Perovskite solar cells (PSCs) offer a number of key advantages over silicon solar cells. These include their low-cost materials, high efficiency, simplicity of fabrication, and inexpensive manufacturing techniques. To commercialize PSCs, there are many methods to develop the quality of the cells, one of them being printing techniques. Different printing techniques deposition have been developed for the perovskite solar cell, such as blade coating, slot die coating, inkjet printing, screen printing, spray coating, flexographic printing, and gravure printing. These techniques have a substantial impact on the performance of PSCs and controlling film formation to commercialize PSCs. This review summarizes a comprehensive overview of various deposition printing techniques used to fabricate PSCs during different years and different techniques, such as using different preparation methods, novel drying techniques, and ink engineering. In addition, the challenges that are faced by using these, such as material stability, reproducibility of printing processes, and cost-effectiveness techniques, are reviewed. Future research should focus on optimizing printing techniques to improve the stability and scalability of PSCs. Exploring novel perovskite materials, deposition techniques, and innovative fabrication methods may further enhance the PSCs and facilitate their commercialization. Full article

Flexographic printing is widely used in the packaging field, but there are still some problems in the printing of flexographic ink on non-absorbent substrates, such as low precision and unstable quality. In this paper, the printing process of flexographic ink is simulated. The interaction of fluid flow, temperature change, and solid deformation in flexographic printing is studied systematically by using the method of fluid–solid thermal coupling for the first time. The process of ink channel formation under static extrusion and fluid–solid thermal coupling was analyzed. The influences of printing pressure, printing speed, ink layer thickness, and ink viscosity on the ink channel were explored. The results show that the printing speed increases and the temperature in the stamping area increases. The printing speed is nonlinear related to the ink flow channel, the influence on the channel is slow at a low speed, the channel increases sharply at a medium and high speed, and tends to be stable at a high speed. When the printing speed is 200 m/min, the ink temperature in the stamping area is 1.5 °C higher than that at the entrance. With an increase in printing pressure, the ink flow channel width showed a trend of decreasing first and then stabilizing, and the pressure was about 0.4 MPa, showing a small fluctuation; the greater the pressure, the higher the temperature of the ink, which will change the performance of the ink and plate, causing adverse effects on the printing belt. The channel width showed obvious nonlinear characteristics with an increase and decrease in ink thickness. When the ink thickness is 30 μm, the deformation of the plate reaches the maximum, and the width of the ink circulation channel is correspondingly the widest. The change in ink viscosity has little influence on the stability of the ink’s internal flow rate and temperature field. The research results provide theoretical support for the transfer of ink printing from gravure to flexo printing. Full article

In recent years, researchers prepared composite conductive inks with high conductivity, high thermal conductivity, strong stability, and excellent comprehensive mechanical properties by combining carbon-based materials such as graphene and carbon nanotubes with metal-based materials. Through new electronic printing technologies, conductive inks can be used not only to promote the development of integrated circuits but also in various new electronic products. The conductive mechanism and the main types of conductive inks are introduced in this review. The advantages of electronic printing technology for preparing integrated circuits are analyzed. The research progress of fabricating integrated circuits with different electronic printing processes, such as screen printing, gravure printing, flexographic printing, and inkjet printing, are summarized. The development trend of carbon-based composite conductive ink for integrated circuits is prospected. Full article

In the flexographic printing industry, anilox rolls play a pivotal role in determining ink usage. These rolls are characterized by anilox cells, which transfer ink to the final printed material. However, these rolls face wear and potential damage during their operational life, largely due to improper cleaning or debris accumulation in the ink duct. Such contamination compromises the ink capacity, impacting print quality. With the industry’s need for consistent and high-quality prints, there is a growing emphasis on the development and consistent implementation of optimal anilox-roll operation methodologies. One cleaning method gaining traction is ultrasonic cleaning. This method employs ultrasonic waves in conjunction with a cleaning agent, providing a quick, efficient, and environmentally conscious cleaning alternative. Yet, there is limited scientific data on the actual condition of anilox rolls after ultrasonic cleaning. In this study, the surface of anilox rolls post-ultrasonic-cleaning was comprehensively examined using microscopic analysis. This assessment provided insights into the method’s efficacy and potential for causing roll damage. The results showed that post-printing, rolls lost approximately 20% of their ink capacity, and ultrasonic cleaning effectively restored the ink capacity of the undamaged rolls. However, for rolls with pre-existing damage, the ultrasonic cleaning process exacerbated the damages, leading to complete delamination in some instances. This study underscores the potential of ultrasonic cleaning in restoring anilox-roll efficiency but also highlights the need for caution with damaged rolls. Full article

