When a CMOS (Complementary Metal–Oxide–Semiconductor) imaging system operates at a high frame rate or a high line rate, the exposure time of the imaging system is limited, and the acquired image data will be dark, with a low signal-to-noise ratio and unsatisfactory sharpness. Therefore, in order to improve the visibility and signal-to-noise ratio of remote sensing images based on CMOS imaging systems, this paper proposes a low-light remote sensing image enhancement method and a corresponding ZYNQ (Zynq-7000 All Programmable SoC) design scheme called the BGIR (Bilateral-Guided Image Restoration) algorithm, which uses an improved multi-scale Retinex algorithm in the HSV (hue–saturation–value) color space. First, the RGB image is used to separate the original image’s H, S, and V components. Then, the V component is processed using the improved algorithm based on bilateral filtering. The image is then adjusted using the gamma correction algorithm to make preliminary adjustments to the brightness and contrast of the whole image, and the S component is processed using segmented linear enhancement to obtain the base layer. The algorithm is also deployed to ZYNQ using ARM + FPGA software synergy, reasonably allocating each algorithm module and accelerating the algorithm by using a lookup table and constructing a pipeline. The experimental results show that the proposed method improves processing speed by nearly 30 times while maintaining the recovery effect, which has the advantages of fast processing speed, miniaturization, embeddability, and portability. Following the end-to-end deployment, the processing speeds for resolutions of 640 × 480 and 1280 × 720 are shown to reach 80 fps and 30 fps, respectively, thereby satisfying the performance requirements of the imaging system. Full article

Identifying the scriptwriter in historical manuscripts is crucial for historians, providing valuable insights into historical contexts and aiding in solving historical mysteries. This research presents a robust deep learning system designed for classifying historical manuscripts by writer, employing intelligent feature selection and vision transformers. Our methodology meticulously investigates the efficacy of both handcrafted techniques for feature identification and deep learning architectures for classification tasks in writer identification. The initial preprocessing phase involves thorough document refinement using bilateral filtering for denoising and Otsu thresholding for binarization, ensuring document clarity and consistency for subsequent feature detection. We utilize the FAST detector for feature detection, extracting keypoints representing handwriting styles, followed by clustering with the k-means algorithm to obtain meaningful patches of uniform size. This strategic clustering minimizes redundancy and creates a comprehensive dataset ideal for deep learning classification tasks. Leveraging vision transformer models, our methodology effectively learns complex patterns and features from extracted patches, enabling precise identification of writers across historical manuscripts. This study pioneers the application of vision transformers in historical document analysis, showcasing superior performance on the “ICDAR 2017” dataset compared to state-of-the-art methods and affirming our approach as a robust tool for historical manuscript analysis. Full article

Contrast enhancement techniques serve the purpose of diminishing image noise and increasing the contrast of relevant structures. In the context of medical images, where the differentiation between normal and abnormal tissues can be quite subtle, precise interpretation might become challenging when noise levels are relatively elevated. The Fast Local Laplacian Filter (FLLF) is proposed to deliver a more precise interpretation and present a clearer image to the observer; this is achieved through the reduction of noise levels. In this study, the FLLF strengthened images through its unique contrast enhancement capabilities while preserving important image details. It achieved this by adapting to the image’s characteristics and selectively enhancing areas with low contrast, thereby improving the overall visual quality. Additionally, the FLLF excels in edge preservation, ensuring that fine details are retained and that edges remain sharp. Several performance metrics were employed to assess the effectiveness of the proposed technique. These metrics included Peak Signal-to-Noise Ratio (PSNR), Mean Squared Error (MSE), Root Mean Squared Error (RMSE), Normalization Coefficient (NC), and Correlation Coefficient. The results indicated that the proposed technique achieved a PSNR of 40.12, an MSE of 8.6982, an RMSE of 2.9492, an NC of 1.0893, and a Correlation Coefficient of 0.9999. The analysis highlights the superior performance of the proposed method when contrast enhancement is applied, especially when compared to existing techniques. This approach results in high-quality images with minimal information loss, ultimately aiding medical experts in making more accurate diagnoses. Full article

