The use of plate-like materials to induce a percolation gel-like effect in electrorheological (ER) fluids is sparsely documented. Hence, we dispersed plate-like materials, namely natural mica, synthetic mica, and glass, as well as their pulverized particles, in various concentrations in silicone oil to form ER fluids. Subsequently, the rheological properties of the fluids were evaluated and compared to identify the threshold concentration for percolating a gel-like state. The shear stress and viscoelastic moduli under zero-field conditions confirmed that plate-like materials can be used to induce percolation gel-like effects in ER fluids. This is because of the high aspect ratio of the materials, which enhances their physical stability. In practical ER investigations, ER fluids based on synthetic mica (30.0 wt%) showed the highest yield stress of 516.2 Pa under an electric field strength of 3.0 kV mm⁻¹. This was attributed to the formation of large-cluster networks and additional polarization induced by the ions. This study provides a practical approach for developing a new type of gel-like ER fluid. Full article

The paper presents the application of a strain gauge sensor and a viscous brake filled with an electrorheological (ER) fluid, which is a smart material with controlled rheological properties, by an electric field to the fluid domain. For experimental tests, a cylindrical viscous brake was designed. The tests were carried out on a test stand especially prepared for this purpose and suitable for the examination of the impact of the rotational speed of the input shaft and the value of the electric voltage supplied to the viscous brake on pressing forces, taking into account the ER fluid temperature and brake fluid filling level. On the basis of the experimental research results, a viscous brake control system to exert constant pressing forces with feedback from a strain gauge sensor, based on the programmable logic controller, was designed and implemented. This system, using its own control algorithm, ensured a control pressing force within the assumed range, both during the constant and follow-up control. The measurement results obtained during the tests of the viscous brake designed to exert a force were presented in the form of time courses, showing the changes of the pressing force, the electric voltage applied to the brake and the rotational speed of the brake input shaft. The developed ER fluid brake control system with feedback was tested for constant and follow-up control, taking into account the impact of the working fluid temperature. During the test it was possible to obtain a maximum pressing force equal to 50 N for an electric voltage limited to 2.5 kV. The resultant error was lower than 1 N, wherein the adjustment time after changing the desired value of the force was around 1.5 s. The correct operation of both the brake and the control system, as well as the compatibility of the pressing force value and time adjustment, were determined. The main technical contribution described in this article is the design of a new type of DECPF and a new method for its control with the use of a specifically programmed programmable logic controller which simulates the proportional-integral controllers’ operation. Full article

Flexoelectric liquid crystalline membranes immersed in asymmetric viscoelastic media is a material system model with physiological applications such as outer hair cells (OHCs), where membrane oscillations generate bulk flow. Motivated by this physiological process, here we extend our previous work by characterizing the force transmission output of our model in addition to viscoelastic fluid flow, since solid–fluid interactions are an essential feature of confined physiological flow and flow in immersed elastic structures. In this work, the rigidity of the confinement results in a passive force reception, while more complete solid–fluid interactions will be considered in the future. A significant contribution of this work is a new asymmetry linear viscoelastic electro-rheological model and the obtained implicit relation between force transmission and flow generation and how this relation is modulated by electric field frequency and the material properties of the device. Maximal force and flow are found at resonant frequencies of asymmetry viscoelastic bulk phases, flexoelectric and dispersion mechanisms through the elastic and Womersley numbers. Full article

Magnetic/conducting polymeric hybrid core-shell typed zinc ferrite (ZnFe₂O₄)/poly(N-methyl aniline) (PMA) particles were fabricated and adopted as electrorheological (ER) and magnetorheological (MR) fluids, and their rheological properties were examined. Solvo-thermally synthesized ZnFe₂O₄ was coated with a conducting PMA through chemical oxidation polymerization. The size, shape, and chemical composition of the final core-shell shaped particles were scrutinized by scanning electron microscopy, transmission electron microscopy, and Fourier transform-infrared spectroscopy. The crystal faces of the particles before and after coating with PMA were analyzed by X-ray diffraction. The ZnFe₂O₄/PMA products were suspended in silicone oil to investigate the rheological response to electro- or magnetic stimuli using a rotating rheometer. The shear stresses were analyzed using the CCJ equation. The dynamic yield stress curve was suitable for the conductivity mechanism with a slope of 1.5. When magnetic fields of various intensities were applied, the flow curve was analyzed using the Hershel–Bulkley equation, and the yield stresses had a slope of 1.5. Optical microscopy further showed that the particles dispersed in insulating medium form chain structures under electric and magnetic fields. Via this core-shell fabrication process, not only spherical conducting particles were obtained but also their dual ER and MR responses were demonstrated for their wide potential applications. Full article

