Based on the dynamic receptance method, a vehicle–track–bridge interaction model was developed to calculate the wheel–rail interaction forces and the forces transmitted to the bridge in an elevated urban rail transit system. A prediction model integrating the finite element method–boundary element method (FEM-BEM) and the statistical energy analysis (SEA) method was established to obtain the noise from the main girder, track slab, and wheel–rail system for elevated urban rail transit. The calculated results agree well with the measured data. Thereafter, the noise radiation characteristics of a single source and the total noise of elevated urban rail transit systems with resilient fasteners, trapezoidal sleepers, and steel spring floating slabs were investigated. The results demonstrate that the noise prediction model for elevated urban rail transit that was developed in this study is effective. The diversity of track forms altered the noise radiation field of elevated urban rail transit systems significantly. Compared to monolithic track beds, where the fastener stiffness is assumed to be 60 × 10⁶ N/m (MTB_60), steel spring floating slab tracks (FSTs), trapezoidal sleeper tracks (TSTs), and resilient fasteners with a stiffness of 40 × 10⁶ N/m (MTB_40) and 20 × 10⁶ N/m (MTB_20) can reduce bridge-borne noise by 24.6 dB, 8.8 dB, 2.1 dB, and 4.2 dB, respectively. These vibration-mitigating tracks can decrease the radiated noise from the track slab by −0.7 dB, −0.6 dB, 2.5 dB, and 2.6 dB, but increase wheel–rail noise by 0.4 dB, 0.8 dB, 1.3 dB, and 2.4 dB, respectively. The noise emanating from the main girder and the track slab was dominant in the linear weighting of the total noise of the elevated section with MTBs. For the TST and FST, the radiated noise from the track slab contributed most to the total noise. Full article

Ride comfort is an important requirement that passenger rail vehicles must meet. Carbody–anti-bending system is a relatively new passive method to enhance the ride comfort in passenger rail vehicles with long and light carbody. The resonance frequency of the first bending mode (FBM) of such vehicle is within the most sensitive frequency range that affects ride comfort. Anti-bending bars consist of two bars that are mounted under the longitudinal beams of the carbody chassis using vertical supports. When the carbody bends, the anti-bending bars develop moments in the neutral axis of the carbody opposing the bending of the carbody. In this way, the carbody structure becomes stiffer and the resonance frequency of the FBM can be increased beyond the upper limit of the discomfort range of frequency, improving the ride comfort. The theoretical principle of this method has been demonstrated employing a passenger rail vehicle model that includes the carbody as a free–free Euler–Bernoulli beam and the anti-bending bars as longitudinal springs jointed to the vertical supports. Also, the method feasibility has been verified in the past using an experimental scale demonstrator system. In this paper, a new model of the carbody–anti-bending bar system is proposed by including three-directional elastic elements (vertical and longitudinal direction and rotation in the vertical–longitudinal plane) to model the fastening of the anti-bending bars to the supports and the vertical motion of the anti-bending bars modelled as free–free Euler–Bernoulli beams connected to the elastic elements of the fastening. In the longitudinal direction, the anti-bending bars work as springs connected to the longitudinal elastic elements of the fastening. The modal analysis method is applied to point out the basic properties of the frequency response functions (FRFs) of the carbody–anti-bending bars system, considering the bounce and FBMs of both the carbody and the anti-bending bars. A parametric study of the FRF of the carbody shows that the vertical stiffness of the fastening should be sufficiently high enough to eliminate the influence of the modes of the anti-bending bars upon the carbody response and to reduce the anti-bending bars vibration in the frequency range of interest. Longitudinal stiffness of the elastic elements of the fastening is critical to increase the bending resonance frequency of the carbody out of the sensitive range. Longer anti-bending bars can improve the capability of the anti-bending bars to increase the bending resonance without the risk of interference effects caused by the bounce and bending modes of the anti-bending bars. Full article

With the widespread construction of the subway in the Chinese mainland, the environmental vibration caused by subway operation has attracted increasing attention. Train-induced environmental vibrations can cause structural deformation, uneven settlement of line foundations, and tunnel leakage, affecting the structural safety of lines and foundations. This research focuses on a segment of the Nanchang Metro Line 3, which has been chosen as the subject of investigation. A numerical model was developed to analyze the subway train-induced environmental vibration, employing the finite element method (FEM). Utilizing a numerical model, an investigation was conducted to examine the impact of train speed on the subway train-induced environmental vibration, the train-induced environmental vibration transmission characteristics were analyzed, and the control effects of vibration reduction tracks on train-induced environmental vibration were discussed. Train-induced vibration tests were also conducted on Nanchang Metro Line 3 to verify the control effects of various vibration reduction tracks. The results indicate that the subway train-induced environmental vibration rises as the train speed goes up, and the vibration peaks always appear around 63 Hz. When the train speed doubles, the Z-vibration level increases from about 5.1 dB to 5.9 dB. Subway train-induced environmental vibration shows a fluctuating decreasing trend with increasing distance from the centerline of the tunnel. The Z-vibration level reaches its maximum 4 m away from the centerline of the tunnel. Compared with the embedded sleeper, the vibration-damping fastener exhibits a vibration reduction effect of about 9 dB to 18 dB, the rubber vibration-damping pad exhibits a better vibration reduction effect of about 16 dB to 24 dB, and the steel spring floating plate exhibits the best vibration-damping effect of about 18 dB to 28 dB. The calculated Z-vibration levels are basically consistent with the measured values, indicating the accuracy of the calculated results of the control effects of the vibration reduction tracks. Full article