Despite numerous methods to optimise their operation and parameters, anilox rolls are subject to rapid wear during use and due to improper cleaning processes. Therefore, regular diagnosis is needed. In this study, X-ray fluorescence (XRF) analysis based on Fe and Cr was used to determine the elemental compositions of raster cylinder coatings. Due to the layered composition of the anilox roll, where Cr₂O₃ coating is applied on the iron core, evaluation of the composition of the roll surface can be used to detection of anilox damage. A portable XRF apparatus was used to identify selected elements even at low concentrations of <1%. In this work, it was proved that XRF can be a preliminary, rapid method for assessing the technical condition of an anilox cylinder. The XRF technique can be safely used in non-destructive chemical analyses of the anilox rollers’ condition in flexographic printing technology, and chemical information that aids in their use may be routinely obtained, thus enabling high-quality printing. This is a pioneering study in which the XRF spectroscopy technique was successfully used to anilox roll condition assessment. Full article

Flexographic printing is a highly sought-after technique within the realm of packaging and labeling due to its versatility, cost-effectiveness, high speed, high-quality images, and environmentally friendly nature. A major challenge in flexographic printing is the need to optimize energy usage, which requires diligent attention to resolve. This research combines lean principles and machine learning to improve energy efficiency in selected flexographic printing machines; i.e., Miraflex and F&K. By implementing the 5Why root cause analysis and Kaizen, the study found that the idle time was reduced by 30% for the Miraflex machine and the F&K machine, resulting in energy savings of 34.198% and 38.635% per meter, respectively. Additionally, a multi-linear regression model was developed using machine learning and a range of input parameters, such as machine speed, production meter, substrate density, machine idle time, machine working time, and total machine run time, to predict energy consumption and optimize job scheduling. The results of the research exhibit that the model was efficient and accurate, leading to a reduction in energy consumption and costs while maintaining or even improving the quality of the printed output. This approach can also add to reducing the carbon footprint of the manufacturing process and help companies meet sustainability goals. Full article

In this study, the extremely important and difficult topic of flexographic printing on a heat-shrinkable substrate was taken up. Six commercially available, electrically conductive inks based on silver, copper and graphite nanoparticles were selected and tested upon their applicability for printing on the temperature-sensitive PET material. As a printing substrate, the one-direction heat-shrinkable PET film, with a maximum shrinkage of 78%, was selected. All of the examined inks were subjected to the printing process throughout three different anilox line screens. The tested inks, along with the electric paths printed with them, were subjected to various tests. The main parameters were evaluated, such as printability combined with the rheology tests and ink adhesion to the examined PET substrate together with the electrical conductivity before and after the shrinkage. Full article

PLA films, as non-absorbent materials, require modification of the surface before the printing process in order to improve the wettability of the substrate and to obtain proper ink adhesion to the substrate. In this paper, the surfaces of two kinds of PLA films were modified using plasma activation with parameters enabling high surface free energy (SFE) values, and then the films were printed on using different kinds of flexographic inks. Two gases, oxygen and argon, were used for activation, as these make it possible to obtain good hydrophilicity and high SFE values while having different effects on the roughness, or the degree of surface etching. Plasma-activated films were subsequently subjected to the measurements of: contact angle with water, diiodomethane and three printing inks, roughness, weight change, strength properties, color and gloss change, and SFE was determined. Unmodified and activated films were flexographically printed in laboratory conditions and then the quality of obtained prints was analyzed. The results showed a strong effect of activation with both oxygen and argon plasma on the SFE value of the films and the contact angles of water and inks, with the gas used for plasma activation and the type of film significantly influencing the thickness of the fused ink layer and the resultant color. Moreover, plasma activation had a especially favorable and significant effect on the quality of prints made with water-based inks, while it had little effect when printing with solvent-based inks. Full article

