Search Results (21)

Extrusion-based printers have attracted much attention for their simplified printing process and broader material compatibility. Carbon fibers (CF), known for their excellent mechanical properties, are incorporated into polypropylene (PP) printing materials. This study presents a shear screw printer (SSP) with a modified screw design. The SSP generates torsional shear forces, enabling helical orientation of CFs within PP/CF composites. The study also compares the SSP’s performance with that of a conventional screw printer (CSP). PP/CF composite specimens containing 15% CF were printed at four different layup angles: 0°, 45°, 90°, and ±45° (net). The results show that combining CFs’ helical orientation with a net printing arrangement can effectively enhance tensile properties while reducing anisotropy. Furthermore, this approach can significantly mitigate warping in printed parts. Full article

Distributed Acoustic Sensing (DAS) has emerged as a groundbreaking technology in seismology, transforming fiber-optic cables into dense, cost-effective seismic monitoring arrays. DAS makes use of Rayleigh backscattering to detect and measure dynamic strain and vibrations over extended distances. It can operate using both pre-existing telecommunication networks and specially designed fibers. This review explores the principles of DAS, including Coherent Optical Time Domain Reflectometry (COTDR) and Phase-Sensitive OTDR (ϕ-OTDR), and discusses the role of optoelectronic interrogators in data acquisition. It examines recent advancements in fiber design, such as helically wound and engineered fibers, which improve DAS sensitivity, spatial resolution, and the signal-to-noise ratio (SNR). Additionally, innovations in deployment techniques include cemented borehole cables, flexible liners, and weighted surface coupling to further enhance mechanical coupling and data accuracy. This review also demonstrated the applications of DAS across earthquake detection, microseismic monitoring, reservoir characterization and monitoring, carbon storage sites, geothermal reservoirs, marine environments, and urban infrastructure surveillance. The study highlighted several challenges of DAS, including directional sensitivity limitations, vast data volumes, and calibration inconsistencies. It also addressed solutions to these problems, such as advances in signal processing, noise suppression techniques, and machine learning integration, which have improved real-time analysis and data interpretability, enabling DAS to compete with traditional seismic networks. Additionally, modeling approaches such as full waveform inversion and forward simulations provide valuable insights into subsurface dynamics and fracture monitoring. This review highlights DAS’s potential to revolutionize seismic monitoring through its scalability, cost-efficiency, and adaptability to diverse applications while identifying future research directions to address its limitations and expand its capabilities. Full article

An arc glow discharge device was used to prepare a helical carbon fiber skeleton with helical carbon fibers hooked to each other by spraying a hydrogen and ethanol mixture onto the iron wire substrate through the discharge area, using anhydrous ethanol as the carbon source. The samples were characterized by SEM, EDS, Raman and XPS. A growth mechanism of helical carbon fiber driven by C sp3 was proposed. The various growth modes of carbon fiber during the formation of carbon fiber skeleton were investigated. A ring appearance that indicated a change in the direction of carbon fiber growth was observed. And double helical carbon fiber was constructed from single helical carbon fiber in two ways. Super-large carbon fiber with a diameter of about 13 μm was observed, and it was speculated that this super-large carbon fiber is the backbone of the carbon fiber skeleton. The mechanical properties of the carbon fiber skeleton are isotropic. Full article

To improve the strength of the metal while maintaining good plasticity, helical fibers are added to the metal matrix. How to form helical fiber and control its parameters in the preparation process are urgent problems to be solved in the study of helical fiber-reinforced metal matrix composites. In this paper, the continuous casting process of helical fiber-reinforced metal matrix composites was proposed. To reduce the difficulty of the experiment, the formation process of helical fiber on metal matrix and the relationship between the continuous casting process parameters and helical shape fiber parameters were studied by preparing helical carbon fiber-reinforced lead matrix composites with a low-melting-point metal matrix. The results show that this process can produce helical fiber-reinforced metal matrix composite stably and continuously, and the helical shape parameters of the composite can be controlled by changing the process parameters of continuous casting. To further improve the practical application of this process, helical carbon fiber-reinforced aluminum matrix composites were prepared. The test result in terms of mechanical property shows that the tensile strength and elongation of the composite were improved. This indicates that the reinforced phase of the helical structure of the metal matrix composite has higher strength and toughness compared with the matrix metal. Full article

