A methanol–steam reformer (MSR) can safely provide hydrogen-rich fuel for a fuel cell system. Since the operating temperature of an MSR is relatively low, convective heat transfer is typically used to provide thermal energy to the endothermic reactions in the MSR. In this study, the use of phase change heat transfer to provide thermal energy to the endothermic reactions was investigated, which enhanced the temperature uniformity longitudinally along the MSR. ANSYS Fluent^® software was used to investigate the performance of the reforming reactions. A comparative analysis using sensible heat and latent heat as the heat supply sources was performed. Using latent heat as a heat source achieved a lesser temperature drop than sensible heat that was under 5.29 K in the outer pipe. Moreover, a sensitivity analysis of methanol–steam-reforming reactions that use phase change heat transfer in terms of the carbon ratio, gas hourly velocity (for the inner and outer pipes of the MSR), inlet temperature (inner and outer pipes), reactor length, and operating pressure (inner pipe) was performed. When the phase change energy of water vapor is used, the wall temperature of the MSR is conveniently controlled and is uniformly distributed along the channel (standard deviation: 0.81 K). Accordingly, the methanol conversion rate of an MSR that uses phase change energy is ~4% higher than that of an MSR that employs convective heat transfer. Full article

The catalytic process of glycerol hydrogenolysis to produce 1,2-propandiol (1,2-PD) in the absence of external hydrogen addition has been investigated. The methanol present in the crude glycerol from a biodiesel production process is used to provide in situ hydrogen produced via methanol steam reforming for the glycerol hydrogenolysis process. This process can reduce the additional cost for the transportation and storage of molecular hydrogen and also reduce the safety risks related to using high hydrogen pressure. It was found that the introduction of Pd onto a Cu/MgO/Al₂O₃ catalyst significantly improved the glycerol conversion and 1,2-PD selectivity. The pseudo-first-order kinetic results suggested that the promoting effect of Pd is primarily attributed to the enhanced activity for the hydrogenation of acetol, which is the intermediate formed via glycerol dehydration. A 2⁷⁻³ fractional factorial design experiment was carried out to investigate the impacts of seven single factors and their binary effects on two responses, namely 1,2-PD selectivity and glycerol conversion. The results showed that the glycerol feed concentration has the most significant effect on the 1,2-PD selectivity, such that the 1,2-PD selectivity is lower if a more concentrated glycerol is used as the feedstock; stirring speed, inert gas pressure and water to methanol molar ratio have insignificant effects on the reaction system. The addition of Pd, higher temperature and higher catalyst loading are the essential factors in order to obtain a high selectivity of 1,2-PD and a high glycerol conversion. Full article

The production of pure hydrogen is one of the most important problems of the modern chemical industry. While high volume production of hydrogen is well under control, finding a cheap method of hydrogen production for small, mobile, or his receivers, such as fuel cells or hybrid cars, is still a problem. Potentially, a promising method for the generation of hydrogen can be oxy–steam-reforming of methanol process. It is a process that takes place at relatively low temperature and atmospheric pressure, which makes it possible to generate hydrogen directly where it is needed. It is a process that takes place at relatively low temperature and atmospheric pressure, which makes it possible to generate hydrogen directly where it is needed. This paper summarizes the current state of knowledge on the catalysts used for the production of hydrogen in the process of the oxy–steam-reforming of methanol (OSRM). The development of innovative energy generation technologies has intensified research related to the design of new catalysts that can be used in methanol-reforming reactions. This review shows the different pathways of the methanol-reforming reaction. The paper presents a comparison of commonly used copper-based catalysts with other catalytic systems for the production of H₂ via OSRM reaction. The surface mechanism of the oxy–steam-reforming of methanol and the kinetic model of the OSRM process are discussed. Full article

In this work, the electronic properties of the metal sites in cubic and monoclinic ZrO₂ supported Pd and PdCu catalysts have been investigated using CO as probe molecule in in-situ IR studies, and the surface composition of the outermost layers has been studied by APXPS (Ambient Pressure X-ray Photoemission Spectroscopy). The reaction products were followed by mass spectrometry, making it possible to relate the chemical properties of the catalysts under reaction conditions with their selectivity. Combining these techniques, it has been shown that the structure of the support (monoclinic or cubic ZrO₂) affects the metal dispersion, mobility, and reorganization of metal sites under methanol steam reforming (MSR) conditions, influencing the oxidation state of surface metal species, with important consequences in the catalytic activity. Correlating the mass spectra of the reaction products with these spectroscopic studies, it was possible to conclude that electropositive metal species play an imperative role for high CO₂ and H₂ selectivity in the MSR reaction (less CO formation). Full article

A methanol steam reformer converts methanol and steam into a hydrogen-rich mixture through an endothermic reaction. The methanol reformer is divided into a reaction section and a heat supply section that transfers thermal energy from 200 to 300 °C. This study presents the behavior of the methanol steam reforming reaction using the latent heat of the steam. A numerical analysis was separately conducted for two different regimes assuming constant heat flux conditions. A methanol steam reformer is an annulus structure that has a phase change heat transfer from an outer tube to an inner tube. Different from the steam zone temperature in the tube, the latent heat of steam condensation decreases, and there is a gradual between-wall temperature decrease along the longitudinal direction. Since the latent heat of steam condensation is very sensitive to the requested heat from the reformer, it is necessary to consider a refined design of a methanol reformer to obtain a large enough amount of heat by steam condensation. Full article

