Recent catastrophic bridge fire incidents have highlighted the critical need for effective post-fire assessment of bridges, thereby challenging the dominant practice of complete replacement following these destructive events. This study investigates the post-fire performance of bare, isolated, and Carbon Fiber Reinforced Polymer (CFRP)-repaired Reinforced Concrete (RC) bridge columns under single-unit truck impact followed by air blast. This extreme loading scenario was deliberately selected given the increased vulnerability of bridge columns to this loading scenario in the recent few years. Three-dimensional Finite Element (FE) models of the structural system and surrounding environment were developed and validated in LS-DYNA. The effectiveness of two in-situ retrofitting schemes in mitigating damage and enhancing structural integrity of three column diameters under the selected multi-hazards was assessed. Results demonstrated that wrapping the bottom half of the column height prevents shear failure and significantly reduces the damage under the coupled impact and blast. In contrast, employing a combination of CFRP bars and externally bonded sheets showed limited enhancement on post-fire impact and blast performance. This study provides critical insights into the feasibility and efficacy of retrofitting bridge columns that have experienced fire, thus laying the groundwork for the reconsideration of current design and rehabilitation protocols. Full article

The resistance to erosion of stainless steel-based plasma transferred arc (PTA)-cladded hardfacings reinforced with ex-situ-synthesized TiC is compared to those reinforced using in-situ-synthesized TiC (formed from TiO₂ and graphite). The PTA cladding was performed under an optimized torch linear velocity of 0.7 m/s and cladding current of 115 A. The microstructure of the cladded overlay was analyzed using scanning electron microscopy (SEM), and the phase composition was determined using X-ray diffraction (XRD). Vickers macrohardness measurements were made at representative areas at the surface of the overlays. An erosive wear test was conducted with impact angles of 30° and 90° and impact velocities of 20, 50, and 80 m/s. The formation of TiC from TiO₂ and graphite started during ball milling and ended during the cladding stage. The final TiC content in the hardfacings was below nominal, which is likely due to carbide segregation occurring during the cladding process. The highest hardness was 2.4 times that of stainless steel, which was observed in the deposit containing 60 vol.% ex-situ-synthesized TiC. Both ex-situ and in-situ TiC reinforcement improved resistance to erosion, providing up to 1.5 times better resistance under the 30° impact angle and up to 6.3 times under the 90° impact angle than that of stainless steel. However, ex-situ TiC showed a slightly larger improvement. At the 30° impact angle, the primary wear mechanism is micro-ploughing, but at the 90° impact angle it is surface fatigue. Both mechanisms appeared at both angles under 80 m/s impact velocity. Full article

In situ particle reinforced aluminum matrix composites have become an important development in the field of materials science due to their unique reinforced structure design and excellent mechanical properties. In this paper, in situ Al₂O₃ and AlSi₃Ti₂ particle reinforced Al12Si matrix composites were prepared via powder metallurgy. The microstructure and mechanical properties of the composites were analyzed systematically. With the increase in TiO₂ content, the grain size of the composites was refined, resulting in the composites exhibiting higher strength. The in situ generated AlSi₃Ti₂ phase has a higher Young’s modulus of elasticity compared to the Si phase. The in situ formed nano-Al₂O₃ and micrometer AlSi₃Ti₂ formed a strong interfacial bonding with the matrix, which ensured a good reinforcement effect. At the same time, the introduction of reinforced particles also changed the texture characteristics of extruded Al12Si, from <001>∥ED of Al12Si to <111>∥ED of composite. As a result, the strength of the Al12Si–7TiO₂ composite was 330 MPa, which is a 120% enhancement compared with that of the matrix. The hardness reached 107 HV, an increase of 80% compared to the matrix. This study can provide a reference value for the design of new multi-particle hybrid reinforced composites to enhance the material properties. Full article

