Search Results (19)

It is essential to investigate the performance output and flow characteristics within deep-sea mineral extraction pumps using appropriate numerical calculation methods. In this study, by taking a deep-sea mineral extraction pump prototype as the subject, a small-scale mineral extraction pump model was constructed. Computational fluid dynamics methods, incorporating the SST$k-\omega$ turbulence model and the discrete phase model, were utilized to systematically investigate the pressure distribution, velocity field, streamline patterns, and performance characteristics of the mineral extraction pump under three operating conditions—low flow rate, rated flow rate, and high flow rate—while transporting mineral particles of three distinct sizes. The results demonstrated that the larger size of the mineral particles induced greater disturbance to the liquid phase. Under different flow conditions, the correlations between the particle size and both the head drop rate and power drop rate exhibited distinct characteristics. Experiments verified the rationality and precision of the numerical simulation approach. This study provides a methodological reference for analyzing the flow characteristics and performance output of deep-sea mineral extraction pumps. Full article

Centrifugal slurry pumps are extensively applied in industrial industries such as power metallurgy, petrochemicals, deep-sea mining, and other industrial fields. The primary objective of this research is to assess how conveying settings and particle characteristics influence the 100SHL4147 slurry pump’s collision and erosion properties. Firstly, the computational fluid dynamics–discrete element method (CFD-DEM) coupling model fully coupled particle–fluid co-flow numerical simulation interface is built by utilizing the C++ language and the results are proven with tests. Subsequently, the simulation examines the wear properties of different sections through which the flow passes in the 100SHL4147 centrifugal slurry pump. In addition, following theoretical guidance, the slurry pump impeller’s wear resistance performance can be improved by adjusting design factors such as the intake edge location and the blade wrap angle. The results are as follows. It is recommended to replace the impeller promptly due to the findings that indicate that the entire blade’s pressure surface is vulnerable to different degrees of erosion under high-concentration situations. When the particle size increased from 0.4 to 0.8 mm, the wear rate decreased by up to 15%, as fewer particles were transported, lowering the collision frequency. Conversely, smaller particles intensify component wear. Adjusting the blade wrap angle from 66° to 96° reduced impeller and volute wear by an estimated 20%, enhancing the durability but slightly decreasing the delivery capacity. Extending the blade’s leading edge toward the intake improved the flow capacity, although it increased the wear frequency from one-third of the pressure surface to the trailing edge. Full article

The deep-sea mining lift pump is one of the pivotal components in deep-sea mineral transportation systems and its internal flow is very complex; consequently, unraveling its unsteady flow behavior pattern holds immense practical value. This study adopts numerical methods to analyze the time-averaged distribution characteristics of the internal flow field in mining lift pumps, as well as the flow field’s pulsation intensity distribution characteristics, the vortex’s spatiotemporal evolution process in both moving and static cascades, and the time- and frequency-domain pulsation characteristics of internal pressure in each flow passage component under four different flow conditions are also investigated. The hydraulic properties of mining lift pumps under these four different conditions are also evaluated, and the outcomes are benchmarked against those of numerical predictions. Our findings reveal that the interplay between impeller blades and guide vanes significantly influences the pump’s flow characteristics, with the pump’s unsteady flow influencing its hydraulic properties. Experimental validation of this system confirms that the pump under study is in line with design specifications in terms of hydraulic properties. The method validation test on the prototype pump shows that the SST k-ω model is capable of successfully forecasting instability in the flow features of deep-sea mining lift pumps. These results will serve as a theoretical reference for regulating the flow state inside deep-sea mining lift pumps. Full article

