Search Results (35)

Search Parameters:
Keywords = inertial frame-based alignment

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
14 pages, 1964 KB
Article
Bridging the Methodological Gap Between Inertial Sensors and Optical Motion Capture: Deep Learning as the Path to Accurate Joint Kinematic Modelling Using Inertial Sensors
by Vaibhav R. Shah and Philippe C. Dixon
Sensors 2025, 25(18), 5728; https://doi.org/10.3390/s25185728 - 14 Sep 2025
Viewed by 709
Abstract
As advancements in inertial measurement units (IMUs) for motion analysis progress, the inability to directly apply decades of research-based optical motion capture (OMC) methodologies presents a significant challenge. This study aims to bridge this gap by proposing an innovative deep learning approach to [...] Read more.
As advancements in inertial measurement units (IMUs) for motion analysis progress, the inability to directly apply decades of research-based optical motion capture (OMC) methodologies presents a significant challenge. This study aims to bridge this gap by proposing an innovative deep learning approach to predict marker positions from IMU data, allowing traditional OMC-based calculations to estimate joint kinematics. Eighteen participants walked on a treadmill with seven IMUs and retroreflective markers. Trials were divided into normalized gait cycles (101 frames), and an autoencoder network with a custom Biomech loss function was used to predict 16 marker positions from IMU data. The model was validated using the leave-one-subject-out method and assessed using root mean squared error (RMSE). Joint angles in the sagittal plane were calculated using OMC methods, and RMSE was computed with and without alignment using dynamic time warping (DTW). The models were also tested on external datasets. Marker predictions achieved RMSE values of 2–4 cm, enabling joint angle predictions with 4–7° RMSE without alignment and 2–4° RMSE after DTW for sagittal plane joint angles (ankle, knee, hip). Validation using separate and open-source datasets confirmed the model’s generalizability, with similar RMSE values across datasets (4–7° RMSE without DTW and 2–4° with DTW). This study demonstrates the feasibility of applying conventional biomechanical models to IMUs, enabling accurate movement analysis and visualization outside controlled environments. This approach to predicting marker positions helps to bridge the gap between IMUs and OMC systems, enabling decades of research-based biomechanical methodologies to be applied to IMU data. Full article
(This article belongs to the Special Issue Wearable Sensors in Biomechanics and Human Motion)
Show Figures

Figure 1

13 pages, 4728 KB
Article
Stereo Direct Sparse Visual–Inertial Odometry with Efficient Second-Order Minimization
by Chenhui Fu and Jiangang Lu
Sensors 2025, 25(15), 4852; https://doi.org/10.3390/s25154852 - 7 Aug 2025
Viewed by 1204
Abstract
Visual–inertial odometry (VIO) is the primary supporting technology for autonomous systems, but it faces three major challenges: initialization sensitivity, dynamic illumination, and multi-sensor fusion. In order to overcome these challenges, this paper proposes stereo direct sparse visual–inertial odometry with efficient second-order minimization. It [...] Read more.
Visual–inertial odometry (VIO) is the primary supporting technology for autonomous systems, but it faces three major challenges: initialization sensitivity, dynamic illumination, and multi-sensor fusion. In order to overcome these challenges, this paper proposes stereo direct sparse visual–inertial odometry with efficient second-order minimization. It is entirely implemented using the direct method, which includes a depth initialization module based on visual–inertial alignment, a stereo image tracking module, and a marginalization module. Inertial measurement unit (IMU) data is first aligned with a stereo image to initialize the system effectively. Then, based on the efficient second-order minimization (ESM) algorithm, the photometric error and the inertial error are minimized to jointly optimize camera poses and sparse scene geometry. IMU information is accumulated between several frames using measurement preintegration and is inserted into the optimization as an additional constraint between keyframes. A marginalization module is added to reduce the computation complexity of the optimization and maintain the information about the previous states. The proposed system is evaluated on the KITTI visual odometry benchmark and the EuRoC dataset. The experimental results demonstrate that the proposed system achieves state-of-the-art performance in terms of accuracy and robustness. Full article
(This article belongs to the Section Vehicular Sensing)
Show Figures