As long as non-contact digital printing remains an uncommon standard in the corrugated packaging industry, corrugated board crushing remains a real issue that affects the load capacity of boxes. Crushing mainly occurs during the converting of corrugated board (e.g., analog flexographic printing or laminating) and is a process that cannot be avoided. However, as this study shows, it can be controlled. In this work, extended laboratory tests were carried out on the crushing of double-walled corrugated board. The influence of fully controlled crushing (with a precision of ±10 μm) in the range from 10 to 70% on different laboratory measurements was checked. The typical mechanical tests—i.e., edge crush test, four-point bending test, shear stiffness test, torsional stiffness test, etc.—were performed on reference and crushed specimens. The residual thickness reduction of the crushed samples was also controlled. All empirical observations and performed measurements were the basis for building an analytical model of crushed corrugated board. The proven and verified model was then used to study the crushing effect of the selected corrugated board on the efficiency of simple packages with various dimensions. The proposed measurement technique was successfully used to precisely estimate and thus control the crushing of corrugated board, while the proposed numerical and analytical techniques was used to estimate the load capacity of corrugated board packaging. A good correlation between the measured reduced stiffness of the corrugated cardboard and the proposed analytical predictive models was obtained. Full article

Over the past decade, there has been an increasing demand for “ready-to-cook” and “ready-to-eat” foods, encouraging food producers, food suppliers, and food scientists to package foods with minimal processing and loss of nutrients during food processing. Following the increasing trend in the customer’s demands for minimally processed foodstuffs, this underscores the importance of promising interests toward industrial applications of novel and practical approaches in food. Along with substantial progress in the emergence of “nanoscience”, which has turned into the call of the century, the efficacy of conventional packaging has faded away. Accordingly, there is a wide range of new types of packaging, including electronic packaging machines, flexible packaging, sterile packaging, metal containers, aluminum foil, and flexographic printing. Hence, it has been demonstrated that these novel approaches can economically improve food safety and quality, decrease the microbial load of foodborne pathogens, and reduce food spoilage. This review study provides a comprehensive overview of the most common chemical or natural nanocomposites used in food packaging that can extend food shelf life, safety and quality. Finally, we discuss applying materials in the production of active and intelligent food packaging nanocomposite, synthesis of nanomaterial, and their effects on human health. Full article

The print quality of prints performed with flexographic printing technology is influenced by various parameters such as viscosity of the printing inks, printing substrates, plates, anilox rolls, etc. The aim of this work is to analyze the influence of ink viscosity, printing plate and printing base on selected properties of print quality, such as optical density of full tone area and the increase of tonal value (TVI). Additionally, the printed dots on 5, 15, 30, 50 and 75% of half tone area were investigated using digital microscopy. The least square fitting method in a matrix form was successfully used in order to confirm the influence of printing process parameters on print quality. The results obtained reveal the significant influence of the printing plate and printing substrate characteristics and the lesser influence of printing ink viscosity for 40–100% coverage area. The values of the optical densities of full tone areas are mainly influenced by the properties of the printing plate and the printing base. Furthermore, the optical density decreases when the value of flow time decreases, which is related to the lower thickness of dried ink film. The TVI on light tones (0 to 20%) is mainly influenced by the ink viscosity. Full article

The aim of this research was to analyze the influence of the solvents commonly used in flexography on photopolymer and ethylene propylene diene monomer (EPDM) flexographic printing plates and prints. EPDM plates are recommended when the reproduction process includes a higher amount of the solvents or aggressive solvents. Since additional UV treatment of flexographic printing plates could decrease the interaction between the plate and solvent, photopolymer and EPDM plates were treated with varied UV radiation and exposed to different types of solvents. Effects of the UV treatment and of the solvents on printing plate properties and on prints were analyzed. Results show that EPDM plates are more resistant to solvents in terms of the degree of swelling; however, surface properties of the plates were affected for both plate materials. In addition, the degree of swelling and increased hardness due to UV radiation were crucial for changes of the width of printed lines, and altered surface free energy affected the thickness of deposited ink film for both plate materials. Therefore, depending on the qualitative requirements of specific printed film, the duration of UV treatment can be adjusted for use with specific types of printing plate and solvent. Full article

We considered pattern formation, i.e. viscous fingering, in the ink splitting process between an elastic flexographic printing plate and the substrate. We observed an unexpected scaling behavior of the emerging pattern length scale (i.e., finger width) as a function of printing velocity, fluid viscosity, surface tension, and plate elasticity coefficients. Scaling exponents depended on the ratio of the capillary number of the fluid flow, and the elastocapillary number defined by plate elasticity and surface tension. The exponents significantly differed from rigid printing plates, which depend on the capillary number only. A dynamic model is proposed to predict the scaling exponents. The results indicate that flexo printing corresponded to a self-regulating dynamical equilibrium of viscous, capillary, and elastic forces. We argue that these forces stabilize the process conditions in a flexo printing unit over a wide range of printing velocities, ink viscosities, and mechanical process settings. Full article
