To simulate the fracture behavior of members during structural collapse, this paper proposes a member fracture simulation algorithm that integrates the plastic hinge model with a ductile fracture damage model within the member discrete element method (MDEM) framework. The coupling is achieved by computing stresses at the four most unfavorable edge points of the contact section and using the minimum fracture strain as the section-level failure criterion. The algorithm is validated against a cantilever beam fracture example, yielding results in good agreement with reference data under two yield stress conditions. The fracture algorithm is then embedded as a self-contained module into an adaptively coupled DEM/FEM algorithm and applied to simulate the shaking table collapse test of a single-layer spherical reticulated shell. The simulation predicts structural collapse at a peak ground acceleration (PGA) of 2268 gal—consistent with the experimental value—with 126 members fractured at collapse onset, and reproduces the observed fracture sequence in which first-ring diagonal members near the supports fail progressively from the bottom upward. The proposed framework provides a computationally robust and practically deployable tool for collapse analysis of large-span reticulated structures, with direct implications for progressive-collapse prevention in seismic design and post-event structural forensic investigation of collapse mechanisms. Full article

Coal-bearing tight gas and deep coalbed methane (CBM) widely co-occur in China, and integrated commingled production outperforms separate development. Conventional separated simulation fails to capture coupled reservoir–wellbore gas–water flow. This study develops an integrated geomechanical coupled numerical model with multi-scale fractures and multi-phase wellbore flow: tight gas reservoirs use a stress-sensitive single-porosity model, deep CBM adopts a dual-porosity model for matrix desorption, and EDFM characterizes non-Darcy flow in hydraulic fractures. The Gray gas column and liquid column methods calculate layered bottomhole pressure according to reservoir vertical distribution, and matrix bordering solves the whole coupled system. Validated by field data of Well C-1 in Shanxi, the model yields average relative errors of 8.76% for daily gas output and 2.92% for daily water output. Sensitivity analysis on Well C-2 indicates vertical reservoir stacking controls interlayer pressure difference, and commingled gas curves show dual peaks with shifting dominant gas sources over production stages. A 3.9% rise in deep coalbed methane gas content significantly boosts mid-term peak production and cumulative gas output, making reservoir gas content the dominant geological factor governing commingled production performance. A 120.0% increase in tight gas saturation only delivers a slight uplift in cumulative production under low-porosity conditions. Elevated reservoir stress sensitivity triggers a cumulative gas production reduction of over 50%. Cumulative gas output varies proportionally with hydraulic fracture length, while fracture network width brings mismatched production improvement due to pressure drawdown funnel effects. Therefore, hydraulic fracturing operations should prioritize extending artificial fractures to expand the drainage area of commingled wells. Schemes with constant bottomhole flowing pressure and constant gas rate exert marginal influences on ultimate cumulative production and can be flexibly switched on site. To stabilize daily gas deliverability throughout the early, middle and late production stages, a bottomhole pressure drawdown rate of 0.05 MPa/d or a fixed daily gas rate of 4000 m³/d is recommended. This work provides theoretical support for optimizing commingled development of superimposed tight gas and deep CBM reservoirs. Full article