This paper investigates the potential influence of different aggregates in the concrete mix design on the concrete cone resistance of different types of anchors as well as the anchor stiffness. In fact, bonded anchors with three different adhesives and mechanical anchors and concrete screws of two types were installed in five different concrete mixes and tested in a standard tensile configuration using pull-out tests with wide support resulting in concrete cone failure. A rigorous analysis of both the initial and secant stiffness values of the different anchor types is carried out in a comparative manner. The results of the experimental program show that the anchor stiffnesses are not influenced by the different aggregates in the concrete mixes, but rather by the type of anchor. Finally, this manuscript provides a narrow range of both initial and secant stiffness values with respect to anchor type only. Full article

The heat treatment process is a vital step for manufacturing high-speed railway spring fasteners. In this study, orthogonal experiments were carried out to obtain reliable optimised heat treatment parameters through a streamlined number of experiments. Results revealed that a better comprehensive mechanical performance could be obtained under the following combination of heat treatment parameters: quenching temperature of 850 °C, holding time of 35 min, medium of 12% polyalkylene glycol (PAG) aqueous solution, tempering temperature of 460 °C, and holding time of 60 min. As one of the most important testing criteria, fatigue performance would be improved with increasing strength. Additionally, a high ratio of martensite to ferrite is proven to improve the fatigue limit more significantly. After this heat treatment process, the metallographic microstructure and mechanical properties satisfy the technical requirements for the high-speed railway practical operation. These findings provide a valuable reference for the practical forming process of spring fasteners. Full article

In the traditional pre-joining technology of aircraft panels, bolts are generally employed for pre-joining. Due to the length and width of panels, bilateral manual operations are required to operate bolts. In this case, there are problems such as low work efficiency, unstable quality, cumbersome operation, and inconvenient installation-removal. This paper takes a temporary fastener with one-side installation-removal as a research object and conducts in-depth research on three levels of quick-pressing: unloading, stable self-locking, and easy automatic installation. Firstly, by coordinating the ratchet and the spring, the restoring force of the spring is used to make the cylindrical top-rod rotary and realize the telescopic function to achieve quick loading and unloading of fasteners; subsequently, through the cooperation between the buckle and the spring, loading and unloading self-locking is attained; afterwards, through the threaded joining and the same cylinder design between the external profile components, the convenience of fasteners for automatic transportation is realized. When assembling two thin-walled parts of the aircraft, only continuous one-side pressing of fasteners is needed to carry out the tightening and unloading work, namely, one-pressing installation and one-pressing removal, which could solve the problems caused by the bilateral operation of traditional bolts and part tolerances. After the application of the fasteners into the pre-joining process of aircraft panels, the experiment results have shown that this temporary fastener provided a good clamping effect, could be quickly and efficiently installed and removed by continuous one-pressing, and avoided the problems of complexity and high cost for pre-joining processes. Full article

The fastening spring of a rail fastening system serves as an important connection in transferring the train load to the sleeper via rails on railway tracks. During initial fastening, a large tensile stress exceeding the yield stress can occur in the fastening spring structure, making it vulnerable to fatigue owing to stress fluctuations during train use. The damage caused by fatigue in the fastening springs have been reported for rail fastening systems on several domestic and international routes; however, research on this topic is limited. This study evaluates the fatigue performance of a fastening spring, SPS9 spring steel, developed in Korea based on shape change by performing a sensitivity analysis of various factors, including the heights at the end of the fastening spring and the spring arm, overall lateral width, and the diameter of the cross section of the fastening spring. The modified Goodman fatigue diagram was applied based on the tensile stress on initial fastening and the constant stress range due to a rail vertical displacement caused by train use through finite element analysis. The fatigue analysis showed that the lateral width and diameter factors of the fastening spring are found to be important variables for fatigue performance. Moreover, as the width and diameter increase, the fatigue performance improves significantly. The fatigue safety margin increased from 64% to 82% when the width increased from −20% to +20%, and increased from 54% to 81% with the diameter increase from 13 mm to 18 mm. Full article

