Tunable photonic devices are increasingly pivotal in modern optical systems, enabling the dynamic control over light propagation, modulation, and filtering. This review systematically explores two prominent classes of materials, thermo-optic and electro-optic, for their roles in such tunable devices. Thermo-optic materials utilize refractive index changes induced by temperature variations, offering simple implementation and broad material compatibility, although often at the cost of slower response times. In contrast, electro-optic materials, particularly those exhibiting the Pockels and Kerr effects, enable rapid and precise refractive index modulation under electric fields, making them suitable for high-speed applications. The paper discusses the underlying physical mechanisms, material properties, and typical figures of merit for each category, alongside recent advancements in organic, polymeric, and inorganic systems. Furthermore, integrated photonic platforms and emerging hybrid material systems are highlighted for their potential to enhance performance and scalability. By evaluating the tradeoffs in speed, power consumption, and integration complexity, this review identifies key trends and future directions for deploying thermo-optic and electro-optic materials in the next generation tunable photonic devices. Full article

In this study, the photonic band structure, transmissivity, and electric field distribution of a two-dimensional photonic crystal coupled waveguide structure are calculated using the supercell technique and finite element method. The waveguide consists of circular $KNb{O}_3$ and functional dielectric cylinders embedded in air. The dielectric constant of a functional medium cylinder is spatially dependent, which is realized through the electro-optic and Kerr effects. The dielectric constant function is defined as ${\epsilon }_c\left(r\right)=k·r+b$ ($0⩽r⩽r_c$), where the coefficient k and parameter b can be adjusted by an external electric field. By tuning k and b, the transmission characteristics of the waveguide, including the propagation direction and light field distribution, exhibit significant adjustability. Specifically, parameter b enhances or suppresses the transmissivity at output ports 1 and 2. By utilizing the regulatory capability of functional media on waveguide transmission characteristics, optical filters with specific filtering functions can be designed. These findings provide novel design strategies for advanced optical devices. Full article

A new approach to the dynamic polarimetric method is proposed, which allows for the decoupling of electro-optical Kerr effect measurements from the electro-absorption effect in partially transparent liquids. The method is illustrated by using the results of engine oil measurements as a function of temperature and modulating field frequency. It was shown that the birefringence induced in the sample, the modulation of the ordinary wave transmission, and the modulation of the extraordinary wave transmission in the sample can be shifted in phase with respect to the square of the applied alternating modulating field. Each of these three phase shifts can depend differently on the temperature and frequency. Neglecting the influence of electro-absorption on electro-optical measurements in liquids or considering electro-absorption as an effect correlated in phase with induced birefringence may lead to significant measurement errors. This indicates that the Kerr constant and the electro-absorption coefficients for an alternating electric field should be considered as complex quantities instead of real values, as they have been traditionally. The proposed approach fills an important gap in measurement techniques described in the literature, which may provide erroneous results for measurements of the Kerr constant in partially transparent liquids including many industrially important liquids. Full article

Oil-pressboard/paper insulation materials are essential in transformers for ensuring their safe and stable operation, primarily due to their roles in spatial electric field distribution and charge migration mechanisms. Current spatial distribution analyses rely on computational methods that lack empirical validation, particularly for oil-pressboard/paper composites. This study leverages the principles of the Kerr electro-optic effect to develop a rapid measurement platform for electric fields within oil-pressboard/paper insulation under impulse voltage conditions, which measures the spatial electric field characteristics using Cu-Cu and Al-Al electrodes under various scenarios: with asymmetric and symmetric pressboard coverage and different numbers of insulating paper layers. Findings indicated: (1) In asymmetric pressboard models, Cu-Cu electrodes exhibit a consistent peak electric field of approximately 16 kV/mm, while Al-Al electrodes show peak values of 18.13 kV/mm and −14.98 kV/mm. Charge density patterns are similar, with Cu-Cu at about 68 μC/m² and Al-Al at 11.2 μC/m² and −124.8 μC/m². (2) Symmetric models present consistent peak electric fields and charge densities for both polarities. (3) Increasing insulating paper layers elevates electric field strengths. Both electrodes show the similar peak field of about 17 kV/mm with differing paper layers due to higher charge injection from the Al electrode. (4) Utilizing the Schottky effect and field emission principles, the study clarifies charge generation and migration mechanisms. These insights could provide a theoretical foundation for designing and verifying oil-pressboard/paper insulation structures in transformers. Full article

