To address the complex structure of existing rod mechanism exoskeleton robots and the difficulty in solving the motion trajectory of multi−rod mechanisms, an exoskeleton knee robot with a differential non−circular gear–pentarod mechanism is designed based on non−circular gears with arbitrary transmission ratios to constrain the degrees of freedom of the R-para-rod mechanism. In this study, the kinematic model of a non-circular gear–five−rod mechanism is established based on motion mapping theory by obtaining the normal motion positions of the human lower limb. An optimization design software for the non-circular gear–five−rod mechanism is developed using the MATLAB 2018b visualization platform, with the non−circular active gear as the sole input variable. A set of ideal parameters is obtained through parameter adjustment and optimal parameter selection, and the corresponding trajectories are compared with human trajectories. The three−dimensional model of the mechanism is established according to the obtained parameters, and the motion simulation of the non−circular gear–five−bar mechanism demonstrates that the mechanism can better reproduce the expected human knee joint motion posture, meeting the working requirements of an exoskeleton knee robot. Full article

Animal joint motion is a combination of rotation and translational motion, which brings high stability, high energy utilization, and other advantages. At present, the hinge joint is widely used in the legged robot. The simple motion characteristic of the hinge joint rotating around the fixed axis limits the improvement of the robot’s motion performance. In this paper, by imitating the knee joint of a kangaroo, we propose a new bionic geared five-bar knee joint mechanism to improve the energy utilization rate of the legged robot and reduce the required driving power. Firstly, based on image processing technology, the trajectory curve of the instantaneous center of rotation (ICR) of the kangaroo knee joint was quickly obtained. Then, the bionic knee joint was designed by the single-degree-of-freedom geared five-bar mechanism and the parameters for each part of the mechanism were optimized. Finally, based on the inverted pendulum model and the Newton–Euler recursive method, the dynamics model of the single leg of the robot in the landing stage was established, and the influence of the designed bionic knee joint and hinge joint on the robot’s motion performance was compared and analyzed. The proposed bionic geared five-bar knee joint mechanism can more closely track the given trajectory of the total center of mass motion, has abundant motion characteristics, and can effectively reduce the power demand and energy consumption of the robot knee actuators under the high-speed running and jumping gait. Full article

A geared five-bar transplanting mechanism can meet the agronomic requirements for the vertical planting of Salvia miltiorrhiza. In order to improve the planting quality, this paper analyzed the structural composition and working principle of a transplanting mechanism and established an interactive human–computer auxiliary interface through a kinematic model. With the aid of an auxiliary interface, by taking the parameters of the transplanting mechanism as the factors and the parameters of the absolute trajectory and posture for the planter as the index, an orthogonal experimental design with five factors and five levels was carried out, and the optimal combination of the parameters of the mechanism was obtained. According to the optimal combination of the parameters of the mechanism, the structure of the transplanting mechanism was designed, a geared five-bar transplanting mechanism for Salvia miltiorrhiza prototype was developed, and a test bench system was built. The actual trajectory of the endpoint for the transplanting mechanism’s prototype was obtained using high-speed photographic technology. The bench test results showed that according to a comparison of the actual trajectory, the posture for the planter and the theoretical analysis results were basically consistent, which verified the correctness, rationality, and consistency of the optimal design for the mechanism. Full article

At present, the research objects of rigid-body guidance synthesis are mostly limited to pure linkages, and there is little research on the combined mechanisms of gears or cams and linkages. In order to expand the research objects of rigid-body guidance and improve the kinematic mapping theory, this paper proposes a rigid-body guidance method of noncircular gear-five-bar combined mechanisms. A noncircular gear-five-bar mechanism can be regarded as a combination of a 2R (two revolute joints) open chain, a 3R (three revolute joints) open chain and a pair of noncircular gears. Firstly, the circle point curves and circle center point curves of the 2R and 3R open chains are obtained by using kinematic mapping, and they are formed into a double crank five-bar linkage. Secondly, the B-spline curve is used to fit the rotation angle relationship of the gear pair to obtain the pitch curves of noncircular gears. Finally, aiming at correcting patients’ abnormal gait, a noncircular gear-five-bar exoskeleton knee joint rehabilitation device is designed based on four task poses. The prototype is developed and the wear test is carried out. The test results verify the correctness of the rigid-body guidance synthesis method and the effectiveness of rehabilitation training. Full article

To support the inspections of different contact walls (rough and smooth), a novel type of wall-climbing robot was proposed. Its design embodied a new gear transmission system arm and an adherence mechanism inspired by cicadas and geckos. The actuating structure consisted of a five-bar link and a gear transmission for the arm stretching, which was driven by the servos. The linkers and gears formed the palm of this robot for climbing on a line. Moreover, the robot’s adherence method for the rough surfaces used bionic spine materials inspired by the cicada. For smooth surface, a bionic adhesion material was proposed inspired by the gecko. To assess the adherence mechanism of the cicada and gecko, the electron microscope images of the palm of the cicada and gecko were obtained by an electron microscope. The 3D printing technology and photolithography technology were utilized to manufacture the robot’s structures. The adherence force experiments demonstrated the bionic spines and bionic materials achieved good climbing on cloth, stones, and glass surfaces. Furthermore, a new gait for the robot was designed to ensure its stability. The dynamic characteristics of the robot’s gear transmission were obtained. Full article

To improve the multi-speed adaptability of the powered prosthetic knee, this paper presented a speed-adaptive neural network control based on a powered geared five-bar (GFB) prosthetic knee. The GFB prosthetic knee is actuated via a cylindrical cam-based nonlinear series elastic actuator that can provide the desired actuation for level-ground walking, and its attitude measurement is realized by two inertial sensors and one load cell on the prosthetic knee. To improve the performance of the control system, the motor control and the attitude measurement of the GFB prosthetic knee are run in parallel. The BP neural network uses input data from only the GFB prosthetic knee, and is trained by natural and artificially modified various gait patterns of different able-bodied subjects. To realize the speed-adaptive control, the prosthetic knee speed and gait cycle percentage are identified by the Gaussian mixture model-based gait classifier. Specific knee motion control instructions are generated by matching the neural network predicted gait percentage with the ideal walking gait. Habitual and variable speed level-ground walking experiments are conducted via an able-bodied subject, and the experimental results show that the neural network control system can handle both self-selected walking and variable speed walking with high adaptability. Full article
