Nonlinear photocurrents (NPs) are electrical currents expected to be measured at the electrodes of a device consisting of an active area, sensitive to light, with a higher-order in-electric field where light-impinging geometry (LIG) is the determining factor in the experimental observation. Although the phenomenology of this light–matter interaction is clear for light directed on a lateral device plane with well-defined azimuthal and incidence angles, as well as light polarization angle, it can be quite complicated for a vertical device structure and reconsideration of the expected NP contributions is necessary in the latter case. In this study, we used a visual approach to describe the LIG for vertical device structures using a specific example of a photodiode, and showed that these angles must be redefined, namely, the interchangeability of azimuthal and incidence angles. The influence of device geometry-dependent optical illumination is reflected on the behavior of NP; therefore, the NPs that are known to be forbidden in certain LIGs can be allowed and vice versa. These results pave the way for the utilization of NPs in flexible optoelectronic applications. Full article

Effective maintenance and management of road infrastructure are essential for community well-being, economic stability, and cost efficiency. Well-maintained roads reduce accident risks, improve safety, shorten travel times, lower vehicle repair costs, and facilitate the flow of goods, all of which positively contribute to GDP and economic development. Accurate intersection mapping forms the foundation of effective road asset management, yet traditional manual digitization methods remain time-consuming and prone to gaps and overlaps. This study presents an automated computational geometry solution for precise road intersection mapping that eliminates common digitization errors. Unlike conventional approaches that only detect intersection positions, our method systematically reconstructs complete intersection geometries while maintaining topological consistency. The technique combines plane surveying principles (including line-bearing analysis and curve detection) with spatial analytics to automatically identify intersections, characterize their connectivity patterns, and assign unique identifiers based on configurable parameters. When evaluated across multiple urban contexts using diverse data sources (manual digitization and OpenStreetMap), the method demonstrated consistent performance with mean Intersection over Union greater than 0.85 and F-scores more than 0.91. The high correctness and completeness metrics (both more than 0.9) confirm its ability to minimize both false positive and omission errors, even in complex roadway configurations. The approach consistently produced gap-free, overlap-free outputs, showing strength in handling interchange geometries. The solution enables transportation agencies to make data-driven maintenance decisions by providing reliable, standardized intersection inventories. Its adaptability to varying input data quality makes it particularly valuable for large-scale infrastructure monitoring and smart city applications. Full article

The present article offers a detailed analysis of helium jet velocity and vorticity intensity distribution using the particle image velocimetry (PIV) technique. A gaseous fuel injector featuring an interchangeable tip was implemented. The test campaign involved the use of three nozzle patterns characterized by different orifices shape and orientations. The helium was injected into a constant volume chamber (CVC) and the delivery pressure varied, as well as that inside the chamber, in order to obtain pressure ratios (PRs) ranging from 2 to 20. The synchronization system was set to record two consecutive frames at different time-instants after the start of energizing (aSOE). Green light from a dual cavity Nd:YAG laser was used for illumination and a 4-megapixel PIV-camera for image capture. Vegetable oil particles were seeded into the chamber to trace the helium jet structure and cross-correlation methodology employed to measure their instantaneous displacements. The role of orifices size and orientations has been deeply scrutinized and related to the morphological outcomes. The least-oriented nozzle (first) exhibited the highest values of jet penetration and well-defined vortex structures. In contrast, the more the orifices are oriented, the wider the regions interacting with surrounding environment. Specifically, geometry with smaller orifice sizes (third) returned an overall absence of localized significant vortex structures. This deficiency is counterbalanced by a large distribution of small vortices that were observed to replace the main rings for each condition examined. Full article

