GaN flying-capacitor-multi-level (FCML) Totem-Pole power-factor-correctors (PFCs) have been demonstrated with very high density and efficiency in the literature. However, there is still a lack of detailed discussion about flying capacitor voltage precharge during the start-up for GaN FCML Totem-Pole PFCs. To enhance the reliability during start-up, we propose a multi-path and multi-step flying capacitor precharge method. In our proposed method, the bulky DC link capacitor is precharged through the path of the auxiliary line-frequency Si diode half-bridge and the body-diodes of the Si MOSFET half-bridge. The flying capacitors which have much smaller capacitances are precharged through the path of the GaN devices and the body-diodes of the Si half-bridge. The DC link capacitor is more than 100 times higher than the flying capacitor in this topology. Therefore, by splitting the total precharging current into two paths, the precharging current through the GaN devices is almost 100 times lower than that through the body-diodes of Si MOSFETs. As a result, this method protects expensive GaN devices from high inrush current and significantly improves the reliability of the GaN devices during the voltage precharge. Detailed operation principles and experimental verifications are presented in this paper. Full article

This paper presents a novel modeling approach for flying capacitor dynamics in boost-type multi-level converters (FCML-boosts) controlled by Phase Shift Pulse Width Modulation (PSPWM). By explicitly taking into account the interaction between the inductor current and the flying capacitor voltage, the model is able to reveal an underlying resonance phenomenon and to predict its frequency at each operating point. Based on such a model, whose derivation is explained in detail, both passive and active damping solutions are proposed, designed, and experimentally verified that significantly reduce the undesirable oscillations. The analytical results and the devised control solutions are tested on a $1\mathrm{k}\mathrm{W}$, four-level, boost DC-DC converter prototype employing $200\mathrm{V}$, $48\mathrm{A}$ rated EPC2034C GaN devices. Full article

With the development of space exploration, high-power and high-voltage power systems are essential for future spacecraft applications. Because of the effects of space radiation such as single event burnout (SEB), the rated voltage of power devices in converters for a spacecraft power system is limited to a level much lower than that for traditional ground applications. Thus, multi-level DC/DC converters are good choices for high-voltage applications in spacecraft. In this paper, a fault-tolerant strategy is proposed for a three-level flying capacitor DC/DC converter to increase the reliability with minimal cost. There is no extra hardware needed for the proposed strategy; the fault tolerance of the converter is only achieved by changing the software control strategy. A stage analysis of the proposed strategy is provided in detail for different fault locations and ratios between the input and output voltage. Finally, a simulation model and prototype are built to verify the effectiveness of the proposed strategy. Full article

Quasi-2-level (Q2L) operation of multi-level bridge-legs, especially of flying-capacitor converters (FCC), is an interesting option for realizing single-cell power conversion in applications whose system voltages exceed the ratings of available power semiconductors. To ensure equal voltage sharing among a Q2L-FCC’s switches, the voltages of a Q2L-FCC’s minimized flying capacitors (FCs) must always be balanced. Thus, we propose a concept for load-independent FC voltage balancing: For non-zero load current, we use a model predictive control (MPC) approach to identify the commutation sequence of the individual switches within a Q2L transition that minimizes the FC or cell voltage errors. In case of zero load current, we employ a novel MPC-based approach using cell multiple switching (CMS), i.e., the insertion of additional zero-current commutations within a Q2L transition, to exchange charge between the FCs via the charging currents of the switches’ parasitic capacitances. Experiments with a 5-level FCC half-bridge demonstrator confirm the validity of the derived models and verify the performance of the proposed load-independent balancing concept. Full article

This paper presents a study of the nonlinear dynamic behavior a flying capacitor four-level three-cell DC-DC buck converter. Its stability analysis is performed and its stability boundaries is determined in the multi-dimensional paramertic space. First, the switched model of the converter is presented. Then, a discrete-time controller for the converter is proposed. The controller is is responsible for both balancing the flying capacitor voltages from one hand and for output current regulation. Simulation results from the switched model of the converter under the proposed controller are presented. The results show that the system may undergo bifurcation phenomena and period doubling route to chaos when some system parameters are varied. One-dimensional bifurcation diagrams are computed and used to explore the possible dynamical behavior of the system. By using Floquet theory and Filippov method to derive the monodromy matrix, the bifurcation behavior observed in the converter is accurately predicted. Based on justified and realistic approximations of the system state variables waveforms, simple and accurate expressions for these steady-state values and the monodromy matrix are derived and validated. The simple expression of the steady-state operation and the monodromy matrix allow to analytically predict the onset of instability in the system and the stability region in the parametric space is determined. Numerical simulations from the exact switched model validate the theoretical predictions. Full article