Figure 1

20 pages, 4874 KB
Article
Analytical Formulation of Relationship Between Sensors and Euler Angle Errors for Arbitrary Stationary Alignment Based on Accelerometer and Magnetometer
by Chang June Lee and Jung Keun Lee
Sensors 2025, 25(8), 2593; https://doi.org/10.3390/s25082593 - 19 Apr 2025
Viewed by 890
Abstract
An attitude and heading reference system (AHRS) based on the inertial measurement unit is crucial for various applications. In an AHRS, stationary alignments are performed to determine the initial orientation of the sensor frame with respect to the navigation frame. However, the stationary [...] Read more.
An attitude and heading reference system (AHRS) based on the inertial measurement unit is crucial for various applications. In an AHRS, stationary alignments are performed to determine the initial orientation of the sensor frame with respect to the navigation frame. However, the stationary alignment accuracy is affected by sensor error factors. Therefore, several studies have attempted to analyze and minimize the effects of these errors. However, there have been no studies describing and analyzing the Euler angle errors for various sensor orientations. This paper presents the analytical formulation of the relationship between the sensor and the Euler angle errors based on accelerometer and magnetometer signals, regardless of alignment between the sensor and the navigation frames. We selected three-axis attitude determination (TRIAD) as the stationary alignment method and considered the scale, installation, and the offset errors, including noise and constant bias, as sensor error factors. The presented formulation describes the relationship between the sensor error factors and the Euler angle errors as a linear equation. To analyze the Euler angle errors, we performed both sensor-aligned and sensor-misaligned simulations in which the Euler angles were 0° and arbitrary, respectively. The results showed that the presented error formulation could describe the total Euler angle errors and the partial errors induced by each sensor error factor for both the sensor-aligned conditions and the arbitrary Euler angle configurations. Thus, the effects of each sensor error factor on the Euler angle errors can be analytically investigated using the presented formulations for random alignment. Full article
(This article belongs to the Section Wearables)
Show Figures

Figure 1

16 pages, 6121 KB
Article
Stereo Event-Based Visual–Inertial Odometry
by Kunfeng Wang, Kaichun Zhao, Wenshuai Lu and Zheng You
Sensors 2025, 25(3), 887; https://doi.org/10.3390/s25030887 - 31 Jan 2025
Cited by 4 | Viewed by 2395
Abstract
Event-based cameras are a new type of vision sensor in which pixels operate independently and respond asynchronously to changes in brightness with microsecond resolution, instead of providing standard intensity frames. Compared with traditional cameras, event-based cameras have low latency, no motion blur, and [...] Read more.
Event-based cameras are a new type of vision sensor in which pixels operate independently and respond asynchronously to changes in brightness with microsecond resolution, instead of providing standard intensity frames. Compared with traditional cameras, event-based cameras have low latency, no motion blur, and high dynamic range (HDR), which provide possibilities for robots to deal with some challenging scenes. We propose a visual–inertial odometry for stereo event-based cameras based on Error-State Kalman Filter (ESKF). The vision module updates the pose by relying on the edge alignment of a semi-dense 3D map to a 2D image, while the IMU module updates the pose using median integration. We evaluate our method on public datasets with general 6-DoF motion (three-axis translation and three-axis rotation) and compare the results against the ground truth. We compared our results with those from other methods, demonstrating the effectiveness of our approach. Full article
(This article belongs to the Section Intelligent Sensors)
Show Figures

