This study presents a design and optimization methodology to enhance the power density and efficiency of wound field synchronous machines (WFSMs) by selectively applying grain-oriented electrical steel (GOES). Unlike conventional non-grain-oriented electrical steel (NOES), GOES exhibits significantly lower core loss along its rolling direction, making it suitable for regions with predominantly alternating magnetic fields. Based on magnetic field analysis, four machine configurations were investigated, differing in the placement of GOES within stator and rotor teeth. Finite element analysis (FEA) was employed to compare electromagnetic performance across the configurations. Subsequently, a multi-objective optimization was conducted using Latin Hypercube Sampling, meta-modeling, and a genetic algorithm to maximize power density and efficiency while minimizing torque ripple. The optimized WFSM achieved a 13.97% increase in power density and a 1.0% improvement in efficiency compared to the baseline NOES model. These results demonstrate the feasibility of applying GOES in rotating machines to reduce core loss and improve overall performance, offering a viable alternative to rare-earth permanent magnet machines in xEV applications. Full article

Grain-oriented electrical steel (GOES) has been used for many years for application in transformed cores due to its excellent magnetic properties. Magnetic properties are strongly influenced by obtaining a texture with a certain orientation (110) [001] for BCC structure. This is related to the easy direction of magnetization [001]. So far, the main research has been focused on obtaining a strong texture in the last stages of the process. The aim of the present study was to additionally trace textural changes for a slab after the continuous casting (CC) process and for a sheet after the hot rolling process. The scope of such an analysis has not been conducted before. With regard to the state after continuous casting (CC), the texture was related to measurements of the anisotropy of Barkhausen magnetic noises and the macrostructure of the slab. Based on the X-ray diffraction examinations that compared the texture intensity calculated from the texture coefficient of the slab, the hot rolled steel and the final product of grain-oriented electrical steel contained 3.1% of Si. The studies performed with the material taken from three different production steps showed high differences in the values of textural intensity indicating the occurrence of a crystallization texture, especially in the area of the columnar crystal zone; textural weakness after the hot rolling process and high texturing in the final product for textural components corresponding to the desired Goss texture. Full article

Solid-state transformer (SST) is an emerging technology that integrates with transformer power electronics converters and control. The most noticeable advantages of SST are the size and weight reduction compared with low-frequency transformers. Since this device is used in many devices such as smart grids, traction systems, systems with renewable energy sources (RESs) and electric vehicle charging devices, it is important to build a high-efficiency device at a low cost. The article evaluates a medium frequency transformer (SST) operating at a frequency of 500 Hz to 6000 Hz with coils wound with aluminum foil or Litz windings and of a grain-oriented electrical steel (GOES) core. The calculations were made using the 3D field method using the numerical finite element method, and the results were compared with the tests of the real model. The measurement method based on the Fourier analysis of real signals was used for the research. Full article

This paper focuses on the evolution of the microstructure in a grain-oriented electrical steel (GOES) thin strip after casting. After solidification, the microstructure consisted of delta-ferrite. A small fraction of austenite was formed during the cooling of the thin strip in the two-phase region (gamma+delta). Fine Cr₂CuS₄ particles precipitated in the ferrite and along the delta/gamma interfaces. Laths of primary Widmanstätten austenite (WA) nucleated directly on the high-angle delta-ferrite grain boundaries. The formation of WA laths in both adjacent ferritic grains resulted in a zig-zag shape of delta-ferrite grain boundaries due to their local rotation during austenite nucleation. Based on the EBSD results, a mechanism of the formation of the zig-zag grain boundaries has been proposed. Besides the Widmanstätten morphology, austenite also formed as films along the delta-ferrite grain boundaries. Sulfide precipitation along the delta/gamma interfaces made it possible to prove that austenite decomposition upon a drop in temperature was initiated by the formation of epitaxial ferrite. Further cooling brought the decay of austenite to either pearlite or a mixture of plate martensite and some retained austenite. Full article