Urban transportation systems, particularly underground interchanges, present significant challenges for sustainable and resilient urban design due to their complex road geometries and dense traffic signage. These challenges are further compounded by the interaction of diverse road users, which heightens the risk of accidents. To enhance both safety and sustainability, this study integrates advanced driving simulation techniques with machine learning models to improve driving safety and comfort in underground interchanges. By utilizing a driving simulator and 3D modeling, real-world conditions were replicated to design key traffic safety features with an emphasis on sustainability and driver well-being. Critical safety parameters, including speed, acceleration, and pedal use, were analyzed alongside comfort metrics such as lateral acceleration and steering torque. The LightGBM machine learning model was used to classify safety and comfort grades with an accuracy of 97.06%. An important ranking identified entrance signage and deceleration zones as having the greatest impact on safety and comfort, while basic road sections were less influential. These findings underscore the importance of considering visual cues, such as markings and wall color, in creating safer and more comfortable underground road systems. This study’s methodology and results offer valuable insights for urban planners and engineers aiming to design transportation systems that are both safe and aligned with sustainable urban mobility objectives. Full article

For years, gears have been self-made by many industrial plants as substitutes (custom spare parts) for original parts from the manufacturer. This common practice uses a process called reverse engineering (RE). However, in the available scientific database, it is difficult to find articles about the accuracy of such a process. And while it is obvious that in order to obtain the most accurate quality of such a process, modern measurement techniques (coordinate, optical) should be used, most companies cannot afford to purchase such equipment. Reproducing gear geometry is difficult. But the issue of RE of non-standard gears seems to be even more difficult. This is why the authors undertook pilot studies to assess the accuracy of the RE process of worn, non-standard spur gears using conventional techniques and measuring instruments. Eight gears were tested, the module of which ranges from 1.020 to 4.98 mm. The key parameter was selected to estimate the accuracy of the process—the base pitch. The goal is to determine the value of the profile angle. Eleven models were proposed to estimate the nominal tolerance field, using various types of random data distribution. The tested gears were made in IT grade: 6, 7, 8, and 9 according to DIN 3961. Vernier disk micrometers were used for research. It has been shown that the nominal module does not have to be treated as a random variable in the population. Equation of identity was developed, allowing conversion of any gear with specific values of geometric parameters into an identical gear with alternative values of these parameters. The most effective estimating model was selected taking into account the symmetric Student–Fisher distribution with a confidence level of 60%. However, it is not possible to correctly reproduce the geometry of the gear wheel in that way. The following aspects should be taken into account: type and degree of mode of failure, number of load cycles, rotational speed, direction of rotation, material, type of thermochemical treatment, and torque. A simulation using FEM should be performed to determine the fatigue plastic deformations and diagnose their impact on the geometric dimensions of the gear wheel. Full article

A car seat’s function is to support, protect, and make passengers and drivers feel comfortable during a trip. A more uniform pressure distribution and a larger contact area usually provide less discomfort. Consequently, the seat pan’s material and geometry play an essential role in the design process. A shaped pad was opportunely designed and realized, starting from the pressure distributions between the buttocks and the seat pan; pressure data were acquired during an initial experiment involving 41 people, representing a wide range of percentiles. The shaped pad was compared with a standard one by building a special seat with an interchangeable internal pad and testing the standard and the new seat; the second experiment involved 52 people that tested both seats. The tests were conducted to assess comfort (33 subjects were asked to be seated for 1 min each) and discomfort (19 subjects were asked to be seated for 15 min each); during the tests, pressure distribution and contact area data were gathered. The results showed that, for both tests, about 80% of the participants, among which 100% of the female sample, preferred the shaped seat pan pad. Even if the material was exactly the same, the shaped pad seemed to be softer, more comfortable, and more suited to the body’s shape than the standard one. The design methodology was demonstrated to be very useful for granting a more uniform pressure distribution and a wider contact area, i.e., higher comfort and less discomfort. Full article