Trophic state index (TSI) is a critical ecological and environmental issue in water resource management that has garnered significant attention. Given the complexity of optical characteristics in aquatic environments, this study employs fuzzy classification methods (FCM) and composite nutrient status indices to meticulously classify in-situ remote sensing reflectance data, aiming to develop evaluation models for different nutrient status categories to facilitate the assessment of the Daihai River in Inner Mongolia, China. Subsequently, we applied this model to MSI data to analyze the nutrient status of Daihai Lake from 2016 to 2021. Furthermore, a structural equation model (SEM) was utilized to explore the primary driving factors influencing nutrient status. The results indicated that the water bodies in Daihai Lake can be broadly classified into three categories, with the nutrient status models demonstrating robust performance for each category (R² = 0.80, R² = 0.83, and R² = 0.74). Comparisons were made between nutrient status accuracies obtained through the NCM and FCM based on measured data, yielding R² values of 0.74 and 0.85, respectively. Furthermore, the TSI results derived from MSI inversion were validated, with NCM achieving an R² of 0.49, RMSE of 6.88, and MAPE of 10.36%, while FCM exhibited an R² of 0.55, RMSE of 8.89, and MAPE of 13.18%. An SEM–based analysis revealed that over the long term, human activities exerted a more substantial impact on eutrophication in Daihai Lake, while climatic factors played an accelerating and reinforcing role. These results are consistent with prior research in the Daihai area, indicating a state of mild eutrophication and the potential of the fuzzy classification method and comprehensive trophic status index method in eutrophication assessment. Full article

This paper discusses the iteration of a seismic retrofit solution for shear-deficient end regions of 19 reinforced concrete (RC) moment-resisting frame (MRF) T-beams located in a 12-story RC MRF building in downtown Los Angeles, California. Local strengthening with externally bonded (EB) fiber-reinforced polymer (FRP) fabric was chosen as the preferred retrofit strategy due to its cost-effectiveness and proven performance. The FRP-shear-strengthening scheme for the deficient end-hinging regions of the MRF beams was designed and evaluated through large-scale cyclic testing of three replica specimens. The specimens were constructed at 4/5 scale and cantilever T-beam configurations with lengths of 3.40 m or 3.17 m. The cross-sectional geometry was 0.98 × 0.61 m with a top slab of 1.59 m in width and 0.12 m in thickness. Applied to these specimens were three different retrofit configurations, tested sequentially, namely: (a) unanchored continuous U-wrap; (b) anchored continuous U-wrap with conventional FRP-embedded anchors at the ends; and (c) fully closed external FRP hoops made of discrete FRP U-wrap strips and FRP through-anchors that penetrate the top slab and connect both ends of the FRP strips, combined with intermediate crack-control joints. The strengthening concept with FRP hoops precluded the premature debonding and anchor pullout issues of the two more conventional retrofit solutions and, despite a more challenging and labor-intensive installation, was selected for the in-situ implementation. The proposed hooplike EB-FRP shear-strengthening scheme enabled the deficient MRF beams to overcome a 30% shear overstress at the end-yielding region and to develop high-end rotations (e.g., 0.034 rad [3.4% drift] at peak and 0.038 rad [3.8% drift]) at strength loss for a beam that, otherwise, would have prematurely failed in shear. These values are about 30% larger than the ASCE 41 prescriptive value for the Life Safety (LS) performance objective. Energy dissipation achieved with the fully closed scheme was 108% higher than that of the unanchored FRP U-wrap and 45% higher than that of the FRP U-wrap with traditional embedded anchors. The intermediate saw-cut grooves successfully attracted crack formation between the strips and away from the FRP reinforcement, which contributed to not having any discernable debonding of the strips up to 3% drift. This paper presents the experimental evaluation of the three large-scale laboratory specimens that were used as the design basis for the final retrofit solution. Full article

Embedded fiber Bragg gratings are increasingly applied for in-situ strain measurement in fiber-reinforced plastics, integral to high-end aerospace equipment. Existing research primarily focuses on in-plane strain measurement, limited by the fact that fiber Bragg gratings are mainly sensitive to axial strain. However, out-of-plane strain measurement is equally important for comprehending structural deformation. The birefringence of fiber Bragg gratings shows promise for addressing this problem; yet, the strain transfer relationship between composites and optical fibers, along with the decoupling method for multi-directional strains, remains inadequately explored. This study introduces an innovative method for multi-directional strain measurement in fiber-reinforced plastics using the birefringence of a single-fiber Bragg grating. The strain transfer relationship between composites and embedded optical fibers was derived based on Kollar’s analytical model, leading to the development of a multi-directional strain decoupling methodology. This method was experimentally validated on carbon fiber/polyetherimide laminates under thermo-mechanical loading. Its reliability was confirmed by comparing experimental results and finite element simulations. These findings significantly broaden the application scenarios of fiber Bragg gratings, advancing the in-situ measurement technology crucial for the next generation of high-end aerospace equipment. Full article

