The conversion of coal-fired power plants to nuclear power stations is a potential method for decarbonizing coal power and offers a pathway for low-carbon development in China’s power industry. This paper focuses on retrofitting China’s coastal coal-fired power stations and compares the potential nuclear reactor technologies for the retrofit: China’s mainstream pressurized water reactor and the commercially operated fourth-generation high-temperature gas-cooled reactor (HTGR). The analysis compares the degree of matching between the two technologies and coal-fired power stations in terms of unit capacity, thermal system parameters, unit speed, structural dimensions, and weight, which significantly impact the retrofit scheme. The results indicate that HTGR is more compatible with coal-fired power plants and is recommended as the type of nuclear reactor technology to be retrofitted. The study selected the 210 MWe High-Temperature Gas-Cooled Reactor Pebble-Bed Module (HTR-PM) as the reactor technology for retrofitting a typical 300 MW class subcritical coal-fired unit. Based on the concept of subcritical parameters upgrading, the potential analysis and strategy study of retrofit is carried out in terms of the turbine, the main heat exchange equipment, the main pumps, and the main thermal system pipelines in the conventional island. The results indicate that the conventional island of the HTR-PM nuclear power plant has significant potential for retrofitting, which can be a crucial research direction for nuclear retrofitting of coal-fired power plants. Full article

Irregularity in the plane layout of a building structure and the vertical discontinuity of lateral resistance components could lead to torsion and result in the brittle failure of a structure. According to the characteristics of the conventional island main building of nuclear power plants, this paper focuses on the conventional island main building of the CAP1400 nuclear power plant (NPP) in Shidaowan as the research object. A prototype structure model of the main building was developed using ABAQUS software. The seismic response of the structure under multidimensional ground motion was studied by inputting the X-direction and Y-direction translational and torsional components of ground motion in ABAQUS. The results demonstrate that the overall transverse displacement of the structure under bidirectional ground motion was significantly higher than that under unidirectional earthquakes, which was about 20%. Under a multidimensional frequent earthquake, the transverse displacement of the structure increased by about 13% on average compared with that under a bidirectional earthquake; the longitudinal increase was the largest, at about 28%. Finally, the lateral displacement of each layer of the steel-reinforced concrete (SRC) frame-bent main building structure with few walls proposed in this article decreased by an average of about 17% compared to the traditional SRC frame-bent main building structure. The longitudinal displacement was reduced by about 14% compared to the traditional SRC frame-bent main building structure. Full article

The gable wall of the conventional island of a nuclear power plant carries various pipeline loads connecting the nuclear island and the conventional island. If the gable wall collapses and is damaged due to the progressive collapse of the main plant structure of the conventional island, it will directly threaten the safety of the nuclear island. Therefore, it is of great significance to systematically study the resistance of the gable structure of the nuclear island to progressive collapse for the safe operation of nuclear power plants. Based on the SAP2000 finite element analysis platform, this paper established a model of the reinforced concrete frame structure of the first span of the shield building on the conventional island of a nuclear power plant, including the gable. According to the alternate path method, the node displacement and bearing capacity responses were used to determine the critical components in the gable, and single column failures of the top four in importance were selected as different analysis conditions. Nonlinear static and dynamic methods were used to analyze the displacement, internal force change, hinge sequence of the gable structure on the side of the nuclear island, and the ability of the gable to resist progressive collapse. The analysis results showed that the gable structure of the nuclear island had good resistance to progressive collapse under four single column failure conditions, whether by nonlinear static or dynamic analysis, and the overall vertical displacement obtained by the nonlinear static analysis was larger than that obtained by the dynamic analysis. Full article

In China, conventional island shield buildings (CISBs), which are situated close to the nuclear islands of nuclear power plants, are class III seismic items. This is the most important level in the seismic fortification standard. Calculations to check resistance overturning under extremely safe seismic action should be carried out. Although strict seismic design has been carried out, many beyond-design-basis events, such as the 3/11 earthquake in Japan, have occurred in recent years. Under the action of such accidental loads, there is still the possibility that the important vertical bearing components of a CISB will be damaged or destroyed, which will lead to the progressive vertical collapse of the CISB structure, and ultimately threaten the safe operation of the nuclear power plant. Therefore, it is necessary to study the progressive collapse resistance mechanism of the CISB in order to further optimize and improve its design. In this paper, we take the CISB as a research object and consider the failure mechanism of its vertical progressive collapse synthetically, using SAP2000 finite element software to study the causation and strength of resistance force and internal force redistribution characteristics due to progressive collapse under different column removal conditions (long-side middle, short-side middle, internal, and corner columns) using the instantaneous unloading method. The results show that the residual structure is at risk of collapse under the corner and long-edge middle column removal conditions, and there is no risk of collapse under the short-edge middle and internal column conditions. The failure and collapse resistance of the corner column only has a beam mechanism, and the long-side middle column forms a catenary mechanism in the Y direction. The short-side middle column can resist collapse by the beam mechanism, while the internal column forms a bidirectional catenary mechanism in the X and Y directions. The axial force of the column in the residual structure is mainly redistributed to column members with adjacent spans to the failure column, and column members with separated spans are less affected. Full article

