Semi-continuous casting is an important method for the large-scale production of high-strength conductive copper-iron (Cu-Fe) alloys in the future. However, serious peeling defects were found on the surface of cold-rolled strips during industrial trials. Due to the multi-step complexity of the manufacturing process (from casting to final product), identifying the root cause of defect formation remains challenging. X-ray computed tomography (X-CT) was used to quantitatively characterize the pores and defects in the horizontal continuous casting Cu-Ni-Sn slab, the semi-continuous casting Cu-Fe alloy slab, and the hot-rolled slab of Cu-Fe, and the relationship between the defect characteristics and processes was analyzed. The results showed that the internal defect sphericity distribution of the Cu-Fe alloy slab after hot rolling was similar to that of the reference Cu-Ni-Sn slab. The main difference lies in the low sphericity range (<0.4). The volume of pore defects inside the Cu-Fe alloy after hot rolling was significantly larger than in the reference sample, with a 52-fold volume difference. This phenomenon may be the source of surface-peeling defects in the subsequent cold-rolling process. The occurrence of internal defects in the Cu-Fe alloy is related to both the composition characteristics and casting processes of the Cu-Fe alloy; on the other hand, it is also related to the hot-rolling process. Full article

The twin-roll casting (TRC) process is widely used in the aluminum industry due to its cost efficiency and continuous production capability. However, maintaining consistently high surface quality remains challenging due to complex heat transfer behavior at the roll/strip interface. This study examines the critical influence of roll surface conditions, especially the formation of an Al coating layer, on solidification behavior and resulting strip quality in the TRC of an Al-5Mg alloy. Experimental results demonstrated that casting without an Al coating layer led to surface defects such as hot tears and porosity due to insufficient cooling. In contrast, strips produced with a stable Al coating layer exhibited excellent surface quality with no surface defects. Numerical simulations further indicated that a stable Al coating enhanced the interfacial heat transfer coefficient (up to 30,000 W/m²K), ensuring effective cooling and complete solidification before the strip exited the roll nip. Moreover, simulations validated the feasibility of using steel rolls in industrial applications, provided the coating layer was consistently maintained. This research highlights the significance of roll surface control in improving TRC product quality. Full article

The twin-roll casting (TRC) process has gained significant attention for aluminum sheet production due to its cost-effectiveness and high processing efficiency. However, controlling the initial grain structure of TRC strips remains challenging due to the absence of a hot rolling stage, necessitating an advanced predictive modeling approach. In this study, a cellular automaton–finite element (CA-FE) model was developed to predict the grain structure and texture of aluminum strips fabricated via TRC. Both pure Al and AA7075 alloys were cast under identical conditions using a pilot-scale horizontal twin-roll caster, and their microstructures were characterized experimentally. The developed model incorporated a Gaussian nucleation distribution function and an equivalent binary approach to account for the solidification behavior of multicomponent alloys. The CA-FE simulation results successfully reproduced the key aspects of solidification, grain structure, and texture evolution of TRC strips. The predicted temperature distribution and solid fraction evolution showed distinct differences between the alloys, with pure Al forming columnar grains and AA7075 developing a fully equiaxed structure, which closely matched the experimental findings. Additionally, texture analysis using inverse pole figures (IPFs) and pole figures (PFs) revealed a clear <001> orientation in pure Al, whereas AA7075 exhibited a random texture, both of which were well captured by the CA-FE model. The findings indicate that the developed model offers a reliable prediction of the solidification microstructure and texture evolution in TRC strips, making it a valuable tool for optimizing continuous casting processes. Full article

