In recent years, 3D printing has emerged as a promising technology in energy storage, particularly for the fabrication of Li-ion battery electrodes. This innovative manufacturing method offers significant material composition and electrode structure flexibility, enabling more complex and efficient designs. While traditional Li-ion battery fabrication methods are well-established, 3D printing opens up new possibilities for enhancing battery performance by allowing for tailored geometries, efficient material usage, and integrating multifunctional components. This article examines three key 3D printing methods for fabricating Li-ion battery electrodes: (1) material extrusion (ME), which encompasses two subcategories—fused deposition modeling (FDM), also referred to as fused filament fabrication (FFF), and direct ink writing (DIW); (2) material jetting (MJ), including inkjet printing (IJP) and aerosol jet printing (AJP) methods; and (3) vat photopolymerization (VAT-P), which includes the stereolithographic apparatus (SLA) subcategory. These methods have been applied in fabricating substrates, thin-film electrodes, and electrolytes for half-cell and full-cell Li-ion batteries. This discussion focuses on their strengths, limitations, and potential advancements for energy storage applications. Full article

We report the design, fabrication, and experimental characterization of an optically transparent printed planar inverted-F antenna (PIFA) operating at 2.45 GHz using the aerosol jet (AJ) printing method. The proposed antenna was fabricated using a clear conductive ink on glass and Delrin. The antenna exhibits a wide fractional bandwidth (FBW) of 20% centered at 2.45 GHz, with a peak realized gain of −3.6 dBi and transparency of ~80%. The proposed fabrication method provides a cost-effective and scalable solution for manufacturing transparent antennas with potential applications in wireless communication, sensing, and wearable devices operating at mmWave frequencies higher than 30 GHz. Full article

This study presents graphene inks produced through the liquid-phase exfoliation of graphene flakes in water using optimized concentrations of dispersants (gelatin, triton X-100, and tween-20). The study explores and compares the effectiveness of the three different dispersants in creating stable and conductive inks. These inks can be printed onto polyethylene terephthalate (PET) substrates using an aerosol jet printer. The investigation aims to identify the most suitable dispersant to formulate a high-quality graphene ink for potential applications in printed electronics, particularly in developing chemiresistive sensors for IoT applications. Our findings indicate that triton X-100 is the most effective dispersant for formulating graphene ink (GTr), which demonstrated electrical conductivity (4.5 S·cm⁻¹), a high nanofiller concentration of graphene flakes (12.2%) with a size smaller than 200 nm (<200 nm), a low dispersant-to-graphene ratio (5%), good quality as measured by Raman spectroscopy (I_D/I_G ≈ 0.27), and good wettability (θ ≈ 42°) over PET. The GTr’s ecological benefits, combined with its excellent printability and good conductivity, make it an ideal candidate for manufacturing chemiresistive sensors that can be used for Internet of Things (IoT) healthcare and environmental applications. Full article

Copper (Cu) and tungsten (W) possess exceptional electrical and thermal conductivity properties, making them suitable candidates for applications such as interconnects and thermal conductivity enhancements. Solution-based additive manufacturing (SBAM) offers unique advantages, including patterning capabilities, cost-effectiveness, and scalability among the various methods for manufacturing Cu and W-based films and structures. In particular, SBAM material jetting techniques, such as inkjet printing (IJP), direct ink writing (DIW), and aerosol jet printing (AJP), present a promising approach for design freedom, low material wastes, and versatility as either stand-alone printers or integrated with powder bed-based metal additive manufacturing (MAM). Thus, this review summarizes recent advancements in solution-processed Cu and W, focusing on IJP, DIW, and AJP techniques. The discussion encompasses general aspects, current status, challenges, and recent research highlights. Furthermore, this paper addresses integrating material jetting techniques with powder bed-based MAM to fabricate functional alloys and multi-material structures. Finally, the factors influencing large-scale fabrication and potential prospects in this area are explored. Full article

