The fragmentation of vessel tracks represents a significant challenge in the context of high-frequency surface wave radar (HFSWR) tracking. This paper proposes a new track segment association (TSA) algorithm that integrates optimal tracklet assignment, iterative discrimination, and multi-stage association. This paper reformulates the optimal tracklet assignment task as an optimal state search problem for modeling and solution purposes. To determine whether competing old and new tracklets can be associated, we assume the existence of a public state that represents the correlation between the tracklets. However, due to track fragmentation, this public state remains unknown. We need to search for the optimal public state of all candidate tracklet pairs within a feasible parameter space, using a fitness function value as the evaluation criterion. The old and new tracklets pairs that match the optimal public state are considered optimally associated. Since the solution process involves searching for the optimal state across multiple dimensions, it constitutes a high-dimensional optimization problem. To accomplish this task, the catch fish optimization algorithm (CFOA) is employed for its ability to escape local optima and handle high-dimensional optimization, enhancing the reliability of tracklet assignment. Furthermore, we achieve precise one-to-one associations by assigning new tracklet to old tracklet through the optimal tracklet assignment method we proposed, a process we abbreviate as AN2O, and its inverse process, which assigns old tracklet to new tracklet, abbreviated as AO2N. This dual approach is further complemented by an iterative discrimination mechanism that evaluates unselected tracklets to identify potential associations that may exist. The algorithm effectiveness of the proposed is validated using field experiment data from HFSWR in the Bohai Sea region, demonstrating its capability to accurately process complex tracklet data. Full article

The monitoring of the sea surface, whether it is the state of the sea or the position of targets (ships), is an up-to-date research topic. In order to determine localization parameters of ships, we propose a high-resolution algorithm for primary signal processing in high-frequency surface wave radar (HFSWR) which operates at two frequencies. The proposed algorithm is based on a high-resolution estimate of the range–Doppler (RD-HR) map formed at every antenna in the receive antenna array, which is an essential task, because the performance of the entire radar system depends on its estimation. We also propose a new focusing method allowing us to have only one RD-HR map in the detection process, which collects the information from both these carrier frequencies. The goal of the bi-frequency mode of operation is to improve the detectability of targets, because their signals are affected by different Bragg-line interference patterns at different frequencies, as seen on the RD-HR maps during the primary signal processing. Also, the effect of the sea (sea clutter) manifests itself in different ways at different frequencies. Some targets are masked (undetectable) at one frequency, but they become visible at another frequency. By exploiting this, we increase the probability of detection. The bi-frequency architecture (system model) for the localization of sea targets and the novel signal model are presented in this paper. The advantage of bi-frequency mode served as a motivation for testing the detectability of small boats, which is otherwise a very challenging task, primarily because such targets have a small radar reflective surface, they move quickly, and often change their direction. Based on experimentally obtained results, it can be observed that the probability of detection of small boats can also be significantly improved by using a bi-frequency architecture. Full article

The transmit/receive-receive (T/R-R) synergetic High Frequency Surface Wave Radar (HFSWR) has increasingly attracted attention due to its high localization accuracy, but multi-target pairing needs to be performed before localization in multi-target scenarios. However, existing multi-target parameter matching methods have primarily focused on track association, which falls under the category of information-level fusion techniques, with few methods based on detected points. In this paper, we propose a multi-target pairing method with high computational efficiency based on angle information for T/R-R synergetic HFSWR. To be more specific, a dual-receiving array signal model under long baseline condition is firstly constructed. Then, the amplitude and phase differences of the same target reaching two subarrays are calculated to establish the cross-correlation matrix. Subsequently, in order to extract the rotation factor matrices containing pairing information and improve angle estimation performance, we utilize the conjugate symmetry properties of the uniform linear array (ULA) manifold matrix for generalized virtual aperture extension. Ultimately, azimuths estimation and multi-target pairing are accomplished by combining the propagator method (PM) and the ESPRIT algorithm. The proposed method relies solely on angle information for multi-target pairing and leverages the rotational invariance property of Vandermonde matrices to avoid peak searching or iterations, making it computationally efficient. Furthermore, the proposed method maintains superb performance regardless of whether the spatial angles are widely separated or very close. Simulation results validate the effectiveness of the proposed method. Full article