An air-independent propulsion system containing fuel cells is applied to improve the operational performance of underwater vehicles in an underwater environment. Fuel-reforming efficiently stores and supplies hydrogen required to operate fuel cells. In this study, the applicability of a fuel-reforming system using various fuels for underwater vehicles was analyzed by calculating the fuel and water consumptions, the amount of CO₂ generated as a byproduct, and the amount of water required to dissolve the CO₂ using aspen HYSYS (Aspen Technology, Inc., Bedford, MA, USA). In addition, the performance of the fuel-reforming system for methanol, which occupies the smallest volume in the system, was researched by analyzing performance indicators such as methanol conversion rate, hydrogen, yield and selectivity, and reforming efficiency under conditions at which pressure, temperature, steam-to-carbon ratio (SCR), and hydrogen separation efficiency vary. The highest reforming efficiency was 77.7–77.8% at 260 °C and 270 °C. At SCR 1.5, the reforming efficiency was the highest, which is 77.8%, and the CO₂ generation amount was the lowest at 1.46 kmol/h. At high separation efficiency, the reforming efficiency increased due to the reduction of reactants, and a rate at which energy is consumed for endothermic reactions also decreased, resulting in a lower CO₂ generation amount. Full article

Methanol as a hydrogen carrier can be reformed with steam over Cu/ZnO/Al₂O₃ catalysts. In this paper a comprehensive pseudo-homogenous model of a multi-tubular packed-bed reformer has been developed to investigate the impact of operating conditions and geometric parameters on its performance. A kinetic Langmuir-Hinshelwood model of the methanol steam reforming process was proposed. In addition to the kinetic model, the pressure drop and the mass and heat transfer phenomena along the reactor were taken into account. This model was verified by a dynamic model in the platform of ASPEN. The diffusion effect inside catalyst particles was also estimated and accounted for by the effectiveness factor. The simulation results showed axial temperature profiles in both tube and shell side with different operating conditions. Moreover, the lower flow rate of liquid fuel and higher inlet temperature of thermal air led to a lower concentration of residual methanol, but also a higher concentration of generated CO from the reformer exit. The choices of operating conditions were limited to ensure a tolerable concentration of methanol and CO in H₂-rich gas for feeding into a high temperature polymer electrolyte membrane fuel cell (HT-PEMFC) stack. With fixed catalyst load, the increase of tube number and decrease of tube diameter improved the methanol conversion, but also increased the CO concentration in reformed gas. In addition, increasing the number of baffle plates in the shell side increased the methanol conversion and the CO concentration. Full article

Production of green chemicals using a biomass derived feedstock is of current interest. Among the processes, the hydrogenolysis of glycerol to 1,2-propanediol (1,2-PD) using externally supplied molecular hydrogen has been studied quite extensively. The utilization of methanol present in crude glycerol from biodiesel production can avoid the additional cost for molecular hydrogen storage and transportation, as well as reduce the safety risks due to the high hydrogen pressure operation. Recently the hydrogenolysis of glycerol with a Cu/ZnO/Al₂O₃ catalyst using in situ hydrogen generated from methanol steam reforming in a liquid phase reaction has been reported. This paper focusses on the effect of added Ni on the activity of a Cu/ZnO/Al₂O₃ catalyst prepared by an oxalate gel-co-precipitation method for the hydrogenolysis of glycerol using methanol as a hydrogen source. It is found that Ni reduces the conversion of glycerol but improves the selectivity to 1,2-PD, while a higher conversion of methanol is observed. The promoting effect of Ni on the selectivity to 1,2-PD is attributed to the slower dehydration of glycerol to acetol coupled with a higher availability of in situ hydrogen produced from methanol steam reforming and the higher hydrogenation activity of Ni towards the intermediate acetol to produce 1,2-PD. Full article

The reforming of natural gas with steam and CO₂ is commonly referred to as mixed reforming and considered a promising route to utilize CO₂ in the production of synthetic fuels and base chemicals such as methanol. In the present study, the mixed reforming reaction is assessed regarding its potential to effectively utilize CO₂ in such processes based on simple thermodynamic models. Requirements for the mixed reforming reactions based on process considerations are defined. These are the avoidance of carbon formation in the reactor, high conversion of the valuable inlet streams CH₄ and CO₂ as well as a suitable syngas composition for subsequent synthesis. The syngas composition is evaluated based on the module $M=\left(z_{{\mathrm{H}}_2}-z_{{\mathrm{CO}}_2}\right)/\left(z_{{\mathrm{CO}}_2}+z_{\mathrm{CO}}\right),$ which should assume a value close to 2. A large number of different configurations regarding CO₂/H₂O/CH₄ at the reactor inlet, operating pressure and outlet temperature are simulated and evaluated according to the defined requirements. The results show that the actual potential of the mixed reforming reaction to utilize CO₂ as feedstock for fuels and methanol is limited to approximately 0.35 CO₂/CH₄, which is significantly lower than suggested in literature. At 900 °C and 7 bar at the reactor outlet, which is seen suitable for solar reforming, a ratio of H₂O/CH₄ of 1.4 can be set and the resulting value of M is 1.92 (CO₂/CO/H₂ = 0.07/0.4/1). Full article