Being a difficult-to-cut material, Fiber Metal Laminates (FML) often pose challenges during conventional drilling and require judicious selection of machining parameters to ensure defect-free laminates that can serve reliably during their service lifetime. Helical milling is a promising technique for producing good-quality holes and is preferred over conventional drilling. The paper compares conventional drilling with the helical milling technique for producing holes in carbon fiber-reinforced aluminum laminates. The effect of machining parameters, such as cutting speed and axial feed, on the magnitude of cutting force and the machining temperature during conventional drilling as well as helical milling is studied. It was observed that the thrust force produced during machining reduces considerably during helical milling in comparison to conventional drilling at a constant axial feed rate. The highest machining temperature recorded for helical milling was much lower in comparison to the highest machining temperature measured during conventional drilling. The machining temperatures recorded during helical milling were well below the glass transition temperature of the epoxy used in carbon fiber prepreg, hence protecting the prepreg from thermal degradation during the hole-making process. The surface roughness of the holes produced by both techniques is measured, and the surface morphology of the drilled holes is analyzed using a scanning electron microscope. The surface roughness of the helical-milled holes was lower than that for holes produced by conventional drilling. Scanning electron microscope images provided insights into the interaction of the hole surface with the chips during the chip evacuation stage under different speeds and feed rates. The microhardness of the aluminum layers increased after processing holes using drilling and helical milling operations. The axial feed/axial pitch had minimal influence on the microhardness increase in comparison to the cutting speed. Full article

CFRP/Ti stacks composed of carbon fiber-reinforced plastic composites (CFRP) and titanium alloys (Ti) are widely used in aerospace fields. However, in the integrated hole-making process of CFRP/Ti stacks, the machining characteristics of various materials are significantly different, and constant machining parameters cannot simultaneously meet the high-quality machining requirements of two materials. In addition, errors exist between the actual thickness of each material layer and the theoretical value, which causes an impediment to the monitoring of the machining interface and the corresponding adjustment of parameters. An adaptive machining method for the helical milling of CFRP/Ti stacks based on interface identification is proposed in this paper. The machining characteristics of the pneumatic spindle and the interface state in the helical milling of CFRP/Ti stacks are analyzed using self-developed portable helical milling equipment, and a new algorithm for the real-time monitoring of the machining interface position and adaptive adjustment of the machining parameters according to the interface identification result is proposed. Helical milling experiments were carried out, the results show that the proposed method can effectively identify the position of the machining interface with good identification accuracy. Moreover, the proposed parameter-adaptive optimized machining method for CFRP/Ti stacks can significantly improve hole diameter accuracy and machining quality. Full article

Carbon fiber-reinforced aluminum laminates, known as CARALL, have wide applications in aircraft structures. However, numerous holes must be processed to assemble these structures, which is conventionally practiced through drilling. However, the drilling process exhibits certain limitations when utilized for hole-making in heterogeneous materials. In the recent past, helical milling has positioned itself as an alternative to the drilling process. However, helical milling performance examination during hole-making in CARALL is scant and needs further evaluation. The present study compares the milling process to the drilling process considering important performance indices, including cutting forces, surface roughness, chip morphology, machining temperature, and burr size. Additionally, microscopic characterization of the boreholes is performed to verify the presence of surface damage and delamination defects. Helical milling successfully lowered the thrust and radial forces and restrained the machining temperature below the levels attained via drilling. The diametrical deviation is higher at entry and lower at exit for both processes; however, helical milling produced holes with much higher accuracy. Helical milling developed smaller sized holes in comparison to drilling. Moreover, rougher surfaces due to the abrasion of continuous chips were observed in drilling, while a smoother finish was noted in helically milled holes. Based on the comprehensive comparative analysis, helical milling positions itself as an acceptable alternative to conventional drilling for machining fiber metal laminates. Full article

Carbon concrete is a new, promising class of materials in the construction industry. This corrosion-resistant reinforcement material leads to a reduction in the concrete cover required for medial shielding. This enables lean construction and the conservation of concrete and energy-intensive cement manufacturing. Bar-type reinforcement is essential for heavily loaded structures. The newly developed helix pultrusion is the first process capable of producing carbon fiber-reinforced polymer (CFRP) reinforcement bars with a topological surface in a single pultrusion process step, with fiber orientation tailored to the specific loads. The manufacturing feasibility and load-bearing capacity were thoroughly tested and compared with other design and process variants. Approaches to increase stiffness and strength while maintaining good concrete anchorage have been presented and fabricated. Tensile testing of the helical rebar variants with a 7.2 mm lead-bearing cross-section was conducted using adapted wedge grips with a 300 mm restraint length. The new helix geometry variants achieved, on average, 40% higher strengths and almost reached the values of the base material. Concrete pull-out tests were carried out to evaluate the bond properties. The helix contour design caused the bar to twist out of the concrete test specimen. Utilizing the Rilem beam test setup, the helical contour bars could also be tested. Compared with the original helix variant, the pull-out forces could be increased from 8.5 kN to up to 22.4 kN, i.e., by a factor of 2.5. It was thus possible to derive a preferred solution that is optimally suited for use in carbon concrete. Full article

