This study presents a bilateral control architecture that links fluoroscopic image feedback directly to the kinematics of a tendon-driven, three-joint robotic catheter and a 3-DoF motorised C-arm, intending to preserve optimal imaging geometry during autonomous catheter insertion and thereby mitigating radiation exposure. Forward and inverse kinematics for both manipulators were derived via screw theory and geometric analysis, while a calibrated projection model generated synthetic X-ray images whose catheter bending angles were extracted through intensity thresholding, segmentation, skeletonisation, and least-squares circle fitting. The estimated angle fed a one-dimensional extremum-seeking routine that rotated the C-arm about its third axis until the apparent bending angle peaked, signalling an orthogonal view of the catheter’s bending plane. Implemented in a physics-based simulator, the framework achieved inverse-kinematic errors below 0.20% for target angles between ${20}^{°}$ and ${90}^{°}$, with accuracy decreasing to 3.00% at ${10}^{°}$. The image-based angle estimator maintained a root-mean-square error $\le 3$% across most of the same range, rising to 6.4% at ${10}^{°}$. The C-arm search consistently located the optimal perspective, and the combined controller steered the catheter tip along a predefined aortic path without collision. These results demonstrate sub-degree angular accuracy under idealised, noise-free conditions and validate real-time coupling of image guidance to dual-manipulator motion; forthcoming work will introduce realistic image noise, refined catheter mechanics, and hardware-in-the-loop testing to confirm radiation-dose and workflow benefits. Full article

In Northeast China, the maize (Zea mays L.) harvester header height is still manually controlled, and the control precision is poor, which limits the quality of maize harvesting and is unfavorable to the long-term development of agricultural harvesting. This work created an adaptive adjustment method for header height to address this issue. A maize harvester header, an STM32 control unit and key module, a hydraulic adjustment mechanism, and a pressure-wheel profiling device comprise the majority of the system. In this scenario, the proposed pressure-wheel profiling device is mounted to the ridge’s surface and walks along it, delivering real-time data on terrain changes. The terrain change signals are received and processed in real time by the STM32 control unit, which subsequently operates the hydraulic adjustment mechanism to alter the header height. The structural dimensions and operational parameters of the essential components for pressure-wheel profiling device were determined using force analysis. A kinematic analysis of the hydraulic adjusting mechanism was performed, and the expression of the relationship between the displacement of hydraulic cylinder and the header height was obtained. The pressure-wheel profiling device was calibrated, the adaptive adjustment parameter model was constructed, and the PID control technique was employed to achieve automatic header height adjustment. This study analyzed the effects of harvester different forward speeds (1.25, 1.45, 1.65, 1.85, and 2.05 m/s) and different operating modes (open and unopened system) on the test indexes (Errors in the automatic adjustment of header height, Cob loss rate, Coefficient of variation in stubble height). The results revealed that, with the adaptive adjustment system mode on, the average difference between the measured actual header height and the predetermined height was 9.96 mm, the average coefficient of variation in stubble height was lowered by 34.44%, and the average cob loss rate was decreased by 7.98%, both of which may accommodate the needs of maize harvester header height adjustment. This study serves as a reference for the automated design of a maize harvester for monopoly crops. Full article

Precision object handling and manipulation require the accurate positioning of industrial robots. A common practice for performing end effector positioning is to read joint angles and use industrial robot forward kinematics (FKs). However, industrial robot FKs rely on the robot Denavit–Hartenberg (DH) parameter values, which include uncertainties. Sources of uncertainty associated with industrial robot FKs include mechanical wear, manufacturing and assembly tolerances, and robot calibration errors. It is therefore necessary to increase the accuracy of DH parameter values to reduce the impact of uncertainties on industrial robot FKs. In this paper, we use differential evolution, particle swarm optimization, an artificial bee colony, and a gravitational search algorithm to calibrate industrial robot DH parameters. A laser tracker system, Leica AT960-MR, is utilized to register accurate positional measurements. The nominal accuracy of this non-contact metrology equipment is less than 3 μm/m. Metaheuristic optimization approaches such as differential evolution, particle swarm optimization, an artificial bee colony and a gravitational search algorithm are used as optimization methods to perform the calibration using laser tracker position data. It is observed that, using the proposed approach with an artificial bee colony optimization algorithm, the accuracy of industrial robot FKs in terms of mean absolute errors of static and near-static motion over all three dimensions for the test data decreases from its measured value of 75.4 μm to 60.1 μm (a 20.3% improvement). Full article

This paper presents a method on how to compute the position of a robotic arm in the 2D and 3D spaces. This method is slightly different from the well-known methods, such as forward or inverse kinematics. The method presented in this paper is an optical method, which uses two video cameras in stereo vision configuration to locate and compute the next move of a robotic arm in space. The method recognizes the coordinates of the markers placed at the joints of the robotic arm using the two video cameras. The coordinate points of these markers are connected with straight lines. Around certain points, circles are drawn. From the tangent to the circles, a non-Cartesian (orthogonal) coordinate system is drawn, which is enough to compute the target position of the robotic arm. All of these drawings are overlaid on the live video feed. This paper also presents another method for calculating the stereo distance using the triangulation method. An alternative method is also presented when a non-Cartesian (orthogonal) 3D coordinate system is created, which is used to compute the target position of the robotic arm in the 3D space. Because the system is in a loop, it can make micro-adjustments of the robotic arm, in order to be exactly in the desired position. In this way, there is no need to make calibrations for the robotic arm. In an industrial system, there is no need to stop the production line, which can be a really big cost saver. Full article

