We present a quantitative and qualitative evaluation of despeckling filters based on a set of Haralick-derived features and the Jensen–Shannon Divergence obtained from ratio images. To that aim, we propose a normalized composite index, called the Texture-Divergence Measurement ($TDM$), that describes the statistical and structural behavior of the filtered images. Complementary qualitative analysis using Image Horizontal Visibility Graphs (IHVGs) confirms the results of the proposed metric. The combination of the proposed $TDM$ metric and IHVG visualization provides a robust framework for assessing despeckling performance from both statistical and structural perspectives. Full article

This paper presents an analysis of different despeckling filters applied on both synthetically corrupted optical images and actual Synthetic Aperture Radar (SAR) images. Several authors use optical images as ground truth and then the images are corrupted by using a Gamma model to simulate the speckle, while other approaches use methods like multitemporal fusion to generate a ground truth using actual SAR images, which provides a result somehow equivalent to the one from the common multi look technique. Well-known filters, like local, and non-local and some of them based on artificial intelligence and deep learning, are applied to these two types of images and their performance is assessed by a quantitative analysis. One last validation is performed with a newly proposed method by using ratio images, resulting from the mathematical division (Hadamard division) of filtered and noisy images, to measure how similar the initial and the remaining speckle are by considering its Gamma distribution and divergence measurement. Our findings suggest that despeckling models relying on artificial intelligence exhibit notable efficiency, albeit concurrently displaying inflexibility when applied to particular image types based on the training dataset. Additionally, our experiments underscore the utility of the divergence measurement in ratio images in facilitating both visual inspection and quantitative evaluation of residual speckles within the filtered images. Full article

Synthetic aperture radar (SAR) images are inevitably interspersed with speckle noise due to their coherent imaging mechanism, which greatly hinders subsequent related research and application. In recent studies, deep learning has become an effective tool for despeckling remote sensing images. However, preserving more texture details while removing speckle noise remains a challenging task in the field of SAR image despeckling. Furthermore, most despeckling algorithms are designed specifically for a specific look and seriously lack generalizability. Therefore, in order to remove speckle noise in SAR images, a novel end-to-end frequency domain decomposition network (SAR−FDD) is proposed. The method first performs frequency domain decomposition to generate high-frequency and low-frequency information. In the high-frequency branch, a mean filter is employed to effectively remove noise. Then, an interactive dual-branch framework is utilized to learn the details and structural information of SAR images, effectively reducing speckles by fully utilizing features from different frequencies. In addition, a blind denoising model is trained to handle noisy SAR images with unknown noise levels. The experimental results demonstrate that the SAR−FDD achieves good visual effects and high objective evaluation metrics on both simulated and real SAR test sets (peak signal-to-noise ratio (PSNR): 27.59 ± 1.57 and structural similarity index (SSIM): 0.78 ± 0.05 for different speckle noise levels), demonstrating its strong denoising performance and ability to preserve edge textures. Full article

Speckle noise is an inherent problem of synthetic aperture radar (SAR) images, which not only seriously affects the acquisition of SAR image information, but also greatly reduces the efficiency of image segmentation and feature classification. Therefore, research on how to effectively suppress speckle noise while preserving SAR image content information as much as possible has received increasing attention. Based on the non-local idea of SAR image block-matching three-dimensional (SAR-BM3D) algorithm and the concept of sparse representation, a novel SAR image despeckling algorithm is proposed. The new algorithm uses K-means singular value decomposition (K-SVD) to learn the dictionary to distinguish valid information and speckle noise and constructs a block filter based on K-SVD for despeckling, so as to avoid strong point diffusion problem in SAR-BM3D and achieve better speckle noise suppression with stronger adaptability. The experimental results on real SAR images show that the proposed algorithm achieves better comprehensive effect of speckle noise suppression in terms of evaluation indicators and information preservation of SAR images compared with several existing algorithms. Full article

Speckle noise is a pervasive problem in medical imaging, and conventional methods for despeckling often lead to loss of edge information due to smoothing. To address this issue, we propose a novel approach that combines a nature-inspired minibatch water wave swarm optimization (NIMWVSO) framework with an invertible sparse fuzzy wavelet transform (ISFWT) in the frequency domain. The ISFWT learns a non-linear redundant transform with a perfect reconstruction property that effectively removes noise while preserving structural and edge information in medical images. The resulting threshold is then used by the NIMWVSO to further reduce multiplicative speckle noise. Our approach was evaluated using the MSTAR dataset, and objective functions were based on two contrasting reference metrics, namely the peak signal-to-noise ratio (PSNR) and the mean structural similarity index metric (MSSIM). Our results show that the suggested approach outperforms modern filters and has significant generalization ability to unknown noise levels, while also being highly interpretable. By providing a new framework for despeckling medical images, our work has the potential to improve the accuracy and reliability of medical imaging diagnosis and treatment planning. Full article