This study reviewed some simplified methods of finite element analysis (FEA) for connections in cold-formed steel (CFS) structure, and summarized eight simplified methods divided into three categories. Shear performance tests were performed for six groups of self-piercing riveted (SPR) connection in CFS. A constitutive model of shear behavior for SPR connections was proposed, which was simplified from the load–displacement curve of shear performance test results. The models of SPR connection were established in ABAQUS by the eight simplified methods, and then the FEA results and the test results were compared. The applicable scope of each simplified model was explored, and a simplified method of FEA that was most suitable for the shear behavior of the CFS-SPR connection was proposed. Moreover, the shear performance test of the CFS shear wall with SPR was conducted by considering the rivet spacing, and failure modes and load–deformation curves were obtained. On this basis, numerical models of the CFS-SPR connection shear wall were established. By comparing the test results and the FEA results for the CFS-SPR connection shear wall, the feasibility of a simplified method of FEA applied to the CFS-SPR connection was verified. The main failure modes of the CFS-SPR connection were that the rivet tail pulled out from the bottom sheet and the rivet head pulled over from the top sheet. The SPR connection of the CFS frame could be simplified with a pin or a fastener element, and the SPR connection between the steel frame and the sheathing could be simulated by a Cartesian connector or a Spring2 element. The FEA results were highly similar to the test results for the CFS-SPR shear wall. Full article

In this study, a combination method of field measurements and numerical simulations is used to investigate the mechanism of rail corrugation in the curve’s inner rail in urban rail transit. Firstly, field measurements on rail corrugation and rail vibration characteristics were conducted on the steel spring floating slab track (SSFST) section of a metro line; secondly, a three-dimensional finite element model of the wheelset-SSFST was established, and complex eigenvalue analysis and transient analysis were conducted. It was found that the main frequency of measured rail vertical vibration and the simulated wheel–rail—which simulated normal contact force on the inner rail—correspond to the first wheel–rail unstable vibration mode, as well as to the field-measured rail corrugation passing frequency. Therefore, the strong agreement between the results of the field measurements and the numerical simulation further verifies that the frictional, self-excited vibration of the wheelset-SSFST system on a sharply curved track can cause rail corrugation. When the vertical and lateral fasteners’ stiffness increases, the possibility of rail corrugation decreases. The decrease in vertical stiffness of the steel spring leads to an increase in the possibility of rail corrugation, but the lateral stiffness changes in the steel spring have almost no effect on the possibility of rail corrugation. The increase in the wheel–rail contact friction coefficient leads to a sharp increase in the trend of rail corrugation occurrence and causes a decrease in the rail corrugation wave-length. Full article

The track fasteners may be damaged by fatigue and impact load during long-term subway operation, resulting in the failure of the connecting components between the rail and the track plate, and the spacing of rail support becomes larger, resulting in an increase in its dynamic deformation, affecting the subway vehicle’s running performance, and, in severe cases, endangering the vehicle’s running safety. A vehicle-subway track system model was created to study the running performance of subway vehicles when fasteners failed. A multi-rigid, body spring damping system is used to describe the vehicle system. The model for the track system is created using the finite element method (FEM), and the vehicle dynamic performances under various fastener failure scenarios are calculated, as well as the vehicle’s running comfort and safety in various scenarios. The findings show that fastener failure has little impact on the vehicle’s running comfort but it has a significant impact on the vehicle’s wheel unloading ratio. Full article

Using bulk formulas, two-year platform (fastened to the seabed) hourly observations from 2016 to 2017 in the East China Sea (121.6° E, 32.4° N) are used to investigate the role of the tide-induced surface elevation in changing the fixed observational height and modifying the momentum and air-sea turbulent heat fluxes. The semidiurnal tide-dominated elevation anomalies ranging from −3.6 to 3.9 m change the fixed platform observational height. This change causes hourly differences in the wind stress and latent and sensible heat fluxes between estimates with and without considering surface elevation, with values ranging from −1.5 × 10⁻³ Nm⁻², −10.2 Wm⁻², and −3.6 Wm⁻² to 2.2 × 10⁻³ Nm⁻², 8.4 Wm⁻², and 4.6 Wm⁻², respectively. More significant differences occur during spring tides. The differences show weak dependence on the temperature, indicating weak seasonal variations. The mean (maximum) difference percentage relative to the mean magnitude is approximately 3.5% (7%), 1.5% (3%), and 1.5% (3%) for the wind stress and latent and sensible heat fluxes, respectively. The boundary layer stability (BLS) can convert from near-neutral conditions to stable and unstable states in response to tide-induced changes in the observational height, with a probability of occurrence of 2%. Wind anomalies play dominant roles in determining the hourly anomalies of the latent heat flux, regardless of the state of the BLS. Extreme cases, including the cold air outbreak in 2016, tropical cyclones Meranti in 2016, and Ampil in 2018, are also examined. This study will facilitate future observation-reanalysis comparisons in the studied coastal region where ocean–atmosphere-land interactive processes are significant. Full article

