Search Results (35)

Amorphous lead oxide (a-PbO) X-ray photoconductors show potential for applications in direct conversion medical imaging detectors within the diagnostic energy range. a-PbO enables large-area deposition at low temperatures and exhibits no signal lag. Low dark current can be maintained through specialized blocking layers, similar to those used in multilayer amorphous selenium (a-Se) structures in commercial detectors. However, the current state of a-PbO technology faces challenges in thick layer deposition, leading to crystalline inclusions and cracks. Our proposed stress-induced crystallization model reveals that intrinsic stress in a-PbO layers amplifies with thickness, leading to crystallographic defects. These defects, which are associated with the stable phase of β-PbO, contribute to increased dark current and initiate layer cracking. We calculate the thermal expansion coefficient of a-PbO, indicating a thermomechanical mismatch between the photoconductor and the substrate as the primary source of stress. Furthermore, we demonstrate that layer deposition parameters significantly impact heat accumulation within the growing layer, thereby facilitating temperature-induced crystallization. Our study suggests that relieving stress in grown a-PbO layers by eliminating thermal expansion coefficient mismatches between different layers in a-PbO blocking structures, coupled with optimizing deposition parameters to prevent heat accumulation during layer growth, may inhibit or even prevent stress-induced crystallization and the emergence of structural defects in thick a-PbO layers. Full article

As screen sizes are becoming larger and larger, exceeding human physical limitations for direct interaction via touching, remote control is inevitable. However, among the current solutions, inertial gyroscopes are susceptible to positional inaccuracies, and gesture recognition is limited by cameras’ focus depths and viewing angles. Provided that the issue of ghost points can be effectively addressed, grating antenna light-trapping technology is an ideal candidate for multipoint inputs. Therefore, we propose a differential amplitude modulation scheme for grating antenna-based multi-beam optical touch, which can recognize different incidence points. The amplitude of the incident beams was first coded with different pulse widths. Then, following the capture of incident beams by the grating antenna and their conversion into electrical currents by the aligned detector arrays, the incident points of the individual beams were recognized and differentiated. The scheme was successfully verified on an 18-inch screen, where two-point optical touch with a position accuracy error of under 3 mm and a response time of less than 7 ms under a modulation frequency of 10 kHz on both incident beams was achieved. This work demonstrates a practical method to achieve remote multi-point touch, which can make digital mice more accurately represent the users’ pointing directions by obeying the natural three-point one-line aiming rule instantaneously. Full article

The oxidation behaviour of iron-based 316L stainless steel was investigated in the temperature range of 700 to 1000 °C. The test specimens in the shape of plates were produced by selective laser melting. After fabrication, the samples were sandblasted and then annealed in air for different periods of time (0.5, 2, 8, 32 h). Under the influence of temperature and time, stainless steels tend to form an oxide layer. Scanning electron microscopy, energy dispersive analysis, and X-ray diffraction were employed to analyse the composition of this layer. Notably, a thin oxide layer primarily composed of (Fe-Cr) formed on the surface due to temperature effects. In addition, with increasing temperature (up to 1000 °C), the oxide of the main alloying elements, specifically Mn₂(Fe-Cr)O₄, appeared alongside the Fe-Cr oxide. Furthermore, the samples were subjected to conversion X-ray (CXMS) and conversion electron (CEMS) Mössbauer spectroscopy. CXMS revealed a singlet with a decreasing Mössbauer effect based on the surface metal oxide thickness. CEMS revealed the presence of Fe³⁺ in the surface layer (0.3 µm). Moreover, an interesting phenomenon occurred at higher temperature levels due to the inhomogeneously thick surface metal oxide layer and the tangential direction of the Mössbauer radiation towards the electron detector. Full article