To resolve the challenges of weak bonding interface and to avoid expensive and time-consuming trials, integrated computational materials engineering (ICME) was applied to study the hot roll bonding and forming of ultra-thick 45 steel stacked assemblies (>60 mm) and to optimize the rolling processes. Microstructure and properties of the continuous cast slabs of 45 steel subjected to heating and forming were acquired from JMatPro V13.2 calculations and essential experimental validations. Interfacial bonding criteria were established from hot compression tests and were applied to the finite element simulations of the multi-pass rolling processes of a two-slab stacked assembly and a three-slab stacked assembly to predict the bonding of interior interfaces and the deformation of the plates. Unlike previous studies, the aim of this research is to apply the concept of integrated computational materials engineering to shorten the development cycle and reduce re-search costs. The results revealed that the compressive strain of 0.05 is sufficient to form metallurgical bonding at the interface for machined 45 steel in a vacuum. Finite element simulation results indicate that complete bonding of the interfaces is established after two passes for the two-slab stacked plate and four passes for the three-slab stacked plate. Optimized rolling process parameters from analyzing the finite element simulation results are applied to design the hot rolling process of the stacked slab assemblies to produce ultra-thick plates. By applying the concept of integrated computational materials engineering, the development cycle of product processes can be significantly shortened, and financial investment can be reduced. Full article

As the main energy-consuming equipment, the reheating furnace plays an important role in the scheduling of continuous casting and hot rolling for a steel mill. This paper studies the energy consumption of cold and hot slab conversion mode in a reheating furnace, forming four conversion relationships, with the goal of minimizing the coupling function between the maximum completion time of the hot rolling and the energy waste of the reheating furnace, and modelling the scheduling of a continuous casting–hot rolling process. An improved ordered pair bat algorithm is used to solve for special process conditions of the proposed scheduling model. The effectiveness of the proposed model and algorithm is verified by solving the different slab charging sequence and conversion mode. Moreover, a comparative study of different types of batches is also conducted, and it is found that the model can save more than 5000 GJ per month for the steel mill, which can achieve the goal of effective energy saving and increasing enterprise profit. Full article

Al 6082 aluminum alloy has excellent corrosion resistance, strength, and formability. However, owing to the recrystallization effect of a hot working process, coarse grains form easily in this material, which reduces its strength and service life. The novel continuous casting direct rolling (CCDR) method can prevent the deterioration of this material. Thus, we used CCDR Al 6082 aluminum alloy as the research material in this study. By subjecting a CCDR Al 6082 aluminum alloy to heat treatment (T4 and T6) and cold rolling, the influence of recrystallization effect on its mechanical properties and on impact failure resistance were explored. The results demonstrated that the specimen subjected to T4 heat treatment had a higher elongation and that the specimen subjected to T6 heat treatment had a higher strength. After cold rolling, the hardness and strength of the specimens subjected to different heat treatments (coded T4R4 and T6R4) increased because of the work’s hardening effect. Moreover, the elongations of both specimens decreased, but they were higher than the industrial standard (>10%). The strength of specimen T6R4 was higher (up to 400 MPa) than specimen T4R4. Moreover, relative to specimen T4R4, specimen T6R4 had greater tensile and Charpy impact failure toughness. Full article

Grain-oriented electrical steel (GOES) has been used for many years for application in transformed cores due to its excellent magnetic properties. Magnetic properties are strongly influenced by obtaining a texture with a certain orientation (110) [001] for BCC structure. This is related to the easy direction of magnetization [001]. So far, the main research has been focused on obtaining a strong texture in the last stages of the process. The aim of the present study was to additionally trace textural changes for a slab after the continuous casting (CC) process and for a sheet after the hot rolling process. The scope of such an analysis has not been conducted before. With regard to the state after continuous casting (CC), the texture was related to measurements of the anisotropy of Barkhausen magnetic noises and the macrostructure of the slab. Based on the X-ray diffraction examinations that compared the texture intensity calculated from the texture coefficient of the slab, the hot rolled steel and the final product of grain-oriented electrical steel contained 3.1% of Si. The studies performed with the material taken from three different production steps showed high differences in the values of textural intensity indicating the occurrence of a crystallization texture, especially in the area of the columnar crystal zone; textural weakness after the hot rolling process and high texturing in the final product for textural components corresponding to the desired Goss texture. Full article

