Remote sensing from unoccupied aerial systems (UASs) has witnessed exponential growth. The increasing use of imaging spectroscopy sensors and RGB cameras on UAS platforms demands accurate, cross-comparable multi-sensor data. Inherent errors during image capture or processing can introduce spatial offsets, diminishing spatial accuracy and hindering cross-comparison and change detection analysis. To address this, we demonstrate the use of an optical flow algorithm, eFOLKI, for co-registering imagery from two pushbroom imaging spectroscopy sensors (VNIR and NIR/SWIR) to an RGB orthomosaic. Our study focuses on two ecologically diverse vegetative sites in Tasmania, Australia. Both sites are structurally complex, posing challenging datasets for co-registration algorithms with initial georectification spatial errors of up to 9 m planimetrically. The optical flow co-registration significantly improved the spatial accuracy of the imaging spectroscopy relative to the RGB orthomosaic. After co-registration, spatial alignment errors were greatly improved, with RMSE and MAE values of less than 13 cm for the higher-spatial-resolution dataset and less than 33 cm for the lower resolution dataset, corresponding to only 2–4 pixels in both cases. These results demonstrate the efficacy of optical flow co-registration in reducing spatial discrepancies between multi-sensor UAS datasets, enhancing accuracy and alignment to enable robust environmental monitoring. Full article

Remote-sensing images of high spatial resolution (HSR) are valuable sources of fine-grained spatial information for various applications, such as urban surveys and governance. There is continuing research on positional errors in remote-sensing images and their impacts in geoprocessing and applications. This paper explores the combined use of multi-point geostatistics (MPS), machine learning—in particular, generalized additive modeling (GAM)—and computer-image correlation for characterizing positional errors in images—in particular, HSR images. These methods are employed because of the merits of MPS in being flexible for non-parametric and joint simulation of positional errors in X and Y coordinates, the merits of GAM in being capable of handling non-stationarity in-positional errors through error de-trending, and the merits of computer-image correlation in being cost-effective in furnishing the training data (TD) required in MPS. Procedurally, image correlation is applied to identify homologous image points in reference-test image pairs to extract image displacements automatically in constructing TD. To cope with the complexity of urban scenes and the unavailability of truly orthorectified images, visual screening is performed to clean the raw displacement data to create quality-enhanced TD, while manual digitization is used to obtain reference sample data, including conditioning data (CD), for MPS and test data for performance evaluation. GAM is used to decompose CD and TD into trends and residuals. With CD and TD both de-trended, the direct sampling (DS) algorithm for MPS is applied to simulate residuals over a simulation grid (SG) at 80 m spatial resolution. With the realizations of residuals and, hence, positional errors generated in this way, the means, standard deviation, and cross correlation in bivariate positional errors at SG nodes are computed. The simulated error fields are also used to generate equal-probable realizations of vertices that define some road centerlines (RCLs), selected for this research through interpolation over the aforementioned simulated error fields, leading to error metrics for the RCLs and for the lengths of some RCL segments. The enhanced georectification of the RCLs is facilitated through error correction. A case study based in Shanghai municipality, China, was carried out, using HSR images as part of generalized point clouds that were developed. The experiment results confirmed that by using the proposed methods, spatially explicit positional-error metrics, including means, standard deviation, and cross correlation, can be quantified flexibly, with those in the selected RCLs and the lengths of some RCL segments derived easily through error propagation. The reference positions of these RCLs were obtained through error correction. The positional accuracy gains achieved by the proposed methods were found to be comparable with those achieved by conventional image georectification, in which the CD were used as image-georectification control data. The proposed methods are valuable not only for uncertainty-informed image geolocation and analysis, but also for integrated geoinformation processing. Full article

Hyperspectral sensors mounted on unmanned aerial vehicles (UAV) offer the prospect of high-resolution multi-temporal spectral analysis for a range of remote-sensing applications. However, although accurate onboard navigation sensors track the moment-to-moment pose of the UAV in flight, geometric distortions are introduced into the scanned data sets. Consequently, considerable time-consuming (user/manual) post-processing rectification effort is generally required to retrieve geometrically accurate mosaics of the hyperspectral data cubes. Moreover, due to the line-scan nature of many hyperspectral sensors and their intrinsic inability to exploit structure from motion (SfM), only 2D mosaics are generally created. To address this, we propose a fast, automated and computationally robust georectification and mosaicking technique that generates 3D hyperspectral point clouds. The technique first morphologically and geometrically examines (and, if possible, repairs) poorly constructed individual hyperspectral cubes before aligning these cubes into swaths. The luminance of each individual cube is estimated and normalised, prior to being integrated into a swath of images. The hyperspectral swaths are co-registered to a targeted element of a luminance-normalised orthomosaic obtained using a standard red–green–blue (RGB) camera and SfM. To avoid computationally intensive image processing operations such as 2D convolutions, key elements of the orthomosaic are identified using pixel masks, pixel index manipulation and nearest neighbour searches. Maximally stable extremal regions (MSER) and speeded-up robust feature (SURF) extraction are then combined with maximum likelihood sample consensus (MLESAC) feature matching to generate the best geometric transformation model for each swath. This geometrically transforms and merges individual pushbroom scanlines into a single spatially continuous hyperspectral mosaic; and this georectified 2D hyperspectral mosaic is then converted into a 3D hyperspectral point cloud by aligning the hyperspectral mosaic with the RGB point cloud used to create the orthomosaic obtained using SfM. A high spatial accuracy is demonstrated. Hyperspectral mosaics with a 5 cm spatial resolution were mosaicked with root mean square positional accuracies of 0.42 m. The technique was tested on five scenes comprising two types of landscape. The entire process, which is coded in MATLAB, takes around twenty minutes to process data sets covering around 30 Ha at a 5 cm resolution on a laptop with 32 GB RAM and an Intel^® Core i7-8850H CPU running at 2.60 GHz. Full article