This study aimed to compare different pancreatic enzyme preparations (PEPs) available in Germany regarding particle geometry and size, and to evaluate enzyme activity under physiologically relevant conditions in vitro. Pancreatic endocrine insufficiency is characterized by deficiency of pancreatic enzymes resulting in maldigestion. It is orally treated by pancreatic enzyme replacement therapy. The formulations differ in their physical properties and enzyme release behavior, potentially resulting in inconsistent dosages and poor interchangeability of products. A total of 25 products were analyzed for particle size and number of particles per capsule. Enzyme activities of lipase, amylase, and protease were measured by digestion of olive oil emulsion, starch, and casein, respectively. To analyze enzyme release, gastric environments were simulated by incubating PEPs at pH 1, 4, or 5. Duodenal conditions were simulated by subsequent incubation at pH 6. Regarding physical properties and enzyme release kinetics, considerable differences between different PEPs were found. Furthermore, compared to the label claim, excess lipase activity was observed for most products, reaching up to 148%. These in vitro results suggest poor interchangeability of PEPs, potentially explained by physical and release characteristics. Physicians and patients should be aware of the potential gap between label claims and the real-life performance of different PEPs. Full article

Heavy plates are indispensable semi-finished products. Quality is strongly linked with production, so the rolling process must be performed within well-defined narrow tolerances. To meet this challenge, adequate modeling has become a necessity. In contrast to continuous strip rolling, where the workpiece can be modeled as a semi-infinite strip and 2D modeling can be argued quite well, this strategy is insufficient for the comprehensive modeling of heavy plate rolling. The geometry of the heavy plate favors an inhomogeneous distribution of relevant state variables, such as temperature. In addition, if the process involves longitudinal and spreading passes, the required plate rotation spoils the assumption of a symmetric arrangement that might have been acceptable before rotation. Consequently, the derivation of suitably reduced models is not trivial, and modeling tailored to the specific objective of investigation is of utmost importance. Models intended to resolve the evolution of inhomogeneities in the field variables are demanding and computationally expensive. An effective modular modeling strategy was developed for such models to be used offline. Mutually complementing and interchangeable modules may constitute an efficient modeling strategy valid for the specific subject of interest. The presented approach reduces the enormous cost of complete 3D simulation as much as the model purpose allows for. Full article

Descriptive geometry has indispensable applications in many engineering activities. A summary of these is provided in the first chapter of this paper, preceded by a brief introduction into the methods of representation and mathematical recognition related to our research area, such as projection perpendicular to a single plane, projection images created by perpendicular projection onto two mutually perpendicular image planes, but placed on one plane, including the research of curves and movements, visual representation and perception relying on a mathematical approach, and studies on toothed driving pairs and tool geometry in order to place the development presented here among them. As a result of the continuous variability of the technological environment according to various optimization aspects, the engineering activities must also be continuously adapted to the changes, for which an appropriate approach and formulation are required from the practitioners of descriptive geometry, and can even lead to improvement in the field of descriptive geometry. The imaging procedures are always based on the methods and theorems of descriptive geometry. Our aim was to examine the spatial variation in the wear of the tool edge and the machining of the components of toothed drive pairs using two cameras. Resolving contradictions in spatial geometry reconstruction research is a constant challenge, to which a possible answer in many cases is the searching for the right projection direction, and positioning cameras appropriately. A special method of enumerating the possible infinite viewpoints for the reconstruction of tool surface edge curves is presented in the second part of this paper. In the case of the monitoring the shape geometry, taking into account the interchangeability of the projection directions, i.e., the property of symmetry, all images made from two perpendicular directions were taken into account. The procedure for determining the correct directions in a mathematically exact way is also presented through examples. A new criterion was formulated for the tested tooth edge of the hob to take into account the shading of the tooth next to it. The analysis and some of the results of the Monge mapping, suitable for the solution of a mechanical engineering task to be solved in a specific technical environment, namely defining the conditions for camera placements that ensure reconstructibility are also presented. Taking physical shadowing into account, conclusions can be drawn about the degree of distortion of the machined surface from the spatial deformation of the edge curve of the tool reconstructed with correctly positioned cameras. Full article

