Search Results (17)

With the aim of addressing the low volumetric efficiency of CO₂ swashplate axial piston pumps, the influence of four volumetric losses—loss of the CO₂ compression retention volume, leakage volume loss of the port pair, leakage volume loss of the plunger pair, and leakage volume loss of the slipper pair—on volumetric efficiency was analyzed using a transient numerical simulation method. The numerical simulation results showed that the real physical property model can accurately describe the compression retention characteristics of CO₂ under high-pressure conditions. CO₂ compression retention volume loss accounted for 28.6% of the volumetric efficiency and was the main factor causing low volumetric efficiency of the piston pump. Leakage volume losses of the slipper pair, the flow distribution pair, and the plunger pair accounted for about 3.4%, 1.5%, and 0.5% of the volumetric efficiency, respectively. These research results provide a reference for volumetric efficiency loss analyses of piston pumps. Full article

The high-pressure common rail (HPCR) injection system, a key technology for enhancing diesel engine performance, plays a decisive role in ensuring fuel injection precision and combustion efficiency through rail pressure stability. This study establishes a coupled simulation model of an electronically controlled HPCR injection system and a diesel engine, using GT-Suite to systematically investigate the effects of fuel supply pressure, camshaft speed, high-pressure pump plunger parameters, and inlet and outlet valve characteristics on rail pressure fluctuations. Gray relational analysis quantifies the correlation between these factors and rail pressure variations. The results demonstrate that increasing camshaft speed, injection pulse width, plunger mass, plunger length, plunger spring preload, inlet valve spring preload, and outlet valve body mass reduces rail pressure fluctuations, while variations in fuel supply pressure, plunger spring stiffness, and valve spring stiffness have minimal impact. Notably, the influence of outlet valve spring preload, inlet valve spring stiffness, and inlet valve body mass on rail pressure is nonlinear, with optimal values observed. Gray relational analysis further identifies inlet valve spring preload as having the highest correlation with rail pressure fluctuations (0.815), followed by inlet valve spring stiffness (0.625), with outlet valve spring preload (0.551) and stiffness (0.527) showing relatively lower correlations. This study provides valuable insights for optimizing the HPCR injection system design and contributes to advancements in diesel engine technology. Full article

Current trends in the development of technology are linked inextricably to the increasing level of automation in technological processes and production systems. In this regard, the development of systems for supplying working fluids with adjustable pumps that have high performance characteristics, an increased service life and low operating costs is an important scientific and technical task. A primary challenge in the development of such systems lies in achieving low fluid flow rates while maintaining stable operating characteristics. This challenge stems from the fact that currently available controlled hydraulic pumps exhibit either a high cost or suboptimal life and efficiency parameters. This work focuses on the development of a plunger hydraulic pump with a small working volume. A mathematical model has been developed to investigate the characteristics, optimize the design of this pump and further expand the size range of such pumps. The solution was implemented on a computer using the dynamic modelling environment MATLAB/Simulink. In order to verify the mathematical model’s adequacy, a plunger pump prototype was built and integrated with a test bench featuring a measurement system. The test results showed higher pump efficiency and a significant reduction in hydraulic losses. An analysis of the obtained data shows that the pump is characterized by increased efficiency due to optimal flow distribution and reduced internal leakage, which makes it promising for use in hydraulic systems requiring improved operating characteristics. The developed pump has more rational characteristics compared to existing alternatives for use in water supply systems for induction superheaters. The experimental external characteristics of the developed pump are 10% higher than the external characteristics of the ULKA EX5 pump selected as an analogue, and the pressure characteristics are 65% higher. It offers production costs that are several times lower compared to existing cam-type plunger or diaphragm pumps with oil sumps and precision valve mechanisms. Additionally, it has significantly better operating characteristics and a longer service life compared to vibrating plunger pumps. Full article