This paper proposes a method for the intelligent detection of high-frequency surface wave radar (HFSWR) targets. This method cascades the adaptive constant false alarm (CFAR) detector variability index (VI) with the convolutional neural network (CNN) to form a cascade detector (VI)CFAR-CNN. First, the (VI)CFAR algorithm is used for the first-level detection of the range–Doppler (RD) spectrum; based on this result, the two-dimensional window slice data are extracted using the window with the position of the target on the RD spectrum as the center, and input into the CNN model to carry out further target and clutter identification. When the detection rate of the detector reaches a certain level and cannot be further improved due to the convergence of the CNN model, this paper uses a dual-detection maps fusion method to compensate for the loss of detection performance. First, the optimized parameters are used to perform the weighted fusion of the dual-detection maps, and then, the connected components in the fused detection map are further processed to achieve an independent (VI)CFAR to compensate for the (VI)CFAR-CNN detection results. Due to the difficulty in obtaining HFSWR data that include comprehensive and accurate target truth values, this paper adopts a method of embedding targets into the measured background to construct the RD spectrum dataset for HFSWR. At the same time, the proposed method is compared with various other methods to demonstrate its superiority. Additionally, a small amount of automatic identification system (AIS) and radar correlation data are used to verify the effectiveness and feasibility of this method on completely measured HFSWR data. Full article

A high-frequency surface wave radar (HFSWR) is the only sensor that provides inexpensive surveillance for up to 200 nautical miles (NM) of the exclusive economic zone in the 3–5 MHz band. However, because of its long wavelength, its angular resolution is low. Multiple-input multiple-output (MIMO) technology is an attractive method to improve angular resolution. This paper proposes MIMO waveforms and their processing that can be used in HFSWR systems. This dual modulation method applies linear frequency modulation to each pulse and orthogonal polyphase codes for a few consecutive pulses to enable MIMO processing. The proposed method can effectively remove the correlation of mutual interference and exhibits excellent performance in removing multiple-time-around echoes. Full article

Due to its maneuverability and agility, the shipborne high-frequency surface wave radar (HFSWR) provides a new way of monitoring large-area marine dynamics and environment information. However, wind direction ambiguity is problematic when using monostatic shipborne HFSWR for wind direction inversion. In this article, an unambiguous wind direction measurement method based on wind direction interval limitation is proposed. The two first-order spectral wind direction estimation methods are first presented using the relationship between the normalized amplitude differences or ratios of the broadened Doppler spectrum and the wind direction. Moreover, based on the characteristic of a small wind direction estimation error in a large included angle between the spectral wind direction and the radar beam, the wind direction interval is obtained by counting the distribution of radar-measured wind direction within this included angle. Furthermore, the eliminated ambiguity of wind direction is transformed to judge the relationship between the wind direction interval and the two curves, which represent the relationship between the spreading parameter and the wind direction. Therefore, the remote sensing monitoring of ocean surface wind direction fields can be realized by shipborne HFSWR. The simulation results are used to evaluate the performance of the proposed method and the multi-beam sampling method for wind direction inversion. The experimental results show that the errors of wind direction estimated by the multi-beam sampling method and the equivalent dual-station model are large, and the proposed method can improve the accuracy of wind direction measurement. Three widely used wave directional spreading models have been applied for performance comparison. The wind direction field measured by the proposed method under a modified cosine model agrees well with that observed by the China-France Oceanography Satellite (CFOSAT). Full article

The echo of shipborne high-frequency surface wave radar (HFSWR) is modulated by six-degrees-of-freedom (6-DOF) motion, affecting the detection of the target and the remote sensing of ocean surface dynamics parameters. Commonly, motion compensation methods of shipborne HFSWR describe each aspect of the 6-DOF motion as the superposition of sinusoidal motion, which results in the effect of motion compensation affected by the precision of 6-DOF motion parameters. A motion compensation method based on dual reference radio frequency (RF) signals is proposed in this paper, without depending on a sinusoidal motion model to describe the 6-DOF motion. By using the motion compensation parameters, which are relevant to the motion attitude and calculated from the information of dual reference RF signals located onshore, the method realizes the compensation of shipborne HFSWR echo modulated by platform 6-DOF motion. This paper proposes the extraction of reference RF signals from radar echo and analyzes the influence of the location of the reference RF signals’ emission source on the motion compensation method. The result shows that a good motion compensation effect is achieved in eliminating the influence of 6-DOF motion modulation. In addition, a traversal of different reference RF signals’ emission source locations is conducted, and the simulation results show that the method proposed in this paper has universality. Full article