Concrete readily develops cracks under service loads, which poses severe risks to the overall safety of engineering structures. In this work, the discrete element method (DEM) integrated with PFC2D 5.0 numerical software is adopted to construct a mesoscale concrete numerical model containing pre-existing internal fractures, and uniaxial compressive loading simulations are subsequently carried out. Unlike previous studies that predominantly examined isolated fracture parameters, this work systematically investigates the coupled effects of fracture inclination angle, length, and quantity on crack propagation mechanisms at the mesoscale, and for the first time establishes a quantitative relationship between microcrack spatial distribution patterns and macroscopic mechanical degradation. Parametric analyses are performed to quantify the influences of fracture geometric characteristics, including fracture inclination angle (30°, 45°, 60°), fracture length (short, long and extra-long), fracture quantity (4, 8 and 16), as well as the comparison between intact and fractured concrete specimens. The fracture quantities of 4, 8, and 16 are selected to represent low, medium, and high levels of initial defect density within the concrete matrix, corresponding to approximately 1%, 2%, and 4% of the total specimen area, respectively, thereby enabling a systematic investigation into the progressive deterioration of mechanical performance with increasing internal damage severity. The whole evolution process of crack initiation, crack propagation and ultimate failure patterns of concrete is systematically explored. Numerical results reveal that specimens with larger fracture angles exhibit higher compressive strength yet generate abundant newly formed microcracks, whereas low-angle prefabricated fractures are prone to triggering abrupt brittle failure. Specimens embedded with shorter fractures achieve superior mechanical strength and develop denser, more intensive microcrack distributions; in contrast, long pre-existing fractures drastically degrade compressive strength while limiting the generation of secondary cracks. Reducing the number of internal defects simultaneously improves compressive strength and expands the coverage range of the induced fracture network. Specimens with 16 prefabricated fractures deliver the weakest mechanical performance, owing to the excessively high initial defect density inside the matrix. In comparison with fractured samples, intact concrete without pre-set fractures achieves better comprehensive performance in terms of compressive strength, deformation compatibility and uniform microcrack development. A core conclusion drawn from this study is that the total quantity of microcracks cannot serve as a direct indicator to evaluate the damage degradation degree of concrete; instead, the spatial distribution pattern of microcracks dominates the deterioration level. Evenly scattered microcrack populations maintain relatively high residual strength, whereas the concentrated coalescence of microcracks into continuous penetrating macrocracks leads to an abrupt decline in structural load-carrying capacity. The findings of this research can provide theoretical references for stability evaluation and safety diagnosis of defective concrete structures in practical engineering. Full article

The exploitation of deep coalbed methane is of great significance for easing China’s energy supply pressure and realizing the “Dual Carbon” goals. However, local grid refinement simulation methods for coalbed methane cannot well capture the characteristics of deep coalbed methane reservoirs, including strong stress sensitivity and high brittleness. To tackle this issue, this paper develops a novel numerical simulation approach dedicated to deep coalbed methane development. Integrated with the fluid–solid coupling effect in rock mechanics, this approach considers the interporosity flow between matrix pores and cleat fractures as well as that between cleat fractures and hydraulic fractures, and establishes a multi-dimensional coupled simulation framework on the basis of the dual-porosity single-permeability model and embedded discrete fracture model. Simulation results show that compared with the local grid refinement model, the daily gas production curve simulated by the proposed method is more consistent with the actual field curve. The local grid refinement method fails to accurately characterize the specific morphology of hydraulic fractures. The average relative error of the local grid refinement model reaches 25.61%, while that of the model in this paper is only 7.54%, representing an accuracy improvement of 18.07%. Sensitivity analysis draws the following conclusions: reservoir gas content is the dominant geological factor governing deep coalbed methane output, and raising reservoir gas content can boost cumulative gas production by 45.77%; hydraulic fracture length mainly affects gas production performance in the middle and late production stages, while fracture conductivity dominates early-stage productivity. This method can fully characterize the coupled flow behaviors of three types of media (matrix pores, cleat fractures and hydraulic fractures), and offers solid technical support for productivity forecasting and development scheme optimization of deep coalbed methane reservoirs. Full article

The severe heterogeneity of carbonate reservoirs poses a significant challenge to matrix acidizing, making the achievement of uniform stimulation across multiple strata a persistent engineering difficulty. To address this, a numerical simulation program for self-diverting acid (SDVA) in multi-layered rocks was developed based on the two-scale continuum model and the open-source framework FMOT. This study primarily investigates the regulatory effects of heterogeneity intensity and initial temperature on uniform acidizing performance. The results indicate that, compared to conventional HCl, SDVA significantly enhances the uniform acidizing efficacy in low-permeability layers. Furthermore, SDVA induces a unique “competitive propagation” pattern among multi-layered rocks, which is fundamentally distinct from the fluid diversion behavior of HCl. As the formation heterogeneity intensity increases, the resulting wormhole morphology becomes increasingly complex, accompanied by more pronounced inter-layer flow competition. Moreover, unlike HCl, whose flow distribution pattern and wormhole morphology are insensitive to thermal changes, the acidizing performance of SDVA exhibits marked temperature dependence. At lower temperatures, the competitive propagation pattern diminishes significantly; however, as the temperature rises, the inter-layer fluid competition becomes progressively intensified, and this competitive state persists until the ultimate breakthrough of the rock matrix. Full article