Amid the escalating global demand for raw materials, the gradual exhaustion of terrestrial mineral resources, and the rise in extraction costs and energy consumption, the development of deep-sea mineral resources has become a focal point of international interest. The pipeline lifting mining system, distinguished by its superior mining efficiency and minimized environmental impact, now accounts for over 50% of the total energy consumption in mining operations. Serving as the “heart” of this system, the deep-sea lifting pump’s comprehensive performance (high pressure tolerance, non-clogging features, elevated lift capacity, wear resistance, corrosion resistance, and high reliability, etc.), is critical to transport efficiency, operational stability, and lifespan of the mining system. As a mixed transport pump for solid and liquid media under extreme conditions, its internal flow structure is exceedingly complex, incorporating gas–liquid–solid multiphase flow. A precise understanding of its internal flow mechanisms is essential for breaking through the design limitations of deep-sea lifting pumps and enhancing their operational stability and reliability under various working conditions and multiphase media, thereby providing technical support for advancing global marine resource development and offshore equipment upgrades. This paper comprehensively reviews the design theory, optimization methods, numerical simulations, and experimental studies of deep-sea lifting pumps. It discusses the application of various design optimization techniques in hydraulic lifting pumps, details the multiphase flow numerical algorithms commonly used in deep-sea lifting pumps along with their modified models, and summarizes some experimental methodologies in this field. Lastly, it outlines the forthcoming challenges in deep-sea lifting pump research and proposes potential directions to promote the commercial development of deep-sea mining, thereby offering theoretical and engineering support for the development of deep-sea mining slurry pumps. Full article

In deep-sea mining hydraulic lifting systems, centrifugal pumps are very important as power units. In the process of transportation, the fluid prewhirl phenomenon in the impeller inlet will lead to changes in the state of motion of the particles and fluid and cause the wear of the inlet pipe, which can lead to centrifugal pump failure in serious cases. In this paper, a numerical simulation of the centrifugal pump is carried out based on the CFD-DEM coupling method to analyze the influence of the prewhirl on the wear of the inlet pipe. The results show that the velocity streamline near the impeller inlet position changes significantly. The flow field velocity increases along the radial direction of the inlet pipe, and it has a maximum value at r/R = 0.98. The prewhirl flow pulls the particles to change their original motion direction, and the area where the particles are subjected to high fluid force is concentrated between 0.5 d/D and 1 d/D, about 0.015 to 0.018 N, resulting in the uneven distribution of particles. The high-wear area appears in the bottom-left area (specifically, L4, L9, and L13), and this is also the location of the largest cumulative force; the high-wear area shows a triangle. The collision energy loss of particles increases due to the influence of the prewhirl, which leads to an increase in wear. Full article

In response to the anticipated scarcity of terrestrial land resources in the coming years, the acquisition of marine mineral resources is imperative. This paper mainly summarizes the development of underwater collection and transportation equipment of polymetallic nodules in deep-sea mining. Firstly, the collection equipment is reviewed. The deep-sea mining vehicle (DSMV), as the key equipment of the collection equipment, mainly includes the collecting device and the walking device. The micro and macro properties of sediments have a great influence on the collection efficiency of mining vehicles. For the collecting device, the optimization of the jet head structure and the solid–liquid two-phase flow transport of the hose are discussed. The structure of the walking device restricts mining efficiency. The optimization of the geometric structure is studied, and the geometric passability and lightweight design of the walking device are discussed. Secondly, the core of transportation equipment is the lifting device composed of a riser and lifting pump. In order to explore the key factors affecting mineral transport, the lifting device is summarized, and the design optimization of the lifting pump and the factors affecting the stability of the riser are discussed. Then, the relationship between each device is discussed, and the overall coupling of the device is summarized. Finally, the existing problems and future research focus are summarized. Full article

The electrochemical ion pumping device is a promising alternative for the development of the industry of recovering metals from natural sources—such as seawater, geothermal water, well brine, or reverse osmosis brine—using electrochemical systems, which is considered a non-evaporative process. This technology is potentially used for metals like Li, Cu, Ca, Mg, Na, K, Sr, and others that are mostly obtained from natural brine sources through a combination of pumping, solar evaporation, and solvent extraction steps. As the future demand for metals for the electronic industry increases, new forms of marine mining processing alternatives are being implemented. Unfortunately, both land and marine mining, such as off-shore and deep sea types, have great potential for severe environmental disruption. In this context, a green alternative is the mixing entropy battery, which is a promising technique whereby the ions are captured from a saline natural source and released into a recovery solution with low ionic force using intercalation materials such as Prussian Blue Analogue (PBA) to store cations inside its crystal structure. This new technique, called “electrochemical ion pumping”, has been proposed for water desalination, lithium concentration, and blue energy recovery using the difference in salt concentration. The raw material for this technology is a saline solution containing ions of interest, such as seawater, natural brines, or industrial waste. In particular, six main ions of interest—Na⁺, K⁺, Mg²⁺, Ca²⁺, Cl⁻, and SO₄²⁻—are found in seawater, and they constitute 99.5% of the world’s total dissolved salts. This manuscript provides relevant information about this new non-evaporative process for recovering metals from aqueous salty solutions using hexacianometals such as CuHCF, NiHCF, and CoHCF as electrodes, among others, for selective ion removal. Full article

