Search Results (10)

Dewatering gas wells typically exhibit a high gas–liquid ratio, making tapered electrical submersible pump (ESP) systems a common choice. However, the flow rate within the pump varies significantly along its length, and production parameters fluctuate considerably across different stages of operation for a gas reservoir. Traditional ESP sizing methods typically consider one single operating case and one single pump model. In contrast, tapered ESP systems require the designer to manually select and combine pump models, stage numbers, and operating frequencies based largely on experience. This process can be cumbersome and time-consuming. To address the limitations of existing ESP sizing methods, this study develops a computational program for ESP operation parameters stage by stage and generates extensive training data. A fully connected neural network (FCNN) based on the backpropagation (BP) algorithm is then trained on these data. The model can predict key parameters such as gas volume fraction (GVF) and flow rate along the pump, operating frequency, and total pump efficiency, using input data such as fluid parameters at the pump’s intake and discharge, as well as pump stage numbers and performance curve data. The model demonstrates high accuracy, with a mean absolute error (MAE) of 0.3431, a mean squared error (MSE) of 0.3231, and a coefficient of determination (R²) of 0.9991. By integrating a wellbore two-phase flow model and leveraging industry experience in pump sizing, a hybrid model for automatic ESP sizing under multiple working conditions is proposed, with the objective of maximizing pump efficiency. This model enables optimal pump sizing, calculates the operating frequency corresponding to given working cases, significantly reduces the workload of designers, and enhances the overall design outcomes. Full article

Due to changes in the German government’s energy concept, the amount of gypsum produced in flue gas desulfurisation plants (FGD gypsum) will fall from 5 million tons per year to 1 million tons or less by 2038 at the latest. As of 2016, FGD gypsum accounts for 55% of German gypsum mix. The resulting raw material gap must be closed through innovative recycling concepts, such as the processing of existing mine dumps. The process development aims to achieve a calcium sulfate dihydrate content of 85% and a reduction in the stockpile volume by 50%. The main components of the stockpiles are calcium sulfate in the form of gypsum stone as well as clay minerals and organic matter. Successful laboratory tests were transferred to a pilot scale jigging machine with dewatering screening. The process water is circulated throughout the entire process. The gypsum content in the heavy fraction is 76% when measured with ICP OES and 87% when measured via thermogravimetric methods. Furthermore, pilot-scale dry screening on the stockpile took place, and up to 1500 tons of material could be processed. Due to fluctuating weather conditions, the screening quality was subject to significant variations. Under optimal conditions, up to 60% of the feed could be recovered as gypsum stone; however, the screening process was nearly impossible during rain; therefore, a process combination of screening and a downstream jigging machine is recommended. Full article

This article furnishes a brief review of the geochemistry of waters produced during coal bed methane and shale gas exploration. Stable deuterium and oxygen isotopes of produced waters, as well as the stable carbon isotope of dissolved inorganic carbon in these waters, are influenced by groundwater recharge, methanogenic pathways, the mixing of formation water with saline water, water–rock interactions, well completion, contamination from water from adjacent litho-units, and coal bed dewatering, among many others. Apart from the isotopic fingerprints, significant attention should be given to the chemistry of produced waters. These waters comprise natural saturated and aromatic organic functionalities, metals, radioisotopes, salts, inorganic ions, and synthetic chemicals introduced during hydraulic fracturing. Hence, to circumvent their adverse environmental effects, produced waters are treated with several technologies, like electro-coagulation, media filtration, the coupling of chemical precipitation and dissolved air flotation, electrochemical Fe⁺²/HClO oxidation, membrane distillation coupled with the walnut shell filtration, etc. Although produced water treatment incurs high costs, some of these techniques are economically feasible and sustain unconventional hydrocarbon exploitation. Full article

The Electrical Submersible Pump (ESP) systems were deployed in two gas wells for the dewatering of the gas reservoir. However, problems, such as the failure to start up the ESP, and changes in reservoir parameters occurred during the production. For the first problem, the well start-up operation records indicate that the ESP’s gas locking happened. To avoid this, an optimization method of the well start-up procedure for the ESP well with a check valve was correspondingly proposed, which can solve the problem without any workovers. Secondly, based on the working characteristics of the ESP and the nodal analysis method, a set of optimization methods for the operating parameters of ESPs were introduced to achieve the inflow and outflow balance. For one well, the original ESP system was planned to be installed after hydraulic fracturing. Traditionally, the ESP operating parameters were designed based on the production rate. However, in this case, the production rate and the ESP operating frequency were designed simultaneously to maximize the pump efficiency. Full article