Natural fractures can significantly affect fluid seepage behavior and development performance in tight formations. However, the optimal configurations and performance of oriented horizontal wells under various natural fracture scenarios remain insufficiently understood. Numerical simulation models for a fractured horizontal well in a five-spot well pattern were established based on the embedded discrete fracture model (EDFM) to consider the coupled effects of hydraulic fractures and natural fractures. Optimization analyses were performed under different natural fracture conditions, with cumulative oil production used as the main evaluation criterion. The results indicate that natural fractures play a significant role in determining the optimal horizontal well orientation. For reservoirs without natural fractures and those with low- to medium-density single-set natural fractures, the optimal horizontal well orientation is perpendicular to the maximum horizontal stress direction. In contrast, for high-density single-set natural fracture systems, a slight rotation of the horizontal wellbore improves cumulative oil production, with an optimal orientation angle of approximately 15° identified in this work. For conjugate fracture networks, the influence of well orientation becomes more significant, and the optimal orientation angle varies with fracture density, ranging from 15° to 45°. This study indicates that the horizontal wellbore trajectory design may highly rely on the characteristics of natural fractures. Therefore, thorough and accurate characterization of natural fractures should be conducted before optimizing the orientation of fractured horizontal wells. The findings of this work provide theoretical guidance for the placement of fractured horizontal wellbores in naturally fractured tight formations. Full article

Shale oil is a vital unconventional resource. Large-scale hydraulic fracturing serves as the core technology for the efficient development of shale oil reservoirs. Well testing can be applied to characterize the reservoir parameters of fractured shale formations. Nevertheless, conventional well testing approaches fail to account for numerous discrete fractures and complex formation geometries. Based on the embedded discrete fracture model (EDFM)—an effective tool for simulating flow in discrete fractures—this work proposes a numerical well testing approach for horizontal wells in hydraulically fractured shale reservoirs. The effects of fracture permeability, number of fracture clusters, matrix permeability, and water saturation on well testing curves are also investigated. The results showed that the parameters such as the main fracture permeability, the number of fracture clusters, and the matrix permeability all have significant effects on the well test curves. When the permeability of main fractures exceeds 20D, radial flow characteristics appear in Stage V. For the distance between fracturing intervals and pressure monitoring points within 0 m to 200 m, it imposes the most significant impact on Stage I and Stage II. The half-length of main fractures, the SRV extent in the Y-direction, and boundary conditions mainly affect Stage VI and Stage VII. Full article

Progressive collapse represents a catastrophic failure mode for reinforced concrete (RC) structures, yet the use of architected materials to mitigate this risk remains largely unexplored. This study presents a numerical feasibility investigation of RC beam–column sub-assemblages with auxetic metamaterial inserts embedded in critical joint regions. A hierarchical multiscale framework is developed to link the effective behavior of auxetic metamaterials with structure-scale collapse response. The framework couples macroscale structural analysis with mesoscale fracture simulations through a hybrid voxel–Voronoi discretization strategy. Baseline finite element models are validated against published experimental results for conventional RC specimens, while the auxetic-enhanced configurations are evaluated numerically. Under high tensile strain, the auxetic insert expands laterally because of its negative Poisson’s ratio and generates a localized confining stress field within the surrounding concrete. The simulations suggest that this mechanism may promote crack bifurcation, redistribute localized cracking into a more distributed damage pattern, and delay compressive crushing and crack coalescence. Compared with the corresponding conventional RC configurations, the auxetic-enhanced models predict a 25% increase in load redistribution capacity and a 20% enhancement in deformation ductility. These predicted improvements require future experimental validation using physical auxetic-enhanced RC specimens. The findings provide a computational basis for exploring material-by-design strategies aimed at improving the robustness of critical RC joint regions under progressive collapse demands. Full article