An excellent quantitative evaluation method of SAR de-speckling filters needs to contain a comprehensive evaluation of both noise smoothing and edge preservation. However, most existing evaluation models only evaluate a single aspect, while a few comprehensive indicators lack robustness. For this reason, a novel integrated quantitative evaluation method of de-speckling filters is proposed. The proposed evaluation method is weighted by two sub-indicators: the coherent equivalent number of looks and edge preservation evaluation. The evaluation indicator of the coherent equivalent number of looks is built to evaluate the noise-smoothing ability of de-speckling filters, whereas the indicator of edge preservation evaluation is built to evaluate the edge-preserving performance of filtered image. Six filters with an excellent performance, five real synthetic aperture radar images with three bands, four polarization modes, four resolutions, and five common evaluation indexes were used in the experiment. The experimental results show that the evaluation results of the proposed evaluation method were consistent with the visual effect and other indicators, and its feasibility was verified. Full article

Multispectral imagery provides unprecedented information on Earth system processes: however, data gaps due to clouds and shadows are a major limitation. Normalized-Difference Vegetation Index (NDVI) and Normalized-Difference Water Index (NDWI) are two spectral indexes employed for monitoring vegetation phenology, land-cover change and more. Synthetic Aperture Radar (SAR) with its cloud-penetrating abilities can fill data gaps using coincident imagery. In this study, we evaluated C-band Sentinel-1, L-band Uninhabited Aerial Vehicle SAR (UAVSAR) and texture for gap filling using efficient machine learning regression algorithms across three seasons. Multiple models were evaluated including Support Vector Machine, Random Forest, Gradient Boosted Trees and an ensemble of models. The Gap filling ability of SAR was evaluated with Sentinel-2 imagery from the same date, 3 days and 8 days later than both SAR sensors in September. Sentinel-1 and Sentinel-2 imagery from winter and spring seasons were also evaluated. Because SAR imagery contains noise, we compared two robust de-noising methods and evaluated performance against a refined lee speckle filter. Mean Absolute Error (MAE) rates of the cloud gap-filling model were assessed across different dataset combinations and land covers. The results indicated de-noised Sentinel-1 SAR and UAVSAR with GLCM texture provided the highest predictive abilities with random forest R² = 0.91 (±0.014), MAE = 0.078 (±0.003) (NDWI) and R² = 0.868 (±0.015), MAE = 0.094 (±0.003) (NDVI) during September. The highest errors were observed across bare ground and forest, while the lowest errors were on herbaceous and woody wetland. Results on January and June imagery without UAVSAR were less strong at R² = 0.60 (±0.036), MAE = 0.211 (±0.005) (NDVI), R² = 0.61 (±0.043), MAE = 0.209 (±0.005) (NDWI) for January and R² = 0.72 (±0.018), MAE = 0.142 (±0.004) (NDVI), R² = 0.77 (±0.022), MAE = 0.125 (±0.004) (NDWI) for June. Ultimately, the results suggest de-noised C-band SAR with texture metrics can accurately predict NDVI and NDWI for gap-filling clouds during most seasons. These shallow machine learning models are rapidly trained and applied faster than intensive deep learning or time series methods. Full article

The ultrasonic technique is an indispensable imaging modality for diagnosis of breast cancer in young women due to its ability in efficiently capturing the tissue properties, and decreasing nega-tive recognition rate thereby avoiding non-essential biopsies. Despite the advantages, ultrasound images are affected by speckle noise, generating fine-false structures that decrease the contrast of the images and diminish the actual boundaries of tissues on ultrasound image. Moreover, speckle noise negatively impacts the subsequent stages in image processing pipeline, such as edge detec-tion, segmentation, feature extraction, and classification. Previous studies have formulated vari-ous speckle reduction methods in ultrasound images; however, these methods suffer from being unable to retain finer edge details and require more processing time. In this study, we propose a breast ultrasound de-speckling method based on rotational invariant block matching non-local means (RIBM-NLM) filtering. The effectiveness of our method has been demonstrated by com-paring our results with three established de-speckling techniques, the switching bilateral filter (SBF), the non-local means filter (NLMF), and the optimized non-local means filter (ONLMF) on 250 images from public dataset and 6 images from private dataset. Evaluation metrics, including Self-Similarity Index Measure (SSIM), Peak Signal to Noise Ratio (PSNR), and Mean Square Error (MSE) were utilized to measure performance. With the proposed method, we were able to record average SSIM of 0.8915, PSNR of 65.97, MSE of 0.014, RMSE of 0.119, and computational speed of 82 seconds at noise variance of 20dB using the public dataset, all with p-value of less than 0.001 compared against NLMF, ONLMF, and SBF. Similarly, the proposed method achieved av-erage SSIM of 0.83, PSNR of 66.26, MSE of 0.015, RMSE of 0.124, and computational speed of 83 seconds at noise variance of 20dB using the private dataset, all with p-value of less than 0.001 compared against NLMF, ONLMF, and SBF. Full article

