The stress distribution after excavation becomes highly complex in large-span bifurcated tunnel sections commonly found in urban underground interchanges. This study investigates the stress evolution induced by the excavation of large-span and bifurcated tunnel, focusing on the 32.17 m maximum-span section of the Shenzhen Baopeng–Shahe Underground Interchange. The results show that stress concentration near the tunnel walls of large-span sections is greater than that in sections with bifurcated tunnels. Adjusting the burial depth of the large-span tunnel, the influence of stiff layer thickness on the redistribution of surrounding rock stress was analyzed. When the tunnel is buried at a shallow depth and the stiff layer thickness is small, the maximum tangential stress of the surrounding rock occurs at the stiff layer boundary, and the surrounding rock remains entirely elastic. In large-span tunnels, as the thickness of the stiff layer increases from 5 m to 20 m, the stress relaxation zone grows from 0 m to 8 m, and the stress-bearing zone expands from 10 m to 27 m. As the burial depth increases and the stiff layer thickness grows, the maximum tangential stress shifts to within the stiff layer. In this case, the tangential stress distribution at the stiff layer boundary becomes non-smooth. Therefore, an appropriate stiff layer thickness must be selected to prevent the surrounding rock from entering a plastic state. The findings provide theoretical guidance and technical support for the design of large-scale underground interchange bifurcated tunnels, advancing the intelligent and scientific development of urban underground transportation facilities and offering significant practical and social benefits. Full article

As transportation networks continue to expand into mountainous regions with high seismic activity, ensuring the seismic safety of tunnels crossing active faults has become increasingly crucial. This study aimed to enhance our understanding of the impact of fault zones on the seismic behavior of tunnels and to provide optimized seismic design recommendations through a comprehensive experimental and numerical investigation. The focus of this research is the Xiangyangshan Highway Tunnel in China, which intersects a significant longitudinal fault. Large-scale shake table tests were performed on 1:100 scale physical models of the tunnel to analyze the seismic responses under various ground motion excitations. Detailed three-dimensional finite difference models were developed in FLAC3D and calibrated based on the shake table results. The tests indicated that strains, earth pressures, and accelerations experience localized amplification within 10–20 m of the fault interface compared to undisturbed ground sections. Common seismic mitigation measures, such as rock grouting, seismic joints, and shock absorption layers, were observed to effectively reduce the amplified seismic demands. Grouting, in particular, led to an average reduction of up to 56.3% in circumferential strain and 38.5% in earth pressure. It was concluded that 6 m thick grouted zones and 20 cm thick rubber interlayers between tunnel lining shells provide optimal structural reinforcement against the effects of fault zones. This study provides valuable insights for improving the seismic resilience of underground transportation corridors in seismically active regions. Full article

With the development of infrastructure construction in mountainous areas, the number of new extra-long tunnels is increasing. However, these tunnels often face the challenge of complex and variable surrounding rock grades, resulting in a large number of overbreak and underbreak due to the untimely adjustment of smooth blasting parameters. This study focuses on the optimization of the peripheral hole charging structure and blasting parameters for extra-long hard rock tunnels, aiming to improve the effectiveness of smooth blasting technology. The results of this study demonstrate a significant improvement in the effect of smooth blasting after implementing bidirectional polymerization blasting in the tunnel. A comparison between the bidirectional shaped charge and spaced decoupled charge blasting reveals that the former yields better results. To obtain accurate data on the tunnel section profile during excavation, a laser cross-section meter is used for measurement. Furthermore, this study quantitatively compares the optimization effect of smooth blasting parameters. The multifractal characteristics of the tunnel profile overbreak point sequences are analyzed under different smooth blasting schemes using the multifractal detrended fluctuation analysis (MF-DFA) method. It is found that both the spaced decoupled charge and the bidirectional shaped charge blasting exhibit multifractal features in the overbreak measurement point sequences. The calculation results of the multifractal features of the tunnel profile under different smooth blasting plans are in line with the actual situation. Full article

In this paper, the aim is to achieve safe, rapid excavation of an extra-long, large-cross-section highway tunnel in Eastern Tianshan, as well as to reduce production costs, simplify production processes, reduce cycle time, and improve production efficiency. In this study, we explored a new technology for smooth blasting without a detonating cord. A series of sympathetic detonation experiments were conducted in the tunnel face to determine critical distances. The critical distance for No. 2 rock emulsion explosive under blasthole constraints was successfully measured to be approximately 1.0–1.1 m. Based on the critical distance, a new charging structure was designed for tunnel excavation. To assess the influence of the new charging structure on blasting performance, its economic benefits, and its feasibility, full-section tests were performed in the East Tianshan Tunnel. The application of the new charging structure produced good smooth blasting results. It not only simplified the charging process and produced smooth blasting without detonating cord in peripheral holes, but also guaranteed normal excavation, an appropriate tunnel profile, and reasonable overbreak and underbreak volumes. This had remarkable economic benefits and possesses better promotional value. Full article

The calculation of load and surrounding rock pressure of extra-large-section tunnels serves as an important premise for the design and construction of tunnel projects with extra-large sections. Based on the large-span section of the Shenzhen Liantang Tunnel (China), which is the largest highway tunnel in the world to date, this paper discusses the challenges existing in the calculation method of state load and surrounding rock pressure for extra-large-section tunnels and puts forward a novel calculation method for process load, which is suitable for extra-large-section highway tunnels. In the current work, we derived the related application correlations and improved the specific application steps, methods, and project models of the proposed calculation method. Both the rationality and feasibility of the calculation method were verified from a practical perspective by comparing the on-site data of surrounding rock pressure at the Liantang Tunnel with the calculated load, which provides a fundamental basis for the process design of tunnels. Full article