This paper presents a mesoscale damage model for composite materials and its validation at the coupon level by predicting scaling effects in un-notched carbon-fiber reinforced polymer (CFRP) laminates. The proposed material model presents a revised longitudinal damage law that accounts for the effect of complex 3D stress states in the prediction of onset and broadening of longitudinal compressive failure mechanisms. To predict transverse failure mechanisms of unidirectional CFRPs, this model was then combined with a 3D frictional smeared crack model. The complete mesoscale damage model was implemented in ABAQUS^®/Explicit. Intralaminar damage onset and propagation were predicted using solid elements, and in-situ properties were included using different material cards according to the position and effective thickness of the plies. Delamination was captured using cohesive elements. To validate the implemented damage model, the analysis of size effects in quasi-isotropic un-notched coupons under tensile and compressive loading was compared with the test data available in the literature. Two types of scaling were addressed: sublaminate-level scaling, obtained by the repetition of the sublaminate stacking sequence, and ply-level scaling, realized by changing the effective thickness of each ply block. Validation was successfully completed as the obtained results were in agreement with the experimental findings, having an acceptable deviation from the mean experimental values. Full article

Metal-ceramic composite coatings are produced on the surface of equipment components by laser cladding, improving the abrasive wear resistance of components and extending their service life. However, defects such as brittleness and cracks limit the wide application of metal-ceramic clad coatings in the field of construction machinery. In the present study, a dual-element (Ti/Nb) alloying method is innovatively adopted to regulate the microstructure and mechanical properties of tungsten carbide (WC)-reinforced clad coatings. Experimental results show that with the introduction of Ti/Nb, novel reinforcements are in-situ synthesized in the cladding coatings with two different kinds of morphologies: one is a core-shell carbide with the core of pure TiC and a shell of (Ti,Nb,W)C multiple carbide; the other is a (Ti,Nb,W)C multiple carbide. With 8 wt.% Ti/Nb addition, the newly formed multiple carbides with the appropriate content are well-dispersed and distributed in the clad coating, which effectively transfers load, inhibits the initiation and expansion of micro-cracks, and resists the wear damage of hard abrasive particles, solving the technical problems of the simultaneous improvement of toughness and abrasive wear resistance of metal-ceramic laser cladding coatings. Full article

The wide size range and high tendency to agglomerate of in-situ TiB₂ particles in reinforced Al matrix composites introduce great difficulties in their size characterization. In order to use a nanoparticle size analyzer (NSA) to obtain the precise size distribution of TiB₂ particles, a controlled size characterization process has been explored. First, the extraction and drying processes for TiB₂ particles were optimized. In the extraction process, alternated applications of magnetic stirring and normal ultrasound treatments were proven to accelerate the dissolution of the Al matrix in HCl solution. Furthermore, freeze-drying was found to minimize the agglomeration tendency among TiB₂ particles, facilitating the acquisition of pure powders. Such powders were quantitatively made into an initial TiB₂ suspension. Second, the chemical and physical dispersion technologies involved in initial TiB₂ suspension were put into focus. Chemically, adding PEI (M.W. 10000) at a ratio of m_PEI/m_TiB2 = 1/30 into the initial suspension can greatly improve the degree of TiB₂ dispersion. Physically, the optimum duration for high-energy ultrasound application to achieve TiB₂ dispersion was 10 min. Overall, the corresponding underlying dispersion mechanisms were discussed in detail. With the combination of these chemical and physical dispersion specifications for TiB₂ suspension, the bimodal size distribution of TiB₂ was able to be characterized by NSA for the first time, and its number-average diameter was 111 ± 6 nm, which was reduced by 59.8% over the initial suspension. Indeed, the small-sized and large-sized peaks of the TiB₂ particles characterized by NSA mostly match the results obtained from transmission electron microscopy and scanning electron microscopy, respectively. Full article