Variations in the corrosion behavior of biomedical NiTi alloys in Cl⁻ containing and acidic environments present a problem with their biological implantation. The objective of this research was to evaluate the synergy of the microstructure, the corrosion behavior, and the biocompatibility of novel continuous-cast NiTi alloys and to compare them with commercial NiTi alloys. The two alloys have a practically identical nominal chemical composition, but they differ in production technology. The continuous casting technology involved vacuum induction melting of the basic components and vertical continuous casting, while the commercial NiTi alloy was produced through a process of casting, hot rolling, and forming into square shapes. The microstructure was revealed to determine the surface area and size of grains. The corrosion of a commercial nickel–titanium alloy and one prepared by a novel continuous casting method in acidic and chloride-containing solutions was studied via analytical and electrochemical tests. Localized corrosion characteristics related to oxide properties, when exposed to 9 g L⁻¹ NaCl solution, were examined with focused ion beam analysis and subsequent microchemical analysis of the formed corrosive products. Corrosion potential over time and the oxide film resistance were analyzed using linear polarization measurements. To obtain a preliminary estimate of biocompatibility, human fibroblast cells were used in indirect contact, i.e., alloy conditioning medium. The continuous casting method resulted in a reduction in the average grain size in comparison to the commercial sample and better corrosion stability of the sample in an acidic environment. Also, in a solution of 9 g L⁻¹ NaCl the commercial sample showed high values for the corrosion current density (j_corr = 6 μA cm⁻²), which indicated low corrosion resistance, while the continuous casting sample possessed much better corrosion stability and lower values for the corrosion current density (j_corr = 0.2 μA cm⁻²). In line with that, elemental analysis of the corroded surfaces showed higher Cl⁻ ion deposition over the surface layer of the commercial sample, suggesting local oxide breakdown. Moreover, NiTi_cc reached a value three times higher for polarization resistance (R_p = 270 kΩ cm²) over time in comparison to the commercial sample (R_p~100 kΩ cm²). Biocompatibility evaluation showed that human fibroblast cells exhibited altered metabolic activity. An MTT assay showed that cells’ mitochondrial activity dropped below that of control cells in the presence of both materials’ supernatants. Full article

Endless rolling urgently requires an increase in the casting speed of continuous casting. For the continuous casting process of a high-casting-speed billet, the heat flux of the mold would be much higher, requiring a stronger cooling performance and longer mold life to match the high-speed casting. Mold material, thickness, and slot structure have a great influence on the casting speed. To design a more efficient billet casting mold, a three-dimensional thermal-stress-coupled analysis model of a 150 mm × 150 mm mold was established in this research to analyze the thermal state of a mold with high casting speed; in addition, the material, thickness, and water slot structure, which pertain to the mold cooling performance, were also studied. The results show that the billet mold of Cu-Ag with a thinner thickness and right-corner water slot is better in terms of casting speed. Regarding the material, the Cu-Ag mold has a higher thermal conductivity efficiency; its hot surface temperature is 4.89 °C lower, its equivalent stress is 7 MPa lower, and its longitudinal deformation is 0.0023% lower compared with the deoxidized phosphorus copper mold. Regarding the thickness, the thinner mold has a 60.76 °C lower hot surface temperature, its equivalent stress is 340 MPa lower, and its longitudinal deformation is 0.0443% lower compared with the thicker mold. For the water slot structure, the mold with the right-angled water slot has a 2.895 °C lower hot surface temperature, its equivalent stress is 37 MPa lower, and its longitudinal deformation is 0.0039% lower compared with the mold with a rounded-corner water slot. Full article