Understanding and managing land use/cover changes (LUCC) is crucial for ensuring the sustainability of the region. With the support of remote sensing technology, intensity analysis, the geodetic detector model, and the Mixed-Cell Cellular Automata (MCCA) model, this paper constructs an integrated framework linking historical evolutionary pattern-driving mechanisms for future simulation for LUCC in the Lower Liaohe Plain. From 1980 to 2018, the increasing trends were in built-up land and water bodies, and the decreasing trends were in grassland, cropland, forest land, unused land, and swamps. Overall, the changes in cropland, forest land, and built-up land are more active, while the changes in water bodies are more stable; the sources and directions of land use conversion are more fixed. Land use changes in the Lower Liaohe Plain are mainly influenced by socio-economic factors, of which population density, primary industry output value, and Gross Domestic Product (GDP) have a higher explanatory power. The interactive influence of each factor is greater than any single factor. The results of the MCCA model showed high accuracy, with an overall accuracy of 0.8242, relative entropy (RE) of 0.1846, and mixed-cell figure of merit (mcFoM) of 0.1204. By 2035, the built-up land and water bodies will increase, while the rest of the land use categories will decrease. The decrease is more pronounced in the central part of the plains. The findings of the study provide a scientific basis for strategically allocating regional land resources, which has significant implications for land use research in similar regions. Full article

The development of direct dimethyl ether (DME) solid oxide fuel cells (SOFCs) has several drawbacks, due to the low catalytic activity and carbon deposition of conventional Ni–zirconia-based anodes. In the present study, the insertion of 2.0 wt.% Ru-Ce_0.7Zr_0.3O_2−δ (ruthenium–zirconium-doped ceria, Ru-CZO) as an anode catalyst layer (ACL) is proposed to be a promising solution. For this purpose, the CZO powder was prepared by the sol–gel synthesis method, and subsequently, nanoparticles of Ru (1.0–2.0 wt.%) were synthesized by the impregnation method and calcination. The catalyst powder was characterized by BET-specific surface area, X-ray diffraction (XRD), field emission scanning electron microscopy with an energy-dispersive spectroscopy detector (FESEM-EDS), and transmission electron microscopy (TEM) techniques. Afterward, the catalytic activity of Ru-CZO catalyst was studied using DME partial oxidation. Finally, button anode-supported SOFCs with Ru-CZO ACL were prepared, depositing Ru-CZO onto the anode support and using an annealing process. The effect of ACL on the electrochemical performance of cells was investigated under a DME and air mixture at 750 °C. The results showed a high dispersion of Ru in the CZO solid solution, which provided a complete DME conversion and high yields of H₂ and CO at 750 °C. As a result, 2.0 wt.% Ru-CZO ACL enhanced the cell performance by more than 20% at 750 °C. The post-test analysis of cells with ACL proved a remarkable resistance of Ru-CZO ACL to carbon deposition compared to the reference cell, evidencing the potential application of Ru-CZO as a catalyst as well as an ACL for direct DME SOFCs. Full article

Distributed laser measurement systems, widely used in high-end equipment such as airplanes, ships, and other manufacturing fields, face challenges in large spatial measurements due to laser plane obstructions and weak intersections. This paper introduces a novel omnidirectional sensor with enhanced adaptability to complex environments and improved measurement accuracy. Initially, an integrated omnidirectional measurement model is established, followed by the analysis of the optical path of the front-end detector, and the design of a signal-conditioning circuit for the photoelectric conversion of the front-end laser signal, Subsequently, a circuit testing platform is established to validate the detection functionality, and the corresponding results indicate that the symmetry of the output waveform is under 10 ns, the response time is under 100 ns, and the maximum detection distance is 22 m. Further, experimental results demonstrate the superiority of omnidirectional sensors over planar ones in complex environments, successfully receiving 360° laser signals. The positional accuracy of the common point to be measured on the top of the omnidirectional sensor is confirmed to exceed 0.05 mm, and the accuracy of the angle of attitude exceeds 0.04°. Using the laser tracker, the measurement accuracy of the system is verified to be better than 0.3 mm. When rotating in the horizontal and pitch directions, the measurement accuracy is better than 0.35 mm and 0.47 mm, respectively, fulfilling the sub-millimeter precision requirement and expanding the application scope of distributed laser measurement systems. Full article