Automatic leaf disease detection techniques are effective for reducing the time-consuming effort of monitoring large crop farms and early identification of disease symptoms of plant leaves. Although crop tomatoes are seen to be susceptible to a variety of diseases that can reduce the production of the crop. In recent years, advanced deep learning methods show successful applications for plant disease detection based on observed symptoms on leaves. However, these methods have some limitations. This study proposed a high-performance tomato leaf disease detection approach, namely attention-based dilated CNN logistic regression (ADCLR). Firstly, we develop a new feature extraction method using attention-based dilated CNN to extract most relevant features in a faster time. In our preprocessing, we use Bilateral filtering to handle larger features to make the image smoother and the Ostu image segmentation process to remove noise in a fast and simple way. In this proposed method, we preprocess the image with bilateral filtering and Otsu segmentation. Then, we use the Conditional Generative Adversarial Network (CGAN) model to generate a synthetic image from the image which is preprocessed in the previous stage. The synthetic image is generated to handle imbalance and noisy or wrongly labeled data to obtain good prediction results. Then, the extracted features are normalized to lower the dimensionality. Finally, extracted features from preprocessed data are combined and then classified using fast and simple logistic regression (LR) classifier. The experimental outcomes show the state-of-the-art performance on the Plant Village database of tomato leaf disease by achieving 100%, 100%, 96.6% training, testing, and validation accuracy, respectively, for multiclass. From the experimental analysis, it is clearly demonstrated that the proposed multimodal approach can be utilized to detect tomato leaf disease precisely, simply and quickly. We have a potential plan to improve the model to make it cloud-based automated leaf disease classification for different plants. Full article

Bilateral Filtering (BF) is an effective edge-preserving smoothing technique in image processing. However, an inherent problem of BF for image denoising is that it is challenging to differentiate image noise and details with the range kernel, thus often preserving both noise and edges in denoising. This letter proposes a novel Dual-Histogram BF (DHBF) method that exploits an edge-preserving noise-reduced guidance image to compute the range kernel, removing isolated noisy pixels for better denoising results. Furthermore, we approximate the spatial kernel using mean filtering based on column histogram construction to achieve constant-time filtering regardless of the kernel radius’ size and achieve better smoothing. Experimental results on multiple benchmark datasets for denoising show that the proposed DHBF outperforms other state-of-the-art BF methods. Full article

In view of traditional point-line feature visual inertial simultaneous localization and mapping (SLAM) system, which has weak performance in accuracy so that it cannot be processed in real time under the condition of weak indoor texture and light and shade change, this paper proposes an inertial SLAM method based on point-line vision for indoor weak texture and illumination. Firstly, based on Bilateral Filtering, we apply the Speeded Up Robust Features (SURF) point feature extraction and Fast Nearest neighbor (FLANN) algorithms to improve the robustness of point feature extraction result. Secondly, we establish a minimum density threshold and length suppression parameter selection strategy of line feature, and take the geometric constraint line feature matching into consideration to improve the efficiency of processing line feature. And the parameters and biases of visual inertia are initialized based on maximum posterior estimation method. Finally, the simulation experiments are compared with the traditional tightly-coupled monocular visual–inertial odometry using point and line features (PL-VIO) algorithm. The simulation results demonstrate that the proposed an inertial SLAM method based on point-line vision for indoor weak texture and illumination can be effectively operated in real time, and its positioning accuracy is 22% higher on average and 40% higher in the scenario that illumination changes and blurred image. Full article