There is a significant energy transition in progress globally. This is mainly driven by the insertion of variable sources of energy, such as wind and solar power. To guarantee that the supply of energy meets its demand, energy storage technologies will play an important role in integrating these intermittent energy sources. Daily energy storage can be provided by batteries. However, there is still no technology that can provide weekly, monthly and seasonal energy storage services where pumped hydro storage is not a viable solution. Herein, we introduce an innovative energy storage proposal based on isothermal air compression/decompression and storage of the compressed air in the deep sea. Isothermal deep ocean compressed air energy storage (IDO-CAES) is estimated to cost from 1500 to 3000 USD/kW for installed capacity and 1 to 10 USD/kWh for energy storage. IDO-CAES should complement batteries, providing weekly, monthly and seasonal energy storage cycles in future sustainable energy grids, particularly in coastal areas, islands and offshore and floating wind power plants, as well as deep-sea mining activities. Full article

Lifting coarse mineral particles from thousands of meters of seabed to the supportive vessSel is a crucial part of exploitation of deep-sea mineral resources, and the vertical transportation part is a key component of the deep-sea mining system. Three typical vertical transportation schemes are discussed and compared from the aspects of working mechanism, structural scheme, transportation capacity, system efficiency and implementation feasibility in the context of commercial exploitation of deep-sea polymetallic nodules. The conclusion is that the hydraulic pipeline lifting system with a centrifugal pump is a comprehensive scheme. Furthermore, the basic composition and function of the hydraulic lifting system are introduced, and the transportation performance indicators and technical requirements under commercial mining conditions are analyzed. As the key equipment of the lifting system, the structural characteristics, design theory, transportation performance analysis methods and research progress of the lifting pump are described. A 1000 m sea trial was carried out. The lifting system, the tests of the centrifugal pump and the sea trial are introduced. Full article

A pump-jet, which is generally and widely adopted on underwater vehicles for applications from deep sea exploration to mine clearing, consists of a rotor, stator, and duct, with the properties of high critical speed, high propulsion efficiency, great anti-cavitation performance, and low radiated noise. The complex interaction of the flow field between the various components and the high degree of coupling with the appendage result in the requirements of in-depth research on the hydrodynamic performance and flow field for application and design. Due to the initial application on the military field and complicated structure, there is scant literature in the evaluation of pump-jet performance and optimal design. This paper, in a comprehensive and specialized way, summarizes the pump-jet hydrodynamic performance, noise performance, and flow field characteristics involving cavitation erosion and vortices properties of tip-clearance, the interaction between the rotor and the stator and the wake field, as well as the optimal design of the pump-jet. The merits and applications range of numerical and experimental methods are overviewed as well as the design method. It also concludes the main challenges faced in practical applications and proposes a vision for future research. It was found that the compact structure and complex internal and external flow field make the pump-jet significantly different, also leading to higher performance. As the focus of cavitation research, vortices interact with the complex structure of the pump-jet, leading to instabilities of the flow field, such as vibration, radiated noise, and cavitation erosion. The effective approaches are adopted to reduce radiated pump-jet with minimal influence on the hydrodynamic performance, such as eliminating the tip clearance and installing the sawtooth duct. Advanced optimal technology can achieve high performance, cavitation performance, and acoustic performance, possessing good prospects. Further developments in investigation and the application of pump-jets in the multidisciplinary integration of fluid dynamics, acoustics, materials, chemistry, and bionics should be the main focus in future research. Full article