Figure 1

17 pages, 6459 KB
Article
Research on Transfer Alignment Algorithms Based on SE(3) in ECEF Frame
by Hongyi Lin, Hongwei Bian, Rongying Wang and Jun Tang
Electronics 2025, 14(3), 453; https://doi.org/10.3390/electronics14030453 - 23 Jan 2025
Cited by 2 | Viewed by 914
Abstract
The initial attitude error is challenging to satisfy the requirements of the linear model due to the complex nature of the ocean environment. This presents a challenge in the transfer alignment of the ship. In order to enhance the precision and velocity of [...] Read more.
The initial attitude error is challenging to satisfy the requirements of the linear model due to the complex nature of the ocean environment. This presents a challenge in the transfer alignment of the ship. In order to enhance the precision and velocity of ship transfer alignment, as well as to streamline the alignment processes, this paper proposes a transfer alignment methodology based on the Earth-Centered Earth-Fixed (ECEF) frame special Euclidean group (SE(3)) matrix Lie group. After introducing the two navigation states, velocity and attitude, from the ECEF frame into SE(3), the nonlinear inertial navigation system error state model and its corresponding measurement equations are derived based on the mapping relationship between the Lie groups and Lie algebra. The method effectively solves the error problem due to linear approximation in the traditional transfer alignment method, and applies to misalignment angles of arbitrary scale. The simulation results verify the effectiveness and rapidity of the proposed alignment method in the case of arbitrary misalignment angles. Full article
(This article belongs to the Section Systems & Control Engineering)
Show Figures

Figure 1

13 pages, 2064 KB
Article
A Robust Method for Validating Orientation Sensors Using a Robot Arm as a High-Precision Reference
by József Kuti, Tamás Piricz and Péter Galambos
Sensors 2024, 24(24), 8179; https://doi.org/10.3390/s24248179 - 21 Dec 2024
Cited by 2 | Viewed by 1944
Abstract
This paper presents a robust and efficient method for validating the accuracy of orientation sensors commonly used in practical applications, leveraging measurements from a commercial robotic manipulator as a high-precision reference. The key concept lies in determining the rotational transformations between the robot’s [...] Read more.
This paper presents a robust and efficient method for validating the accuracy of orientation sensors commonly used in practical applications, leveraging measurements from a commercial robotic manipulator as a high-precision reference. The key concept lies in determining the rotational transformations between the robot’s base frame and the sensor’s reference, as well as between the TCP (Tool Center Point) frame and the sensor frame, without requiring precise alignment. Key advantages of the proposed method include its independence from the exact measurement of rotations between the reference instrumentation and the sensor, systematic testing capabilities, and the ability to produce repeatable excitation patterns under controlled conditions. This approach enables automated, high-precision, and comparative evaluation of various orientation sensing devices in a reproducible manner. Moreover, it facilitates efficient calibration and analysis of sensor errors, such as drift, noise, and response delays under various motion conditions. The method’s effectiveness is demonstrated through experimental validation of an Inertial Navigation System module and the SLAM-IMU fusion capabilities of the HTC VIVE VR headset, highlighting its versatility and reliability in addressing the challenges associated with orientation sensor validation. Full article
Show Figures

Figure 1

18 pages, 1365 KB
Article
LIO-SAM++: A Lidar-Inertial Semantic SLAM with Association Optimization and Keyframe Selection
by Bingke Shen, Wenming Xie, Xiaodong Peng, Xiaoning Qiao and Zhiyuan Guo
Sensors 2024, 24(23), 7546; https://doi.org/10.3390/s24237546 - 26 Nov 2024
Cited by 2 | Viewed by 5090
Abstract
Current lidar-inertial SLAM algorithms mainly rely on the geometric features of the lidar for point cloud alignment. The issue of incorrect feature association arises because the matching process is susceptible to influences such as dynamic objects, occlusion, and environmental changes. To address this [...] Read more.
Current lidar-inertial SLAM algorithms mainly rely on the geometric features of the lidar for point cloud alignment. The issue of incorrect feature association arises because the matching process is susceptible to influences such as dynamic objects, occlusion, and environmental changes. To address this issue, we present a lidar-inertial SLAM system based on the LIO-SAM framework, combining semantic and geometric constraints for association optimization and keyframe selection. Specifically, we mitigate the impact of erroneous matching points on pose estimation by comparing the consistency of normal vectors in the surrounding region. Additionally, we incorporate semantic information to establish semantic constraints, further enhancing matching accuracy. Furthermore, we propose an adaptive selection strategy based on semantic differences between frames to improve the reliability of keyframe generation. Experimental results on the KITTI dataset indicate that, compared to other systems, the accuracy of the pose estimation has significantly improved. Full article
Show Figures