Despeckling is a key preprocessing step for applications using PolSAR data in most cases. In this paper, a technique based on a nonlocal weighted linear minimum mean-squared error (NWLMMSE) filter is proposed for polarimetric synthetic aperture radar (PolSAR) speckle filtering. In the process of filtering a pixel by the LMMSE estimator, the idea of nonlocal means is employed to evaluate the weights of the samples in the estimator, based on the statistical equalities between the neighborhoods of the sample pixels and the processed pixel. The NWLMMSE estimator is then derived. In the preliminary processing, an effective step is taken to preclassify the pixels, aiming at preserving point targets and considering the similarity of the scattering mechanisms between pixels in the subsequent filter. A simulated image and two real-world PolSAR images are used for illustration, and the experiments show that this filter is effective in speckle reduction, while effectively preserving strong point targets, edges, and the polarimetric scattering mechanism. Full article

In this work, we extended a procedure for the spatial decorrelation of fully-developed speckle, originally developed for single-polarization SAR data, to fully-polarimetric SAR data. The spatial correlation of the noise depends on the tapering window in the Fourier domain used by the SAR processor to avoid defocusing of targets caused by Gibbs effects. Since each polarimetric channel is focused independently of the others, the noise-whitening procedure can be performed applying the decorrelation stage to each channel separately. Equivalently, the noise-whitening stage is applied to each element of the scattering matrix before any multilooking operation, either coherent or not, is performed. In order to evaluate the impact of a spatial decorrelation of the noise on the performance of polarimetric despeckling filters, we make use of simulated PolSAR data, having user-defined polarimetric features. We optionally introduce a spatial correlation of the noise in the simulated complex data by means of a 2D separable Hamming window in the Fourier domain. Then, we remove such a correlation by using the whitening procedure and compare the accuracy of both despeckling and polarimetric features estimation for the three following cases: uncorrelated, correlated, and decorrelated images. Simulation results showed a steady improvement of performance scores, most notably the equivalent number of looks (ENL), which increased after decorrelation and closely attained the value of the uncorrelated case. Besides ENL, the benefits of the noise decorrelation hold also for polarimetric features, whose estimation accuracy is diminished by the correlation. Also, the trends of simulations were confirmed by qualitative results of experiments carried out on a true Radarsat-2 image. Full article

For the existence of speckles, many standard optical image processing methods, such as classification, segmentation, and registration, are restricted to synthetic aperture radar (SAR) images. In this work, an end-to-end deep multi-scale recurrent network (MSR-net) for SAR image despeckling is proposed. The multi-scale recurrent and weights sharing strategies are introduced to increase network capacity without multiplying the number of weights parameters. A convolutional long short-term memory (convLSTM) unit is embedded to capture useful information and helps with despeckling across scales. Meanwhile, the sub-pixel unit is utilized to improve the network efficiency. Besides, two criteria, edge feature keep ratio (EFKR) and feature point keep ratio (FPKR), are proposed to evaluate the performance of despeckling capacity for SAR, which can assess the retention ability of the despeckling algorithm to edge and feature information more effectively. Experimental results show that our proposed network can remove speckle noise while preserving the edge and texture information of images with low computational costs, especially in the low signal noise ratio scenarios. The peak signal to noise ratio (PSNR) of MSR-net can outperform traditional despeckling methods SAR-BM3D (Block-Matching and 3D filtering) by more than 2 dB for the simulated image. Furthermore, the adaptability of optical image processing methods to real SAR images can be enhanced after despeckling. Full article