To fully exploit the rich state and fault information embedded in the acoustic signals of a hydraulic plunger pump, this paper proposes an intelligent diagnostic method based on sound signal analysis. First, acoustic signals were collected under normal and various fault conditions. Then, four distinct acoustic features—Mel Frequency Cepstral Coefficients (MFCCs), Inverse Mel Frequency Cepstral Coefficients (IMFCCs), Gammatone Frequency Cepstral Coefficients (GFCCs), and Linear Prediction Cepstral Coefficients (LPCCs)—were extracted and integrated into a novel hybrid cepstral feature called MIGLCCs. This fusion enhances the model’s ability to distinguish both high- and low-frequency characteristics, resist noise interference, and capture resonance peaks, achieving a complementary advantage. Finally, the MIGLCC feature set was input into a double layer long short-term memory (DLSTM) network to enable intelligent recognition of the hydraulic plunger pump’s operational states. The results indicate that the MIGLCC-DLSTM method achieved a diagnostic accuracy of 99.41% under test conditions. Validation on the CWRU bearing dataset and operational data from a high-pressure servo motor in a turbine system yielded overall recognition accuracies of 99.64% and 98.07%, respectively, demonstrating the robustness and broad application potential of the MIGLCC-DLSTM method. Full article

Based on the effect of damped shear deformation on energy dissipation, a new constrained damping base for a polymer injection platform deck is proposed to reduce the excessive vibrations caused when multiple plunger pumps are jointly operated. A model for analyzing the vibration response of an I-beam-constrained damping base for a polymer injection platform with multiple plunger pumps was established using Abaqus 6.14 software and compared with rigid base and traditional rubber vibration isolators in terms of its vibration isolation performance. Furthermore, the effects of the damping material’s loss factor, the thickness of the damping layer, and the number of expansion layers on the vibration isolation characteristics of the constrained damping base were explored. This study shows that, with an increase in the damping material’s loss factor, the thickness of the damping layer and the number of extended layers, the vibration isolation performance of the constrained damping base is gradually enhanced. When the damping material’s loss factor is 1.0, the thickness of the damping layer is 20 mm, and the number of extended layers is 3, the constrained damping base’s vibration damping effect is optimized, and its vibration isolation rate becomes as high as 46.63%, which can significantly reduce the vibration response of the polymer injection platform. Full article

Most energy-saving testing methods for plunger pumps use hydraulic motors. The loading test of coal mine emulsion pumps generally uses an overflow valve as the loading unit, which is characterized by high energy consumption. The coal mine emulsion pump uses emulsion as the transmission medium, and the viscosity and lubricity of the emulsion are much lower than those of hydraulic oil, which creates great difficulties in the development of high water-based hydraulic products. The nominal flow rate of the emulsion motor is much smaller than that of the emulsion pump, and there is no mature and reliable water-based flow control valve. Based on the above reasons, traditional energy-saving testing methods cannot be utilized for the testing process of emulsion pumps. The loading test of emulsion pumps generally uses an overflow valve as the loading unit, and during the testing process, all electrical energy is converted into internal energy, resulting in very high energy consumption. This article proposes an energy-saving testing system for emulsion pumps based on multiple emulsion motors in parallel. In order to solve the flow regulation problem of each parallel branch, a flow-intelligent control algorithm is proposed that utilizes the pressure difference flow characteristics of digital relief valves combined with artificial neural network predictive control. Firstly, the feasibility of the proposed system and method is theoretically verified through the analysis of the mathematical model of the digital relief valve. Secondly, further verification is carried out by establishing simulation and testing platforms. The simulation results show that the energy recovery efficiency of the system exceeds 53%. The experimental results show that the proposed testing system has a pressure control error of less than 1%, a flow control error of about 5%, and a maximum overshoot of about 9 L/min relative to the steady-state flow rate. The control accuracy and system stability are high. Full article

