The extended operation of high-speed railways has led to an increased incidence of tunnel lining defects, with falling debris posing a significant safety threat. Within tunnels, single-train passage and trains-crossing events constitute the most frequent operational scenarios, both generating extreme aerodynamic environments that alter debris trajectories from free fall. To systematically investigate the aerodynamic differences and underlying mechanisms governing falling debris behavior under these two distinct conditions, a three-dimensional computational fluid dynamics (CFD) model (debris–air–tunnel–train) was developed using an improved delayed detached eddy simulation (IDDES) turbulence model. Comparative analyses focused on the translational and rotational motions as well as the aerodynamic load coefficients of the debris in both single-train and trains-crossing scenarios. The mechanisms driving the changes in debris aerodynamic behavior are elucidated. Findings reveal that under single-train operation, falling debris travels a greater distance compared with trains-crossing conditions. Specifically, at train speeds ranging from 250–350 km/h, the average flight distances of falling debris in the X and Z directions under single-train conditions surpass those under trains crossing conditions by 10.3 and 5.5 times, respectively. At a train speed of 300 km/h, the impulse of C_Fx and C_Fz under single-train conditions is 8.6 and 4.5 times greater than under trains-crossing conditions, consequently leading to the observed reduction in flight distance. Under the conditions of trains crossing, the falling debris is situated between the two trains, and although the wind speed is low, the flow field exhibits instability. This is the primary factor contributing to the reduced flight distance of the falling debris. However, it also leads to more pronounced trajectory deviations and increased speed fluctuations under intersection conditions. The relative velocity (CRV) on the falling debris surface is diminished, resulting in smaller-scale vortex structures that are more numerous. Consequently, the aerodynamic load coefficient is reduced, while the fluctuation range experiences an increase. Full article

This study investigates the spread patterns of tunnel fires and examines issues related to emergency response. It focuses on the temperature characteristics, spread patterns, conditions leading to multi-source fires, and the efficacy of water mist suppression methods in heavy-haul railway tunnel fires. The research employs theoretical derivations and numerical simulations to achieve its objectives. It was discovered that, during a fire in a heavy-haul railway tunnel, the temperature inside the tunnel can exceed 500 °C. Furthermore, depending on the nature of the goods transported by the train and under specific wind speed conditions, the fire source has the potential to spread to other carriages, resulting in a multi-source fire. Using the numerical simulation software Pyrosim 2022, various wind speed conditions were simulated. The results revealed that at lower wind speeds, the smoke demonstrates a reverse flow phenomenon. Concurrently, when the adjacent carriage on the leeward side of the fire is ignited, the high-temperature reverse flow smoke, along with the thermal radiation from the flames, ignites combustible materials in the adjacent carriage on the windward side of the burning carriage. Through theoretical derivation and numerical simulation, the critical wind speed for the working conditions was determined to be 2.14 m/s. It was found that while a higher wind speed can lead to a decrease in temperature, it also increases the flame deflection angle. When the wind speed exceeds 2.4 m/s, although the temperature significantly drops in a short period, the proximity of combustible materials on the leeward side of the carriage becomes a concern. At this wind speed, the flame deflection angle causes heat radiation on the leeward side, specifically between 0.5 m and 3 m, to ignite the combustible materials on the carriage surface, resulting in fire spread and multiple fire incidents. The relationship between wind speed and the angle of deflection from the fire source was determined using relevant physics principles. Additionally, the relationship between wind speed and the trajectory of water mist spraying was established. It was proposed to optimize the position of the water mist based on its deviation, and the results indicated that under critical wind speed conditions, when the water mist spraying is offset approximately 5 m towards the upwind side of the fire source, it can act more directly on the surface of the fire source. Numerical simulation results show a significant reduction in the maximum temperature and effective control of fire spread. Under critical wind speed conditions, the localized average temperature of the fire decreased by approximately 140 °C when spraying was applied, compared to the conditions without spraying, and the peak temperature decreased by about 190 °C. This modification scheme can effectively suppress the threat of fire to personnel evacuation under simulated working conditions, reflecting effective control over fires. Additionally, it provides theoretical support for the study of fire patterns in tunnels and emergency response measures. Full article