The rapid development of unmanned aerial vehicles (UAVs), miniature hyperspectral imagers, and relevant instruments has facilitated the transition of UAV-borne hyperspectral imaging systems from concept to reality. Given the merits and demerits of existing similar UAV hyperspectral systems, we presented a lightweight, integrated solution for hyperspectral imaging systems including a data acquisition and processing unit. A pushbroom hyperspectral imager was selected owing to its superior radiometric performance. The imager was combined with a stabilizing gimbal and global-positioning system combined with an inertial measurement unit (GPS/IMU) system to form the image acquisition system. The postprocessing software included the radiance transform, surface reflectance computation, geometric referencing, and mosaic functions. The geometric distortion of the image was further significantly decreased by a postgeometric referencing software unit; this used an improved method suitable for UAV pushbroom images and showed more robust performance when compared with current methods. Two typical experiments, one of which included the case in which the stabilizing gimbal failed to function, demonstrated the stable performance of the acquisition system and data processing system. The result shows that the relative georectification accuracy of images between the adjacent flight lines was on the order of 0.7–1.5 m and 2.7–13.1 m for cases with spatial resolutions of 5.5 cm and 32.4 cm, respectively. Full article

Fixed video camera systems are consistently prone to importune motions over time due to either thermal effects or mechanical factors. Even subtle displacements are mostly overlooked or ignored, although they can lead to large geo-rectification errors. This paper describes a simple and efficient method to stabilize an either continuous or sub-sampled image sequence based on feature matching and sub-pixel cross-correlation techniques. The method requires the presence and identification of different land-sub-image regions containing static recognizable features, such as corners or salient points, referred to as keypoints. A Canny edge detector ( $CED$ ) is used to locate and extract the boundaries of the features. Keypoints are matched against themselves after computing their two-dimensional displacement with respect to a reference frame. Pairs of keypoints are subsequently used as control points to fit a geometric transformation in order to align the whole frame with the reference image. The stabilization method is applied to five years of daily images collected from a three-camera permanent video system located at Anglet Beach in southwestern France. Azimuth, tilt, and roll deviations are computed for each camera. The three cameras showed motions on a wide range of time scales, with a prominent annual signal in azimuth and tilt deviation. Camera movement amplitude reached up to 10 pixels in azimuth, 30 pixels in tilt, and 0.4° in roll, together with a quasi-steady counter-clockwise trend over the five-year time series. Moreover, camera viewing angle deviations were found to induce large rectification errors of up to 400 m at a distance of 2.5 km from the camera. The mean shoreline apparent position was also affected by an approximately 10–20 m bias during the 2013/2014 outstanding winter period. The stabilization semi-automatic method successfully corrects camera geometry for fixed video monitoring systems and is able to process at least 90% of the frames without user assistance. The use of the $CED$ greatly improves the performance of the cross-correlation algorithm by making it more robust against contrast and brightness variations between frames. The method appears as a promising tool for other coastal imaging applications such as removal of undesired high-frequency movements of cameras equipped in unmanned aerial vehicles (UAVs). Full article

Hyperspectral systems integrated on unmanned aerial vehicles (UAV) provide unique opportunities to conduct high-resolution multitemporal spectral analysis for diverse applications. However, additional time-consuming rectification efforts in postprocessing are routinely required, since geometric distortions can be introduced due to UAV movements during flight, even if navigation/motion sensors are used to track the position of each scan. Part of the challenge in obtaining high-quality imagery relates to the lack of a fast processing workflow that can retrieve geometrically accurate mosaics while optimizing the ground data collection efforts. To address this problem, we explored a computationally robust automated georectification and mosaicking methodology. It operates effectively in a parallel computing environment and evaluates results against a number of high-spatial-resolution datasets (mm to cm resolution) collected using a push-broom sensor and an associated RGB frame-based camera. The methodology estimates the luminance of the hyperspectral swaths and coregisters these against a luminance RGB-based orthophoto. The procedure includes an improved coregistration strategy by integrating the Speeded-Up Robust Features (SURF) algorithm, with the Maximum Likelihood Estimator Sample Consensus (MLESAC) approach. SURF identifies common features between each swath and the RGB-orthomosaic, while MLESAC fits the best geometric transformation model to the retrieved matches. Individual scanlines are then geometrically transformed and merged into a single spatially continuous mosaic reaching high positional accuracies only with a few number of ground control points (GCPs). The capacity of the workflow to achieve high spatial accuracy was demonstrated by examining statistical metrics such as RMSE, MAE, and the relative positional accuracy at 95% confidence level. Comparison against a user-generated georectification demonstrates that the automated approach speeds up the coregistration process by 85%. Full article

