Four-wheel independent steering (4WIS) vehicles can improve low-speed maneuverability and high-speed stability by independently regulating the steering angles of all four wheels. However, under large-curvature trajectories, parameter perturbations, and external disturbances, inconsistent coordination among the four-wheel steering angles may increase tire lateral slip, yaw response deviation, and trajectory tracking errors. To address the difficulty of conventional trajectory tracking methods in simultaneously ensuring geometric consistency, tracking accuracy, and robustness, this paper proposes an adaptive sliding mode trajectory tracking control method based on instantaneous center of rotation (ICR) constraints. First, the tire instantaneous turning center (TTC) of each wheel is derived using rigid-body spatial kinematics, and the TTCs are mapped onto a unified vehicle-body reference plane based on the SAE J670 coordinate system to obtain a real-time vehicle-level ICR estimation. Second, a lateral–yaw dynamic model and a trajectory tracking error model are established. The yaw rate and sideslip angle are corrected using ICR geometric information, and an adaptive sliding mode controller is designed with an equivalent control term, adaptive switching gain, adaptive boundary layer, and sideslip suppression term. The uniform ultimate boundedness of the sliding variable and closed-loop tracking errors is proven using Lyapunov theory. Finally, MATLAB (2023a)2024/CarSim (2019) co-simulations are conducted under small-curvature sinusoidal, double-lane-change, large-curvature sinusoidal, low-adhesion, and mass-perturbation conditions. The results show that the proposed ICR-SMC method significantly reduces lateral and heading errors compared with U-LQR and U-SMC, especially under large-curvature and low-adhesion conditions, demonstrating improved tracking accuracy and robustness for 4WIS vehicles. Full article

To clarify the spreading law of river crab pellet feed in a centrifugal spreading mechanism and provide a physical basis for the path planning of automatic feeding boats, this study took 4.0 mm sinking extruded river crab feed as the research object. A systematic research method combining physical experiments and Discrete Element Method (DEM) simulation was established. Physical experiments were conducted to calibrate the intrinsic parameters (density, Poisson’s ratio, elastic modulus) and contact parameters (friction coefficients and restitution coefficients between feed and 304 stainless steel/ABS plastic, as well as between feed particles) of the pellet feed. On this basis, a DEM simulation model of a vibration blanking-dual disc centrifugal spreading mechanism was constructed using the multi-sphere aggregation method and the Hertz-Mindlin (no-slip) contact model. A Central Composite Design (CCD) response surface experiment was employed to investigate the spreading law, with boat speed (0.5–1.5 m/s) and spreading disc rotation speed (800–1000 rpm) as independent variables, and unilateral spreading width (W), track superposition uniformity (ω), and transverse coefficient of variation ($Cv$) as response indicators to characterize spreading range and particle distribution. The results showed that the spreading disc rotation speed had an extremely significant effect (p < 0.0001) on all three response indicators, while boat speed had no significant effect. The feed exhibited a characteristic double fan-shaped superposition distribution pattern. Through multi-objective optimization, the optimal operational parameters were determined as a boat speed of 1.0 m/s and a spreading disc rotation speed of 879 rpm, yielding a unilateral spreading width of 2.9 m, a track superposition uniformity of 88.31%, and a transverse coefficient of variation of 8.33%. This study establishes a quantitative method for analyzing feed spreading characteristics and clarifies the spreading range and particle distribution law, providing a reliable physical basis for full-coverage path planning of crab pond feeding boats. Full article

This paper develops the ideal plastic flow theory for the stationary planar flow of pressure-dependent materials. Two rigid plastic material models are considered. One of these models is the double-shearing model, and the other is the double slip and rotation model. Both are based on the Mohr–Coulomb yield criterion. It is shown that the general ideal plastic flow theory is only possible for the double slip and rotation model if the intrinsic spin vanishes. The theory applies to calculating the shape of optimal extrusion and drawing dies of minimum length. The latter condition requires a singular characteristic field. The solution is facilitated using the extended R–S method, commonly employed in the classical plasticity of pressure-independent materials. In particular, Riemann’s method is used in a region where all characteristics are curved. It is advantageous since determining the optimal shape does not require the characteristic field inside the region. The solution is semi-analytical. A numerical procedure is only required to evaluate ordinary integrals. It is shown that the optimal shape depends on the angle of internal friction involved in the yield criterion. Full article

