This study investigates skimming flow regimes, two-phase air–water flow conditions, and simple measures to improve energy dissipation in stepped spillways. Experiments were conducted using two different scale physical models, 1:50 and 1:17, within separate rectangular flumes to define scale effects. Flow patterns were analyzed using the Bubble Image Velocimetry (BIV) technique, which tracks air bubbles. The introduction of splitters resulted in a 7% increase in relative energy dissipation. Additionally, the length of inception was reduced to $L_i/k_s$ = 10, thereby decreasing the potential for subsequent cavitation. Beyond the BIV experiments, two experiments were conducted on the large-scale model using Acoustic Doppler Velocimetry (ADV), with and without splitters, to examine the impact of splitters on the velocity profile above the crest. In the experiment with splitters, the vertical velocity vector (v) contributed to turbulence by changing direction, thereby reducing average velocities both in front of and behind the ogee crest. This led to a reduction in energy on the downstream side of the spillway. Although the small-scale model appears unsuitable for studying two-phase flow, the change in relative energy dissipation from the baseline to the splitter configuration was practically identical for both scale models, thereby supporting the findings of the large-scale model. Full article

The lack of sidewalls in a spillway leads to lateral expansion of the flow and, consequently, a non-uniform transversal flow rate distribution along the chute. The present work shows the velocity field measured in a physical model of a 1 V:0.8 H steeply sloping stepped spillway without sidewalls. An application of a Bubble Image Velocimetry (BIV) technique in the self-aerated region is shown, using air bubbles entrained into the flow downstream of the inception point as tracers. The results indicate that, for small dimensionless discharges and sufficiently downstream of the point of inception, the free-surface velocity compares relatively well with the corresponding air–water interfacial velocity previously obtained with a double-tip fiber optical probe in the same facility. In turn, the velocity profiles along the normal to the pseudo-bottom, far downstream of the inception point, are reasonably in agreement with the air–water interfacial velocity profiles in the inner part of the skimming flow, with the largest differences being verified in the upper skimming flow region near the free-surface. Full article

Stepped spillways have been increasingly used to handle flood releases from large dams associated with hydropower plants, and it is important to evaluate the fluctuating pressure field on the steps. Hydraulic model investigations were conducted on three 53° (1V:0.75H) sloping and relatively large-stepped chutes to characterize the mean, fluctuating, and extreme pressures acting on the most critical regions of the step faces, near their outer edges. The pressure development along the chutes is presented, generally indicating an increase of the modulus of pressure coefficients up to the vicinity of the point of inception of air entrainment, and a decrease further downstream. The extreme pressure coefficients along the spillway are fitted by an empirical formula, and the critical conditions potentially leading to cavitation on prototypes are calculated. The correlation between the cavitation index and the friction factor is also applied for predicting the onset of cavitation on prototypes, and the results are compared with the pressure data-based method. Generally, the results obtained from those methods yield typical values for the cavitation index in the vicinity of the point of inception, varying approximately from 0.8 to 0.6, respectively. In light of these results, maximum unit discharges of about 15–20 m²/s are considered advisable on 53° sloping large-stepped spillways without artificial aeration, for step heights ranging from 0.6 to 1.2 m. For much higher unit discharges, a considerable reach of the spillway may potentially be prone to the risk of cavitation damage. Full article

Jet velocity is an important parameter affecting the air entrainment rate of plunging liquid jet processes. While the vast majority of researchers have investigated the effect of jet velocity, only a few of them considered the effect of jet length in calculating the jet velocity at impingement point. This study investigates the difference (ΔV) between the jet velocity at the inception of the nozzle (V_j) and the impingement point (V_L) for a range of operating conditions. Furthermore, bubble voidage inside the downcomer, another critical parameter in plunging jets, is estimated using three different voidage equations incorporated inside a momentum balance model to predict the two-phase elevation level (H_R) inside the downcomer. Results showed that ΔV is significant (V_L > V_j), especially at low jet flow rates and high jet lengths. Generally, the momentum balance model predicted the H_R well, and its prediction improves with downcomer diameter. Given that, the model still needs to be refined for more accuracy for a wide range of operating conditions. Full article

Spillway is a crucial hydraulic structure used to discharge excess water from the dam reservoir. Air entrainment is essential to prevent cavitation damage on the spillway, however, without air entrainment the risk of cavitation over the spillway increases. The most important parameter for the determination of air entrainment in stepped spillways is the inception point. The inception point is the location where the air starts to inter into the water flow surface over the spillway. It occurs when the turbulent boundary layer meets the free surface. The location of the inception point depends upon different parameters like flow rate, geometry, step size, and slope of the spillway. The main aim of this study was applying numerical simulation by using the realizable k-ϵ model and the volume of fluid (VOF) method to locate the location of the inception point. For this purpose, by using different stepped spillways with four different slopes (12.5°, 19°, 29°, and 35°) different flow rates were simulated, which gives the location of the inception point of different channel slopes of stepped spillways at different flow rates. The results demonstrated that the inception point location of mild slopes is farther from the crest of the spillway than the steep slope stepped spillway. Non-aerated flow zone length increases when the channel slope decreases from steep to mild slope. Full article