In the current design and verification processes of insulation structures for high-voltage oil-immersed capacitors, there is a heavy reliance on electric field simulation calculations using idealized models that lack empirical validation of spatial electric fields. This study employs the Kerr electro-optic effect to establish a non-contact optical remote sensing system for measuring the spatial electric field distribution in the insulating liquid dielectric (benzyltoluene) between the capacitor’s element and the case under various temperatures and main insulation distances. The findings reveal that the measured spatial electric field stress can be up to 15% higher than the simulated values. The electric field stress measured in the Y1 direction (up toward the capacitor top) is comparable to that measured in the Y2 direction (down toward the capacitor end). Furthermore, when varying the main insulation distance, the electric field stress consistently shows a negative correlation with increasing measurement distance. Specifically, at a main insulation distance of 1.5 mm, the electric field stress is 1.81 times that at 5.5 mm. As the temperature rises, the spatial electric field stress increases gradually, and the electric field distribution becomes more uneven at higher temperatures. At 80 °C, the field stress is approximately 1.57 times that at 20 °C, with the measured field stress at 80 °C being 19% higher than the simulated value. Finally, this paper undertakes a comprehensive theoretical analysis and experimental validation to elucidate the discrepancies between simulated and measured spatial electric fields. Leveraging these insights, it proposes advanced optimization strategies for the insulation structures of capacitor elements. The outcomes of this study furnish substantial technical and theoretical support, significantly enhancing the design, verification, and optimization processes for insulation in oil-immersed capacitors. Full article

The electro-optical properties of methyl silicone oils with viscosities ranging from 10 to 10,000 cSt have been studied extensively to verify their suitability as immersion liquids. Immersion liquids are often used in nonlinear optics to protect hygroscopic crystals from moisture, reduce multiple reflections, and protect against electrical breakdown. However, the lack of experimental data makes it difficult to select an optimal liquid that does not exhibit a significant electro-optical Kerr effect in the fringing electric field around the electrodes on the crystal. Electro-optical measurements were performed using an improved dynamic polarimetric method, which compensates for the measurement errors caused by inaccurate positioning of the electro-optical modulator’s operating point on its transmission characteristics. The values of the Kerr coefficient ranged from −8.83 × 10⁻¹⁶ to −6.79 × 10⁻¹⁶ m V⁻² for all oil samples, at temperatures from 25 to 80 °C and frequencies from 67 to 1017 Hz. These exceptionally low values, together with a low dielectric constant, very good transparency, and high chemical stability, make methyl silicone oils highly suitable as immersion liquids. The Kerr coefficient and other electro-optical coefficients increased with increasing temperature. This unusual result cannot be adequately explained by Buckingham’s molecular theory of the Kerr effect. Full article

The functionality enhancement of ferroelectrics by local polar clusters called polar nanoregions (PNRs) is one of the current interests in materials science. KTa_1−xNb_xO₃ (KTN) with perovskite structure is a well-known electro-optic crystal with a large Kerr effect. The existence of PNRs in relaxor-like ferroelectric Nb-rich KTN with homovalent B-site cations is controversial. This paper reviews recent progress in understanding precursor dynamics in Nb-rich KTN crystals studied using Brillouin scattering. The intense central peak (CP) and significant softening of sound velocity are observed above the Curie temperature (T_C) due to the polarization fluctuations in PNRs. The effects of Li-doping, defects, and electric fields on the growth and/or creation of PNRs are found using changes in acoustic properties. The electric-field-induced T_C, which is shifted to higher values with increases in applied voltage, including critical endpoint (CEP) and field gradient by trapped electrons, are discussed as well. This new knowledge may give new insight into advanced functionality in perovskite ferroelectrics. Full article