Lining thinning is a common defect in railway tunnels; however, its impact on shallow four-track high-speed railway (HSR) tunnels—particularly on rock pressure—remains poorly understood. This study investigates the influence of lining thinning on the genuine pressure (also referred to as “deformation pressure”) of such tunnels through field investigation, long-term monitoring, and numerical simulation. Firstly, a lining thinning survey was conducted across ten tunnels, and the statistical distribution of defect parameters was analyzed. Second, over 180 days of field monitoring were carried out in China’s first four-track HSR tunnel (XBS Tunnel) to evaluate the rock pressure state. Third, a three-dimensional numerical model was developed to evaluate the effects of lining thinning and structural degradation on the principal stress, deformation, and genuine pressure of shallow four-track HSR tunnels. The results indicate that thinning defects are widespread, with 38.64% occurring at the vault and over 84% having minimum thicknesses below 0.26 m. The actual rock pressure in the XBS Tunnel was significantly lower than theoretical predictions, and the tunnel primarily experienced genuine pressure rather than loosening pressure during construction, with the secondary lining serving as a safety reserve. Lining thinning leads to stress redistribution and concentration, weakens structural stiffness, and increases the likelihood of damage. It also induces a transition from genuine pressure to loosening pressure, a process that is further accelerated by surrounding rock and lining degradation. The findings provide important insights for the evaluation, design, and long-term maintenance of large-span HSR tunnels. Full article

Wind-induced vibrations in additional conductors on electrified railway catenary systems pose a risk to operational safety and long-term structural performance. This study investigates the dynamic response of these components under wind excitation through nonlinear finite element analysis. A wind speed spectrum model is developed using wind tunnel tests and field data, and the autoregressive method is used to generate realistic wind fields incorporating longitudinal, lateral, and vertical components. A detailed finite element model of the additional conductors and fittings was constructed using the Absolute Nodal Coordinate Formulation to account for large deformations. Time domain simulations with the Newmark-β method were conducted to analyze vibration responses. The results show that increased wind speeds lead to greater vibration amplitudes, and the stochastic nature of wind histories significantly affects vibration modes. Higher conductor tension effectively reduces vibrations, while longer spans increase flexibility and susceptibility to oscillation. The type of fitting also influences system stability; support-type fittings demonstrate lower stress fluctuations, reducing the likelihood of resonance. This study enhances understanding of wind-induced responses in additional conductor systems and informs strategies for vibration mitigation in high-speed railway infrastructure. Full article

The rapid development of urban transportation renovation and transportation networks in China has driven the construction of an increasing number of large-span, large cross-section tunnels under sensitive environments, such as airport runways, critical infrastructure, and high-speed railways. These projects often require strict settlement control within a millimeter-level tolerance range, thus theoretical methods and key technologies for micro-settlement control have been developed. This study first derives a calculation formula for surface settlement associated with large cross-section tunnels and elucidates its correlations with factors such as pipe-roof stiffness, support system stiffness, pipe-roof construction procedures, and groundwater level changes. Theoretical approaches for controlling micro-settlement are introduced, including increasing pipe-roof stiffness, reinforcing the support system, mitigating group pipe effects, maintaining pressure and reducing resistance around the pipe, and controlling groundwater levels. A method is proposed for determining the appropriate stiffness of the pipe roof and support system. The stiffness should be selected from the transition segment between the steep decline and the gentle slope on the stiffness-settlement curves of the pipe roof and the support system. If the stiffness of the pipe roof and primary support combined with temporary support fails to meet the micro-settlement control requirements, an integrated support system with greater stiffness can be adopted. A reasonable pressure-regulating grouting technique for maintaining pressure and reducing resistance around the pipe is proposed. It is recommended that the spacing for simultaneous jacking of pipes be greater than half the width of the settlement trough. For over-consolidation-sensitive strata such as medium or coarse sands, water-blocking measures, including freezing, grouting, or a combination of both, are recommended. For over-consolidation-insensitive strata like gravels and cobbles with strong permeability, water-blocking treatments are generally unnecessary. The proposed theoretical approaches have been successfully implemented in projects such as the tunnel beneath Beijing Capital Airport runways and Taiyuan Railway Station, demonstrating their reliability. The research findings provide valuable insights into surface micro-settlement control for similar projects. Full article