Nowadays, energy shortages and environmental pollution have received a lot of attention, which makes the electrification of transportation systems an inevitable trend. As the core part of an electrical driving system, the electrical machine faces the extreme challenge of keeping high power density and high efficiency output under complex workin g conditions. The development and research of new soft magnetic materials has an important impact to solve the current bottleneck problems of electrical machines. In this paper, the variation trend of magnetic properties of ultra-thin grain-oriented silicon steel electrical steel (GOES) under thermal-mechanical-electric-magnetic fields is studied, and the possibility of its application in motors is explored. The magnetic properties of grain-oriented silicon steel samples under different conditions were measured by the Epstein frame method and self-built multi-physical field device. It is verified that the magnetic properties of grain-oriented silicon steel selected within 30° magnetization deviation angle are better than non-grain-oriented silicon steel. The magnetic properties of the same ultra-thin grain-oriented silicon steel as ordinary non-oriented silicon steel deteriorate with the increase in frequency. Different from conventional non-grain-oriented silicon steel, its magnetic properties will deteriorate with the increase in temperature. Under the stress of 30 Mpa, the magnetic properties of the grain-oriented silicon steel are the best; under the coupling of multiple physical fields, the change trend of magnetic properties of grain-oriented silicon steel is similar to that of single physical field, but the specific quantitative values are different. Furthermore, the application of grain-oriented silicon steel in interior permanent magnet synchronous motor (IPM) for electric vehicles is explored. Through a precise oriented silicon steel motor model, it is proved that the magnetic flux density of stator teeth increases by 2.2%, the electromagnetic torque of motor increases by 2.18%, and the peak efficiency increases by 1% after using grain-oriented silicon steel. In this paper, through the investigation of the characteristics of grain-oriented silicon steel, it is preliminarily verified that grain-oriented silicon steel has a great application prospect in the drive motor (IPM) of electric vehicles, and it is an effective means to break the bottleneck of current motor design. Full article

Ceramic insulation coating (glass film) is an important constituent of grain-oriented electrical steel (GOES) designed for use in transformers. Within the scope of this study, the glass film was obtained by means of interaction between the surface of GOES containing 0.5 wt. % Cu and a heat-resistant MgO coating during annealing up to 1100 °C in the 75%H₂ + 25%N₂ atmosphere. The structure of glass film was analyzed using X-ray diffraction, glow-discharge optical emission spectroscopy, scanning probe microscopy, scanning electron microscopy, differential scanning calorimetry and thermodynamic calculations. After annealing, the glass film contained the following phases: crystalline (MgFe)₂SiO₄ and amorphous Fe-based solid solutions. The multi-stage mechanism of the glass film formation on GOES surface during high-temperature annealing was determined. Full article

The paper proposes a simple structure of high-power solid-state transformers (SSTs) able to control the energy flow in critical lines of the medium-voltage (20 kV) distribution grid. With an increasing number of renewable intermittent sources connected at the nodes of the meshed distribution grid and a reduced number of nodes connected to large power plants, the distribution grid stability is more and more difficult to achieve. Control of the energy flow in critical lines can improve the stability of the distribution grid. This control can be provided by the proposed high-power SSTs operating a 20 kV with powers over 10 MW. This function is difficult to achieve with standard SST technologies that operate at high frequencies. These devices are made with expensive magnetic materials (amorphous or nanocrystalline cores) and a limited power by SST cells. The required total power is reached by assembling many SST cells. On the other hand, existing SST designs are mainly aimed at reducing the equipment’s size and it is difficult to design small objects able to operate at high voltages. The authors propose to use cores made with grain-oriented electrical steel (GOES) thin strips assembled in wound cores. Experimental results obtained, with GOES wound cores, show that the core losses are lower for a square voltage than for a sine one. This counterintuitive result is explained with an analytical calculus of eddy currents and confirmed by a non-linear time-stepping simulation. Therefore, simple converter structures, operating with rectangular voltages and low switching losses, are the best solutions. Experimental results also show that the core losses decrease with temperature. Consequently, high-power SST cells can be made with transformers whose GOES cores are hotter than coils for reducing core losses and keeping copper losses at low levels. The paper proposes an appropriate transformer mechanical structure that avoids any contact between the hot GOES wound core and the winding, with a specific cooling system and thermal insulation of the hot GOES wound core. The proposed design makes it possible to build SST cells over 1MW and full SSTs over 10 MW at moderate costs. Full article