Long-term safety assessment of deep geological repositories for spent nuclear fuel requires explicit evaluation of thermo-mechanical (TM) processes induced by decay heat and their influence on fractured host rock. A safety-relevant, though low-probability, scenario concerns shear reactivation of fractures intersecting deposition holes, which could compromise canister integrity if displacement exceeds design limits. This study presents a three-dimensional discrete element modelling approach to analyze the thermal evolution of the Forsmark repository (Sweden) and the associated long-term response of a discrete fracture network (DFN) during the post-closure phase. The model explicitly represents repository panel, deterministic deformation zones, and a stochastically generated fracture network embedded in a bonded particle assembly representing the rock for Particle Flow Code (PFC) numerical simulations. Time-dependent heat release from spent nuclear fuel canisters is implemented using a physically based decay power function. A deposition panel-scale heat-loading formulation accounts for deposition-hole and tunnel spacing. Two emplacement scenarios are analyzed: (a) a simultaneous all-panel heating scenario, used as a conservative bounding case, and (b) a sequential panel heating scenario representing staged emplacement and closure. The simulations show that temperature and thermally induced stress evolution are sensitive to the emplacement and closure sequence. Sequential heating produces a more gradual thermal build-up and lower peak temperatures than simultaneous heating, indicating that thermal and stress perturbations in the host rock can be influenced not only through repository design, but also by operational strategy. Thermally induced fracture shear displacement displays a systematic temporal response. Fractures located within the deposition panel footprint develop shear displacement rapidly during the early post-closure period, reaching peak values at approximately 200 years, followed by gradual relaxation as temperatures decline. The average peak shear displacement on fractures is on the order of 2–3 mm, while fractures outside the panel footprint show smaller early-time displacements and a more prolonged long-term response. All simulated shear displacements remain more than one order of magnitude below the commonly cited canister damage threshold for Forsmark of approximately 50 mm, even for the conservative simultaneous heating case. These results indicate that thermally induced fracture shear is unlikely to cause direct mechanical damage to canisters. At the same time, the persistence of residual shear displacement after heating implies permanent fracture dilation, which may influence long-term hydraulic properties and indirectly affect processes such as groundwater flow and canister corrosion. The modelling framework and results presented here were conducted for review purposes independently from the Swedish safety case, and provide a mechanistic basis for evaluating thermally induced fracture deformation in crystalline rock repositories and contribute to bounding the role of thermo-mechanical processes in the safety assessment of spent nuclear fuel disposal at Forsmark. Full article

In water injection development of tight oil reservoirs (TORs), the complex fracture network formed by hydraulic fracturing and water injection induction is the key factor determining the development effectiveness. Accurate inversion of water injection-induced fracture parameters holds significant importance for enhancing reservoir development outcomes. This paper innovatively proposes a parameter inversion framework that integrates the Embedded Discrete Fracture Model (EDFM) with intelligent optimization algorithms. EDFM efficiently characterizes complex unstructured fracture systems while maintaining mass conservation between the matrix and fractures; intelligent optimization algorithms automatically invert parameters such as fracture half-length, orientation, and conductivity. First, a three-dimensional geological model of the TOR is constructed, utilizing EDFM to handle the impact of fractures on the seepage field. Based on considerations of fracture geometry, conductivity, and stress sensitivity, a coupled fluid dynamics model for fractures and matrix is developed. Subsequently, an objective function is built based on water injection production dynamic data, and the Projection-Iterative-Methods-based Optimizer (PIMO) algorithm is employed to achieve efficient inversion of fracture parameters. Taking a TOR in the Ordos Basin as an example for verification, through synthetic model validation, this method significantly improves the accuracy and efficiency of history matching, with inversion results reliably guiding numerical simulation predictions. The results demonstrate that this method can effectively enhance the precision of fracture parameter identification, offering clear advantages in inversion speed and accuracy over traditional trial-and-error approaches. This study provides new insights for modeling induced fractures in TORs and optimizing water injection development strategies. Full article

