Non-impregnated small-pore graphite (NSPG), which has a compact microstructure and is used in molten salt reactors (MSRs), was prepared by a novel process. The pore diameter of NSPG was reduced to ~800 nm. The irradiation evaluation of NSPG was carried out by 7 MeV Xe²⁶⁺ ion irradiation. The microstructural changes of NSPG were investigated with IG-110 as a comparison. The graphitization degree of NSPG was higher than that of IG-110, though it was not subjected to an impregnation process. Under low-dose ion irradiation (<2.5 dpa), the microscopic morphology of the NSPG changes in a small magnitude, and the lamellar structure of graphite remains within the scale of more than a dozen nanometers, which exhibits a better resistance to irradiation. With the increase in irradiation dose, the accumulation of defects leads the graphite toward amorphization, which shows consistency with IG-110. This study provides an efficient and low-cost method for the preparation of graphite for MSR, and investigates the damage behavior of graphite, which is of great significance in accumulating data for the development of MSR nuclear graphite and the optimal design of graphite materials. Full article

Solid-solid phase-change materials have great potential for developing compact and low-cost thermal storage systems. The solid-state nature of these materials enables the design of systems analogous to those based on natural rocks but with an extraordinarily higher energy density. In this scenario, the evaluation and improvement of the mechanical and thermophysical properties of these solid-solid PCMs are key to exploiting their full potential. In this study, LiNaSO₄-based composites, comprising porous MgO and expanded graphite (EG) as the dispersed phases and LiNaSO₄ as the matrix, have been prepared with the aim of enhancing the thermophysical and mechanical properties of LiNaSO₄. The characteristic structure of MgO and the high degree of crystallinity of the EG600 confer on the LiNaSO₄ sample mechanical stability, which leads to an increase in the Young’s modulus (almost three times higher) compared to the pure LiNaSO₄ sample. These materials are proposed as a suitable candidate for thermal energy storage applications at high temperatures (400–550 °C). The addition of 5 wt.% of MgO or 5% of EG had a minor influence on the solid-solid phase change temperature and enthalpy; however, other thermal properties such as thermal conductivity or specific heat capacity were increased, extending the scope of PCMs use. Full article

The use of interleaving material with viscoelastic properties is one of the most effective solutions to improve the damping capacity of carbon fibre-reinforced polymer (CFRP) laminates. Improving composite damping without threatening mechanical performance is challenging and the use of nanomaterials should lead to the target. In this paper, the effect of a nanostructured interlayer based on graphite nanoplatelets (GNPs) on the damping capacity and fracture toughness of CFRP laminates has been investigated. High-content GNP/epoxy (70 wt/30 wt) coating was sprayed on the surface of CF/epoxy prepregs at two different contents (10 and 40 g/m²) and incorporated at the middle plane of a CFRP laminate. The effect of the GNP areal weights on the viscoelastic and mechanical behaviour of the laminates is investigated. Coupons with low GNP content showed a 25% increase in damping capacity with a trivial reduction in the storage modulus. Moreover, a reduction in interlaminar shear strength (ILSS) and fracture toughness (both mode I and mode II) was observed. The GNP alignment and degree of compaction reached during the process were found to be key parameters on material performances. By increasing the GNP content and compaction, a mitigation on the fracture drop was achieved (−15%). Full article