Figure 1

13 pages, 3686 KB
Communication
A Novel Robust Position Integration Optimization-Based Alignment Method for In-Flight Coarse Alignment
by Xiaoge Ning, Jixun Huang and Jianxun Li
Sensors 2024, 24(21), 7000; https://doi.org/10.3390/s24217000 - 31 Oct 2024
Viewed by 1091
Abstract
In-flight alignment is a critical milestone for inertial navigation system/global navigation satellite system (INS/GNSS) applications in unmanned aerial vehicles (UAVs). The traditional position integration formula for in-flight coarse alignment requires the GNSS velocity data to be valid throughout the alignment period, which greatly [...] Read more.
In-flight alignment is a critical milestone for inertial navigation system/global navigation satellite system (INS/GNSS) applications in unmanned aerial vehicles (UAVs). The traditional position integration formula for in-flight coarse alignment requires the GNSS velocity data to be valid throughout the alignment period, which greatly limits the engineering applicability of the method. In this paper, a new robust position integration optimization-based alignment (OBA) method for in-flight coarse alignment is presented to solve the problem of in-flight alignment under a prolonged ineffective GNSS. In this methodology, to achieve a higher alignment accuracy in case the GNSS is not effective throughout the alignment period, the integration of GNSS velocity into the local-level navigation frame is replaced by the GNSS position in the Earth-centered, Earth-fixed frame, which avoids the need for complete GNSS velocity data. The simulation and flight test results show that the new robust position integration method proposed in this paper achieves higher stability and robustness than the conventional position integration OBA method and can achieve an alignment accuracy of 0.2° even when the GNSS is partially time-invalidated. Thus, this greatly extends the application of the OBA method for in-flight alignment. Full article
Show Figures

Figure 1

16 pages, 5739 KB
Article
Comparison of IMU-Based Knee Kinematics with and without Harness Fixation against an Optical Marker-Based System
by Jana G. Weber, Ariana Ortigas-Vásquez, Adrian Sauer, Ingrid Dupraz, Michael Utz, Allan Maas and Thomas M. Grupp
Bioengineering 2024, 11(10), 976; https://doi.org/10.3390/bioengineering11100976 - 28 Sep 2024
Cited by 4 | Viewed by 2951
Abstract
The use of inertial measurement units (IMUs) as an alternative to optical marker-based systems has the potential to make gait analysis part of the clinical standard of care. Previously, an IMU-based system leveraging Rauch–Tung–Striebel smoothing to estimate knee angles was assessed using a [...] Read more.
The use of inertial measurement units (IMUs) as an alternative to optical marker-based systems has the potential to make gait analysis part of the clinical standard of care. Previously, an IMU-based system leveraging Rauch–Tung–Striebel smoothing to estimate knee angles was assessed using a six-degrees-of-freedom joint simulator. In a clinical setting, however, accurately measuring abduction/adduction and external/internal rotation of the knee joint is particularly challenging, especially in the presence of soft tissue artefacts. In this study, the in vivo IMU-based joint angles of 40 asymptomatic knees were assessed during level walking, under two distinct sensor placement configurations: (1) IMUs fixed to a rigid harness, and (2) IMUs mounted on the skin using elastic hook-and-loop bands (from here on referred to as “skin-mounted IMUs”). Estimates were compared against values obtained from a harness-mounted optical marker-based system. The comparison of these three sets of kinematic signals (IMUs on harness, IMUs on skin, and optical markers on harness) was performed before and after implementation of a REference FRame Alignment MEthod (REFRAME) to account for the effects of differences in coordinate system orientations. Prior to the implementation of REFRAME, in comparison to optical estimates, skin-mounted IMU-based angles displayed mean root-mean-square errors (RMSEs) up to 6.5°, while mean RMSEs for angles based on harness-mounted IMUs peaked at 5.1°. After REFRAME implementation, peak mean RMSEs were reduced to 4.1°, and 1.5°, respectively. The negligible differences between harness-mounted IMUs and the optical system after REFRAME revealed that the IMU-based system was capable of capturing the same underlying motion pattern as the optical reference. In contrast, obvious differences between the skin-mounted IMUs and the optical reference indicated that the use of a harness led to fundamentally different joint motion being measured, even after accounting for reference frame misalignments. Fluctuations in the kinematic signals associated with harness use suggested the rigid device oscillated upon heel strike, likely due to inertial effects from its additional mass. Our study proposes that optical systems can be successfully replaced by more cost-effective IMUs with similar accuracy, but further investigation (especially in vivo and upon heel strike) against moving videofluoroscopy is recommended. Full article
(This article belongs to the Special Issue Biomechanics of Human Movement and Its Clinical Applications)
Show Figures