A novel empirical approach to categorize oil slicks’ sea surface expressions in synthetic aperture radar (SAR) measurements into oil seeps or oil spills is investigated, contributing both to academic remote sensing research and to practical applications for the petroleum industry. We use linear discriminant analysis (LDA) to try accuracy improvements from our previously published methods of discriminating seeps from spills that achieved ~70% of overall accuracy. Analyzing 244 RADARSAT-2 scenes containing 4562 slicks observed in Campeche Bay (Gulf of Mexico), our exploratory data analysis evaluates the impact of 61 combinations of SAR backscatter coefficients (σ°, β°, γ°), SAR calibrated products (received radar beam given in amplitude or decibel, with or without a despeckle filter), and data transformations (none, cube root, log₁₀). The LDA ability to discriminate the oil-slick category is rather independent of backscatter coefficients and calibrated products, but influenced by data transformations. The combination of attributes plays a role in the discrimination; combining oil-slicks’ size and SAR information is more effective. We have simplified our analyses using fewer attributes to reach accuracies comparable to those of our earlier studies, and we suggest using other multivariate data analyses—cubist or random forest—to attempt to further improve oil-slick category discrimination. Full article

Speckle noise is presented as an inherent dilemma that affects the image processing field, and in particular synthetic aperture radar images. In order to mitigate the adverse effects caused by this phenomenon, several approaches have been introduced in the scientific community during the last three decades including spatial-based and non-local filtering approaches. However, these proposed techniques suffer from some limitations. In fact, it is very difficult to find an approach that is able, on the one hand, to perform well in terms of noise reduction and image detail preservation and, on the other hand, provide a filtering output solution without high computational complexity and within a short processing time. In this paper, we aim to evaluate the performance of a newly-developed despeckling algorithm, presented as an enhancement of the classical Wiener filter and properly designed to work with a Graphics Processing Unit (GPU). The algorithm is tested on both a simulated framework and real Sentinel-1 SAR data. The results, obtained in comparison with other filters, are interesting and promising. Indeed, the proposed method turns out to be a useful filtering instrument in the case of large images by performing the processing within a limited time and ensuring good speckle noise reduction with a considerable image detail preservation. Full article

Due to the inherent characteristics of the electromagnetic wave scattering phenomenon, synthetic aperture radar (SAR) images are directly degraded by high-frequency multiplicative speckle (HMS) noise, which makes image de-speckling filter application and selection a challenge. In this regard, an adverse effects analysis of the HMS under implementation of seven different spatial de-speckling filters on a reference SAR image is considered in this paper. The investigation includes the formulation of the backscattered data and the HMS based on the pixel statistics and their distribution as an image noise behavioral analysis method. The resulting complex behavioral model is used for HMS power spectral density (PSD) function modeling. This paper also includes HMS system resolution effects analysis on the raw data generation (RDG) and the received frequency profile (RFP). An objective quality assessment procedure was also carried out to investigate both the de-speckled image resolution and the spatial filter evaluation in the presence of the HMS. As a result, the simulations verify that speckles are embedded within the high-frequency parts of the raw data, directly affecting the spatial resolution and the image resolution with non-specific patterns. The results also show that no spatial de-speckling filter consistently outperforms others, and their implementation is completely dependent on the texture, the system parameters, and their evaluation index. As a novel approach, HMS spectral behavioral modeling within the filtered images, as well as the proposed spatial de-speckling filter evaluation methods, are the proper techniques for optimum filter selection and specific purpose applications. The results are very helpful for remote sensing image restoration and data preservation when dealing with SAR images with a less fine resolution, such as ice-covered areas, coastal change detection, vegetation texture detection, geological structures mapping, and so forth. The SAR system resolution analysis is completed based on inversed problem solution (IPS) and with the help of a hybrid-domain image formation algorithm (IFA). Full article

The $\mathcal{M}$ estimator is a recently proposed image-quality index used to evaluate the despeckling operation in SAR (Synthetic Aperture Radar) data. It is used also to rank despeckling filters and to improve their design. As a difference with traditional image-quality estimators, it operates not on the filtered result but on a derived one, i.e., the ratio image. However, a deep statistical analysis of its properties remains open and, with it, the ability to use it as a test statistic. In this work, we focus on obtaining insights into its distribution as well as on exploring other remarkable statistical properties of this unassisted estimator. This study is performed through EDA (Exploratory Data Analysis) and the well-known ANOVA (ANalysis Of VAriance). We test our results on a set of simulated SAR data and provide guides to enrich the $\mathcal{M}$ estimator to extend its capabilities. Full article