This study investigates the stability of multilayer shield tunnels beneath high-speed railway bases, with a particular focus on the influence of dynamic loads induced by high-speed rail vibrations and shield thrust. A self-designed scale test apparatus was employed to simulate the effects of these dynamic loads on tunnel soil stability, face integrity, formation stress, deformation, and settlement. The experimental setup was specifically designed to accurately replicate the deformation characteristics of the tunnel face and surrounding strata under the combined influence of shield tunneling and high-speed rail loads. The reliability of the experimental results was validated through comparison with numerical simulations performed using FLAC^3D software. The study underscores the effectiveness of integrating physical model tests with numerical simulations to predict the failure characteristics and ultimate support forces of tunnel faces under dynamic loading conditions. The findings provide novel insights into the deformation and failure mechanisms of tunnel faces during shield excavation, particularly under the influence of high-speed rail loads. This research establishes a robust methodological framework for assessing tunnel face stability and offers valuable guidance for the design and construction of shield tunnels in analogous geological and operational contexts. Full article

Train-induced environmental vibrations are a common issue in urban rail transit systems, particularly in suburban railways operating at high speeds, where the impact of these vibrations is more pronounced. This presents significant challenges for urban planners and engineers. Existing research has mainly focused on the impact of single tunnel structures on ground vibrations, with limited understanding of the vibration propagation characteristics of adjacent bidirectional tunnels. To address this gap in knowledge, this study investigates the ground vibration attenuation characteristics induced by train operations in the underground sections of suburban railways, with a focus on the amplification effects of adjacent tunnels on ground vibrations. The results show that the vibrations induced by the trains are concentrated in the 20–50 Hz frequency range and exhibit similar characteristics in all directions. The maximum vertical vibration acceleration and peak acceleration occur directly above the train tunnel. Additionally, adjacent tunnels significantly amplify the maximum peak acceleration at measurement points in directions perpendicular to the track, including both horizontal and vertical directions. Furthermore, the soil within the adjacent tunnels also exhibits amplification of the vertical power spectral amplitude in the 40–100 Hz frequency range. The findings of this study provide new insights into the influence of adjacent bidirectional tunnels on environmental vibrations in suburban railway operations. These results are of significant importance for optimizing railway design and vibration mitigation measures. Full article

High-speed railways are critical infrastructure in many countries, but their construction generates substantial spoil, particularly in mountainous regions dominated by tunnels and slopes, necessitating the establishment and monitoring of spoil disposal areas. Inadequate monitoring of spoil disposal areas can lead to significant environmental issues, including soil erosion and geological hazards such as landslides and debris flows, while also hindering the recycling and reuse of construction spoil, thereby impeding the achievement of circular economy and sustainable development goals for high-speed railways. Although the potential of geographic information systems, remote sensing, and global positioning systems in waste monitoring is increasingly recognized, there remains a critical research gap in their application to spoil disposal areas monitoring within high-speed railway projects. This study proposes an innovative framework integrating geographic information systems, remote sensing, and global positioning systems for monitoring spoil disposal areas during high-speed railway construction across three key scenarios: identification of disturbance boundaries (scenario 1), extraction of soil and water conservation measures (scenario 2), and estimation of spoil volume changes (scenario 3). In scenario 1, disturbance boundaries were identified using Gaofen-1 satellite data through processes such as imagery fusion, unsupervised classification, and spatial analysis. In scenario 2, unmanned aerial vehicle data were employed to extract soil and water conservation measures via visual interpretation and overlay analysis. In scenario 3, Sentinel-1 data were used to analyze elevation changes through the differential interferometric synthetic aperture radar method, followed by the estimation of spoil volume changes. The effectiveness of this integrated framework was validated through a case study. The results demonstrate that the framework can accurately delineate disturbance boundaries, efficiently extract soil and water conservation measures, and estimate dynamic changes in spoil volume with an acceptable error margin (15.5%). These findings highlight the framework’s capability to enhance monitoring accuracy and efficiency. By integrating multi-source data, this framework provides robust support for sustainable resource management, reduces the environmental impact, and advances circular economy practices. This study contributes to the efficient utilization of construction spoil and the sustainable development of high-speed railway projects. Full article