Figure 1

15 pages, 6203 KB
Article
Experimental Research on Shipborne SINS Rapid Mooring Alignment with Variance-Constraint Kalman Filter and GNSS Position Updates
by Zhipeng Fan, Hua Chai, Xinghui Liang and Hubiao Wang
Sensors 2024, 24(11), 3487; https://doi.org/10.3390/s24113487 - 28 May 2024
Cited by 3 | Viewed by 1123
Abstract
Analytical coarse alignment and Kalman filter fine alignment based on zero-velocity are typically used to obtain initial attitude for inertial navigation systems (SINS) on a static base. However, in the shipboard mooring state, the static observation condition is corrupted. This paper presents a [...] Read more.
Analytical coarse alignment and Kalman filter fine alignment based on zero-velocity are typically used to obtain initial attitude for inertial navigation systems (SINS) on a static base. However, in the shipboard mooring state, the static observation condition is corrupted. This paper presents a rapid alignment method for SINS on swaying bases. The proposed method begins with a coarse alignment technique in the inertial frame to obtain an initial rough attitude. Subsequently, a Kalman filter with position updates is employed to estimate the remaining misalignment error. To enhance the filter estimation performance, an appropriate lower boundary is set to the target states’ variances according to a carefully designed relative convergence index. The variance-constraint Kalman filter (VCKF) approach is proposed in this paper, and the shipborne experiments validate its effectiveness. The results demonstrate that the VCKF approach significantly reduces the time requirement for fine alignment to achieve the same accuracy on a swaying base, from 90 min in the classic Kalman filter to 30 min. Additionally, the parameter estimation performance in the Kalman filter is also improved, particularly in situations where unpredicted external interference is involved during fine alignment. Full article
(This article belongs to the Section Navigation and Positioning)
Show Figures

Figure 1

15 pages, 3498 KB
Article
Validation of Inertial-Measurement-Unit-Based Ex Vivo Knee Kinematics during a Loaded Squat before and after Reference-Frame-Orientation Optimisation
by Svenja Sagasser, Adrian Sauer, Christoph Thorwächter, Jana G. Weber, Allan Maas, Matthias Woiczinski, Thomas M. Grupp and Ariana Ortigas-Vásquez
Sensors 2024, 24(11), 3324; https://doi.org/10.3390/s24113324 - 23 May 2024
Cited by 3 | Viewed by 1890
Abstract
Recently, inertial measurement units have been gaining popularity as a potential alternative to optical motion capture systems in the analysis of joint kinematics. In a previous study, the accuracy of knee joint angles calculated from inertial data and an extended Kalman filter and [...] Read more.
Recently, inertial measurement units have been gaining popularity as a potential alternative to optical motion capture systems in the analysis of joint kinematics. In a previous study, the accuracy of knee joint angles calculated from inertial data and an extended Kalman filter and smoother algorithm was tested using ground truth data originating from a joint simulator guided by fluoroscopy-based signals. Although high levels of accuracy were achieved, the experimental setup leveraged multiple iterations of the same movement pattern and an absence of soft tissue artefacts. Here, the algorithm is tested against an optical marker-based system in a more challenging setting, with single iterations of a loaded squat cycle simulated on seven cadaveric specimens on a force-controlled knee rig. Prior to the optimisation of local coordinate systems using the REference FRame Alignment MEthod (REFRAME) to account for the effect of differences in local reference frame orientation, root-mean-square errors between the kinematic signals of the inertial and optical systems were as high as 3.8° ± 3.5° for flexion/extension, 20.4° ± 10.0° for abduction/adduction and 8.6° ± 5.7° for external/internal rotation. After REFRAME implementation, however, average root-mean-square errors decreased to 0.9° ± 0.4° and to 1.5° ± 0.7° for abduction/adduction and for external/internal rotation, respectively, with a slight increase to 4.2° ± 3.6° for flexion/extension. While these results demonstrate promising potential in the approach’s ability to estimate knee joint angles during a single loaded squat cycle, they highlight the limiting effects that a reduced number of iterations and the lack of a reliable consistent reference pose inflicts on the sensor fusion algorithm’s performance. They similarly stress the importance of adapting underlying assumptions and correctly tuning filter parameters to ensure satisfactory performance. More importantly, our findings emphasise the notable impact that properly aligning reference-frame orientations before comparing joint kinematics can have on results and the conclusions derived from them. Full article
(This article belongs to the Special Issue Biosensors for Gait Measurements and Patient Rehabilitation)
Show Figures