Carbonate reservoirs in the Shunbei area develop pronounced fracture networks after acidized hydraulic fracturing and thus have the potential to be repurposed as underground gas storage (UGS) after hydrocarbon depletion. Characterizing their mechanical behavior is essential for safe UGS operation; however, deep to ultra-deep natural cores are difficult to obtain, and conventional macroscopic tests often cannot provide parameters that meet engineering requirements. To address this issue, nanoindentation combined with QEMSCAN (Quantitative Evaluation of Minerals by Scanning Electron Microscopy) was employed to quantify microscale mineral distributions and the mechanical properties of the major constituents. The investigated rock is calcite-dominated (89.62%), with minor quartz (9.89%) and trace feldspar-group minerals (1.89%). Minerals are randomly embedded, and soft–hard phase boundaries are widely distributed. A finite–discrete element method (FDEM) model was then constructed and calibrated in ABAQUS. The discrepancies in uniaxial compressive strength and elastic modulus relative to laboratory results were 6.51% and 9.91%, respectively, indicating good agreement in both mechanical response and failure mode. Parametric analyses using three additional models with different mineral proportions show that damage preferentially initiates at mineral phase boundaries and stress concentration zones induced by end constraints. Microcracks then propagate and coalesce into a dominant compressive–shear band, and final failure is mainly governed by slip along the shear band with localized tensile cracking. With increasing quartz and feldspar contents, enhanced heterogeneity and a higher density of phase boundaries lead to a higher density of crack nucleation sites and increased crack branching, and the failure pattern transitions from a single shear-band–controlled mode to a more network-like fracture system. Moreover, macroscopic strength is not determined solely by the intrinsic strength of individual minerals; heterogeneity and phase-boundary characteristics strongly govern microcrack behavior, such that higher hard-phase contents may result in a lower peak strength. Full article

Shale oil reservoirs are characterized by ultra-low matrix permeability. After large-scale hydraulic fracturing is applied to horizontal wells, fluid transport becomes highly complex, posing major challenges for accurately predicting production performance. In this study, a coupled multi-mechanism numerical model is developed for shale oil reservoirs with complex fracture networks. Using the Embedded Discrete Fracture Model (EDFM), the mass transport between the fracture and matrix and within the hydraulic fracture network can be accurately quantified. Based on core analysis and fluid experimental data, the dynamic evolution of rock and fluid properties is characterized by incorporating nanopore confinement effects, stress sensitivity, and threshold pressure gradient behavior. Numerical simulations are then conducted to investigate the impacts of multiple mechanisms, including nanopore confinement effects, stress sensitivity, and threshold pressure gradient, as well as their coupling effects on shale oil production. A field application is carried out using Well H1 in the Qingcheng shale oil reservoir. Simulation results indicate that nanopore confinement reduces bubble-point pressure, leading to a 3.60% increase in cumulative oil production and a noticeable reduction in the producing gas–oil ratio. Stress sensitivity causes a 2.68% decrease in cumulative oil production and suppresses gas production. The threshold pressure gradient exerts the strongest negative impact, resulting in an 8.01% reduction in cumulative oil production and a slight decrease in gas–oil ratio. When all mechanisms are simultaneously considered, strong nonlinear interactions emerge, yielding a 7.09% reduction in cumulative oil production—significantly different from the linear superposition of individual effects. These results demonstrate the necessity of accounting for multi-mechanism coupling to achieve reliable production forecasting in fractured shale oil reservoirs. Full article