Among conductive polymers, poly(3,4 ethylenedioxythiophene) polystyrene sulfonate (PEDOT:PSS) has been widely used as an electrode material for supercapacitors, solar cells, sensors, etc. Although PEDOT:PSS-based thin films have acceptable properties such as good capacitive and electrical behaviour and biocompatibility, there are still several challenges to be overcome in their use as an electrode material for supercapacitors. For this reason, the aim of this work is to fabricate and characterise ternary nanocomposites based on PEDOT:PSS and graphene oxide (GO), blended with green additives (glucose (G) or ascorbic acid (AA)), which have the benefits of being environmentally friendly, economical, and easy to use. The GO reduction process was first accurately investigated and demonstrated by UV-Vis and XRD measurements. Three-component inks have been developed, and their morphological, rheological, and surface tension properties were evaluated, showing their printability by means of Aerosol Jet^® Printing (AJ^®P), an innovative direct writing technique belonging to the Additive Manufacturing (AM) for printed electronics applications. Thin films of the ternary nanocomposites were produced by drop casting and spin coating techniques, and their capacitive behaviour and chemical structures were evaluated through Cyclic Voltammetry (CV) tests and FT-IR analyses. CV tests show an increment in the specific capacitance of AAGO-PEDOT up to 31.4 F/g and excellent overtime stability compared with pristine PEDOT:PSS, suggesting that this ink can be used to fabricate supercapacitors in printed (bio)-electronics. The inks were finally printed by AJ^®P as thin films (10 layers, 8 × 8 mm) and chemically analysed by FT-IR, demonstrating that all components of the formulation were successfully aerosolised and deposited on the substrate. Full article

Nowadays, digital printing technologies such as inkjet and aerosol jet printing are gaining more importance since they have proven to be suitable for the assembly of complex microsystems. This also applies to medical technology applications like hearing aids where patient-specific solutions are required. However, assembly is more challenging than with conventional printed circuit boards in terms of material compatibility between substrate, interconnect material and printed ink. This paper describes how aerosol jet printing of nano metal inks and subsequent assembly processes are utilized to connect electrical components on 3D substrates fabricated by Digital Light Processing (DLP). Conventional assembly technologies such as soldering and conductive adhesive bonding were investigated and characterized. For this purpose, curing methods and substrate pretreatments for different inks were optimized. Furthermore, the usage of electroless plating on printed metal tracks for improved solderability was investigated. Finally, a 3D ear mold substrate was used to build up a technology demonstrator by means of conductive adhesives. Full article

An aerosol jet printing (AJP) printing head built on top of precise motion systems can provide positioning deviation down to 3 μm, printing areas as large as 20 cm × 20 cm × 30 cm, and five-axis freedom of movement. Typical uses of AJP are 2D printing on complex or flexible substrates, primarily for applications in printed electronics. Nearly all commercially available AJP inks for 2D printing are designed and optimized to reach desired electronic properties. In this work, we explore AJP for the 3D printing of free-standing pillar arrays. We utilize aryl epoxy photopolymer as ink coupled with a cross-linking “on the fly” technique. Pillar structures 550 μm in height and with a diameter of 50 μm were 3D printed. Pillar structures were characterized via scanning electron microscopy, where the morphology, number of printed layers and side effects of the AJP technique were investigated. Satellite droplets and over-spray seem to be unavoidable for structures smaller than 70 μm. Nevertheless, reactive ion etching (RIE) as a post-processing step can mitigate AJP side effects. AJP-RIE together with photopolymer-based ink can be promising for the 3D printing of microstructures, offering fast and maskless manufacturing without wet chemistry development and heat treatment post-processing. Full article

Currently, silver nanoparticles have attracted large interest in the photonics, electrics, analytical, and antimicrobial/biocidal fields due to their excellent optical, electrical, biological, and antibacterial properties. The versatility in generating different sizes, shapes, and surface morphologies results in a wide range of applications of silver nanoparticles in various industrial and health-related areas. In industrial applications, silver nanoparticles are used to produce conductive inks, which allows the construction of electronic devices on low-cost and flexible substrates by using various printing techniques. In order to achieve successful printed patterns, the necessary formulation and synthesis need to be engineered to fulfil the printing technique requirements. Additional sintering processes are typically further required to remove the added polymers, which are used to produce the desired adherence, viscosity, and reliable performance. This contribution presents a review of the synthesis of silver nanoparticles via different methods (chemical, physical and biological methods) and the application of silver nanoparticles under the electrical field. Formulation of silver inks and formation of conductive patterns by using different printing techniques (inkjet printing, screen printing and aerosol jet printing) are presented. Post-printing treatments are also discussed. A summary concerning outlooks and perspectives is presented at the end of this review. Full article