This paper presents a geometric approach for real-time forward kinematics of the general Stewart platform, which consists of two rigid bodies connected by six general serial manipulators. By describing the rigid-body motion as exponential of twist, and taking advantage of the product of exponentials formula, a step-by-step derivation of the proposed algorithm is presented. As the algorithm naturally solves all passive joint displacements, the correctness is then verified by comparing the forward-kinematic solutions from all chains. The convergence ability and robustness of the proposed algorithm are demonstrated with large amounts of numerical simulations. In all test cases, the proposed algorithm terminates within four iterations, converging with near-quadratic speed. Finally, the proposed algorithm is also implemented on a mainstream embedded motion controller. Compared with the incremental method, the proposed algorithm is more robust, with an average execution time of 0.48 ms, meeting the requirements of most applications, such as kinematic calibration, motion simulation, and real-time control. Full article

The paper presents research on methods of a wheeled mobile robot localization using an optical motion capture system. The results of localization based on the model of forward kinematics and odometric measurements were compared. A pure pursuit controller was used to control the robot’s behaviour in the path following tasks. The paper describes a motion capture system based on infrared cameras, including the calibration method. In addition, a method for determining the accuracy of robot location using the motion capture system, based on the Hausdorff distance, was proposed. As a result of the research it was found that the Hausdorff distance is very useful in determining the accuracy of localization of wheeled robots, especially those described by differential drive kinematics. Full article

Terrestrial laser scanning is used in many disciplines of engineering. Examples include mobile mapping, architecture surveying, archaeology, as well as monitoring and surveillance measurements. For most of the mentioned applications, 3D object capturing in an accuracy range of several millimeters up to a few centimeters is sufficient. However, in engineering geodesy, particularly in industrial surveying or monitoring measurements, accuracies in a range of a few millimeters are required. Additional increased quality requirements apply to these applications. This paper focuses on the quality investigation of data captured with static and kinematic terrestrial laser scanning. For this purpose, suitable sensors, which are typically used in the approach of a multi-sensor-system, as well as the corresponding data capturing/acquisition strategies, are presented. The aim of such systems is a geometry- and surface-based analysis in an industrial environment with an accuracy of +/− 1–2 mm or better. Full article

Automatic fitting of an arc center and radius is a quality problem frequently encountered when manufacturing a mechanical component. Due to the complexity of the measurement, validating each manufactured component via inspection is not feasible or economical. This paper introduces a new validation procedure for measuring arcs from distributed sensors. The goal of this proposed measurement process is to improve measurement throughput (i.e., parts measured per unit of time) and reduce measurement errors associated with hardware and algorithms. This proposed model develops a three-point inverse kinematic algorithm (TPIK) accompanied by a calibration master to obtain the relative location of the measurement system by solving a set of six non-linear equations. This technique allows deployment of a high accuracy gauge systems that in general, reduces machine and algorithm errors. The direct fitting is validated by using mathematical, CAD, and experimental models. Furthermore, a modified definition for the roundness index is introduced based on the proposed forward and inverse algorithms. The simulations examine the roundness index in relation to the measurement precision, sampling angle, nominal radius, and part variation. A benefit of this proposed method is accurate and rapid inspection of the radii and elimination of the human error associated with part loading variation during conventional radii measurement. The rapid, accurate inspection and corresponding reduction in human error make this method an excellent process for inspection of large quantities of components. Full article

This study aimed to develop a novel 3D parallel mechanism robot driven by three vertical-axial pneumatic actuators with a stereo vision system for path tracking control. The mechanical system and the control system are the primary novel parts for developing a 3D parallel mechanism robot. In the mechanical system, a 3D parallel mechanism robot contains three serial chains, a fixed base, a movable platform and a pneumatic servo system. The parallel mechanism are designed and analyzed first for realizing a 3D motion in the X-Y-Z coordinate system of the robot’s end-effector. The inverse kinematics and the forward kinematics of the parallel mechanism robot are investigated by using the Denavit-Hartenberg notation (D-H notation) coordinate system. The pneumatic actuators in the three vertical motion axes are modeled. In the control system, the Fourier series-based adaptive sliding-mode controller with H_∞ tracking performance is used to design the path tracking controllers of the three vertical servo pneumatic actuators for realizing 3D path tracking control of the end-effector. Three optical linear scales are used to measure the position of the three pneumatic actuators. The 3D position of the end-effector is then calculated from the measuring position of the three pneumatic actuators by means of the kinematics. However, the calculated 3D position of the end-effector cannot consider the manufacturing and assembly tolerance of the joints and the parallel mechanism so that errors between the actual position and the calculated 3D position of the end-effector exist. In order to improve this situation, sensor collaboration is developed in this paper. A stereo vision system is used to collaborate with the three position sensors of the pneumatic actuators. The stereo vision system combining two CCD serves to measure the actual 3D position of the end-effector and calibrate the error between the actual and the calculated 3D position of the end-effector. Furthermore, to verify the feasibility of the proposed parallel mechanism robot driven by three vertical pneumatic servo actuators, a full-scale test rig of the proposed parallel mechanism pneumatic robot is set up. Thus, simulations and experiments for different complex 3D motion profiles of the robot end-effector can be successfully achieved. The desired, the actual and the calculated 3D position of the end-effector can be compared in the complex 3D motion control. Full article