Aluminum alloy 6201 is a wrought, heat-treatable alloy, which is used in electricity transmission and distribution lines. The alloy is processed in a commercial continuous casting and rolling system, which includes a series of in-line thermomechanical processes involving hot working, quenching, cold working and artificial aging. In this study and following cold working, the alloy is subjected to a solution heat treatment at 510 °C for an hour, quenched in ice water, and artificially aged at various temperatures for various times (150–200 °C for 2–30 h) (T6-temper) in order to investigate the effect of precipitation on mechanical properties and electrical conductivity. The results show that optimum mechanical properties and electrical conductivity were obtained after artificial aging at 155 °C for 30 h (155-30). The tensile strength was almost equal to that of the as received cold drawn wire of 326 MPa, but interestingly, electrical conductivity significantly increased to 58.6% IACS from a value of 52.7% IACS of the as received cold drawn wire. Intermetallic particles α-AlFeSi (Al₈Fe₂Si) and β-AlFeSi (Al₅FeSi and Al₉Fe₂Si₂) were observed in all samples, which were nucleated during solidification and homogenization; they were not affected by the aging process. β″/β′/β -precipitates formed during artificial aging, which affected the final mechanical properties and the final electrical conductivity. Full article

Subsurface inclusions are one of the most common defects that affect the inner quality of continuous casting slabs. This increases the defects in the final products and increases the complexity of the hot charge rolling process and may even cause breakout accidents. The defects are, however, hard to detect online by traditional mechanism-model-based and physics-based methods. In the present paper, a comparative study is carried out based on data-driven methods, which are only sporadically discussed in the literature. As a further contribution, a scatter-regularized kernel discriminative least squares (SR-KDLS) model and a stacked defect-related autoencoder back propagation neural network (SDAE-BPNN) model are developed to improve the forecasting performance. The scatter-regularized kernel discriminative least squares is designed as a coherent framework to directly provide forecasting information instead of low-dimensional embeddings. The stacked defect-related autoencoder back propagation neural network extracts deep defect-related features layer by layer for a higher feasibility and accuracy. The feasibility and efficiency of the data-driven methods are demonstrated through case studies based on a real-life continuous casting process, where the imbalance degree drastically vary in different categories, showing that the defects are timely (within 0.01 ms) and accurately forecasted. Moreover, experiments illustrate the merits of the developed scatter-regularized kernel discriminative least squares and stacked defect-related autoencoder back propagation neural network methods regarding the computational burden; the F1 scores of the developed methods are clearly higher than common methods. Full article

Slivers on the surface of rolled plates, which are serious defects for interstitial-free (IF) steel, occur mainly as a result of inclusions in continuous casting (CC) slabs. It is, therefore, important to study inclusions in CC slabs in terms of their migration towards the surface during hot rolling. To investigate inclusion migration during the hot rolling of ultralow carbon steel, a 3D numerical model was constructed using the finite element method. The positions of the inclusions in the surface layer of an IF steel slab (50 mm) were tracked during hot rolling using a node-tracking method. Furthermore, the study analyzed the effects of scarfing on inclusion migration during hot rolling and inclusion distribution in a hot-rolled plate. During the hot-rolling process, inclusions in the wide faces of the intermediate slab gradually migrated to the surface of the intermediate slab. Owing to a thickness reduction, accumulation areas of inclusions were finally generated at the edge of the hot-rolled plate; these areas may lead to sliver defects. The scarfing of the slab did not affect the distribution of inclusions in the hot-rolled plate; however, it may have reduced the inclusion content in the outermost layers of the hot-rolled plate. The inclusions were mainly located within 1 mm underneath the hot-rolled plate. Moreover, the inclusions near the inner arc of the CC slab were concentrated within 1.5 mm of the upper plate surface. Using galvanostatic electrolysis, the number of large inclusions in samples prepared from a hot-rolled plate obtained from a plant was measured. The measurements agreed well with the numerical model predictions, which validated the FE model in the current work. Full article

