Ultrasonic flowmeters are essential sensor devices widely used in remote metering systems, smart grids, and monitoring systems. In these environments, a low-power design is critical to maximize energy efficiency. Real-time data collection and remote consumption monitoring through remote metering significantly enhance network flexibility and efficiency. This paper proposes a low-complexity structure that ensures an accurate time-of-flight (ToF) estimation within an acceptable error range while reducing computational complexity. The proposed system utilizes Hilbert envelope detection and a differentiator-based parallel peak detector. It transmits and collects data through ultrasonic transmitter and receiver transducers and is designed for seamless integration as a node into wireless sensor networks (WSNs). The system can be involved in various IoT and industrial applications through high energy efficiency and real-time data transmission capabilities. The proposed structure was validated using the MATLAB software, with an LPG gas flowmeter as the medium. The results demonstrated a mean relative deviation of 5.07% across a flow velocity range of 0.1–1.7 m/s while reducing hardware complexity by 78.9% compared to the conventional FFT-based cross-correlation methods. This study presents a novel design integrating energy-efficient ultrasonic flowmeters into remote metering systems, smart grids, and industrial monitoring applications. Full article

Piezoelectric composite materials, combining the advantages of both piezoelectric materials and polymers, have been extensively used in ultrasonic transducers. However, the pitch size of radial array ultrasonic transducers normally exceeds one wavelength, which limits their performance. In order to minimize grating lobes of current radial transducers and then increase their imaging resolution, a 2.5 MHz 1-3 composite radial array transducer with 64 elements and 600 μm pitch was designed and fabricated by combining flexible circuit board and using a bending-and-superposition method. All the array elements were connected and actuated via the customized circuit board which is thin and soft. The kerf size is set to be 1/3 wavelength. PZT-5H/epoxy 1-3 composite was used as an active material because it exhibits an ultrahigh electromechanical coupling coefficient (k_t = 0.74), a very low mechanical quality factor (Q_m = 11), and relatively low acoustic impedance (Z_c = 13.43 MRayls). The developed radial array transducer exhibited a center frequency of 2.72 MHz, an average −6 dB bandwidth of 36%, an insertion loss of 31.86 dB, and a crosstalk of −26.56 dB between the adjacent elements near the center frequency. These results indicate that the bending-and-superposition method is an effective way to fabricate radial array transducers by binding flexible circuit boards. Furthermore, the utilization of tailored flexible circuitry boards presents an effective approach for realizing reductions in crosstalk level (CTL). Full article

This study presents a novel, coil-only magnetostrictive ultrasonic detection method that operates effectively without permanent magnets, introducing a simpler alternative to conventional designs. The system configuration is streamlined, consisting of a single meander coil, an excitation source, and a nickel sheet, with both the bias magnetic field and ultrasonic excitation achieved by a composite excitation containing both DC and AC components. This design offers significant advantages, enabling high-frequency Lamb wave generation in nickel sheets for ultrasonic detection while reducing device complexity. Experimental validation demonstrated that an S0-mode Lamb wave at a frequency of 2.625 MHz could be effectively excited in a 0.2 mm nickel sheet using a double-layer meander coil. The experimentally measured wave velocity was 4.9946 m/s, with a deviation of only 0.4985% from the theoretical value, confirming the accuracy of the method. Additionally, this work provides a theoretical basis for future development of flexible MEMS-based magnetostrictive ultrasonic transducers, expanding the potential for miniaturized magnetostrictive patch transducers. Full article

Flexible ultrasonic devices represent a feasible technology for providing timely signal detection and even a non-invasive disease treatment for the human brain. However, the deformation of the devices is always accompanied by a change in the acoustic field, making it hard for accurate focusing. Herein, we report a stable and flexible transducer. This device can generate a high-intensity acoustic signal with a controllable acoustic field even when the device is bent. The key is to use a low-impedance piezoelectric material and an island-bridge device structure, as well as to design a unique time-reversal algorithm to correct the deviation of signals after transcranial propagation. To provide an in-depth study of the acoustic field of flexible devices, we also analyze the effects of mechanical deformation and structural parameters on the corresponding acoustic response. Full article