Aircraft panel assembly mainly includes the pre-joining process and the riveting process. In addition, the traditional pre-joining process is mainly executed by bolts, which has problems such as the large tightening torque, inconvenient bilateral tightening, heavy workload, and inconvenient loading and unloading. To solve the above-mentioned problems, a research of new temporary fastener is performed deeply from three levels of quick installation, labor-saving, and reversible ability. This involves (a) employing the lever mechanism and the rapid expansion anchor to implement the rapid clamping and disassembly of working processes by labor-saving; (b) integrating the adjusting spring to overcome the tolerances of parts; and (c) building up the space-cross slide rails to provide the axial clamping forces and the reversible forces. The application of designed fasteners was employed into the production of aircraft panel, and the error between theoretical and experimental values was less than 10%. Besides this, the result showed the good effect in panel clamping and the reliable processes of loading and unloading installation, and will greatly reduce the complexity of pre-joining process, the difficulty of installation, and the comprehensive cost. Full article

In this study, we present the Diverse Holding and Release Mechanism Can Satellite (DHRM CanSat) platform developed by the Space Technology Synthesis Laboratory (STSL) at Chosun University, South Korea. This platform focuses on several types of holding and release mechanisms (HRMs) for application in deployable appendages of nanosatellites. The objectives of the DHRM CanSat mission are to demonstrate the design effectiveness and functionality of the three newly proposed HRMs based on the burn wire triggering method, i.e., the pogo pin-type HRM, separation nut-type HRM, and Velcro tape-type HRM, which were implemented on deployable dummy solar panels of the CanSat. The proposed mechanisms have many advantages, including a high holding capability, simultaneous constraints in multi-plane directions, and simplicity of handling. Additionally, each mechanism has distinctive features, such as spring-loaded pins to initiate deployment, a plate with a thread as a nut for a high holding capability, and a hook and loop fastener for easy access to subsystems of the satellite without releasing the holding constraint. The design effectiveness and functional performance of the proposed mechanisms were demonstrated through an actual flight test of the DHRM CanSat launched by a model rocket. Full article

The surface of a quenched and tempered spring steel may have a decarburized layer from which the carbon component has been reduced. The fatigue strength of the decarburized layer is low compared to the base metal, which can easily develop fatigue cracks. Recently, fatigue failure was reported in the tension clamp (SKL 15) of the DFF-300 rail fastening system during use on one urban transit route in South Korea. As a result of measuring the depth of the decarburized layer of the SKL 15 tension clamp where the fatigue failure occurred, a decarburized layer thinner than the manufacturer’s maximum allowable decarburized layer was found in one of the eight tension clamps. To check the depth of the decarburized layer where the fatigue crack may have initiated, the decarburized layer was assumed to be the initial crack, and fatigue crack initiation was assessed based on the linear elastic fracture mechanics. The manufacturer’s maximum allowable decarburized layer depth of 0.2 mm may result in fatigue cracks. Full article

Track–bridge interaction (TBI) is an increasingly essential consideration for the design and operation of railway bridges, especially for the innovative bridge structure systems that constantly spring up over the years. This paper focuses on the characteristics of additional forces in continuous welded rails (CWRs) on the 3 × 70 m integral rigid-frame bridge of the Fuzhou–Xiamen High-Speed Railway, which is a novel high-speed railway (HSR) bridge structure system in China. The differential equations of rail stress and displacement are first investigated and an integrative analysis model comprising of rail, track, bridge and piers is then established. Secondly, the characteristics of representative additional forces are illustrated and the influences of different design parameters are discussed in detail. Furthermore, suitable rail fasteners, optimal layout schemes of adjacent bridges and reasonable stiffness of piers are also studied. The results indicate that the additional expansion force accounts for the largest proportion of additional forces in integral rigid-frame bridges and that resistance reduction obviously weakens the various additional forces caused by the TBI effect, while the broken gap of the rail increases greatly. Small resistance fasteners are recommended to be applied onto this new type of HSR line as these provide reductions in additional stresses of CWRs compared to WJ-8 fasteners. The additional rail stresses after adopting an adjacent span scheme of 4 × 32 m simply supported beams are less than the corresponding stresses in other schemes. The results also show that there is a strong correlation between the minimum threshold value of the pier stiffness and the longitudinal resistance of HSR lines for the integral rigid-frame bridge. This work could serve as a valuable reference for detailed design and safety evaluation of integral rigid-frame bridges. Full article