The operational costs of wastewater treatment plants (WWTPs) are mainly driven by electric power consumption, making the energy-efficient operation an all-time present target for engineers and operators. A well known approach to reduce the demand for purchased electricity is the operation of an anaerobic sludge stabilisation process. Although anaerobic digesters make it possible to recover large quantities of energy-rich methane gas, additional strategies are required to handle the increased internal return flow of nitrogen, which arises with the sludge dewatering effluent (SDE). SDE treatment increases the oxygen demand and in turn the energy required for aeration. In this study, different SDE treatment processes were compared with regard to the treatment in mainstream, sidestream nitritation, as well as nitritation combined with anammox for two-stage and single-stage WWTPs. Although SDE treatment in sidestream nitritation was found to have no effect on the energy demand of single-stage WWTPs, this concept allows the treatment capacity in the activated sludge tank to be raised, while contributing to a high nitrogen removal under carbon limitation. In contrast, SDE sidestream treatment showed great potential for saving energy at two-stage WWTPs, whereby sidestream nitritation and the further treatment in the first stage was found to be the most efficient concept, with a savings of approx. 11% of the aeration energy. Full article

The water-and-waste sector has shown a marked interest in innovative management practices for dewatered sludge. The need to manage increased sludge volumes at rising disposal costs, coupled with the recognition of the potential for on-site energy production, have been the key drivers for this recent appeal. With the current political view supporting the development of a renewable-gas industry in Portugal, renewable gases are considered an attractive solution for dewatered-sludge valorization. Moreover, investment in renewable-gas supply chains would help the industry to mature to a level at which the technology and market are rapidly established. Recognizing this interest, dewatered-sludge gasification was selected as a possible valorization pathway, with the potential for hydrogen and bio-SNG production, as well as decentralized heat and power. This document identifies the market opportunities for the establishment of sewage-sludge gasification in Portugal. The analysis starts with a brief overview of the Portuguese water-and-waste sector, and a description of the current status of the renewable-gas markets. Finally, the dewatered-sludge amounts are quantified, and the potential for energy and renewable-gas production is estimated to support the interest in wastewater management in advanced processes, and to pave the way for future feasibility studies. Full article

Municipal landfills generate a significant amount of high-energy biogas, which can be used as a renewable gaseous fuel. However, it is necessary to improve the quality of this biogas due to the presence of various chemical compounds. The most common pollutants in landfill biogas include volatile compounds of silicon, sulphur, phosphorus and chlorine. The aforementioned elements, as well as other metals, were found both in the deposits and in the engine oil. The paper presents detailed characteristics of the solid residues formed in selected parts of gas engines powered by landfill biogas. Its elemental composition and morphology were investigated in order to determine the structure and influence of these deposits. In order to better understand the observed features, selected analyses were also conducted for biogas, engine oil and the condensate generated during biogas dewatering. It was found that the content of individual elements in samples collected from the same part of the gas engine but sourced from various landfills vary. The occurrence of elements in deposits, e.g., Mg, Zn, P and Cr, depends on the location of sampling sites and the type of engine. It was also observed that the deposits formed in parts that come into contact with both biogas and engine oil contain Ca or Zn, which can be related to biogas pollutants as well as different oil additives. The presence of Al, Fe, Cu, Cr, Sn or Pb in selected motor oil samples can be explained by the penetration of metallic abrasives, which confirms the abrasive properties of the formed deposits. The analysis of the characteristic deposits may contribute to the selection of an appropriate landfill biogas purification technology, thus reducing the operating costs of energy cogeneration systems. Finally, we highlight challenges for biogas purification processes and anticipate the direction of future work. Full article