Figure 1

23 pages, 5998 KB
Article
A Fast Self-Calibration Method for Dual-Axis Rotational Inertial Navigation Systems Based on Invariant Errors
by Xin Sun, Jizhou Lai, Pin Lyu, Rui Liu and Wentao Gao
Sensors 2024, 24(2), 597; https://doi.org/10.3390/s24020597 - 17 Jan 2024
Cited by 3 | Viewed by 2154
Abstract
In order to ensure that dual-axis rotational inertial navigation systems (RINSs) maintain a high level of accuracy over the long term, there is a demand for periodic calibration during their service life. Traditional calibration methods for inertial measurement units (IMUs) involve removing the [...] Read more.
In order to ensure that dual-axis rotational inertial navigation systems (RINSs) maintain a high level of accuracy over the long term, there is a demand for periodic calibration during their service life. Traditional calibration methods for inertial measurement units (IMUs) involve removing the IMU from the equipment, which is a laborious and time-consuming process. Reinstalling the IMU after calibration may introduce new installation errors. This paper focuses on dual-axis rotational inertial navigation systems and presents a system-level self-calibration method based on invariant errors, enabling high-precision automated calibration without the need for equipment disassembly. First, navigation parameter errors in the inertial frame are expressed as invariant errors. This allows the corresponding error models to estimate initial attitude even more rapidly and accurately in cases of extreme misalignment, eliminating the need for coarse alignment. Next, by utilizing the output of a gimbal mechanism, angular velocity constraint equations are established, and the backtracking navigation is introduced to reuse sensor data, thereby reducing the calibration time. Finally, a rotation scheme for the IMU is designed to ensure that all errors are observable. The observability of the system is analyzed based on a piecewise constant system method and singular value decomposition (SVD) observability analysis. The simulation and experimental results demonstrate that this method can effectively estimate IMU errors and installation errors related to the rotation axis within 12 min, and the estimated error is less than 4%. After using this method to compensate for the calibration error, the velocity and position accuracies of a RINS are significantly improved. Full article
(This article belongs to the Topic Multi-Sensor Integrated Navigation Systems)
Show Figures

Figure 1

19 pages, 12035 KB
Article
Global Visual–Inertial Localization for Autonomous Vehicles with Pre-Built Map
by Yun Hao, Jiacheng Liu, Yuzhen Liu, Xinyuan Liu, Ziyang Meng and Fei Xing
Sensors 2023, 23(9), 4510; https://doi.org/10.3390/s23094510 - 5 May 2023
Cited by 5 | Viewed by 2879
Abstract
Accurate, robust and drift-free global pose estimation is a fundamental problem for autonomous vehicles. In this work, we propose a global drift-free map-based localization method for estimating the global poses of autonomous vehicles that integrates visual–inertial odometry and global localization with respect to [...] Read more.
Accurate, robust and drift-free global pose estimation is a fundamental problem for autonomous vehicles. In this work, we propose a global drift-free map-based localization method for estimating the global poses of autonomous vehicles that integrates visual–inertial odometry and global localization with respect to a pre-built map. In contrast to previous work on visual–inertial localization, the global pre-built map provides global information to eliminate drift and assists in obtaining the global pose. Additionally, in order to ensure the local odometry frame and the global map frame can be aligned accurately, we augment the transformation between these two frames into the state vector and use a global pose-graph optimization for online estimation. Extensive evaluations on public datasets and real-world experiments demonstrate the effectiveness of the proposed method. The proposed method can provide accurate global pose-estimation results in different scenarios. The experimental results are compared against the mainstream map-based localization method, revealing that the proposed approach is more accurate and consistent than other methods. Full article
(This article belongs to the Section Navigation and Positioning)
Show Figures