The longwall system is an extraction system commonly used in coal mining in many countries, including Poland. One of the methods for reducing extraction costs is the dual use of the gateroad. In the first instance, the gateroad serves as the tailgate, and during the exploitation of the second coal panel, it functions as the headgate. Such a situation requires maintenance of the roadway behind the longwall face, which is typically challenging, due to significant stress-related loads on the support and its substantial deformation. The support design for this kind of roadway should take into consideration the dual impact of exploitation pressure and the caved zone influence behind the longwall face. This article presents the results of in-situ research conducted on two roadways behind the longwall face. In both roadways, the effectiveness of specially designed steel arch frames and rock bolt patterns were examined to minimize roadway deformations and maintain their functionality. The research project was comprised of several stages. Initially, mining and laboratory studies were conducted to determine the geomechanical parameters of the rocks. Subsequently, excavation stability and functionality forecasts were performed based on the authors’ empirical indicators. Then, numerical analyses were carried out to design support schemes (steel arches and rock bolt) in both roadways. A fully automated monitoring system with programmed data loggers was designed to check the behaviour of a specific rock mass and the support elements. The load on the steel arch support was measured with the help of load cells, while the load on the rock bolt support was carried out with the help of measurement bolts. Behind the longwall face, the loads on the wooden cribs set from the goaf side were also monitored. Additionally, the measurement station was equipped with extensometers to monitor the movement of roof layers and stress meters to determine changes in rock mass stress. Laser scanning or traditional surveying methods were also used to verify the support schemes through roadway convergence measurements. The obtained results allowed us to draw conclusions regarding the optimization of support schemes and to give recommendations for the practical application of specific reinforcements in excavations maintained behind the longwall face. Full article

Fused Deposition Modeling (FDM) is an additive manufacturing technology that has emerged as a promising technique for fabricating 3D printed polymers. It has gained attention recently due to its ease of use, efficiency, low cost, and safety. However, 3D-printed FDM components lack sufficient strength compared to those made using conventional manufacturing methods. This low strength can be mainly attributed to high porosity and low sinterability of layers and then to the characteristics of the polymer used in the FDM process or the FDM process itself. Regarding polymer characteristics, there are two main types of reinforcing fibers: discontinuous (short) and continuous. Continuous-fiber reinforced composites are becoming popular in various industries due to their excellent mechanical properties. Since continuous reinforcing fibers have a more positive effect on increasing the strength of printed parts, this article focuses primarily on continuous long fibers. In addition to polymer characteristics, different mechanisms have been developed and introduced to address the issue of insufficient strength in 3D-printed FDM parts. This article comprehensively explains two main FDM mechanisms: in-situ fusion and ex-situ prepreg. It also provides relevant examples of these mechanisms using different reinforcing elements. Additionally, some other less frequently utilized mechanisms are discussed. Each mechanism has its own advantages and disadvantages, indicating that further development and modification are needed to increase the strength of 3D-printed FDM parts to be comparable to those produced using traditional methods. Full article

Under a global carbon-neutralizing environment, renewable wood is a viable alternative to non-renewable resources due to its abundance and high specific strength. However, fast-growing wood is hard to be applied extensively due to low mechanical strength and poor dimensional stability and durability. In this study, epoxy-acrylic resin-modified wood was prepared by forming a functional monomer system with three monomers [glycidyl methacrylate (GMA), maleic anhydride (MAN), and polyethylene glycol-200-dimethylacrylic acid (PEGDMA)] and filling into the wood cell cavity. The results showed that in the case of an optimal monomer system of nGMA:nPEGDMA = 20:1 and an optimal MAN dosage of 6%, the conversion rate of monomers reached 98.01%, the cell cavity was evenly filled by the polymer, with the cell wall chemically bonded. Thus, a bonding strength of as high as 1.13 MPa, a bending strength of 112.6 MPa and an impact toughness of 74.85 KJ/m² were applied to the modified wood, which presented excellent dimensional stability (720 h water absorption: 26%, and volume expansion ratio: 5.04%) and rot resistance (loss rates from white rot and brown rot: 3.05% and 0.67%). Additionally, polymer-modified wood also exhibited excellent wear resistance and heat stability. This study reports a novel approach for building new environmentally friendly wood with high strength and toughness and good structural stability and durability. Full article