Current inspection rigorously explores the tuning of a few relevant nonlinear optical (NLO)properties of GaAs quantum dot (QD) under the stewardship of Gaussian noise-anharmonicity interplay. The NLO properties explored are total optical absorption coefficient (TOAC), total optical refractive index change (TORIC), nonlinear optical rectification (NOR), second harmonic generation (SHG), third harmonic generation (THG), DC-Kerr effect (DCKE), electro-absorption coefficient (EAC), group index (GI)and optical gain (OG). The route of application of noise (additive/multiplicative) to the QD, as well as the symmetry (odd/even) of the anharmonicity, influence the aforesaid NLO properties. These NLO properties exhibit steadfast growth, steadfast fall, maximization, minimization and saturation. The outcomes of the inspection appear to be quite pertinent in the context of the immense technological demand of QD, taking into account the combined impact of anharmonicity and noise. Full article

Polymer-stabilised blue phase (PSBP) could be employed in novel fast response optical and photonic devices. It is inferred that inside PSBPs, the polymers are selectively aggregated by location in −1/2 disclinations, which are defects coexisting with the blue phase as a periodic lattice, thereby extending the temperature range of the blue phase. The polymer aggregate structure in PSBPs strongly affects their physical properties. In this study, we employed a non-destructive synchrotron ultra-small-angle X-ray diffraction analysis to investigate the effect of polymerisation rates on the polymer aggregate structure in PSBPs prepared with monomers of different polymerisation rates and examined the structure formation process of the polymer during polymerisation. When methacrylate monomers, which exhibit a relatively low polymerisation rate, were used to form polymers in PSBP, the resulting polymer was more selectively aggregated at disclinations in the PSBP. Furthermore, the electro-optical effect in the PSBP was successfully improved by reducing the polymer concentration in the PSBPs prepared with the optimised monomer combinations. Full article

A polarization-independent electro-optical (EO) laser beam steerer based on a bulk relaxor ferroelectric polycrystalline Pb(Mg_1/3Nb_2/3)O₃-PbTiO₃ (PMN-PT) was developed in this study to steer light ranging from visible to mid-IR wavelengths. A large number of the resolvable spots was achieved with this EO steerer. A Fourier-transform infrared (FTIR) spectroscopy was employed to determine the refractive index of the polycrystalline PMN-PT over a wide range of optical wavelengths. Besides measuring the transmission of this material, the capacitance bridge analysis was used to characterize the effect of temperature on the dielectric constant of PMN-PT. The performance of the steerer over a variety of wavelengths was simulated using COMSOL Multiphysics. The deflection angle for the wavelengths of 532, 632.8, 1550, and 4500 nm was measured in the lab in terms of mrad.mm/kV at two different temperatures and compared to the simulation results. The quadratic Kerr electro-optic coefficient and the halfwave electric field were determined for those four wavelengths at two different temperatures. The results showed polycrystalline PMN-PT has a large quadratic EO coefficient for visible light, almost as large in the near IR, but drops significantly in the mid-IR. No significant temperature dependency for the EO coefficients was observed for any of those four wavelengths. Full article