At present, pointer meters are still widely used because of their mechanical stability and electromagnetic immunity, and it is the main trend to use a computer vision-based automatic reading system to replace inefficient manual inspection. Many correction and recognition algorithms have been proposed for the problems of skew, distortion, and uneven illumination in the field-collected meter images. However, the current algorithms generally suffer from poor robustness, enormous training cost, inadequate compensation correction, and poor reading accuracy. This paper first designs a meter image skew-correction algorithm based on binary mask and improved Mask-RCNN for different types of pointer meters, which achieves high accuracy ellipse fitting and reduces the training cost by transfer learning. Furthermore, the low-light enhancement fusion algorithm based on improved Retinex and Fast Adaptive Bilateral Filtering (RBF) is proposed. Finally, the improved ResNet101 is proposed to extract needle features and perform directional regression to achieve fast and high-accuracy readings. The experimental results show that the proposed system in this paper has higher efficiency and better robustness in the image correction process in a complex environment and higher accuracy in the meter reading process. Full article

The range kernel of bilateral filter degrades image quality unintentionally in real environments because the pixel intensity varies randomly due to the noise that is generated in image sensors. Furthermore, the range kernel increases the complexity due to the comparisons with neighboring pixels and the multiplications with the corresponding weights. In this paper, we propose a noise-aware range kernel, which estimates noise using an intensity difference-based image noise model and dynamically adjusts weights according to the estimated noise, in order to alleviate the quality degradation of bilateral filters by noise. In addition, to significantly reduce the complexity, an approximation scheme is introduced, which converts the proposed noise-aware range kernel into a binary kernel while using the statistical hypothesis test method. Finally, blue a fully parallelized and pipelined very-large-scale integration (VLSI) architecture of a noise-aware bilateral filter (NABF) that is based on the proposed binary range kernel is presented, which was successfully implemented in field-programmable gate array (FPGA). The experimental results show that the proposed NABF is more robust to noise than the conventional bilateral filter under various noise conditions. Furthermore, the proposed VLSI design of the NABF achieves 10.5 and 95.7 times higher throughput and uses 63.6–97.5% less internal memory than state-of-the-art bilateral filter designs. Full article

High dynamic range (HDR) imaging is used to represent scenes with a greater dynamic range of luminance on a standard dynamic range display. Usually, HDR images are synthesized through base–detail separations. The base layer is used for tone compression and the detail layer is used for detail preservation. The representative detail-preserved algorithm iCAM06 has a tendency to reduce the sharpness of dim surround images, because of the fixed edge-stopping function of the fast-bilateral filter (FBF). This paper proposes a novel base–detail separation and detail compensation technique using the contrast sensitivity function (CSF) in the segmented frequency domain. Experimental results show that the proposed rendering method has better sharpness features and image quality than previous methods correlated by the human visual system. Full article

A reasonable plant type is an essential factor for improving canopy structure, ensuring a reasonable expansion of the leaf area index and obtaining a high-quality spatial distribution of light. It is of great significance in promoting effective selection of the ecological breeding index and production practices for maize. In this study, a method for calculating the phenotypic traits of the maize canopy in three-dimensional (3D) space was proposed, focusing on the problems existing in traditional measurement methods in maize morphological structure research, such as their complex procedures and relatively large error margins. Specifically, the whole maize plant was first scanned with a FastSCAN hand-held scanner to obtain 3D point cloud data for maize. Subsequently, the raw point clouds were simplified by the grid method, and the effect of noise on the quality of the point clouds in maize canopies was further denoised by bilateral filtering. In the last step, the 3D structure of the maize canopy was reconstructed. In accordance with the 3D reconstruction of the maize canopy, the phenotypic traits of the maize canopy, such as plant height, stem diameter and canopy breadth, were calculated by means of a fitting sphere and a fitting cylinder. Thereafter, multiple regression analysis was carried out, focusing on the calculated data and the actual measured data to verify the accuracy of the calculation method proposed in this study. The corresponding results showed that the calculated values of plant height, stem diameter and plant width based on 3D scanning were highly correlated with the actual measured data, and the determinant coefficients R² were 0.9807, 0.8907 and 0.9562, respectively. In summary, the method proposed in this study can accurately measure the phenotypic traits of maize. Significantly, these research findings provide technical support for further research on the phenotypic traits of other crops and on variety breeding. Full article