Ambient backscatter communication (AmBC), an emerging mechanism for batteryless communications that can utilize ambient radio-frequency signals to modulate information and thus reduce power consumption, has attracted considerable attention and has been considered as a critical technology in green “Internet of Things” sensor networks due to its ultra-low power consumption. This paper presents the first a complete dual-polarization AmBC (DPAm) system model, which can extend AmBC into polarization diversity and improve the data-transmission rate of backscatter symbols. We proposed two scenarios: direct dual-polarization-based DPAm node structures and polarization-conversion-based DPAm node structures. In addition, we consider a parallel backscatter mode with differential coding and develop corresponding detectors, which also give the analytical detection thresholds. Moreover, we consider a simultaneous backscatter mode with Manchester coding in order to avoid complex-parameter estimation. To address the power imbalance problem of the DPAm system that arises because the polarization deflection angle would cause the power level to change with different polarization patterns, we also develop a power-average detector and a clustering detector. Simulation results show the throughput performance on each DPAm node structure with each detector, demonstrating the feasibility and efficiency of the proposed DPAm nodes and detectors. Compared with single-polarization AmBC (SPAm), the proposed DPAm node can achieve higher throughput in most cases. Finally, the clustering detector is shown to be more robust to short training sequences and complex environments. Full article

We investigate the prospects for the direct detection of dark matter (DM) particles, incident on the upper atmosphere. A recent work relating the burst-like temperature excursions in the stratosphere at heights of ≈38–47 km with low speed incident invisible streaming matter is the motivation behind this proposal. As an example, dark photons could match the reasoning presented in that work provided they constitute part of the local DM density. Dark photons emerge as a U(1) symmetry within extensions of the standard model. Dark photons mix with real photons with the same total energy without the need for an external field, as would be required, for instance, for axions. Furthermore, the ionospheric plasma column above the stratosphere can resonantly enhance the dark photon-to-photon conversion. Noticeably, the stratosphere is easily accessible with balloon flights. Balloon missions with up to a few tons of payload can be readily assembled to operate for months at such atmospheric heights. This proposal is not limited to streaming dark photons, as other DM constituents could be involved in the observed seasonal heating of the upper stratosphere. Therefore, we advocate a combination of different types of measurements within a multi-purpose parallel detector system, in order to increase the direct detection potential for invisible streaming constituents that affect, annually and around January, the upper stratosphere. Full article

In this paper, the nexus between the Bell-state measurement and extracting phase information from the zeropoint field is investigated. For this purpose, the Wigner representation in the Heisenberg picture is applied in a Bell-type experiment in which the polarisation-entangled photon pairs generated in a type-II parametric down-conversion do not overlap. The signal intensities at the detectors are calculated in a four-mode approximation, being expressed as functions of the modules and phases of the four zeropoint amplitudes entering the crystal. A general criterion for identifying the correlated detectors is proposed based on the equality of the signal intensities, and without involving the calculation of the joint detection probabilities. In addition, from the analyses in the rectilinear and diagonal basis, it is shown that the distinguishability of the polarisation Bell states, which is in direct correspondence with the joint detection events in each experiment, can be related to the knowledge of the phases of the vacuum field entering the entanglement source, and giving rise to correlated detections. To this purpose, it is conjectured that a detection event is associated with a maximum value of the signal intensity averaged in the modules of the zeropoint amplitudes, as a function of the vacuum phases. Full article