Blood viscosity is influenced by several factors, including red blood cell (RBC) deformability, hematocrit (Hct), and plasma protein levels. To effectively isolate the individual contributions of several factors, it is necessary to simultaneously measure the viscosities of the blood and plasma. In this study, the viscosities of suspended blood and plasma were obtained sequentially by adopting an ultrasonic transducer for plasma separation and a co-flowing microfluidic channel for viscosity measurement. To improve the measurement accuracy of viscosity, the correction factor was obtained through experiments and numerical simulations, which was then inserted into the analytical expression for viscosity. To stabilize the pulsatile blood flow resulting from a micropump, the frequency (f) and voltage (v) were set to f = 300 Hz and v = 140 au, respectively. Flexible polyethylene tubing (i.d. = 500 µm, length = 40 mm) was connected to the microfluidic device as an air damper. Consequently, the coefficient of variance of the blood velocity decreased by up to 1%. As a demonstration, suspended blood (Hct = 20%, 30%, and 40%) was prepared by adding normal RBCs to autologous plasma. Compared with the previous method, the present method overestimates the viscosity values of both the fluids (i.e., suspended blood: 14–25% and plasma: 7–21%). The present method has the ability to sequentially measure the viscosities of suspended blood and plasma. The integrated system contributes to reducing blood-handling procedures (i.e., blood collection, blood loading into the syringe, and syringe installation into the syringe pump). Full article

Ultrasonic (US) transducers have been widely used in the field of ultrasonic and photoacoustic imaging system in recent years, to convert acoustic and electrical signals into each other. As the core part of imaging systems, US transducers have been extensively studied and achieved remarkable progress recently. Imaging systems employing conventional rigid US transducers impose certain constraints, such as not being able to conform to complex surfaces and comfortably come into contact with skin and the sample, and meet the applications of continuous monitoring and diagnosis. To overcome these drawbacks, significant effort has been made in transforming the rigid US transducers to become flexible and wearable. Flexible US transducers ensure self-alignment to complex surfaces and maximize the transferred US energy, resulting in high quality detection performance. The advancement in flexible US transducers has further extended the application range of imaging systems. This review is intended to summarize the most recent advances in flexible US transducers, including advanced functional materials optimization, representative US transducers designs and practical applications in imaging systems. Additionally, the potential challenges and future directions of the development of flexible US transducers are also discussed. Full article

In this paper, a flexible piezoelectric micromachined ultrasonic transducer (PMUT) based on Scandium (Sc)-doped Aluminum Nitride (AlN) film was designed and modeled by the three-dimensional finite element method (3D-FEM). The resonant frequency of 218.1 kHz was reported. It was noticeable that a high effective electromechanical coupling coefficient (k²_eff) of 1.45% was obtained when a combination of a flexible PI and a thin Si layer was used as the PMUT supporting structure layer. Compared with a pure Si supporting layer counterpart, the coupling coefficient had been improved by 110.68%. Additionally, the increase of Sc doping concentration in AlN film further enhanced the device electromechanical coupling coefficient and resulted in an improvement for transmitting/receiving sensitivity of the proposed flexible PMUT. When the doping concentration of Sc reached 30%, the emission sensitivity was as large as 1.721 μm/V, which was 2.86 times greater than that of conventional AlN film-based PMUT. The receiving sensitivity was found to be 2.11 V/KPa, which was as high as 1.23 times the performance of an undoped device. Furthermore, the bending simulation result showed that the proposed flexible PMUT device can maintain a good mechanical stability when the bending radius is greater than 1.5 mm. The simulation of sound field characteristics demonstrated that the flexible PMUT based on AlScN could receive stable sound pressure signals under the bending radius of 1.5 cm. Full article

Butt welding is extensively applied in long-distance oil and gas pipelines, and it is of great significance to conduct non-destructive ultrasonic testing of girth welds in order to avoid leakage and safety accidents during pipeline production and operation. In view of the limitations of large transducer size, single fixed beam angle, low detection resolution and high cost of conventional ultrasonic inspection technologies, a 16-channel piezoelectric micro ultrasonic transducer (PMUT) array probe was developed through theoretical analysis and structural optimization design. After the probe impedance characterization, the experimental results show that the theoretical model can effectively guide the design of the ultrasonic transducer array, offering the maximum operating frequency deviation of less than 5%. The ultrasonic echo performance tests indicate that the average −6 dB bandwidth of the PMUT array probe can be up to 77.9%. In addition, the fabricated PMUT array probe has been used to successfully detect five common internal defects in pipeline girth welds. Due to the multiple micro array elements, flexible handling of each element, large bandwidth and high resolution of defect detection, the designed PMUT array probe can provide a good application potential in structural health monitoring and medical ultrasound imaging fields. Full article