Electrochemical sensors are attracting great interest for their different applications. To improve their performances, basic research focuses on two main issues: improve their metrological characteristics (e.g., repeatability, reusability and sensitivity) and investigate innovative fabrication processes. In this work, we demonstrate an innovative microstructuration technique aimed at increasing electrochemical sensor sensitivity to improve electrode active area by an innovative fabrication technique. The process is empowered by aerosol jet printing (AJP), an additive-manufacturing and non-contact printing technique that allows depositing functional inks in precise patterns such as parallel lines and grids. The 3D printed microstructures increased the active surface area by up to 130% without changing the substrate occupancy. Further, electrochemical detection of ferro/ferri-cyanide was used to evaluate the sensitivity of the electrodes. This evaluation points out a sensitivity increase of 2.3-fold on average between bare and fully microstructured devices. The increase of surface area and sensitivity are well linearly correlated as expected, verifying the fitness of our production process. The proposed microstructuration is a viable solution for many applications that requires high sensitivity, and the proposed technique, since it does not require masks or complex procedures, turns out to be flexible and applicable to infinite construction geometries. Full article

This paper is focused on copper–nickel nanoparticle resistive inks compatible with thick printed copper (TPC) technology, which can be used for power substrate manufacturing instead of conventional metallization techniques. Two types of copper–nickel inks were prepared and deposited by Aerosol Jet technology. The first type of ink was based on copper and nickel nanoparticles with a ratio of 75:25, and the second type of ink consisted of copper–nickel alloy nanoparticles with a ratio of 55:45. The characterization of electrical parameters, microstructure, thermal analysis of prepared inks and study of the influence of copper–nickel content on electrical parameters are described in this paper. It was verified that ink with a copper–nickel ratio of 55:45 (based on constantan nanoparticles) is more appropriate for the production of resistors due to low sheet resistance ~1 Ω/square and low temperature coefficient of resistance ±100·10⁻⁶ K⁻¹ values. Copper–nickel inks can be fired in a protective nitrogen atmosphere, which ensures compatibility with copper films. The compatibility of copper–nickel and copper films enables the production of integrated resistors directly on ceramics substrates of power electronics modules made by TPC technology. Full article

In 2018, the European Parliament and Council laid down a directive about the promotion of the use of energy from renewable sources connected with the Paris Agreement, which sets a global ambition on climate change mitigation through deep and fast cuts in greenhouse gas emissions. Since then, the science world has been even more focused on the development of green technologies such as wind farms, waterpower stations, and photovoltaics as the European Union is preparing to shift to renewables-based energy systems. Each green power technology has its own problems and limitations. Nevertheless, for environmental protection, new power technologies have to be implemented in the near future as primary power sources. Described in this article is the application of aerosol jet printing in manufacture of photovoltaic cells, moving the technology boundaries further toward highly efficient, cost-effective, green power production. The research focused on utilizing aerosol jet printing technology to create finger-shaped collecting electrodes on a newly constructed, non-silicon photovoltaic cell, based on metal oxides. Three commercial nanosilver inks were investigated considering their printing parameters, printability on the specified substrate (AZO-coated glass, AZO-coated copper plate), resistivity of the cured composite, quality of the overprints, and application in photovoltaics. As a result, we obtained finger-shaped collecting electrodes with a resistivity of 3.5 µΩ∙cm and 8 µm width, which compares well with the literature. Full article

The use of flexible sensors has tripled over the last decade due to the increased demand in various fields including health monitoring, food packaging, electronic skins and soft robotics. Flexible sensors have the ability to be bent and stretched during use and can still maintain their electrical and mechanical properties. This gives them an advantage over rigid sensors that lose their sensitivity when subject to bending. Advancements in 3D printing have enabled the development of tailored flexible sensors. Various additive manufacturing methods are being used to develop these sensors including inkjet printing, aerosol jet printing, fused deposition modelling, direct ink writing, selective laser melting and others. Hydrogels have gained much attention in the literature due to their self-healing and shape transforming. Self-healing enables the sensor to recover from damages such as cracks and cuts incurred during use, and this enables the sensor to have a longer operating life and stability. Various polymers are used as substrates on which the sensing material is placed. Polymers including polydimethylsiloxane, Poly(N-isopropylacrylamide) and polyvinyl acetate are extensively used in flexible sensors. The most widely used nanomaterials in flexible sensors are carbon and silver due to their excellent electrical properties. This review gives an overview of various types of flexible sensors (including temperature, pressure and chemical sensors), paying particular attention to the application areas and the corresponding characteristics/properties of interest required for such. Current advances/trends in the field including 3D printing, novel nanomaterials and responsive polymers, and self-healable sensors and wearables will also be discussed in more detail. Full article