The objective of this research work is to obtain the hot ductility behavior, and the structural, microstructural and mechanical characteristics of one of the latest generation of AHSS steels, a complex phase (CP) steel microalloyed with boron (0.006 wt.%), processed by hot and cold rolling operations and heat-treated using two different quenching and partitioning (Q&P) treatments, a one-step partitioning (quenching to 420 °C) and the other a two-step partitioning (quenching to 420 °C and reheated to 600 °C). The results show that boron has a marked effect on the solidification process of the CP steel, refining the austenitic grain size. Due to its refinement, the boron-containing steel had better ductility throughout the temperature range examined (700–900 °C), i.e., the hot ductility trough. Thus, the minimum percentage of reduction in area (%RA) value occurring at 800 °C was 43% for the boron-free steel, compared with 58% for the boron-containing steel. Hence, cracking would not be a problem when straightening the strand on continuous casting. The benefit of boron addition on the room temperature properties was found to be very marked for the higher temperature two-step partitioning treatment, giving a yield stress of 1200 MPa, a UTS (ultimate tensile strength) of 1590 MPa and a total elongation above 11%. The final Q&P microstructure, in both one- and two-step partitioning conditions, consisted of retained austenite (RA-γ), martensite and ferrite islands in a bainitic matrix. Furthermore, the boron treated steel on quenching produced a greater amount of RA-γ, which accounted for its better room temperature ductility and produced a martensitic matrix rather than a bainitic one, giving it greater strength. The addition of boron improved the corrosion resistance of this type of third generation AHSS steel. Full article

The steel making processes involves extreme and harsh operating conditions; hence, the production hardware is exposed to degradation mechanisms under high temperature oxidation, erosion, wear, impact, and corrosive environments. These adverse factors affect the product quality and efficiency of the steel making industry, which contributes to production downtime and maintenance costs. Thermal spray technologies that circumvent surface degradation mechanisms are also attractive for their environmental safety, effectiveness and ease of use. The need of thermal spray coatings and advancement in terms of materials and spray processes are reviewed in this article. Application and development of thermal spray coatings for steel making hardware from the molten metal processing stages such as electric arc and basic oxygen furnaces, through to continuous casting, annealing, and the galvanizing line; to the final shaping process such as cold and hot rolling of the steel strips are highlighted. Specifically, thermal spray feedstock materials and processes that have potential to replace hazardous hard chrome plating are discussed. It is projected that novel coating solutions will be incorporated as awareness and acceptance of thermal spray technology grows in the steel making sectors, which will improve the productivity of the industry. Full article

Cu-Ni-Si alloy is the key raw material for the lead frame of large integrated circuits. The disordered grain orientation of alloy billet, high hardening rate, residual stress, and poor surface quality of cold working strips seriously affect its processability. In order to improve the cold-working properties of Cu-Ni-Si alloy, two kinds of C70250 copper alloy strips were produced through hot mold continuous casting (HMCC) and cold mold continuous casting (CMCC) technology. The effects of solidified microstructure on the cold-working deformation behavior, mechanical properties, and residual stress of the alloy were studied. The results show that C70250 copper alloys with columnar grain and equiaxed grain were prepared through HMCC and CMCC. After a 98% reduction in cold rolling, columnar grain strip surface quality was very good, and the elongation was still as high as 3.2%, which is 2.9 times that of equiaxed grain alloy. The residual stress of equiaxed grain strips reached 363 MPa, which is 2.7 times that of columnar grain strips. During the cold rolling process, equiaxed grain strips are prone to cause intersecting plane dislocations, stacking faults, shear bands, and grain breakage during large deformation cold rolling. The columnar grain strip causes parallel plane dislocations, stacking faults, and shearbands. Furthermore, the deformation structure was found to be uniform, and, ultimately, the alloy formed a fibrous structure. Therefore, the elongation and latter distortion of columnar grain strips improved after being put through large deformation cold rolling, which greatly reduced residual stress. Full article