Conductive graphene polymer composites are considered promising functional materials in gas detection, strain detection, metal corrosion prevention, and electromagnetic wave absorption, owing to their good flexibility, lightweight, and adjustable conductivity. The internal defects or external damages of composite films will seriously affect the electrical and functional properties of the materials. Based on the conductive network inside the conductive polymer film and the self-inductance to ultrasonic wave, the defect self-monitoring system of the conductive polymer film is designed and optimized in this work. The self-damage detection system is composed of an electrode array, excitation source, resistance signal acquisition and processing circuit, and damage display. Aiming at different scenarios, the improved interdigital structure transducer for sensors and damage detection device for coating film with a large area are presented and optimized respectively. Meanwhile, the damage location algorithm based on time difference measurement and kernel density estimation algorithm is also optimized. The multiple damage detection is realized by a device with a 4 × 8 electrode array, and the relative error of damage area with 1 mm × 1 mm is less than 5%, and the lower detection limits of damage size are 0.3 mm × 0.3 mm. Full article

Ultrasonic gene transfer has advantages beyond other cell transfer techniques because ultrasound does not directly act on cells, but rather pushes the gene fragments around the cells into cells through an acoustic hole effect. Most examples reported were carried out in macro volumes with conventional ultrasonic equipment. In the present study, a MEMS focused ultrasonic transducer based on piezoelectric thin film with flexible substrate was integrated with microchannels to form a microfluidic system of gene transfer. The core part of the system is a bowl-shaped curved piezoelectric film structure that functions to focus ultrasonic waves automatically. Therefore, the low input voltage and power can obtain the sound pressure exceeding the cavitation threshold in the local area of the microchannel in order to reduce the damage to cells. The feasibility of the system is demonstrated by finite element simulation and an integrated system of MEMS ultrasonic devices and microchannels are developed to successfully carry out the ultrasonic gene transfection experiments for HeLa cells. The results show that having more ultrasonic transducers leads a higher transfection rate. The system is of great significance to the development of single-cell biochip platforms for early cancer diagnosis and assessment of cancer treatment. Full article

Advances in flexible integrated circuit technology and piezoelectric materials allow high-quality stretchable piezoelectric transducers to be built in a form that is easy to integrate with the body’s soft, curved, and time-dynamic surfaces. The resulting capabilities create new opportunities for studying disease states, monitoring health/wellness, building human–machine interfaces, and performing other operations. However, more widespread application scenarios are placing new demands on the high flexibility and small size of the array. This paper provides a 8 × 8 two-dimensional flexible ultrasonic array (2D-FUA) based on laser micromachining; a novel single-layer “island bridge” structure was used to design flexible array and piezoelectric array elements to improve the imaging capability on complex surfaces. The mechanical and acoustoelectric properties of the array are characterized, and a novel laser scanning and positioning method is introduced to solve the problem of array element displacement after deformation of the 2D-FUA. Finally, a multi-modal localization imaging experiment was carried out on the multi-target steel pin on the plane and curved surface based on the Verasonics system. The results show that the laser scanning method has the ability to assist the rapid imaging of flexible arrays on surfaces with complex shapes, and that 2D-FUA has wide application potential in medical-assisted localization imaging. Full article