This paper investigates the use of shop-floor ferrous scrap that contains iron ore as a raw material for the purpose of making steel products through an in situ carbothermic reduction. The technique of powder metallurgy (PM) was used for the purpose of studying reduction followed by densification during sintering. Two sources of iron oxide—ferrous grinding-sludge powder and iron ore—and three sources of the carbonaceous material—graphite, charcoal, and carbon black—were considered. The carbonaceous material was added to the iron oxide after calculating the stoichiometric carbon requirement for facilitating both direct reduction and direct–indirect reduction. This involves a simultaneous change in weight and volume. During sintering, an in situ reduction of the iron oxide takes place that often results in severe volumetric changes. The test results revealed the degree of reduction (DOR) and degree of densification (DOD) of the grinding sludge (GS) to be 15% and 45% higher, respectively, than that of iron ore (IO). This is essentially due to the presence of distinct iron-oxide phases coupled with a greater amenability to the occurrence of carbothermic reduction. Indirect reduction also took place and contributed to improving the degree of reduction (DOR) and degree of densification (DOD) of the final products. Overall, the shape stability of the sintered grinding-sludge (GS) powder was found to be optimized when parameter settings of graphite (from 25% in excess to 50% in excess) were added, a compaction pressure of 1050 MPa was applied, and a sintering temperature of 1200 °C was employed. Hence, ferrous scrap can be chosen as direct reduced iron for the manufacture of steel and can also be used for cost-efficient and eco-friendly structural components with a marginal compromise on both the purity and strength of the ferrous products. Full article

To endow synergistically epoxy resin (EP) with excellent fire resistance and high optical transparency, a nitrogen-rich DOPO-based derivate (named as FATP) was synthesized and incorporated into EP. It showed that the incorporation of the FATP reduced the fire hazard of the EP, as demonstrated by the fact that the EP/4% FATP blends gained a UL-94 V-0 rating and an LOI value of 35%, with the lowest values of the THR (86.7 MJ/m²), the PHRR (1059.3 kW/m²), and the TSP (89.6 MJ/m²). The presence of the FATP also reduced the thermal stability and the crosslinking density whilst improving the curing reaction and the storage modulus of the EP/FATP blends. The TG-FTIR spectra showed that •HPO/•PO free radicals and some nonflammable gases (HN₃ and NH₃) were produced during the pyrolysis, and the characterization (SEM, Raman spectroscopy, and XPS) of char residues confirmed that the FATP facilitated the formation of continuous and compact carbon layers of greater graphitization degree. It was thus concluded that the FATP played the flame-retardant roles in both the gas and condensed phases. Furthermore, the FREPs kept almost identical transparency as the pristine EP, and mechanical properties were also slightly enhanced. The FREPs presented in this work show promising applications in the fields of advanced optical technology. Full article

In recent years, high-Si ductile cast irons (3–6% Si) have begun to be used more and more in the automotive and maritime industries, but also in wind energy technology and mechanical engineering. Si-alloyed ferrite has high strength, hardness and oxidation and corrosion resistance, but it has low ductility, toughness and thermal conductivity, with graphite as an important influencing factor. In this study, 4.5% Si uninoculated ductile iron solidified in thin wall castings (up to 15 mm section size) via a permanent (metal) mold versus a sand mold, was evaluated. Solidification in a metal mold led to small size, higher graphite particles (less dependent on the section size). The graphite particles’ real perimeter was 3–5% higher than the convex perimeter, while the values of these parameters were 41–43% higher in the sand mold. Increasing the casting section size led to an increased graphite perimeter, with it being much higher for sand mold. The graphite particles’ shape factors, involving the maximum and minimum size, were at a lower level for metal mold solidification, while by involving the difference between P_r and P_c, is higher for the metal mold. The shape factor, including the graphite area and maximum size, had higher values in the metal mold, sustaining a higher compactness degree of graphite particles and a higher nodularity regarding metal mold solidification (75.5% versus 67.4%). The higher was due to the graphite compactness degree level (shape factor increasing from 0.50 up to 0.80), while the lower was due to the graphite nodularity for both the metal mold (39.1% versus 88.5%) and the sand mold (32.3% versus 83.1%). The difference between the metal mold and sand mold as the average graphite nodularity increased favored the metal mold. Full article