Stretchable yarn/fiber electronics with conductive features are optimal components for different wearable devices. This paper presents the construction of coil structure-based carbon nanotube (CNT)/polymer fibers with adjustable piezoresistivity. The composite unit fiber is prepared by wrapping a conductive carbon CNT sheath onto an elastic spandex core. Owing to the helical coil structure, the resultant CNT/polymer composite fibers are highly stretchable (up to approximately 300%) without a noticeable electrical breakdown. More specifically, based on the difference in the coil index (which is the ratio of the coil diameter to the diameter of the fiber within the coil) according to the polymeric core fiber (spandex or nylon), the composite fiber can be used for two different applications (i.e., as strain sensors or supercapacitors), which are presented in this paper. The coiled CNT/spandex composite fiber sensor responds sensitively to tensile strain. The coiled CNT/nylon composite fiber can be employed as an elastic supercapacitor with excellent capacitance retention at 300% strain. Full article

Recycling carbon fibers (rCF) for reuse is one approach to improve the sustainability of CFRP. However, until now, recycled carbon fiber plastics (rCFRP) had limited composite properties due to the microgeometry of the fibers, which made it difficult to use in load-bearing components. The production of hybrid yarns from rCF and PA6 fibers allows the fibers to be aligned. The geometric properties of the yarn and the individual fibers influence the mechanical properties of the composite. An approach for the modeling and simulation of hybrid yarns consisting of recycled carbon fibers and thermoplastic fibers is presented. The yarn unit cell geometry is modeled in the form of a stochastic fiber network. The fiber trajectory is modeled in form of helical curves using the idealized yarn model of Hearle et al. The variability in the fiber geometry (e.g., length) is included in form of statistical distributions. An additional compaction step ensures a realistic composite geometry. The created model is validated geometrically and by comparison with tensile tests of manufactured composites. With the validated model, multiple parameter studies investigating the influence of fiber and yarn geometry are carried out. Full article

As a new machining method, ultrasonic-assisted bi-direction helical milling has obvious advantages in making holes on carbon fiber-reinforced plastics (CFRP). However, cutting edges of the flat-bottomed milling cutter are easy to wear, which may cause severe defects such as burrs and tears in the outlet of the hole. In order to improve the hole-making quality of CFRP, the gradual-removal reverse edge milling cutter was proposed and designed. The finite method models of reverse helical milling CFRP with the flat-bottomed reverse edge milling cutter and the gradual-removal reverse edge milling cutter under an ultrasonic vibration were established, and the comparative cutting experiments of the two cutters were carried out. By comparing the cutting performance of the two milling cutters under the condition of ultrasonic vibration assistance, the cutting mechanism of improving the hole wall quality by the gradual-removal reverse edge milling cutter was studied. The results showed that when the reverse cumulative cutting depth reached about 60 mm, compared with the flat-bottomed reverse edge milling cutter, the gradual-removal reverse edge milling cutter transferred part of the cutting task of the peripheral edge to the end edge, and the wear of the reverse peripheral edges which directly affects the hole quality was effectively alleviated. This mechanism made the cutting state of the peripheral edge dominated by shear failure, which led to the significant improvement of the quality at the outlet of the hole. Full article

In order to promote the industrialization of the large deformation technology of carbon fiber composites, this paper studies a new method of forming of helical carbon fiber reinforced aluminum matrix composite. The purpose is to solve the problem of large deformation of carbon fiber with low elongation and metal matrix with high elongation. By introducing carbon fiber with helical space structure into the aluminum matrix, the helical carbon fiber reinforced aluminum matrix composites were prepared and the subsequent drawing deformation was carried out. Here we systematically studied the large plastic deformation behavior of helical carbon fiber reinforced aluminum matrix composite via a combination of numerical simulations and experiments, and analyzed the deformation law and stress of helical carbon fiber in the deformation process. We found that the plastic deformation of the composite causes local stress concentration around the helical carbon fiber, and the helical carbon fiber will move synchronously with the aluminum matrix during the deformation, and receive the pressure from the aluminum matrix. Second, the best process parameters obtained from the simulation, that is, the drawing die angle α = 7°, when five-pass drawing experiments were carried out, the total deformation reached 58%, and the average elongation of a single pass was 18.9%. The experimental show carbon fiber reinforced aluminum matrix composite with helical space structure can achieve large deformation and high strength. The experimental and simulation are in general agreement, which verifies the correctness of the carbon fiber helical structure model. Full article