Due to their unique anisotropic morphology and properties, graphene-based materials have received extensive attention in the field of smart materials. Recent studies show that graphene-based materials have potential application as a dispersed phase to develop high-performance electrorheological (ER) fluids, a kind of smart suspension whose viscosity and viscoelastic properties can be adjusted by external electric fields. However, pure graphene is not suitable for use as the dispersed phase of ER fluids due to the electric short circuit caused by its high electrical conductivity under electric fields. However, graphene oxide (GO) and graphene-based composites are suitable for use as the dispersed phase of ER fluids and show significantly enhanced property. In this review, we look critically at the latest developments of ER fluids based on GO and graphene-based composites, including their preparation, electrically tunable ER property, and dispersed stability. The mechanism behind enhanced ER property is discussed according to dielectric spectrum analysis. Finally, we also propose the remaining challenges and possible developments for the future outlook in this field. Full article

ZnFe₂O₄ particles initially synthesized through a simple solvothermal method were coated using polyindole (PIn) to prepare an actively controllable core-shell typed hybrid material under both electric and magnetic fields. An advantage of this process is not needing to add the stabilizers or surfactants commonly used for uniform coating when synthesizing core or shell-structured particles. The synthesized ZnFe₂O₄/PIn particles have a lower density than conventional magnetic particles and have suitable properties as electrorheological (ER) particles. The expected spherical shape of the particles was proven using both scanning electron microscopy and transmission electron microscopy. The chemical characterization was performed using Fourier-transform infrared spectroscopy and X-ray diffraction analysis. To analyze the rheological properties, a ZnFe₂O₄/PIn based suspension was prepared, and dynamic rheological measurements were performed for different electric field strengths using a rotary rheometer. Both dynamic and elastic yield stresses of the ER fluid had a slope of 1.5, corresponding to the conductivity model. Excellent ER effect was confirmed through rheological analysis, and the prepared ER fluid had a reversible and immediate response to repeated electric fields. Full article

Magnetic and semiconducting Fe₃O₄/poly(o-anisidine) (POA) core/shell composite particles were fabricated by an oxidation process using Fe₃O₄ synthesized separately. The dispersion stability in a liquid medium and the electrical conductivity of synthesized particles were improved because of the conductive POA polymeric shell. The morphological, microstructural, compositional/elemental, and thermal behaviors of the particles were characterized using SEM with energy dispersive X-ray spectroscopy, TEM, XRD, and thermogravimetric analysis, respectively. A smart electro-magneto-rheological suspension containing Fe₃O₄/POA particles with two functionalities, magnetism and conductivity, was prepared. Its electrorheological properties were investigated at different electric field strengths using a rotational rheometer. Without an electric field, the sample demonstrated typical Newtonian fluid behavior, as expected. However, while under the electric field, it exhibited a solid-like behavior, and the dynamic (or elastic) yield stress of the ER fluid increased linearly as a function of the electric field strength in a power-law function with an index of 2.0, following the polarization mechanism. Full article

Possible mechanisms of particle attraction providing formation of the field aligned microparticle strings in complex plasmas at elevated gas pressures are theoretically investigated in the light of the Plasmakristall-4 (PK-4) experiment on board the International Space Station. The particle interaction energy is addressed by two different approaches: (i) using the dynamically screened wake potential for small Mach numbers derived by Kompaneets et al., in 2016, and (ii) introducing effect of polarization of the trapped ion cloud by discharge electric fields. Is is found that both approaches yield the particle interaction energy which is independent of the operational discharge mode. In the parameter space of the performed experiments, the first approach can provide onset of the particle attraction and string formation only at gas pressures higher than 40–45 Pa, whilst the mechanism based on the trapped ion effect yields attraction in the experimentally important pressure range 20–40 Pa and may reconcile theory and observations. Full article

Ionic liquids (ILs) are a class of pure ions with melting points lower than 100 °C. They are getting more and more attention because of their high thermal stability, high ionic conductivity and dielectric properties. The unique dielectric properties aroused by the ion motion of ILs makes ILs-contained inorganics or organics responsive to electric field and have great application potential in smart electrorheological (ER) fluids which can be used as the electro-mechanical interface in engineering devices. In this review, we summarized the recent work of various kinds of ILs-contained inorganic ionogels and poly(ionic liquid)s (PILs) as ER materials including their synthesis methods, ER responses and dielectric analysis. The aim of this work is to highlight the advantage of ILs in the synthesis of dielectric materials and their effects in improving ER responses of the materials in a wide temperature range. It is expected to provide valuable suggestions for the development of ILs-contained inorganics and PILs as electric field responsive materials. Full article