Triangles are an ever-present feature in nature, which the building construction industry duly echoes. However, an exact expression intended to supply the radiant field of any triangle in an upright or inclined position has not been identified by previous research. In this case, the author has been able to solve, via direct integration, the canonical expression of radiative transfer. This result alone confers a myriad of possibilities, that had been inconceivable before, for studying in detail the three-dimensional heat-transfer behavior of volumes and figures in which triangles manifest, such as fins, windows, roof-gables and louvers of various kinds. Typically, shading devices, when tilted, give rise in their extremes to rhomboidal shapes which were difficult to take into account or had to be subject to discretization and subsequent Monte Carlo methods in order to perform an approximate calculation of their emissions. This implied a lengthy and inexact procedure that induced many errors and consumed computing time. We can now avoid all these former downsides due to the advances hereby presented. As this novel expression can be converted into an algorithm, it will be advantageously employed for simulation. This significant finding dovetails into the intricate puzzle of radiated heat and we believe that its consequences will greatly affect the conception and design of HVAC devices, aircraft manufacturing and specifically the building or lighting industries, among others. Full article

Radiant heat interchanges are pivotal to assessing the energy use of buildings and facilities that channel some sort of solar radiation. Form factor integrals are needed for an accurate simulation of the main features of the envelope of such buildings. However, the expressions required when the space under analysis is curved, for instance, in domes and vaults, are not feasible. The calculation process of algorithms is usually addressed by cumbersome analytical deductions or else by rough statistical approximations included in the simulations, such as ray-tracing methods. Neither of which works properly under curved geometries. The following article deals with an innovative methodology for employing an exact property that solves any spherical configuration of the radiant surfaces. The newly found relationship is validated by comparison with other solutions previously deducted by the author and by numerical simulations when available. Since there is no other exact method of calculating radiation exchanges within spherical fragments, we consider that this finding represents an advance which contributes to overcoming a variety of unexplained and practical problems of radiative heat transfer applicable to architectural developments, lighting elements and aircraft components. Full article

Quantum fluctuations inherent in electronic systems positioned close to magnetic instabilities can lead to novel collective phenomena. One such material, $\beta$-Ti${}_6$Sn${}_5$, sits close to ferromagnetic (FM) instability and can be pushed to an itinerant FM-ordered state with only minute magnetic or non-magnetic doping. The binary nature of this compound, however, limits the tuning variables that can be applied to study any emergent physics, which are likely to be sensitive to the introduction of chemical disorder.Accordingly, we grew high-quality single crystals of a new quaternary compound Zr${}_3$V${}_3$GeSn${}_4$ from a Sn-rich self flux, and determined the structure with single-crystal X-ray diffraction. Zr${}_3$V${}_3$GeSn${}_4$ forms in an ordered derivative of the hexagonal $\beta$-Ti${}_6$Sn${}_5$ structure with Zr and V atomic positions that show no indication of site interchange. Ge likewise occupies a single unique atomic position. The V site, which would be the one most likely to give rise to any magnetic character, is located at the center of a distorted octahedron of Sn, with such octahedra arranged in face-sharing chains along the crystallographic c axis, while the chains themselves are organized in a kagome geometry. Zr${}_3$V${}_3$GeSn${}_4$ represents the second known quaternary phase within this system, suggesting that other compounds with this structure type await discovery. Full article

The rigid-backbone bidentate ligands Indoline-2-carboxylic acid (IndoliH) and Indole-2-carboxylic acid (IndolH) were evaluated for rhodium(I). IndoliH formed [Rh(Indoli)(CO)(PPh₃)] (A2), while IndolH yielded the novel dinuclear [Rh¹(Indol’)(CO)(PPh₃)Rh²(CO)(PPh₃)₂] (B2) complex (Indol’ = Indol²⁻), which were characterized by SCXRD. In B2, the Rh¹(I) fragment [Rh¹(Indol’)(CO)(PPh₃)] (bidentate N,O-Indol) exhibits a square-planar geometry, while Rh²(I) shows a ‘Vaska’-type trans-[O-Rh²(PPh₃)₂(CO)] configuration (bridging the carboxylate ‘oxo’ O atom of Indol²⁻). The oxidative addition of MeI to A2 and B2 via time-resolved FT-IR, NMR, and UV/Vis analyses indicated only Rh(III)-alkyl species (A3/B3) as products (no migratory insertion). Variable temperature kinetics confirmed an associative mechanism for A2 via an equilibrium-based pathway (ΔH^≠ = (21 ± 1) kJ mol⁻¹; ΔS^≠ = (−209 ± 4) J K⁻¹mol⁻¹), with a smaller contribution from a reverse reductive elimination/solvent pathway. The dinuclear complex B2 showed the oxidative addition of MeI only at Rh¹(I), which formed a Rh(III)-alkyl, but cleaved the bridged Rh²(I) site, yielding trans-[Rh^I(PPh₃)₂(I)(CO)] (5B) as a secondary product. A significantly smaller negative activation entropy [ΔH^≠ = (73.0 ± 1.2) kJ mol⁻¹; ΔS^≠ = (−21 ± 4) J K⁻¹mol⁻¹] via a more complex/potential interchange mechanism (the contribution of ΔS^≠ to the Gibbs free energy of activation, ΔG^≠, only ±10%) was inferred, contrary to the entropy-driven oxidative addition of MeI to A2 (the contribution of ΔS^≠ to ΔG^≠ ± 75%). Full article

