thin-walled-load-bearing frame bolted connection structures. It delineates the relationship between vibration response and fatigue life while assessing the impact of three distinct load parameters. Full article

In this article, a comprehensive review of the computational fluid dynamics (CFD)-based modeling approach for thermoacoustic energy conversion devices is proposed. Although thermoacoustic phenomena were discovered two centuries ago, only in recent decades have such thermoacoustic devices been spreading for energy conversion. The limited understanding of thermoacoustic nonlinearities is one of the reasons limiting their diffusion. CFD is a powerful tool that allows taking into consideration all the nonlinear phenomena neglected by linear theory, on which standard designs are based, to develop energy devices that are increasingly efficient. Starting from a description of all possible numerical models to highlight the difference from a full CFD method, the nonlinearities (dynamic, fluid dynamic and acoustic) are discussed from a physical and modeling point of view. The articles found in the literature were analyzed according to their setup, with either a single thermoacoustic core (TAC) or a full device. With regard to the full devices, a further distinction was made between those models solved at the microscopic scale and those involving a macroscopic porous media approach to model the thermoacoustic core. This review shows that there is no nonlinear porous media model that can be applied to the stack, regenerator and heat exchangers of all thermoacoustic devices in oscillating flows for each frequency, and that the eventual choice of turbulence model requires further studies. Full article

This paper is concerned with the study of low-cost, low-power thermoacoustic electricity generators. Based on target electrical output power values of 50 and 100 W, three standing wave prototypes (of both one-stage and two-stage prototypes) integrating a commercial loudspeaker with different coupling arrangements are conceived. Each stage consists of a square-pore stack sandwiched between hot and ambient heat exchangers. The working gas is air at atmospheric pressure. The prototypes’ efficiency in converting heat to electrical power is simulated by the specialized Design Environment for Low-Amplitude ThermoAcoustic Engines (DeltaEC) design tool based on the linear theory of thermoacoustics. At a given operation frequency, the optimal impedance matching between the loudspeaker and the engine is realized by adjusting both the engine parameters (stack location, stack length, heat exchangers length, loudspeaker location) and loudspeaker parameters (load resistance and box volume). Computations reveal that the one-stage engine and two-stage engine with loudspeakers coupled in side-branch mode are able to meet the target output power values with comparable thermal-to-electric efficiency (4.6%). The two-stage engine with the loudspeaker coupled in push–pull mode is unable to reach the desired power output and is characterized by low conversion efficiencies (2%) due to the poor loudspeaker–engine acoustic impedance matching. Full article

In this paper a simplified two-dimensional computational model for studying the entropy generation characteristics of thermoacoustic heat exchangers with plane fins is presented. The model integrates the equations of the standard linear thermoacoustic theory into an energy balance-based numerical calculus scheme. Relevant computation results are the spatial distribution of the time-averaged temperature, heat fluxes and entropy generation rates within a channel of a parallel-plate stack and adjoining heat exchangers. For a thermoacoustic device working in the refrigeration mode, this study evidences as a target refrigeration output level can be achieved selecting simultaneously the heat exchangers fin length and fin interspacing for minimum entropy generation and that the resulting configuration is a point of maximum coefficient of performance. The proposed methodology, when extended to other configurations, could be used as a viable design tool for heat exchangers in thermoacoustic applications. Full article