The development of advanced composite materials has taken center stage because of its advantages over traditional materials. Recently, carbon-based advanced additives have shown promising results in the development of advanced polymer composites. The inter- and intra-laminar fracture toughness in modes I and II, along with the thermal and electrical conductivities, were investigated. The HMWCNTs/epoxy composite was prepared using a multi-dispersion method, followed by uniform coating at the mid-layers of the CF/E prepregs interface using the spray coating technique. Analysis methods, such as double cantilever beam (DCB) and end notched flexure (ENF) tests, were carried out to study the mode I and II fracture toughness. The surface morphology of the composite was analyzed using field emission scanning electron microscopy (FESEM). The DCB test showed that the fracture toughness of the 0.2 wt.% and 0.4 wt.% HMWCNT composite laminates was improved by 39.15% and 115.05%, respectively, compared with the control sample. Furthermore, the ENF test showed that the mode II interlaminar fracture toughness for the composite laminate increased by 50.88% and 190%, respectively. The FESEM morphology results confirmed the HMWCNTs bridging at the fracture zones of the CF/E composite and the improved interlaminar fracture toughness. The thermogravimetric analysis (TGA) results demonstrated a strong intermolecular bonding between the epoxy and HMWCNTs, resulting in an improved thermal stability. Moreover, the differential scanning calorimetry (DSC) results confirmed that the addition of HMWCNT shifted the T_g to a higher temperature. An electrical conductivity study demonstrated that a higher CNT concentration in the composite laminate resulted in a higher conductivity improvement. This study confirmed that the demonstrated dispersion technique could create composite laminates with a strong interfacial bond interaction between the epoxy and HMWCNT, and thus improve their properties. Full article

Reducing the fingerprint of infrastructure has become and is likely to continue to be at the forefront of stakeholders’ interests, including engineers and researchers. It necessary that future buildings produce minimal environmental impact during construction and remain durable for as long as practicably possible. The use of basalt fiber-reinforced polymer (BFRP) bars as a replacement for carbon steel is reviewed in this article by examining the literature from the past two decades with an emphasis on flexural strength, serviceability, and durability. The provisions of selected design and construction guides for flexural members are presented, compared, and discussed. The bond of BFRP bars to the surrounding concrete was reportedly superior to carbon steel when BFRP was helically wrapped and sand coated. Experimental studies confirmed that a bond coefficient k_b = 0.8, which is superior to carbon steel, may be assumed for sand-coated BFRP ribbed bars that are helically wrapped, as opposed to the conservative value of 1.4 suggested by ACI440.1R-15. Code-based models overestimate the cracking load for BFRP-reinforced beams, but they underestimate the ultimate load. Exposure to an alkaline environment at temperatures as high as 60 °C caused a limited reduction in bond strength of BFRP. The durability of BFRP bars is influenced by the type of resin and sizing used to produce the bars. Full article

The principal objective of the work is to compare among carbon-glass filament wound epoxy matrix hybrid composites with a different fiber ratio made by robotized winding processes and optimize the geometry suitable for the Rocket Propelled Grenade Launcher. ANSYS based finite element analysis was used to predict the axial as well as radial compression behavior. Experimental samples were developed by a robot-controlled filament winding process that was incorporated with continuous resin impregnation. The experimental samples were evaluated for the corresponding compressional properties. Filament wound tubular composite structures were developed by changing the sequence of stacking of hoop layers and helical layers, and also by changing the angle of wind of the helical layers while keeping the sequence constant. The samples were developed from carbon and glass filaments with different carbon proportions (0%, 25%, 50%, 75%, and 100%) and impregnated with epoxy resin. The compressional properties of the tubular composites that were prepared by filament winding were compared with the predicted axial and radial compressional properties from computational modelling using the finite element model. A very high correlation and relatively small prediction error was obtained. Full article