We consider the influence of vapor content in the mixed flow leaving a liquid-vapor ejector on the energy efficiency of a vacuum unit. As shown by numerical studies of liquid-vapor ejectors, this issue is important as vapor overproduction, which accompanies the process of secondary flow ejection, directly impacts the efficiency of the working process of both the liquid-vapor ejector and the vacuum unit as a whole. The greater the degree of vapor overproduction, the greater the load on the vapor phase of the separator, which is part of the vacuum unit. In addition, the liquid phase must be returned to the cycle to ensure the constancy of the mass flow rate of the working fluid of the primary flow. Our numerical study results revealed the rational value of the degree of vapor overproduction at which the efficiency of the liquid–vapor ejector was maximized, and the amount of additional working fluid that needed to enter the cycle of the vacuum unit was minimal. Experimental condition monitoring studies on the liquid–vapor ejector were carried out on plane-parallel transparent models with different flow path geometries. Through experimental studies, we confirmed and adjusted the values of the achievable efficiency of the working process of a liquid–vapor ejector, depending on the degree of vapor overproduction. Using a comparative analysis of liquid–vapor ejectors with different flow path geometries, differences were revealed in their working processes, which consisted of the degree of completion of the mixing of the working media of primary and secondary flows. To determine the feasibility of using liquid–vapor ejectors with different flow path geometries, exergy analysis was performed, resulting in achievable efficiency indicators. Full article

The colors of copper-containing pigments, copper (II) oxide and malachite, and their origins in ceramic glazes were systematically examined over a wide firing temperature range using a suite of analytical and spectroscopy techniques including SEM, UV-Vis FORS, XRD, FTIR, and EPR to gain new insight into the structural and chemical transformations of the glaze during firing. The two colorants investigated were black copper (II) oxide (CuO) nanopowder and blue-green basic copper carbonate, or malachite (Cu₂CO₃(OH)₂), both of which produce a final light blue color following firing. Additionally, silicon carbide (SiC) was used to locally reduce CuO to simulate firing glazes in a reductive environment and produce a final red color. At lower temperatures, malachite was found to decompose to form CuO at 550 °C, elucidating the reason that two different copper colorants could be used interchangeably to form the same “Robin’s Egg Blue” color. At 850 °C, a glaze sintering process occurred, resulting in the distribution of Cu²⁺ in a square planar geometry and an observed blue color. This structural change occurred at temperatures lower than the glaze’s melting point, indicating that complete vitrification of the glaze is not required for glaze coloration. Conversely, the reduction in Cu²⁺ to Cu⁺ through the addition of SiC did not occur until the glaze was fired above the melting temperature (1000 °C), signifying that high temperatures are required for the redox reaction to occur. This study sheds light on intermediate colorant-glaze interactions that are beneficial for understanding and predicting glaze coloring upon exposure to varying temperatures, and the results from this study can be applied to better-controlled glaze production for artists and a deeper appreciation of ceramic glaze chemistry and aesthetics. Full article