Microalgae have attracted significant attention worldwide as one of the most promising feedstock fossil fuel alternatives. However, there are a few challenges for algal fuels to compete with fossil fuels that need to be addressed. Therefore, this study reviews the R&D status of microalgae-based polyculture and biocrude oil production, along with wastewater treatment. Mixotrophic algae are free to some extent from light restrictions using organic matter and have the ability to grow well even in deep water-depth cultivation. It is proposed that integrating the mixotrophic microalgae polyculture and wastewater treatment process is the most promising and harmonizing means to simultaneously increase capacities of microalgae biomass production and wastewater treatment with a low land footprint and high robustness to perturbations. A large amount of mixotrophic algae biomass is harvested, concentrated, and dewatered by combining highly efficient sedimentation through flocculation and energy efficient filtration, which reduce the carbon footprint for algae fuel production and coincide with the subsequent hydrothermal liquefaction (HTL) conversion. HTL products are obtained with a relatively low carbon footprint and separated into biocrude oil, solid, aqueous, and gas fractions. Algae biomass feedstock-based HTL conversion has a high biocrude oil yield and quality available for existing oil refineries; it also has a bioavailability of the recycled nitrogen and phosphorus from the aqueous phase of algae community HTL. The HTL biocrude oil represents higher sustainability than conventional liquid fuels and other biofuels for the combination of greenhouse gas (GHG) and energy return on investment (EROI). Deep water-depth polyculture of mixotrophic microalgae using sewage has a high potential to produce sustainable biocrude oil within the land area of existing sewage treatment plants in Japan to fulfill imported crude oil. Full article

Effective flocculation and dewatering of mineral processing streams containing clays are microstructure dependent in clay-water systems. Initial clay flocculation is crucial in the design and for the development of a new methodology of gas exploitation. Microstructural engineering of clay aggregates using covalent cations and Keggin macromolecules have been monitored using the new state of the art Transmission X-ray Microscope (TXM) with 60 nm tomography resolution installed in a Taiwanese synchrotron. The 3-D reconstructions from TXM images show complex aggregation structures in montmorillonite aqueous suspensions after treatment with Na⁺, Ca²⁺ and Al₁₃ Keggin macromolecules. Na-montmorillonite displays elongated, parallel, well-orientated and closed-void cellular networks, 0.5–3 µm in diameter. After treatment by covalent cations, the coagulated structure displays much smaller, randomly orientated and openly connected cells, 300–600 nm in diameter. The average distances measured between montmorillonite sheets was around 450 nm, which is less than half of the cell dimension measured in Na-montmorillonite. The most dramatic structural changes were observed after treatment by Al₁₃ Keggin; aggregates then became arranged in compacted domains of a 300 nm average diameter composed of thick face-to-face oriented sheets, which forms porous aggregates with larger intra-aggregate open and connected voids. Full article

Within the German integrated project SUGAR, aiming for the development of new technologies for the exploration and exploitation of submarine gas hydrates, the option of gas transport by gas hydrate pellets has been comprehensively re-investigated. A series of pVT dissociation experiments, combined with analytical tools such as x-ray diffraction and cryo-SEM, were used to gather an additional level of understanding on effects controlling ice formation. Based on these new findings and the accessible literature, knowns and unknowns of the self-preservation effect important for the technology are summarized. A conceptual process design for methane hydrate production and pelletisation has been developed. For the major steps identified, comprising (i) hydrate formation; (ii) dewatering; (iii) pelletisation; (iv) pellet cooling; and (v) pressure relief, available technologies have been evaluated, and modifications and amendments included where needed. A hydrate carrier has been designed, featuring amongst other technical solutions a pivoted cargo system with the potential to mitigate sintering, an actively cooled containment and cargo distribution system, and a dual fuel engine allowing the use of the boil-off gas. The design was constrained by the properties of gas hydrate pellets, the expected operation on continental slopes in areas with rough seas, a scenario-defined loading capacity of 20,000 m³ methane hydrate pellets, and safety as well as environmental considerations. A risk analysis for the transport at sea has been carried out in this early stage of development, and the safety level of the new concept was compared to the safety level of other ship types with similar scopes, i.e., LNG carriers and crude oil tankers. Based on the results of the technological part of this study, and with best knowledge available on the alternative technologies, i.e., pipeline, LNG and CNG transportation, an evaluation of the economic competitiveness of the methane hydrate transport technology has been performed. The analysis considers capital investment as well as operational costs and comprises a wide set of scenarios with production rates from 20 to 800 10³ Nm³·h⁻¹ and transport distances from 200 to 10,000 km. In contrast to previous studies, the model calculations in this study reveal no economic benefit of methane hydrate transportation versus competing technologies. Full article