In recent years, there has been a growing interest in the design, development and commercialization of nuclear power Small Modular Reactors (SMRs). Actual SMR designs cover the full spectrum of nuclear reactor technologies, including water-, gas-, liquid-metal-, and molten-salt-cooled. Despite physical and technological differences, SMRs share some relevant design features, such as small size, modularity, inherent and passive safety systems. These features are expected to enhance availability, recoverability, promptness and robustness, thereby contributing to the resilience of power supply. Thanks to the peculiar design features of SMRs, they are likely to satisfy a number of Functional Requirements (FRs) for this objective, namely: (i) low vulnerability to external hazards; (ii) natural circulation of primary coolant; (iii) prompt, unlimited and independent core cooling under shutdown conditions; (iv) shutdown avoidance in response to variations of the offsite power supply quality and electrical load; (v) island mode operation; (vi) robust load-following; (vii) independent, self-cranking start. These make advanced Nuclear Power Plants (aNPPs) comprised of SMRs perfect candidates to withstand a broader range of natural disruptions and to recover faster from them, compared to conventional Nuclear Power Plants (cNPPs), thus rendering them a major potential asset for guaranteeing resilience and security of power supply. The review focuses on Natural Technological (NaTech) events that impact a typical Integrated Energy System (IESs) within which SMRs are embedded: IESs are, indeed, being developed to integrate different power generation plants with gas facilities, through gas and electricity infrastructures, because they are expected to bring increased security and resilience of power supply, as shown in the qualitative case study presented. Full article

In order to improve the deformation energy consumption and self-centering ability of reinforced concrete (RC) frame beam-column joints for main buildings of conventional islands in nuclear power plants, a new type of self-centering joint equipped with super-elastic shape memory alloy (SMA) bars and a steel plate as kernel components in the core area of the joint is proposed in this study. Four 1/5-scale frame joints were designed and manufactured, including two contrast joints (a normal reinforced concrete joint and a concrete joint that replaces steel bars with SMA bars) and two new model joints with different SMA reinforcement ratios. Subsequently, the residual deformation, energy dissipation capacity, stiffness degradation and self-centering performance of the novel frame joints were studied through a low-frequency cyclic loading test. Finally, based on the OpenSees finite element software platform, an effective numerical model of the new joint was established and verified. On this basis, varying two main parameters, the SMA reinforcement ratio and the axial compression ratio, a simulation was systematically conducted to demonstrate the effectiveness of the proposed joint in seismic performance. The results show that replacing ordinary steel bars in the beam with SMA bars not only greatly reduces the bearing capacity and stiffness of the joint, but also makes the failure mode of the joint brittle. The construction of a new type of joint with consideration of the SMA reinforcement and the steel plate can improve the bearing capacity, delay the stiffness degradation and improve the ductility and self-centering capability of the joints. Within a certain range, increasing the ratio of the SMA bars can further improve the ultimate bearing capacity and energy dissipation capacity of the new joint. Increasing or decreasing the axial compression ratio of column ends has little effect on the overall seismic performance of new joints. Full article

Due to the excellent impact resistant performance of steel-plate concrete (SC) structure compared with the conventional reinforced concrete (RC) structure, SC structure is preferred to be used in the design of external walls of nuclear island buildings for new nuclear power plants (NPPs). This study aims at evaluating the effect of material and geometric parameters of SC containment on its impact resistant performance, thus the numerical simulation and sensitivity analysis of SC containment subjected to malicious large commercial aircraft attack are conducted based on the force time-history analysis method. The results show that: (1) the impact resistant performance of full SC containment is better than that of half SC containment; (2) for relatively thin full SC containment, the impact response and concrete damage can be significantly reduced by the enhancing of concrete strength grade or the increasing of steel plate thickness; (3) for the thicker full SC containment, concrete strength grade has only a slight influence on the impact displacement response, and the increasing of steel plate thickness has no significant effect on mitigating the impact displacement response. However, the increasing of steel plate thickness can effectively reduce its plastic strain, and the decreasing of strength grade of steel plate may obviously increase its plastic strain; and (4) concrete thickness plays a decisive role on the improvement of impact resistance, which is more effective than the enhancing of concrete strength grade. Resultantly, this paper provides a reference and guidance for the design of SC structure external walls of nuclear island buildings against a large commercial aircraft. Full article

The use of renewable energy sources can provide a path toward sustainable development and regional energy independence. In particular, renewable-based energy autonomy constitutes a viable option in remote areas. This work presents a survey on the use of renewable energy as part of an energy autonomy plan on a Mediterranean island. The study also included personal communications with residents and local community leaders. The results show an overall positive attitude toward renewable energy applications. The majority of the respondents support the implementation of renewable-based, small-scale projects corresponding to local energy autonomy scenarios. They are, furthermore, convinced that a wider use of renewable technologies can reduce the environmental impact of conventional fuels. However, although people are aware of technologies widely used on the island, they are much less so when it comes to less prominent technologies (wave energy, fuel cells, etc.). People tend to be more open to installations of solar, wind and geothermal energy, while generally they dislike nuclear and coal power plants. Lastly, the majority of the respondents believe that local policies on energy issues should change, while they also perceive the lack of political will as one of the most important obstacles to the implementation of renewable technologies. Full article