Nowadays there is an increasing demand for the cost-effective monitoring of potential threats to the integrity of high-voltage networks and electric power infrastructures. Optical fiber sensors are a particularly interesting solution for applications in these environments, due to their low cost and positive intrinsic features, including small size and weight, dielectric properties, and invulnerability to electromagnetic interference (EMI). However, due precisely to their intrinsic EMI-immune nature, the development of a distributed optical fiber sensing solution for the detection of partial discharges and external electrical fields is in principle very challenging. Here, we propose a method to exploit the third-order and second-order nonlinear effects in silica fibers, as a means to achieve highly sensitive distributed measurements of external electrical fields in real time. By monitoring the electric-field-induced variations in the refractive index using a highly sensitive Rayleigh-based CP-φOTDR scheme, we demonstrate the distributed detection of Kerr and Pockels electro-optic effects, and how those can assign a new sensing dimension to optical fibers, transducing external electric fields into visible minute disturbances in the guided light. The proposed sensing configuration, electro-optical time domain reflectometry, is validated both theoretically and experimentally, showing experimental second-order and third-order nonlinear coefficients, respectively, of χ⁽²⁾ ~ 0.27 × 10⁻¹² m/V and χ⁽³⁾ ~ 2.5 × 10⁻²² m²/V² for silica fibers. Full article

Electroabsorption in metallic nanoparticles within transparent dielectric media has been measured. In particular, gold nanoparticles in glass and subnanometer-size metallic domains in iodine doped nonconjugated conductive polymer have been studied. Measurements have been made for applied ac fields at 4 kHz, at a wavelength close to the onset of the surface plasmon resonance. The measured electroabsorption (imaginary part of χ⁽³⁾ or Kerr coefficient) has a quadratic dependence on electric field. Its magnitudes were compared for different sizes of the metallic nanoparticles down to the subnanometer-size particles in iodine-doped nonconjugated conductive polymer. As in the case of quadratic electro-optic effect reported earlier, electroabsorption has approximately a 1/d³ dependence, d being the diameter of nanoparticle. This is consistent with existing theories on confined metallic systems. Full article

In this study, we propose driving the amorphous blue phase III (BPIII) with a tilted electric field to enhance or magnify its inherent linear electro-optical properties. The electro-optical properties of in-plane-switching (IPS) BPIII and tilted-field-switching (TFS) BPIII cells are compared here. According to the change in the induced birefringence with varying the strength of the electric field in the TFS-BPIII cell, the Kerr effect occurs in the low electric field and the Pockels effect dominates in the high electric field. In addition, the transmittance of the TFS-BPIII cell depends on the polarity of the applied field from 1 Hz to 10 kHz. It also results in the rise time of the TFS-BPIII cell being almost half of that of the IPS-BPIII cell. These experimental results and discussion allowed us to unravel the mystery of the amorphous BPIII step by step and provide the potential application of BPIII in photonic devices. Full article

The effects of the fluorinated monomer with an ethynyl group on the electro-optical properties of polymer-stabilized blue phase liquid crystals (PSBPLCs) were investigated in different polymer systems. In rigid polymer systems, the Kerr constant can be increased by about 27.6%, while keeping a microsecond response time. In soft polymer systems, hysteresis decreased by about 45.5% and residual birefringence can be reduced from 1.85% to 0.6%. The above phenomena exhibited dual functions of affecting the anchoring energy and the viscosity of the system simultaneously. The results provide a potential value for the ethynyl-containing monomers in PSBPLC systems. Full article

The quadratic electro-optic effect/Kerr coefficients were measured for the first time for metal nanoparticles. In particular, gold nanoparticles in glass were studied. Measurements were made using the field-induced birefringence method at a wavelength near the onset of the surface plasmon resonance. The magnitudes of the Kerr coefficients for different sizes of gold nanoparticles in glass were measured and compared with that of subnanometer size metallic particles in non-conjugated conductive polymers. The magnitude of the Kerr coefficient was found to increase rapidly (about d⁻³) when the diameter, d, of the nanoparticles was decreased. This is consistent with the existing theories and understanding of nonlinear optics in metal nanoparticles. The results imply a broad range of new applications of metal nanoparticles in electro-optic switching/modulation, low-cost Kerr cells and other uses in optoelectronics. Full article