In the stepped spillway, the steps, by providing an artificial roughening bed, dissipate the flow of energy more than other types of spillways, so the construction costs for stilling basin are reduced. However, what is important in this type of spillway is increasing the effectiveness of steps in the rate of energy dissipation. The present study deals with experimental and numerical simulations regarding the influence of geometric appendance elements on the steps and its impact on the energy dissipation performances, flow patterns properties, turbulent kinetic energy, flow resistance and the Darcy roughness. The localization of inception point of air entrainment is also assessed. To this aim, different configurations are taken into account. The computational procedure is validated with experimental results and then used to test the hydraulic behavior of different geometric configurations. The results showed that the appendance elements on the steps increased the turbulent kinetic energy (TKE) values and Darcy–Weisbach friction and the energy dissipation increased significantly. By reducing the height of the elements, energy dissipation and the TKE value increase more significantly. With the appendance elements on step, the air entrainment inception locations a positioning further upstream than the flat step stepped spillway. Full article

This work presents numerical simulations carried out to study the influence of geometric characteristics of pooled steps on the energy dissipation performance, flow patterns properties, velocity rates, and pressure distributions over a spillway. The localization of the inception point of air entrainment was also assessed, being a key design parameter of spillways. With this aim, different configurations of steps were taken in account, including flat, pooled, and notch pooled types. The computational procedure was first validated with experimental results from the literature and then used to test the hydraulic behavior derived from different geometric configurations. The flat step configuration showed the best energy dissipation performance as compared with other configurations. With the notched pooled step configuration, the efficiency performance of the pooled structure improved by about 5.8%. The interfacial velocities of the flat stepped spillway were smaller than those of the pooled structure. The pressure value at the beginning of the step in the pooled configuration was larger than the flat configuration, while for the notched pool the maximum pressure values decreased near the step pool. Pool configuration (simple or notched) did not have a significant influence on the location of air entrainment. Full article

Air entrainment in a stepped spillway is very important to protect the spillway from cavitation damage. The inception point is the location where air starts entering the non-aerated flow zone. The inception point location depends on different parameters, such as the discharge, step height, and step shape. In this paper, various stepped spillways, including flat steps, pooled steps, and round steps with different step heights were numerically simulated using the volume of fluid and realizable k-ε models. The results indicate that the inception point location moves downwards with the increase of the discharge of the stepped spillways. The length of the non-aerated flow zone increases with the discharge. The inception point location moves downwards as the step height decreases and the step number increases at the same discharge. The inception point location of the round stepped spillway model is much closer to the spillway crest than that of the flat stepped spillway with the same number of steps. The inception point location of the pooled stepped spillway is closer to the spillway crest than that of the flat stepped spillway, but more downstream than that of the round stepped spillway. Full article

Aerated flows are characterized by complex hydrodynamics and mass-transfer processes. As a Lagrangian method, smoothed particle hydrodynamics (SPH) has a significant advantage in tracking the air-water interface in turbulent flows. This paper presents the application of an SPH method to investigate hydrodynamics and reaeration over stepped spillways. In the SPH method, the entrainment of dissolved oxygen (DO) is studied using a multiphase mass transfer SPH method for reaeration. The numerical results are compared with the hydrodynamics data from Chanson and DO data from Cheng. The simulation results show that velocity distribution and the location of free-surface aeration inception agree with the experimental results. Compared with the experimental results, the distribution of DO concentration over the stepped spillway is consistent with the measurement results. The study shows that the two-phase DO mass transfer SPH model is reliable and reasonable for simulating the hydrodynamics characteristics and reaeration process. Full article

One of the most uncertain parameters in stepped spillway design is the length (from the crest) of boundary layer development. The normal velocity profiles responding to the steps as bed roughness are investigated in the developing non-aerated flow region. A detailed analysis of the logarithmic vertical velocity profiles on stepped spillways is conducted through experimental data to verify the computational code and numerical experiments to expand the data available. To determine development length, the hydraulic roughness and displacement thickness, along with the shear velocity, are needed. This includes determining displacement height d and surface roughness length z₀ and the relationship of d and z₀ to the step geometry. The results show that the hydraulic roughness height k_s is the primary factor on which d and z₀ depend. In different step height, step width, discharge and intake Froude number, the relations d/k_s = 0.22–0.27, z₀/k_s = 0.06–0.1 and d/z₀ = 2.2–4 result in a good estimate. Using the computational code and numerical experiments, air inception will occur over stepped spillway flow as long as the Bauer-defined boundary layer thickness is between 0.72 and 0.79. Full article