The newest generation of lubricants needs to adapt to stricter environmental policies. Simple and sustainable formulations with tunable rheological properties under the action of electric potentials may be the key. The present research explored the feasibility of producing electro-sensitive ecolubricants based on nanocellulose (crystalline and fibrillar) or nanoclay (Cloisite 15A montmorillonite and halloysite nanotubes) dispersions in castor oil, at concentrations that ranged from 2 to 6 wt.%. Broadband dielectric spectroscopy (BDS) measurements allowed for a first estimate on the electro-responsive potential of the nanofluids. The nanocelluloses and the montmorillonite suspensions presented a relaxation event in the dielectric loss, ε″, centered at ca. 2–4 kHz, which is related to interfacial polarization. Moreover, their actual electro-rheological (ER) effect under high electric potentials up to 4 kV/mm was assessed by determining the magnitude of the yield stress from steady flow curves at 25 °C. It was found that the nanocelluloses and the montmorillonite showed an enhancement of three orders of magnitude in their yield stress values at 4 kV/m. This enhancement was much greater than in the halloysite nanoclay, which did not exhibit any polarization). This is the starting point for the development of environmentally friendly ER lubricating fluids, based on nanocellulose and montmorillonites (layered nanosilicates), which might assist in reducing the friction and wear through the application of controlled electric fields. Full article

Conducting polymer-coated nanoparticles used in electrorheological (ER) and magnetorheological (MR) fluids are reviewed along with their fabrication methods, morphologies, thermal properties, sedimentation stabilities, dielectric properties, and ER and MR characteristics under applied electric or magnetic fields. After functionalization of the conducting polymers, the nanoparticles exhibited properties suitable for use as ER materials, and materials in which magnetic particles are used as a core could also be applied as MR materials. The conducting polymers covered in this study included polyaniline and its derivatives, poly(3,4-ethylenedioxythiophene), poly(3-octylthiophene), polypyrrole, and poly(diphenylamine). The modified nanoparticles included polystyrene, poly(methyl methacrylate), silica, titanium dioxide, maghemite, magnetite, and nanoclay. This article reviews many core-shell structured conducting polymer-coated nanoparticles used in ER and MR fluids and is expected to contribute to the understanding and development of ER and MR materials. Full article

Microfibrillated cellulose (MFC) particles were synthesized by a low-pressure alkaline delignification process, and their shape and chemical structure were investigated by SEM and Fourier transformation infrared spectroscopy, respectively. As a novel electrorheological (ER) material, the MFC particulate sample was suspended in insulating oil to fabricate an ER fluid. Its rheological properties—steady shear stress, shear viscosity, yield stress, and dynamic moduli—under electric field strength were characterized by a rotational rheometer. The MFC-based ER fluid demonstrated typical ER characteristics, in which the shear stresses followed the Cho–Choi–Jhon model well under electric field strength. In addition, the solid-like behavior of the ER fluid was investigated with the Schwarzl equation. The elevated value of both dynamic and elastic yield stresses at applied electric field strengths was well described using a power law model (~E^1.5). The reversible and quick response of the ER fluid was also illustrated through the on–off test. Full article

The electrorheological (ER) effect was experimentally observed in dielectric suspensions containing tungsten oxide (WO₃) modified with surfactant molecules (sodium dodecyl sulfate (SDS) and dodecylamine (DDA)) in electric fields up to several kilovolts per millimeter. The dielectric properties of WO₃ suspensions in silicone oil were analyzed, depending on the frequency of the electric field, in the range from 25 to 10⁶ Hz. Unmodified WO₃ suspensions, as well as suspensions modified with sodium dodecyl sulfate, were shown to exhibit a positive electrorheological effect, whereas suspensions modified with dodecylamine demonstrated a negative electrorheological effect. The quantitative characteristics of the negative electrorheological effect in the strain–compression and shear regimes were obtained for the first time. Visualization experiments were performed to see the chain structures formed by WO₃ particles modified with sodium dodecyl sulfate, as well as for dynamic electroconvection in electrorheological fluids containing WO₃ modified with dodecylamine. The negative electrorheological effect was shown to be associated with the processes of phase separation in the electric field, which led to a multiplicative effect and a strong electroconvection of the suspension at field strengths above 1 kV/mm. Full article

Composite particles associated with graphene oxide (GO) and inorganic materials provide the synergistic properties of an appropriate electrical conductivity of GO with the good dielectric characteristics of inorganic materials, making them attractive candidates for electrorheological (ER) materials. This review paper focuses on the fabrication mechanisms of GO/inorganic composites and their ER response when suspended in a non-conducting medium, including steady shear flow curves, dynamic yield stress, On-Off tests, and dynamic oscillation analysis. Furthermore, the morphologies of these composites, dielectric properties, and sedimentation of the ER fluids are covered. Full article

Electro-responsive smart electrorheological (ER) fluids consist of electrically polarizing organic or inorganic particles and insulating oils in general. In this study, we focus on various conducting polymers of polyaniline and its derivatives and copolymers, along with polypyrrole and poly(ionic liquid), which are adopted as smart and functional materials in ER fluids. Their ER characteristics, including viscoelastic behaviors of shear stress, yield stress, and dynamic moduli, and dielectric properties are expounded and appraised using polarizability measurement, flow curve testing, inductance-capacitance-resistance meter testing, and several rheological equations of state. Furthermore, their potential industrial applications are also covered. Full article