Prediction of fatigue failure in concrete structures remains a major challenge due to progressive material degradation. Reliable prediction, therefore, requires modeling the 3D heterogeneous microstructure of concrete to explain the underlying mechanisms governing fatigue failure. While such mesoscale models can reliably predict the fatigue-induced fracture mechanisms, the identification of the associated material parameters remains a significant challenge due to the high-dimensional parameter space introduced by the model. The key challenge addressed in this study is to capture microcrack initiation and coalescence under fatigue loading, using a model capable of representing fracture process: crack initiation, crack propagation, and final failure. Firstly, concrete domain is discretized into Voronoi cells, enabling explicit representation of aggregates and mortar by randomly assigning cohesive links connecting Voronoi cells as aggregates and mortar. After this, mortar links are modeled as coupled damage–plasticity 3D Timoshenko beam elements with nonlinear kinematic hardening and isotropic softening introduced using embedded discontinuity formulation, enabling fracture Modes I–III, whereas aggregate links are modeled as elastic 3D Timoshenko beam elements. The model efficiency is additionally reinforced by using surrogate model approach, with corresponding material parameter identification carried out by multi-objective Bayesian optimization framework to reproduce experimental results. The performance of the proposed model is illustrated by reproducing experimental results obtained from concrete cube compression test and three-point bending test under low-cycle fatigue loading, where the errors between experimental and numerical results are reduced by 82% (stress) and 88% (energy) for the cube test and by 86% (force) and 93% (energy) for the bending test, relative to the initial dataset error. Full article

With the increasing global energy demand, natural gas hydrates have become a focus of research and development. The South China Sea deepwater area has abundant natural gas hydrate resources, but its low permeability limits the commercialization process. This paper explores how to enhance gas production from natural gas hydrate reservoirs through a combination of fracturing technology and depressurization using numerical simulations. Numerical experiments were conducted under various well types and fracture configurations to evaluate their effects on cumulative gas production. The fracturing layer was optimized for different well types. We employed the embedded discrete fracture model (EDFM) to characterize the fracture structures in the reservoir and coupled it with a conventional hydrate numerical simulator to simulate different fracture morphologies. The results show that fractures in the three-phase layer provide the most significant production enhancement among all tested layers. Fractures within the three-phase layer deliver the largest production gain among all layers tested. By comparing the development effects of different well types, it is found that the combination of horizontal wells and hydraulic fracturing can effectively improve the recovery of hydrates compared with single well types and traditional exploitation methods. In particular, horizontal wells with stimulated reservoir volume (SRV) yield a big rise in gas production compared with the single-fracture model under identical conditions. Fractures in the three-phase layer shows the most significant improvement in production. Horizontal wells under the three-phase layer achieve about an 88.26% increase in production compared with the single-fracture simulation under the same conditions. Full article

The development of shale gas reservoirs relies on complex fracture networks created via multistage hydraulic fracturing, yet most existing models still use oversimplified fracture geometries and therefore cannot fully capture the coupled effects of multiscale fracture topology on flow and production. To address this gap, in this study, we combine fractal geometry with the Embedded Discrete Fracture Model (EDFM) to analyze the production dynamics of hydraulically fractured horizontal wells in shale gas reservoirs. A tree-like fractal fracture network is first generated using a stochastic fractal growth algorithm, where the iteration number, branching number, scale factor, and deviation angle control the self-similar hierarchical structure and spatial distribution of fractures. The resulting fracture network is then embedded into an EDFM-based, fully implicit finite-volume simulator with Non-Neighboring Connections (NNCs) to represent multiscale fracture–matrix flow. A synthetic shale gas reservoir model, constructed using representative geological and engineering parameters and calibrated against field production data, is used for all numerical experiments. The results show that increasing the initial water saturation from 0.20 to 0.35 leads to a 26.4% reduction in cumulative gas production due to enhanced water trapping. Optimizing hydraulic fracture spacing to 200 m increases cumulative production by 3.71% compared with a 100 m spacing, while longer fracture half-lengths significantly improve both early-time and stabilized gas rates. Increasing the fractal iteration number from 1 to 3 yields a 36.4% increase in cumulative production and markedly enlarges the pressure disturbance region. The proposed fractal–EDFM framework provides a synthetic yet field-calibrated tool for quantifying the impact of fracture complexity and design parameters on shale gas well productivity and for guiding fracture network optimization. Full article