Hybrid materials combining an organic matrix and high-Z nanomaterials show potential for applications in radiation detection, allowing unprecedented device architectures and functionality. Herein, novel hybrid organic–inorganic systems were produced using a mixture of tungstate (CaWO${}_4$ or ZnWO${}_4$) nanoparticles with a P3HT:PCBM blend. The nano-tungstates with a crystallite size of 43 nm for CaWO${}_4$ and 30 nm for ZnWO${}_4$ were synthesized by the hydrothermal method. Their structure and morphology were characterized by X-ray diffraction and scanning electron microscopy. The hybrid systems were used to fabricate direct conversion X-ray detectors able to operate with zero bias voltage. The detector performance was tested in a wide energy range using monochromatic synchrotron radiation. The addition of nanoparticles with high-Z elements improved the detector response to X-ray radiation compared with that of a pure organic P3HT:PCBM bulk heterojunction cell. The high dynamic range of our detector allows for recording X-ray absorption spectra, including the fine X-ray absorption structure located beyond the absorption edge. The obtained results suggest that nanocrystalline tungstates are promising candidates for application in direct organic–inorganic X-ray detectors. Full article

The agro-pastoral ecotone of northern China (AENC) is a significant ecological barrier, where the topographical features play basic roles in land-use change. In order to reveal the influence of topographical factors on land-use changes in the AENC, we used land-use transfer matrix, geo-information graphics, terrain niche, distribution index and geographical detector to explore the topographic gradient effect of land-use changes during 2000–2020 in the AENC based on remote-sensing image data from 2000, 2010, and 2020. The findings indicate that: (1) The total areas of land-use changes were 121,744 km², accounting for 17.41% between 2000–2020. This was characterized by increasing amounts of land-use changes in the AENC. The changes in land-use were dominated by the conversions among farmland, forestland, and grassland, which were distributed widely in the mountainous regions of northern, western, and eastern margins. The expansion of construction land was derived mainly from farmland and grassland occurred in river valleys. (2) The pattern of land-use changes was divided into five types including stable type, prophase change, anaphase change, continuous change, and repeated change. Stable type accounted for 559,868.86 km² and 80.09% of the total area. It was dominant in high altitude and complex terrain areas with terrain niches of more than 1.61. Prophase and anaphase changes accounted for 3.95% and 13.03%, respectively, which occupied to dominant positions in the 0.69–1.17 and 0.04–0.69, 1.17–1.61 terrain niches topographic gradient, respectively. Continuous and repeated changes occupied dominant positions in low altitude and flat complex areas with terrain niches of 0.04–1.17. (3) The topographic gradient effect of land-use changes in the AENC was influenced comprehensively by natural, geographical location, socioeconomic, and policy factors. Natural environmental factors and geographical location determined the topographic gradient pattern of land-use structure, while the direction of the topographical gradient pattern of land-use changes in the AENC is influenced by socioeconomic and policy factors. This research can provide a scientific reference for the development and protection of territorial space and optimal allocation of land resources in the AENC. Full article

Low-voltage direct current (LVDC) systems have been increasingly studied as new efficient power systems. However, existing studies have primarily focused on power conversion designs, control, and operation, and research on ground configurations of LVDC systemsis insufficient. Consideration of the installation criteria of protective equipment and grounding systems is crucial because ground configurations in general households for end users are highly associated with the risk of human electrocution. Therefore, we investigate a mid-point grounding system using capacitors to ensure electrical safety in a mono-polar LVDC system that a general end user can directly experience in a household. MATLAB/Simulink is used to analyze the fault characteristics of the mid-point grounding system using capacitors by considering the effects of DC on the human body based on the International Electrical Code (IEC). Consequently, this paper suggests the minimum required values of the capacitors and resistors to operate the DC residual current detector (DC RCD), and the operation of the DC RCD was confirmed. By confirming the applicability of DC RCD in a household LVDC system with a mid-point grounding system using capacitors and resistors, unnecessary power loss in a mid-point grounding system and electrical accidents, such as electric shocks and fires, could be minimized. Full article