Changes in the dynamics of glaciers must be assessed, as they are important for sea level changes. Glacier velocity is the most important parameter used in glacier dynamics studies. Various image matching techniques, which are implemented in different domains, have been utilized to estimate the surface velocity of glaciers, since the first use of remote sensing technology. In this study, we derived the precise velocity of the Polar Record Glacier (PRG), east Antarctica, in recent years, using optical remote sensing. The secondary objective of the study was to comparatively test the accurate geospatial tools for velocity estimation. The study was first conducted on a single image pair, and four different tools were used for the estimation of the glacier velocity, which are the COSI-Corr (Co-registration of Optically Sensed Images and Correlation) tool in ENVI (Exelis Visual Information Solutions), the IMGRAFT (Image GeoRectification and Feature Tracking) in MATLAB, the IMCORR (Image correlation) feature tracking tool in SAGA-GIS, and the image correlation software CIAS. After evaluation of the four feature tracking tools, COSI-Corr yielded a pixel-level velocity with both magnitude and directions, while IMGRAFT provided the glacier speed without the directions. On the other hand, IMCORR yielded good results with respect to magnitude and directions of the glacier velocity, but the pixel-wise magnitude was not produced. CIAS also provided closely bundled velocity products without pixel-wise velocity. COSI-Corr and IMGRAFT were found to be the best of the four tools, and COSI-Corr is recommended for further studies to estimate the velocity of the PRG. Full article

Hyperspectral imagery has proven its potential in many research applications, especially in the field of environmental sciences. Currently, hyperspectral imaging is generally performed by satellite or aircraft platforms, but mini-UAV (Unmanned Aerial Vehicle) platforms (<20 kg) are now emerging. On such platforms, payload restrictions are critical, so sensors must be selected according to stringent specifications. This article presents the integration of a light pushbroom hyperspectral sensor onboard a multirotor UAV, which we have called Hyper-DRELIO (Hyperspectral DRone for Environmental and LIttoral Observations). This article depicts the system design: the UAV platform, the imaging module, the navigation module, and the interfacing between the different elements. Pushbroom sensors offer a better combination of spatial and spectral resolution than full-frame cameras. Nevertheless, data georectification has to be performed line by line, the quality of direct georeferencing being limited by mechanical stability, good timing accuracy, and the resolution and accuracy of the proprioceptive sensors. A georegistration procedure is proposed for geometrical pre-processing of hyperspectral data. The specifications of Hyper-DRELIO surveys are described through two examples of surveys above coastal or inland waters, with different flight altitudes. This system can collect hyperspectral data in VNIR (Visible and Near InfraRed) domain above small study sites (up to about 4 ha) with both high spatial resolution (<10 cm) and high spectral resolution (1.85 nm) and with georectification accuracy on the order of 1 to 2 m. Full article

Analyzing temporal series of satellite data for regional scale studies demand high accuracy in calibration and precise geo-rectification at higher spatial resolution. The Advanced Very High Resolution Radiometer (AVHRR) sensor aboard the National Oceanic and Atmospheric Administration (NOAA) series of satellites provide daily observations for the last 30 years at a nominal resolution of 1.1 km at nadir. However, complexities due to on-board malfunctions and orbital drifts with the earlier missions hinder the usage of these images at their original resolution. In this study, we developed a new method using multiple open source tools which can read level 1B radiances, apply solar and thermal calibration to the channels, remove bow-tie effects on wider zenith angles, correct for clock drifts on earlier images and perform precise geo-rectification by automated generation and filtering of ground control points using a feature matching technique. The entire workflow is reproducible and extendable to any other geographical location. We developed a time series of brightness temperature maps from AVHRR local area coverage images covering the sub alpine lakes of Northern Italy at 1 km resolution (1986–2014; 28 years). For the validation of derived brightness temperatures, we extracted Lake Surface Water Temperature (LSWT) for Lake Garda in Northern Italy and performed inter-platform (NOAA-x vs. NOAA-y) and cross-platform (NOAA-x vs. MODIS/ATSR/AATSR) comparisons. The MAE calculated over available same day observations between the pairs—NOAA-12/14, NOAA-17/18 and NOAA-18/19 are 1.18 K, 0.67 K, 0.35 K, respectively. Similarly, for cross-platform pairs, the MAE varied between 0.5 to 1.5 K. The validation of LSWT from various NOAA instruments with in-situ data shows high accuracy with mean R² and RMSE of 0.97 and 0.91 K respectively. Full article