The development of commercial collagen inks for extrusion-based bioprinting has increased the amount of research on pure collagen bioprinting, i.e., collagen inks not mixed with gelatin, alginate, or other more common biomaterial inks. New printing techniques have also improved the resolution achievable with pure collagen bioprinting. However, the resultant collagen constructs still appear too weak to replicate dense collagenous tissues, such as the cornea. This work aims to demonstrate the first reported case of bioprinted recombinant collagen films with suitable optical and mechanical properties for corneal tissue engineering. The printing technology used, aerosol jet^® printing (AJP), is a high-resolution printing method normally used to deposit conductive inks for electronic printing. In this work, AJP was employed to deposit recombinant human collagen type III (RHCIII) in overlapping continuous lines of 60 µm to form thin layers. Layers were repeated up to 764 times to result in a construct that was considered a few hundred microns thick when swollen. Samples were subsequently neutralised and crosslinked using EDC:NHS crosslinking. Nanoindentation and absorbance measurements were conducted, and the results show that the AJP-deposited RHCIII samples possess suitable mechanical and optical properties for corneal tissue engineering: an average effective elastic modulus of 506 ± 173 kPa and transparency ≥87% at all visible wavelengths. Circular dichroism showed that there was some loss of helicity of the collagen due to aerosolisation. SDS-PAGE and pepsin digestion were used to show that while some collagen is degraded due to aerosolisation, it remains an inaccessible substrate for pepsin cleavage. Full article

Solvent-free aerosol jet printing has been investigated for fabricating metallic and semiconductor (gas-sensitive) microstructures based on copper nanoparticles on alumina, borosilicate glass, and silicon substrates. The synthesis of nanoparticles was carried out using a spark discharge directly in the printing process without the stage of preparing nano-ink. Printed lines with a width of 100–150 µm and a height of 5–7 µm were formed from submicron agglomerates consisting of primary nanoparticles 10.8 ± 4.9 nm in size with an amorphous oxide shell. The electrical resistivity, surface morphology, and shrinkage of printed lines were investigated depending on the reduction sintering temperature. Sintering of copper oxides of nanoparticles began at a temperature of 450 °C in a hydrogen atmosphere with shrinkage at the level of 45–60%. Moreover, aerosol heat treatment was used to obtain highly conductive lines by increasing the packing density of deposited nanoparticles, providing in-situ transformation of submicron agglomerates into spherical nanoparticles with a size of 20–50 nm. Copper lines of spherical nanoparticles demonstrated excellent resistivity at 5 μΩ·cm, about three times higher than that of bulk copper. In turn, semiconductor microstructures based on unsintered agglomerates of oxidized copper have a fairly high sensitivity to NH₃ and CO. Values of response of the sensor based on non-sintered oxidized copper nanoparticles to ammonia and carbon monoxide concentration of 40 ppm were about 20% and 80%, respectively. Full article

Printing nano-ink with platinum nanoparticles to generate conductive microstructures for electronics on different types of substrates has gained increasing interest in recent years. To solve the problem of the low conductivity of platinum (Pt) nano-ink, we synthesized chemically pure Pt nanoparticles with sizes of 18.2 ± 9.0 nm by spark discharge method. A low toxic solvent, ethylene glycol with water, was used to ensure the aggregation stability of Pt nanoparticles. Polyvinylpyrrolidone was used as an adhesive additive and binder in the nano-ink. Narrow and conductive Pt lines were generated by aerosol jet printing technology. The resistivity of the Pt lines sintered at 750 °C on alumina substrate was found to exceed the bulk Pt by about 13%. Moreover, the Pt film fabricated on polymer substrates has demonstrated excellent mechanical flexibility in terms of twisting tests. Full article