Figure 1

22 pages, 4797 KB
Article
A Polar Moving Base Alignment Based on Backtracking Scheme
by Jianhua Cheng, Jiaxin Liu, Yu Wang and Jing Cai
Electronics 2023, 12(9), 2037; https://doi.org/10.3390/electronics12092037 - 27 Apr 2023
Cited by 1 | Viewed by 1476
Abstract
In the polar region, the gravity vector and Earth’s rotation vector tend to be in the same direction, leading to a slower convergence speed and longer alignment time of the moving base alignment. When the alignment time is short, the alignment cannot converge, [...] Read more.
In the polar region, the gravity vector and Earth’s rotation vector tend to be in the same direction, leading to a slower convergence speed and longer alignment time of the moving base alignment. When the alignment time is short, the alignment cannot converge, resulting in low azimuth accuracy. To address this issue, we propose a polar moving base alignment method based on a backtracking scheme. Notably, this work first derives a polar coarse alignment method with the inertial frame based on the transverse Earth model. On this basis, we designed a polar coarse alignment method based on a backtracking scheme and optimized the data storage scheme. Then, a backward navigation algorithm based on the transverse inertial navigation mechanical arrangement scheme was derived, and a polar fine alignment method based on a backtracking scheme was designed. Semi-physical simulation experiments showed that the alignment algorithm based on a backtracking scheme could converge in the 180 s with high alignment accuracy, which is 70% faster than the current polar moving base alignment method. Full article
Show Figures

Graphical abstract

23 pages, 10452 KB
Article
A Fast North-Finding Algorithm on the Moving Pedestal Based on the Technology of Extended State Observer (ESO)
by Yunchao Bai, Bing Li, Haosu Zhang, Sheng Wang, Debao Yan, Ziheng Gao and Wenchao Pan
Sensors 2022, 22(19), 7547; https://doi.org/10.3390/s22197547 - 5 Oct 2022
Cited by 1 | Viewed by 2195
Abstract
We propose a kind of fast and high-precision alignment algorithm based on the ESO technology. Firstly, in order to solve the problems of rapid, high-accuracy, and anti-interference alignment on the moving pedestal in the north-seeker, the ESO technology in control theory is introduced [...] Read more.
We propose a kind of fast and high-precision alignment algorithm based on the ESO technology. Firstly, in order to solve the problems of rapid, high-accuracy, and anti-interference alignment on the moving pedestal in the north-seeker, the ESO technology in control theory is introduced to improve the traditional Kalman fine-alignment model. This method includes two stages: the coarse alignment in the inertial frame and fine alignment based on the ESO technology. By utilizing the ESO technology, the convergence speed of the heading angle can be greatly accelerated. The advantages of this method are high-accuracy, fast-convergence, strong ability of anti-interference, and short time-cost (no need of KF recursive calculation). Then, the algorithm model, calculation process, and the setting initial-values of the filter are shown. Finally, taking the shipborne north-finder based on the FOG (fiber-optic gyroscope) as the investigated subject, the test on the moving ship is carried out. The results of first off-line simulation show that the misalignment angle of the heading angle of the proposed (traditional) method is ≤2.1′ (1.8′) after 5.5 (10) minutes of alignment. The results of second off-line simulation indicate that the misalignment angle of the heading angle of the proposed (traditional) method is ≤4.8′ (14.2′) after 5.5 (10) minutes of alignment. The simulations are based on the ship-running experimental data. The measurement precisions of Doppler velocity log (DVL) are different in these two experiments. Full article
(This article belongs to the Special Issue Mobile Robots for Navigation)
Show Figures

Figure 1