Frost damage is one of the main influencing factors for the deterioration of support structures in cold-region tunnels. A new dual transverse isotropic model of frozen rock mass is first proposed based on parameter strain and elastic modulus to serve as the theoretical basis for tunnel operation safety in cold regions. Subsequently, a unified elasto-plastic solution for high-speed railway tunnels in cold regions is derived based on the new dual transverse isotropic model, and the accuracy of the analytical solution is verified by comparisons with existing models and experimental results. Finally, the effect of the model parameters on stress and displacement is explored. The results reveal a significant negative correlation between the plastic radius of the frozen rock mass zone and the pressure acting on the inner surface of the support structure, the influence coefficient of intermediate principal stress, radial-gradient influence coefficient of the frozen rock mass, and anisotropic frost heave coefficient of the frozen rock mass, as well as between the frost-heaving force and the influence coefficient of intermediate principal stress parameter. However, the frost-heaving force is positively correlated with the pressure acting on the inner surface of the support structure, the radial gradient influence coefficient of the frozen rock mass, and the anisotropic frost heave coefficients of the frozen rock mass. Therefore, the pressure acting on the inner surface of the support structure, the radial gradient influence co-efficient of the frozen rock mass, and the anisotropic frost heave coefficients of frozen rock mass should be reasonably considered, but the strength theory of the surrounding rock should be strongly considered in the design of tunnel structures in cold regions. Full article

The settlement of existing high-speed railway tunnels due to adjacent excavations is a complex phenomenon influenced by multiple factors, making accurate estimation challenging. To address this issue, a prediction model combining extreme gradient boosting (XGBoost) with Bayesian optimization (BO), namely BO-XGBoost, was developed. Its predictive performance was evaluated against conventional models, such as artificial neural networks (ANNs), support vector machines (SVMs), and vanilla XGBoost. The BO-XGBoost model showed superior results, with evaluation metrics of MAE = 0.331, RMSE = 0.595, and R² = 0.997. In addition, the BO-XGBoost model enhanced interpretability through an accessible analysis of feature importance, identifying volume loss as the most critical factor affecting settlement predictions. Using the prediction model and a particle swarm optimization (PSO) algorithm, a hybrid framework was established to adjust the operational parameters of a shield tunneling machine in the Changsha Metro Line 3 project. This framework facilitates the timely optimization of operational parameters and the implementation of protective measures to mitigate excessive settlement. With this framework’s assistance, the maximum settlements of the existing tunnel in all typical sections were strictly controlled within safety criteria. As a result, the corresponding environmental impact was minimized and resource management was optimized, ensuring construction safety, operational efficiency, and long-term sustainability. Full article

This paper presents a new slant insertion-opening combination sand fence designed to reduce the hazards of traditional railway sand damage along the line. This new fence aims to decrease the disturbance caused by lateral wind on the high-speed railway and minimize the deposition of track sand particles. Numerical modeling and wind tunnel testing were employed to examine the structure’s defensive capabilities. Using the computational fluid dynamics (CFD) method and the Eulerian–Eulerian two-fluid model, the wind protection effect and airflow characteristics of the new sand fence with different slant insertion angles and spacings were simulated, and the optimal configuration parameters were selected. The study found that the new mechanical sand fence exhibits similar performance to the traditional sand fence. Since there is a “narrow tube effect”, the leeward side of the inclined plate generates a local high-speed airflow zone. In the top acceleration zone, the new mechanical sand fence efficiently lowers air velocity, thereby enhancing its protective capabilities. Moreover, the optimal protective performance of the new mechanical sand fence is achieved with an inclination angle of 15°, with improved protection observed as the angle increases. Additionally, the protective performance of double rows of these fences is influenced by the spacing between them. Increasing the distance between the two rows enhances protective performance, with the optimal protection achieved at a spacing of 25H. Beyond this distance, protective performance decreases. Full article

Due to its inherent advantages, shield tunnelling has become the primary construction method for urban tunnels, such as high-speed railway and metro tunnels. However, there are numerous technical challenges to shield tunnelling in complex geological conditions. Under the disturbance induced by shield tunnelling, sandy pebble soil is highly susceptible to ground loss and disturbance, which may subsequently lead to the risk of surface collapse. In this paper, large-diameter slurry shield tunnelling in sandy pebble soil is the engineering background. A combination of field monitoring and numerical simulation is employed to analyze tunnelling parameters, surface settlement, and deep soil horizontal displacement. The patterns of ground disturbance induced by shield tunnelling in sandy pebble soil are explored. The findings reveal that slurry pressure, shield thrust, and cutterhead torque exhibit a strong correlation during shield tunnelling. In silty clay sections, surface settlement values fluctuate significantly, while in sandy pebble soil, the settlement remains relatively stable. The longitudinal horizontal displacement of deep soil is significantly greater than the transverse horizontal displacement. In order to improve the surface settlement troughs obtained by numerical simulation, a cross-anisotropic constitutive model is used to account for the anisotropy of the soil. A sensitivity analysis of the cross-anisotropy parameter α was performed, revealing that as α increases, the maximum vertical displacement of the ground surface gradually decreases, but the rate of decrease slows down and tends to level off. Conversely, as the cross-anisotropy parameter α decreases, the width of the settlement trough narrows, improving the settlement trough profile. Full article