Lead oxide (PbO) photoconductors are proposed as X-ray-to-charge transducers for the next generation of direct conversion digital X-ray detectors. Optimized PbO-based detectors have potential for utilization in high-energy and dynamic applications of medical X-ray imaging. Two polymorphs of PbO have been considered so far for imaging applications: polycrystalline lead oxide (poly-PbO) and amorphous lead oxide (a-PbO). Here, we provide the comparative analysis of two PbO-based single-pixel X-ray detector prototypes: one prototype employs only a layer of a-PbO as the photoconductor while the other has a combination of a-PbO and poly-PbO, forming a photoconductive bilayer structure of the same overall thickness as in the first prototype. We characterize the performance of these prototypes in terms of electron–hole creation energy (W_±) and signal lag—major properties that define a material’s suitability for low-dose real-time imaging. The results demonstrate that both X-ray photoconductive structures have an adequate temporal response suitable for real-time X-ray imaging, combined with high intrinsic sensitivity. These results are discussed in the context of structural and morphological properties of PbO to better understand the preparation–fabrication–property relationships of this material. Full article

In this work, we investigate the potential of employing a direct conversion integration mode X-ray detector with micron-scale pixels in two different X-ray phase-contrast imaging (XPCi) configurations, propagation-based (PB) and edge illumination (EI). Both PB-XPCi and EI-XPCi implementations are evaluated through a wave optics model—numerically simulated in MATLAB—and are compared based on their contrast, edge-enhancement, visibility, and dose efficiency characteristics. The EI-XPCi configuration, in general, demonstrates higher performance compared to PB-XPCi, considering a setup with the same X-ray source and detector. However, absorption masks quality (thickness of X-ray absorption material) and environmental vibration effect are two potential challenges for EI-XPCi employing a detector with micron-scale pixels. Simulation results confirm that the behavior of an EI-XPCi system employing a high-resolution detector is susceptible to its absorption masks thickness and misalignment. This work demonstrates the potential and feasibility of employing a high-resolution direct conversion detector for phase-contrast imaging applications where higher dose efficiency, higher contrast images, and a more compact imaging system are of interest. Full article

The reduction of the dark current (DC) to a tolerable level in amorphous selenium (a-Se) X-ray photoconductors was one of the key factors that led to the successful commercialization of a-Se-based direct conversion flat panel X-ray imagers (FPXIs) and their widespread clinical use. Here, we discuss the origin of DC in another X-ray photoconductive structure that utilizes amorphous lead oxide (a-PbO) as an X-ray-to-charge transducer and polyimide (PI) as a blocking layer. The transient DC in a PI/a-PbO detector is measured at different applied electric fields (5–20 V/μm). The experimental results are used to develop a theoretical model describing the electric field-dependent transient behavior of DC. The results of the DC kinetics modeling show that the DC, shortly after the bias application, is primarily controlled by the injection of holes from the positively biased electrode and gradually decays with time to a steady-state value. DC decays by the overarching mechanism of an electric field redistribution, caused by the accumulation of trapped holes in deep localized states within the bulk of PI. Thermal generation and subsequent multiple-trapping (MT) controlled transport of holes within the a-PbO layer governs the steady-state value at all the applied fields investigated here, except for the largest applied field of 20 V/μm. This suggests that a thicker layer of PI would be more optimal to suppress DC in the PI/a-PbO detector presented here. The model can be used to find an approximate optimal thickness of PI for future iterations of PI/a-PbO detectors without the need for time and labor-intensive experimental trial and error. In addition, we show that accounting for the field-induced charge carrier release from traps, enhanced by charge hopping transitions between the traps, yields an excellent fit between the experimental and simulated results, thus, clarifying the dynamic process of reaching a steady-state occupancy level of the deep localized states in the PI. Practically, the electric field redistribution causes the internal field to increase in magnitude in the a-PbO layer, thus improving charge collection efficiency and temporal performance over time, as confirmed by experimental results. The electric field redistribution can be implemented as a warm-up time for a-PbO-based detectors. Full article