The fuel injection system heavily relies on the high-pressure fuel pump, which plays a critical role in its overall performance. The fuel pump plunger is subjected to high levels of stress and experiences irregular lubrication during dynamic loads, causing premature wear. In the industrial sector, laser surface micro-texturing has been utilized to reduce friction and enhance anti-wear properties, and its positive impact has been supported by both theoretical and experimental evidence. This article presents a method for determining the hydromechanical characteristics of plunger pairs under conditions of hydrodynamic friction. The microgeometry of friction surfaces was taken into account through the cavitation effect of the lubricating fluid, described by the modified Reynolds equation. Software was developed according to the proposed method. The developed software can be used to analyze the contacting surfaces of plunger pairs and evaluate their tribotechnical characteristics based on the microgeometry parameters of the friction surfaces. The article also discusses the impact of the microgeometry parameters on the quality criteria of the hydromechanical characteristics of the plunger pairs. Computational examples are given for the analysis of contacting surfaces of plunger pairs separated by a lubrication layer. The technical characteristics are evaluated depending on the parameters of the microgeometry of the roughness of the friction surfaces. The influence of the microgeometry parameters on the quality criteria of the hydromechanical characteristics of the plunger pairs is presented. Full article

Hydraulic water plunger pumps have come to be widely used in coal mining, seawater desalination, and oil exploitation due to their high output pressure and large flow characteristics. In a high-pressure large-flow plunger pump, the leakage of the annular channel of the plunger pair is an essential factor affecting volume efficiency. The axial pressure gradient exists in the fluid inside the annular channel, resulting in the plunger and plunger sleeve forming similar funnel-like shapes. Moreover, the characteristics of large diameter, high working pressure, and low fluid viscosity of the plunger pump will lead to the complicated flow of the annular channel. The influence of eccentricity and structural deformation on leakage is difficult to evaluate. Therefore, considering the deformation gradient and eccentricity of the plunger pair and the compressibility of the water, the deformation equations and leakage equations of the annular channel under the laminar and turbulent flow state are derived in this study. The eccentricity and leakage of the annular channel under different pressure conditions are measured using a built sealing test bench. It is proved that the discrepancy between the calculated model and the experimental results is less than 6% under different pressures, which effectively predicts the sealing performance of plunger pumps. The results show that under the laminar flow condition, the effects of eccentricity, structural deformation, and medium compressibility on leakage are 148%, 4.92%, and 0.92%, respectively. In turbulent conditions, they were 31%, 2.84%, and 1.19%, respectively. Besides, the reasonable material pairing of the plunger friction pair can reduce the variation of leakage due to structural deformation. Full article

The opposed-power reciprocating pump has the characteristics of high pressure, large flow, and high efficiency and energy saving. However, due to the special structure of the opposed-power reciprocating pump, existing theoretical methods cannot analyze its dynamic performance. Therefore, this paper proposes a method of analyzing the power end of the opposed-power reciprocating pump. Firstly, according to the working principle and structural characteristics of the traditional plunger pump, the novel and complex structure of the opposed-power reciprocating pump is analyzed by analogy, and the force analysis model of the crankshaft is established. The dynamic analysis model of the Matlab program is used to solve the dynamic load and section stress in the working process, and the variation law of crankshaft load is obtained. The 25 most critical working conditions are selected for analysis, and the most critical station and section of the crankshaft are obtained. With the connection between ANSYS Workbench and Solidworks, the model is imported into ANSYS Workbench, the load on the crank pin is loaded by APDL command flow, and the static analysis of the crankshaft is carried out to obtain the stress and strain of the crankshaft. Finally, the static and fatigue strength of the dangerous section is checked, and it is proven that the strength and stiffness of the crankshaft meet the design requirements. The results show that the dynamic analysis results of the crankshaft under critical working conditions are consistent with the finite element analysis, verifying the rationality of the method and providing a reference for the improvement and optimized design of the crankshaft of the opposed-power reciprocating pump. Full article