Compared to traditional steel reinforcement, GFRP anchors demonstrate outstanding mechanical performance and corrosion resistance, and so they are an ideal substitute for steel reinforcement in anti-floating projects. Based on finite element software, a 3D axisymmetric calculation model of GFRP anti-floating anchors in medium-weathered granite was established in this paper. Combined with the in-situ ultimate pull-out tests, the bonding anchoring performance and bearing characteristics between the anchor body, anchoring mortar, and rock–soil mass were analyzed. The research findings indicated that the cohesive bonding elements exhibited a high degree of conformity in defining the interface contact relationship of the GFRP anti-floating anchor anchoring system. The axial force of the GFRP anti-floating anchor body is “attenuated” along the depth direction, and there was a critical value of anchoring length; under the same conditions, the reasonable anchoring length should be 3.5~5.0 m. All the anchors in the in-situ tests exhibited interfacial shear slip failure between the anchor body and the anchor mortar, with an average maximum load of 450 kN, which is consistent with the maximum failure load of the simulated anchors. Compared to a load of 50 kN, the maximum stress of the anchor mortar increased by 50% under a load of 450 kN. The displacement variation of the surrounding rock–soil mass showed a decreasing trend from the inside to the outside and from the top to the bottom. The research results provided valuable references for the optimization design of GFRP anti-floating anchors. Full article

The development of novel embedded sensors for structural health monitoring (SHM) is crucial to provide real-time assessments of composite structures, ensuring safety, and prolonging their service life. Early damage diagnostics through advanced sensors can lead to timely maintenance, reducing costs and preventing potential catastrophic failures. This paper presents the synthesis, 3D printing, and characterization of novel embedded strain sensors using multi-walled carbon nanotube (MWCNT) -enhanced nanocomposites in fiberglass reinforced composites for potential damage diagnostics and SHM applications. MWCNTs are dispersed within structural epoxy for the additive manufacturing of nanocomposites with piezoresistive sensing capability. The 3D-printed nanocomposite sensors are embedded in fiberglass-reinforced composite laminates. The piezoresistive sensing capabilities of the 3D-printed sensors within composites are characterized by applying different levels of maximum loads and load rates under three-point bending loads. Additionally, the long-term reliability of the developed strain sensors is evaluated up to 1000 cycles. The recorded piezoresistive sensing signals show high sensitivity for the externally applied bending loads with advanced gauge factor up to 100, resulting in potential load sensing capability for in-situ damage diagnostics and real-time SHM for structural composites. Full article

Composite structure design is an important way to improve reinforcement strengthening efficiency. The dispersion of the external reinforcement is often not uniform enough, however, and it is agglomerated in the matrix, which cannot uniformly and effectively bear the load. The interconnected reinforcement network prepared by the in-situ self-growth method is expected to obtain higher material properties. In this paper, the TiN shell was formed on the surface of Ti powder by the in-situ nitriding method, and then the network TiN/Ti composites were prepared by sintering. In the control group, TiN was dispersed by mechanical ball milling, and it was found that TiN powder was coated on the surface of Ti particles, and the sintered TiN/Ti composites formed a discontinuous structure with a great deal of TiN agglomeration. A uniform TiN nitride layer of 5~7 μm was formed on the surface of Ti powder by the in-situ nitriding method, and a connected TiN network was formed in the sintered Ti-N/Ti composites. The composites prepared by nitriding have higher compressive strength, hardness, and plasticity. The hardness of the Ti-N/Ti composite is 685.7 HV and the compressive strength is 1468.5 MPa. On this basis, the influence of the connected TiN structure on the material properties was analyzed, which provided theoretical guidance for the structural design of the network structure-reinforced titanium matrix composites. Full article