Tunnel stability is influenced by the rheological properties of the surrounding rock. This study, based on the Ganshen high-speed railway tunnel project, examines the rheological characteristics of siltstone and sandstone through laboratory tests and theoretical analysis. Rheological curves and parameters are derived, revealing the time-dependent deformation mechanisms of the surrounding rocks. A numerical simulation model is created using these parameters to analyze deformation and stress characteristics based on different rock levels and inverted arch closure distances. Results indicate that sandstone follows the Cvisc model, with the Maxwell elastic modulus increasing under higher loads while the viscous coefficient decreases. The vault displacement is mainly affected by the surrounding rock strength; lower strength leads to greater displacement, which also increases with the closure distance of the inverted arch. These findings are crucial for determining the optimal closure distance of inverted arches in sandstone conditions. Full article

In urban metro construction, shield tunneling often needs to pass through building and bridge pile foundations, potentially affecting the stability of existing structures. Therefore, accurately assessing the impact of shield tunneling on bridges and buildings is crucial. This study presents a comprehensive prediction method combining numerical simulation and empirical formulas, taking the underpass project of the Shijiazhuang–Wuhan High-Speed Railway Bridge by Zhengzhou Metro Line 5 as a case study. Three-dimensional numerical model calculations were performed using finite element software to analyze the displacement and stress changes of buildings and tunnel structures at different construction stages, revealing the deformation patterns of buildings adjacent to the tunnel during shield tunneling. In particular, the ground settlement caused by twin-tunnel excavation was compared with Peck’s empirical formula to verify the reliability of the numerical simulation. The results show that twin-tunnel excavation exacerbates the horizontal displacement, uplift, and settlement of the ground, with maximum deformation rates increasing by 7.10%, 20%, and 11.4%, respectively. Comparing the ground deformation results of Peck’s empirical formulas with numerical calculations revealed similar trends in the settlement curves, with a maximum deviation of 6.67%. It can be concluded that using Peck’s empirical formula to calculate ground deformation characteristics complements the limitations of numerical simulations, making the assessment results more reliable. The findings of this study demonstrate that integrating numerical simulation with empirical formulas significantly enhances the reliability of deformation predictions in complex tunneling scenarios. This research not only offers a comprehensive safety assessment method for shield tunneling construction but also provides valuable guidance for the design and construction of similar projects, serving as a theoretical reference for future engineering endeavors. Full article

To ensure the construction and operational safety of tunnel undercrossing multi-situational goafs, the Huaying Mountain High-Speed Rail Tunnel, a critical section of the Xi’an-Chongqing High-Speed Railway, was taken as a case study. Based on a three-dimensional finite difference numerical simulation platform, twelve situations were established to analyze the effects of three factors: distance, scale, and angle. The stability analysis was conducted by examining the displacement and deformation characteristics of the surrounding rock, stress changes, and axial forces of the initial support for each situation. The results show that in tunnel undercrossing multi-situational goafs, the vertical deformation, horizontal convergence of the surrounding rock, and the maximum axial force of initial support are all affected. Within a certain range, changes in distance significantly impact subsidence and settlement deformation of the surrounding rock. However, as the distance increases, the horizontal and vertical displacements of the tunnel and the axial force of the initial support tend to decrease. Conversely, the scale and angle of the goaf have an opposite effect on the surrounding rock: as the scale and angle increase, the stability of the surrounding rock deteriorates. In this case study, when the distance exceeds 1.13 times the tunnel span, the influence of the goaf on the stability of the surrounding rock gradually decreases. When the angle exceeds 45°, vertical displacement decreases, and the increasing trend of horizontal displacement gradually diminishes. The conclusions of this paper can provide guidance for designing reinforcement schemes for tunnels crossing through multi-situational goafs. The findings provide valuable insights and guidance for similar engineering projects. Full article