The boundary conditions significantly affect solution behavior near rough interfaces. This paper presents general asymptotic analysis of solutions for the rigid plastic double slip and rotation model in the vicinity of an envelope of characteristics under plane strain and axially symmetric conditions. This model is used in the mechanics of granular materials. The analysis has important implications for solving boundary value problems because the envelope of characteristics is a natural boundary of the analytic solution. Moreover, an envelope of characteristics often coincides with frictional interfaces. In this case, the regime of sticking is not possible independently of the friction law chosen. It is shown that the solution is singular in the vicinity of envelopes. In particular, the profile of the velocity component tangential to the envelope is described by the sum of the constant and square root functions of the normal distance to the envelope in its vicinity. As a result, some components of the strain rate tensor approach infinity. This finding might help to develop an efficient numerical method for solving boundary value problems and provide the basis for the interpretation of some experimental results. Full article

The slip angle and attitude are vital for automated driving. In this paper, a systematic inertial measurement unit (IMU)-based vehicle slip angle and attitude estimation method aided by vehicle dynamics is proposed. This method can estimate the slip angle and attitude simultaneously and autonomously. With accurate attitude, the slip angle can be estimated precisely even though the vehicle dynamic model (VDM)-based velocity estimator diverges for a short time. First, the longitudinal velocity, pitch angle, lateral velocity, and roll angle were estimated by two estimators based on VDM considering the lever arm between the IMU and rotation center. When this information was in high fidelity, it was applied to aid the IMU-based slip angle and attitude estimators to eliminate the accumulated error correctly. Since there is a time delay in detecting the abnormal estimation results from VDM-based estimators during critical steering, a novel delay estimation and prediction structure was proposed to avoid the outlier feedback from vehicle dynamics estimators for the IMU-based slip angle and attitude estimators. Finally, the proposed estimation method was validated under large lateral excitation experimental tests including double lane change (DLC) and slalom maneuvers. Full article

Modeling the effect of deformation twinning and the ensuing twin-twin- and slip-twin-induced hardening is a long-standing problem in computational mechanical metallurgy of materials that deform by both slip and twinning. In this work, we address this effect using the twin volume transfer method, which obviates the need of any cumbersome criterion for twin variant selection. Additionally, this method is capable of capturing, at the same time, secondary or double twinning, which is particularly important for modeling in large strain regimes. We validate our modeling methodology by simulating the behavior of an Fe-23Mn-1.5Al-0.3C twinning-induced plasticity (TWIP) steel under large strain conditions, experimentally achieved in this work through equal-channel angular pressing (ECAP) for up to two passes in a 90° die following route B_C at 300 °C. Each possible twin variant, whether nucleating inside the parent grain or inside a potential primary twin variant was predefined in the initial list of orientations as possible grain of the polycrystal with zero initial volume fraction. A novelty of our approach is to take into account the loss of coherency of the twins with their parent matrix under large strains, obstructing progressively their further growth. This effect has been captured by attenuating growth rates of twins as a function of their rotation away from their perfect twin orientation, dubbed here as “disorientation” with respect to the mother grain’s lattice. The simulated textures and the hardening under tensile strain showed very good agreement with experimental characterization and mechanical testing results. Furthermore, upper-bound Taylor deformation was found to be operational for the TWIP steel deformation when all the above ingredients of twinning are captured, indicating that self-consistent schemes can be bypassed. Full article

A novel brushless double rotor machine (BDRM) is proposed in this paper. The BDRM is an important component in the brushless compound-structure permanent-magnet synchronous machine (CS-PMSM) system, which is a promising technology for power-split hybrid electric vehicle (HEV) applications. Compared with common double rotor machines, the brushes and slip rings required by rotating winding have been omitted in the BDRM, thus there are no such problems as maintenance, friction losses and so forth. Firstly, the torque characteristics of the BDRM are analyzed. As the stator has ring-shaped centralized windings, the size characteristics of the BDRM are different from those of conventional machines. The new sizing and torque equations are analyzed and the theoretical results are applied to determine the main dimensions. Additionally, studies of the analytical magnetic circuit and finite element method (FEM) model show that the BDRM tends to have high leakage flux and low power factor. Although the scope for improving the serious flux leakage of the BDRM is limited by the special magnetic topology, a method to obtain higher power factor is provided. Finally, a 10 kW prototype machine was manufactured, assembly of the prototype is discussed in detail and experimental tests are performed to validate the analytical and simulation results. Full article