The mining emulsion pump is mainly used on a fully mechanized coal mining face, but it is rarely used on other occasions, so research on its loading test method is relatively limited. This paper proposes the application of a digital relief valve to the emulsion pump loading test. In addition, the small number of plungers in the emulsion pump will lead to large flow pulsation and pressure pulsation, and the nominal flow of different types of emulsion pumps varies greatly. These factors lead to the deficiency of a traditional PID control algorithm in control accuracy and efficiency. In order to improve control accuracy and efficiency, firstly, the influence of the flow rate of the tested pump and extension of the linear stepping motor shaft on the working pressure is studied. A backpropagation (BP) artificial neural network (ANN) model is used to fit a functional relationship between the three parameters. The flow rate of the tested pump and target pressure were provided as inputs to predict the extension of the linear stepping motor shaft, thereby realizing the remote intelligent control of the system pressure. Next, a BP ANN model is constructed, and its reliability is verified; the BP neural network algorithm and proportional-integral-derivative (PID) algorithm are compared through simulation. The simulation results show that the BP neural network algorithm has high control accuracy and small overshoot. Finally, two pumps with different flows are tested in a self-developed digital relief valve and test platform. The test results show that the proposed loading test method is intelligent and efficient, and it has high accuracy. Full article

This paper developed a 3D physical model of the hydraulic end of a high-pressure liquid hydrogen reciprocating pump to research the dynamic characteristics of the pump valve system. Based on dynamic mesh technology, we analyzed the coupling characteristics of pump valve and plunger motion and spool force considering the leakage model, closure model of valve gap, and compressibility of liquid hydrogen. Further, we analyzed the effect of the spring stiffness and preload force on the laws of motion of the pump valve. Finally, a liquid hydrogen pressurization test was conducted to revise the simulation model and verify the accuracy of the simulation. The results of the simulation and test show that the simulation method in this paper can simulate the liquid hydrogen pressurization process more accurately and obtain the motion law of the suction and discharge valves. Both the suction and discharge valves have an opening hysteresis angle of about 40°, and there is a strong coupling relationship between the spool motion and the piston motion and forces. The greater the preload force of the suction valve, the more obvious the oscillation effect of the suction valve. As the preload of the discharge valve increases, the opening hysteresis angle of the discharge valve increases significantly and the closing hysteresis angle decreases. The results of the research can provide some useful reference for the design of pump valves of high-pressure liquid hydrogen reciprocating pumps. Full article

To solve the problem of the low recovery rate of braking energy and the short driving range of electric vehicles, a novel mechanical-electric-hydraulic dynamic coupling drive system (MEH-DCDS) is proposed in this article. MEH-DCDS is a new power integration device that allows electric, mechanical, and hydraulic energy to be converted mutually. It comprises a swash plate plunger pump/motor and a permanent magnet synchronous motor. This article explains the structure and working principles of MEH-DCDS. We describe the dynamic characteristics of MEH-DCDS and analyze the pump and hydraulic motor in the MEH-DCDS hydraulic module. The simulation results show that the flow variation of the MEH-DCDS hydraulic module accords with the design concept of MEH-DCDS, and the pressure variation of high and low pressure accumulators also accords with the theoretical situation. The energy flow of Mechanical-Electric-Hydraulic Power Coupling Electric Vehicle (MEHPC-EV) under different working modes is expounded, and the mathematical model of its key components is established. Based on AMESim and Simulink, the article establishes a vehicle simulation dynamic model. The dynamic performance of MEHPC-EV in UDDS is analyzed by co-simulation. The simulation results show that the application of MEH-DCDS in electric vehicles is feasible. MEHPC-EV reduced battery energy consumption by 26.18% compared to EV. The research in this paper verifies the accuracy and superiority of the system, which has a significant reference value for the development and study of electric vehicles in the future. Full article