A piperazine phosphate doped with Mn²⁺ (HP-Mn), as a new char-forming agent for intumescent flame retardant systems (IFR), was designed and synthesized using 1-hydroxy ethylidene-1,1-diphosphonic acid, piperazine, and manganese acetate tetrahydrate as raw materials. The effect of HP-Mn and ammonium polyphosphate (APP) on the fire safety and thermal stability of polypropylene (PP) was investigated. The results showed that the combined incorporation of 25 wt.% APP/HP-Mn at a ratio of 1:1 endowed the flame retardant PP (PP6) composite with the limiting oxygen index (LOI) of 30.7% and UL-94 V-0 rating. In comparison with the pure PP, the peak heat release rate (PHRR), the total heat release (THR), and the smoke production rate (PSPR) of the PP6 were reduced by 74%, 30%, and 70%, respectively. SEM and Raman analysis of the char residues demonstrated that the Mn²⁺ displayed a catalytic cross-linking charring ability to form a continuous and compact carbon layer with a high degree of graphitization, which can effectively improve the flame retardancy of PP/APP composites. A possible flame-retardant mechanism was proposed to reveal the synergistic effect between APP and HP-Mn. Full article

This paper presents the design, development and evaluation of a unique non-contact instrumentation system that can accurately measure the interface displacement between two rigid components in six degrees of freedom. The system was developed to allow measurement of the relative displacements between interfaces within a stacked column of brick-like components, with an accuracy of 0.05 mm and 0.1 degrees. The columns comprised up to 14 components, with each component being a scale model of a graphite brick within an Advanced Gas-cooled Reactor core. A set of 585 of these columns makes up the Multi Layer Array, which was designed to investigate the response of the reactor core to seismic inputs, with excitation levels up to 1 g from 0 to 100 Hz. The nature of the application required a compact and robust design capable of accurately recording fully coupled motion in all six degrees of freedom during dynamic testing. The novel design implemented 12 Hall effect sensors with a calibration procedure based on system identification techniques. The measurement uncertainty was ±0.050 mm for displacement and ±0.052 degrees for rotation, and the system can tolerate loss of data from two sensors with the uncertainly increasing to only 0.061 mm in translation and 0.088 degrees in rotation. The system has been deployed in a research programme that has enabled EDF to present seismic safety cases to the Office for Nuclear Regulation, resulting in life extension approvals for several reactors. The measurement system developed could be readily applied to other situations where the imposed level of stress at the interface causes negligible material strain, and accurate non-contact six-degree-of-freedom interface measurement is required. Full article

Previous experiments pointed out that the deviation using a sphere as reference of graphite particles is noticeably increased by Si-alloying, with inoculation as a possible beneficial effect. The main objective of the present work is to evaluate the effects of commercial inoculants (Ca/Ca, Ba/Ca, RE-FeSi alloys) on 4.5%Si ductile iron, thin wall castings. FeSiMgRE treated iron (0.032–0.036%Mg_res) is in-mold inoculated (a four-work-positions pattern). A complex chemical composition is obtained for each inoculation variant. Wedge casting W₃ (ASTM A 367) is used to evaluate structure characteristics at different wall thickness (3–15 mm). Minimum and maximum size, area, nodule count, and representative graphite shape factors are evaluated. Roundness (including A_G and F_max) at 0.6–0.8 level illustrates the common formation of slightly irregular spheroidal graphite (Type V, ISO 945). Ca, RE-FeSi inoculation leads to the highest level of real perimeter and, consequently, to the lowest level of Sphericity. Ca, Ba-FeSi inoculation appears to be better than simple Ca-FeSi for improving graphite parameters, while Ca, RE-FeSi has the lowest beneficial effect, especially as it negatively affects the compactness degree of graphite particles. A two-step liquid treatment using RE-bearing FeSiCaMg master alloy and Ca, Ba-FeSi inoculant appears to be a solution to improve graphite parameters for high-Si ductile irons solidified in thin wall castings. Full article