This work presents the CODEUS platform, which includes a simulation tool together with an online experimental demonstrator to offer analysis and testing flexibility for researchers and developers in Ultrasonic Indoor Positioning Systems (UIPSs). The simulation platform allows most common encoding techniques and sequences to be tested in a configurable UIPS. It models the signal modulation and processing, the ultrasonic transducers’ response, the beacon distribution, the channel propagation effects, the synchronism, and the application of different positioning algorithms. CODEUS provides results and performance analysis for different metrics and at different stages of the signal processing. The UIPS simulation tool is specified by means of the MATLAB© App-Designer environment, which enables the definition of a user-friendly interface. It has also been linked to an online demonstrator that can be managed remotely by means of a website, thus avoiding any hardware requirement or equipment on behalf of researchers. This demonstrator allows the selected transmission schemes, modulation or encoding techniques to be validated in a real UIPS, therefore enabling a fast and easy way of carrying out experimental tests in a laboratory environment, while avoiding the time-consuming tasks related to electronic design and prototyping in the UIPS field. Both simulator and online demonstrator are freely available for researchers and students through the corresponding website. Full article

Ultrasonic guided waves provide unique capabilities for the structural health monitoring of plate-like structures. They can detect and locate various types of material degradation through the interaction of shear-horizontal (SH) waves and Lamb waves with the material. Magnetostrictive transducers (MSTs) can be used to generate and receive both SH and Lamb waves and yet their characteristics have not been thoroughly studied, certainly not on par with piezoelectric transducers. A series of multiphysics simulations of the MST/plate system is conducted to investigate the characteristics of MSTs that affect guided wave generation and reception. The results are presented in the vein of showing the flexibility that MSTs provide for guided waves in a diverse range of applications. In addition to studying characteristics of the MST components (i.e., the magnetostrictive layer, meander electric coil, and biased magnetic field), single-sided and double-sided MSTs are compared for preferential wave mode generation. The wave mode control principle is based on the activation line for phase velocity dispersion curves, whose slope is the wavelength, which is dictated by the meander coil spacing. A double-sided MST with in-phase signals preferentially excites symmetric SH and Lamb modes, while a double-sided MST with out-of-phase signals preferentially excites antisymmetric SH and Lamb modes. All attempted single-mode actuations with double-sided MSTs were successful, with the SH3 mode actuated at 922 kHz in a 6-mm-thick plate being the highest frequency. Additionally, the results show that increasing the number of turns in the meander coil enhances the sensitivity of the MST as a receiver and substantially reduces the frequency bandwidth. Full article

Capacitive micromachined ultrasonic transducers (CMUTs) have been indispensable owing to their resonance characteristics in the MHz frequency range. However, the inferior pressure sensitivity and linearity of traditional CMUTs themselves cannot meet the actual demands of micro-pressure measurements. In this paper, two novel CMUTs are proposed for the first time to improve the measuring performance of micro-pressure in the range of 0–10 kPa. The core concept of the enhancement is strengthening membrane deformability by partly adjusting the CMUT framework under the combined action of electrostatic force and uniform pressure. Two modified structures of an inverted frustum cone-like cavity and slotted membrane are presented, respectively, and a finite element model (FEM) of CMUT was constructed and analyzed using COMSOL Multiphysics 5.5. The results demonstrate that the maximum displacement and pressure sensitivity are improved by 16.01% and 30.79% for the frustum cone-like cavity and 104.22% and 1861.31% for the slotted membrane, respectively. Furthermore, the results show that the width uniformity of the grooves does not influence the characteristics of the membrane, which mainly depend on the total width of the grooves, greatly enriching design flexibility. In brief, the proposed structural designs can significantly improve the micro-pressure measurement performance of the CMUT, which will accelerate the rapid breakthrough of technical barriers in the fields of aerospace, industry control, and other sensing domains. Full article

Evolvable acoustic fields are considered an effective method for solving technical problems related to fields such as biological imaging, particle manipulation, drug therapy and intervention. However, because of technical difficulties and the limited technology available for realizing flexible adjustments of sound fields, few studies have reported on this aspect in recent years. Herein, we propose a novel solution, using a Fresnel lens-focused ultrasonic transducer for generating excited-signal-dependent acoustic pressure patterns. Finite element analysis (FEA) is used to predict the performance of a transducer with a Fresnel lens. The Fresnel lens is printed using 3D additive manufacturing. Normalized intensity maps of the acoustic pressure fields are characterized from the Fresnel lens-focused transducer under various numbers of excited-signal cycles. The results demonstrate that under different cycle excitations, a temporal evolution acoustic intensity can be generated and regulated by an ultrasound transducer with a 3D Fresnel lens. This acoustical pattern control method is not only simple to realize but also has considerable application prospects. Full article