During oil fields operation, gas is extracted along with oil. In this article it is suggested to use jet pumps for utilization of the associated oil gas, burning of which causes environmental degradation and poses a potential threat to the human body. In order to determine the possibility of simultaneous application of a sucker-rod pump, which is driven by a rocking machine, and a jet pump (ejector) in the oil well, it is necessary to estimate the distribution of pressure along the borehole from the bottomhole to the mouth for two cases: when the well is operated only be the sucker-rod pump and while additional installation of the oil-gas jet pump above its dynamic level. For this purpose, commonly known methods of Poettman-Carpenter and Baksendel were used. In addition, the equations of high-pressure and low-pressure oil-gas jet pumps were obtained for the case, when the working stream of the jet pump is a gas-oil production mixture and the injected stream is a gas from the annulus of the well. The values which are included in the resulting equations are interrelated and can only be found in a certain sequence. Therefore, a special methodology has been developed for the practical usage of these equations in order to calculate the working parameters of a jet pump based on the given independent working parameters of the oil well. Using this methodology, which was implemented in computer programs, many operating parameters were calculated both for the well and for the jet pump itself (pressures, densities of working, injected and mixed flows, flow velocities and other parameters in control sections). According to the results of calculations, graphs were built that indicate a number of regularities during the oil well operation with such a jet pump. The main result of the performed research is a recommendation list on the choice of the oil-gas jet pump location inside the selected oil well and generalization of the principles for choosing the perfect location of such ejectors for other wells. The novelty of the proposed study lays in a systematic approach to rod pump and our patented ejector pump operation in the oil and chrome plating of pump parts. The result of scientific research is a sound method of determining the rational location of the ejector in the oil well and the calculation of its geometry, which will provide a complete selection of petroleum gas released into the annulus of the oil well. To ensure reliable operation of jet and plunger pumps in oil wells, it is proposed to use reinforcement of parts (bushings, plungers, rods, etc.) by electrochemical chromium plating in a flowing electrolyte. This has significantly increased the wear resistance and corrosion resistance of the operational surfaces of these parts and, accordingly, the service life of the pumps. Such measures will contribute to oil production intensification from wells and improve the environmental condition of oil fields. Full article

Reducing harmful emissions from exhaust gases and increasing energy efficiency are urgent tasks when designing reciprocating internal combustion engines. In this experimental work, the fuel system of a diesel locomotive engine operating on the Miller cycle is improved. The purpose of the study is to improve the environmental and economic indicators of diesel engines at minimal financial cost. The article provides an overview of the main research on improving fuel supply, mixing and combustion. The features of engine operation are also briefly described. Numerical simulation of the diesel engine operating cycle was performed before the bench tests. The experiments were performed on a full-size diesel engine with a power of 1200 kW. The measuring equipment and experimental technique are described in the article. The technical solutions that made it possible to improve the fuel supply are described. A new design for the high-pressure fuel pump drive is proposed. The optimal fuel injection advance angles are determined. An original design for the fuel pump plunger was developed. The proposed technical solutions made it possible to reduce fuel consumption by up to 3% (from 217.8 to 211.4 g/kW·h) and NOx emissions two-fold (from 19.4 to 8.8 g/kW·h). Full article

The paper is devoted to the analysis of the operating cycle of a high-pressure injection pump used in common rail systems. The investigation is based on experimental activities, and it is carried out in a novel pump set-up that allows measurements of the instantaneous pressure in the piston working chamber. A single plunger pump has been equipped with a piezo-resistive pressure transducer which allows for the measurement of the pressure signal during pump operation on a test rig. The paper describes the experimental set-up, the modified injection pump equipped with the pressure transducer, and the experimental tests carried out. Main results obtained using a standard commercial diesel fuel are discussed at first; secondly, the focus moves on to the use of an alternative fuel (biodiesel) whose features in terms of bulk modulus, viscosity, and density significantly differ from the reference fuel. Based on the characteristics of the pump operating cycle, the fuel suction and delivery processes are analyzed, pointing out how the used fuel type is reflected on them. The investigations are aimed at describing the operating characteristics of the pump, focusing the attention on those features playing a fundamental role on the global efficiency of the pump. The amplitudes of the pump-work phases, the ranges of pressure fluctuations, and the pressure-rise rates are quantified and reported, providing crucial indications for lumped parameter modeling and design activities in the field of current generation high-pressure injection pumps. Full article