In this study, a flame-retardant additive with 9,10-dihydro-9-oxa-10-phosphaphenanthrene-10-oxide (DOPO) groups denoted DSD was successfully synthesized from DOPO, 4,4′-diaminodiphenyl sulfone (DDS), and salicylaldehyde. The chemical structure of DSD was characterized by FTIR–ATR, NMR, and elemental analysis. DSD was used as an amine curing agent, and the transparent, tensile strength-enhanced epoxy resins named EP–DSD were prepared via thermal curing reactions among the diglycidyl ether of bisphenol A (DGEBA), 4,4′-diaminodiphenylmethane (DDM), and DSD. The flame-retardancy of composites was studied by the limiting oxygen index (LOI) and UL-94 test. The LOI values of EP–DSD composites increased from 30.7% for a content of 3 wt % to 35.4% for a content of 9 wt %. When the content of DSD reached 6 wt %, a V-0 rating under the UL-94 vertical test was achieved. SEM photographs of char residues after the UL-94 test indicate that an intumescent and tight char layer with a porous structure inside was formed. The TGA results revealed that EP–DSD thermosets decomposed ahead of time. The graphitization degree of the residual chars was also investigated by laser Raman spectroscopy. The measurement of tensile strength at breaking point shows that the loading of DSD increases the tensile strength of epoxy thermosets. Py-GC/MS analysis shows the presence of phosphorus fragments released during EP–DSD thermal decomposition, which could act as free radical inhibitors in the gas phase. Owing to the promotion of the formation of intumescent and compact char residues in the condensed phase and nonflammable phosphorus fragments formed from the decomposition of DOPO groups, EP–DSD composites displayed obvious flame-retardancy. Full article

Lignin can be a candidate as a charring agent applied in halogen-free flame retardant polymers, and incorporation of silicon and nitrogen elements in lignin can benefit to enhancing its thermal stability and charring ability. In the present work, wheat straw alkali lignin (Lig) was modified to incorporate silicon and nitrogen elements by γ-divinyl-3-aminopropyltriethoxysilane, and the modified lignin (CLig) was combined with ammonium polyphosphate (APP) as intumescent flame retardant to be applied in poly(Lactic acid) (PLA). The flame retardancy, combustion behavior and thermal stability of PLA composites were studied by the limited oxygen index (LOI), vertical burning testing (UL-94), cone calorimetry testing (CCT) and thermogravimetric analysis (TGA), respectively. The results showed a significant synergistic effect between CLig and APP in flame retarded PLA (PLA/APP/CLig) occured, and the PLA/APP/CLig had better flame retardancy. CCT data analysis revealed that CLig and APP largely reduced the peak heat release rate (PHRR) and total heat release rate (THR) of PLA, indicating their effectiveness in decreasing the combustion of PLA. TGA results exhibited that APP and CLig improved the thermal stability of PLA at high temperature. The analysis of morphology and structure of residual char indicated that a continuous, compact and intumescent char layer on the material surface formed during firing, and had higher graphitization degree. Mechanical properties data showed that PLA/APP/CLig had higher tensile strength as well as elongation at break. Full article

Two halogen-free inorganic flame retardants, ammonium polyphosphate (APP) and aluminum hydroxide (ATH) were added to wood-flour/polypropylene composites (WPCs) at different APP to ATH mass ratios (APP/ATH ratios), with a constant total loading of 30 wt % (30% by mass). Water soaking tests indicated a low hygroscopicity and/or solubility of ATH as compared to APP. Mechanical property tests showed that the flexural properties were not significantly affected by the APP/ATH ratio, while the impact strength appeared to increase with the increasing ATH/APP ratio. Cone calorimetry indicated that APP appeared to be more effective than ATH in reducing the peak of heat release rate (PHRR). However, when compared to the neat WPCs, total smoke release decreased with the addition of ATH but increased with the addition of APP. Noticeably, WPCs containing the combination of 20 wt % APP and 10 wt % ATH (WPC/APP-20/ATH-10) showed the lowest PHRR and total heat release in all of the formulations. WPCs combustion residues were analyzed by scanning electron microscopy, laser Raman spectroscopy, and Fourier transform infrared spectroscopy (FTIR). Thermogravimetric analysis coupled with FTIR spectroscopy was used to identify the organic volatiles that were produced during the thermal decomposition of WPCs. WPC/APP-20/ATH-10 showed the most compact carbonaceous residue with the highest degree of graphitization. Full article