In order to improve the hydraulic performance of a deep-sea mining pump, this research proposed a multi-objective optimization strategy based on the computational fluid dynamics (CFD) numerical simulation, genetic algorithm back propagation (GABP) neural network, and non-dominated sorting genetic algorithm-III (NSGA-III). Significance analysis of the impeller and diffuser parameters was conducted using the Plackett–Burman experiment to filter out the design variables. The optimum Latin hypercube sampling method was used to produce sixty sample cases. The GABP neural network was then utilized to establish an approximate model between the pump’s hydraulic performance and design variables. Finally, the NSGA-III was utilized to solve the approximation model to determine the optimum parameters for the impeller and diffuser. The results demonstrate that the GABP neural network can accurately forecast the deep-sea mining pump’s hydraulic performance, and the NSGA-III global optimization is effective. On the rated clear water conditions, the optimized pump has a 14.65% decrease in shaft power and a 6.04% increase in efficiency while still meeting the design requirements for the head. Under rated solid-liquid two-phase flow conditions, the head still meets the design requirements, the shaft power is decreased by 15.64%, and the efficiency is increased by 6.00%. Full article

The returnability of the deep-sea mining pump has been a key issue restricting further development of deep-sea mining technologies. Although many research studies have been conducted on mining pump, the mining process still faces challenges. Particularly, the reflux capacities of externally developed mine pumps are often insufficient, resulting in blockages in the flow channels. In this study, we determine that the blade wrap angle is one of the key factors affecting the reflux of the ore pump, which is also based on earlier research. Therefore, a numerical simulation of the ore pump was performed using computational fluid dynamics–discrete element method, and it was determined to be beneficial to the reflux of particles. The hydraulic performance and reflux ability were studied via experiments. Full article

A key piece of equipment in deep-sea mineral particle transportation systems, the deep-sea mining pump can be affected by factors such as different mineral particle parameters as well as its operating conditions. In this study, the influence of different particle parameters—such as particle size, concentration, and density—and different operating conditions—such as flow rate and speed—on the pressure and particle velocity distribution in a mining pump, as well as the movement trajectory of the particles in it, were analyzed. The reduction in the head and efficiency of the mining pump were obtained, and a comparison between experimental results and numerical calculations was conducted. The experimental and numerical analysis results showed good agreement, verifying the analytical results and the performance of the mining pump. Full article

In the process of conveying coarse-grained minerals, the internal flow-through passage components of mining pumps are subject to wear. The flow of coarse particles in such pumps is complex and changes constantly, making it necessary to study the non-steady-state wear characteristics and test the flow passage components. The evolution of the surface wear rate for the flow passage components during one third of a rotation cycle (120°) of a mining pump impeller with small, design, and large flow rates was analyzed in this study based on a discrete phase model (DPM). The flow that occurs during an entire rotation cycle of the impeller was investigated. The wear test was carried out with a small test pump with the same specific speed as and a similar structure to that of the deep-sea mining pump. The test results were compared with the numerical calculation results of the deep-sea mining pump obtained by using the same numerical calculation method and wear model, and the test wear area was found to be more consistent with the numerical calculation wear area. The results show that the numerical calculation method used in this article can more accurately predict the surface wear of the passage components of the mining pump and provides a suitable method for the prediction of the wear characteristics of the mining pump. Full article

Centrifugal pumps are the critical components in deep-sea mining. In order to investigate the particle motion in the curved channel of the impeller, three different types of curvature conform to blade profile to simplify the impeller design of pumps. A numerical study is conducted to investigate the flow field in a varying-curvature channel for solid-liquid two-phase flow. The flow of particles within the varying curvature channel is studied by combining the discrete element method (DEM) with computational fluid dynamics (CFD) and a comparison with Particle Image Velocimetry (PIV) test results. The results show that a polyhedral mesh with a small mesh number yields very accurate results, which makes it very suitable for CFD-DEM. Based on this method, the movement of a single particle is compared and analyzed, and the particle-motion law is obtained. The effects of the curvature ratio Cr and area ratio Ar on the motion law for a single particle are studied, and the simulation results are analyzed statistically. The results show that the effect of Cr on both the particle slip velocity and the turbulent kinetic energy only changes its strength, while the distribution law does not change significantly. Compared with the curvature ratio Cr, the area ratio Ar has a greater impact on the particles, and its distribution law becomes clearly different. As the area ratio Ar increases, the arc radius and length of the corresponding particle trajectory decrease. Full article
