Search Results (16)

The continuous synthesis of nanoparticles (NPs) has been actively studied due to its great potential to produce NPs with reproducible and controllable physicochemical properties. Here, we achieved the high throughput production of nanostructured lipid carriers (NLCs) using a coaxial turbulent jet mixer with an added heating system. This device, designed for the crossflow of precursor solution and non-solvent, combined with the heating system, efficiently dissolves solid lipids and surfactants. We reported the flow regime according to the Reynolds number (Re). Also, we confirmed the size controllability of NLCs as dependent on both Re and lipid concentration. The optimized synthesis yields NLCs around 80 nm, ideal for targeted drug delivery by enhanced permeability and retention (EPR) effect. The coaxial turbulent jet mixer enables effective mixing, producing uniform size distribution of NLCs. The NLCs prepared using the coaxial turbulent jet mixer were smaller, more uniform, and had higher drug loading compared to the NLCs synthesized by a bulk nanoprecipitation method, showcasing its potential for advancing nanomedicine. Full article

Coaxial multirotors, characterized by overlapping rotors, represent a common solution to increasing payload capacity while maintaining a compact platform size. However, the overlap between motors generates airflow disturbances that, if not taken into account properly, may decrease the system’s overall performance. In this paper, aerodynamic interactions for coaxial multirotors are analyzed and characterized. Two rotor models are introduced, which account for the aerodynamic interaction between the upper and the lower rotor. Each model is accompanied by its corresponding mixer design and analyzed with respect to the state-of-the-art mixer solution for classical multirotor systems. The proposed approaches are tested through rotor stand experiments, simulations, and implementation on an actual coaxial platform. The results demonstrate the effectiveness of these models in mitigating the adverse aerodynamic effects, thereby improving the performance and efficiency of coaxial multirotor systems. Full article

The performance of gas-liquid mixing processes in agitated vessels is commonly measured by the degree of gas dispersion, and local measurements of this parameter can provide a more accurate description of the mixing, especially for non-Newtonian fluids. For instance, the fluid flow of complex yield-pseudoplastic solutions is highly affected by the local shear stress, leading to a non-homogeneous air distribution throughout the mixing vessel. Coaxial mixers have demonstrated energy-efficient characteristics for non-Newtonian fluids that improve mixing homogeneity due to the independent rotation of a central impeller and a close-clearance impeller. Therefore, this work aims to investigate the axial profile of the local gas holdup in a PBT-anchor coaxial mixer containing xanthan gum solutions, which is a biopolymer widely utilized as an emulsion stabilizer, dispersing agent, and thickener. The rheological behavior of the solutions was described by the Herschel-Bulkley model, and the effect of the xanthan gum concentration on the gas holdup distribution was analyzed. Electrical resistance tomography (ERT) was employed to obtain the gas holdup from the conductivity measurements of the mixture in each of the four horizontal planes. Results show that the gas holdup increased downward for all solutions, and a lower xanthan gum concentration reduced the non-homogeneity in gas distribution and the overall gas volume fraction. In contrast, higher xanthan gum concentrations enhanced gas holdup in high shear stress regions while weakening air dispersion distant from those regions due to higher viscous forces. Full article

Uniform gas dispersion and shear distribution in highly viscous non-Newtonian fluids are challenging due to the complex rheological behavior exhibited by this type of medium. In addition, most large-scale bioreactors used in biochemical processes such as wastewater treatment and fermentation demand higher aspect ratios (i.e., fluid height to tank diameter ratio) than laboratory-scale bioreactors. This, in turn, underlines uneven gas and shear distribution throughout the bioreactor, especially those comprising yield-pseudoplastic fluids. For this type of fluid, there are two distinct zones within the bioreactor: a higher-shear zone with a lower apparent viscosity around the impeller and a lower-shear area with a higher apparent viscosity away from the impeller. Due to the viscosity gradient, homogeneous gas dispersion within a single impeller aerated bioreactor with an aspect ratio of more than one is hard to attain. It has been reported that a well-designed mixing configuration contributes to maintaining a consistent fluid viscosity, resulting in improved mixing performance and consistent final product quality. Recent studies have demonstrated the superior performance of double coaxial bioreactors furnished with two central impellers and one anchor for uniform shear distribution and gas dispersion in pseudoplastic fluids. Despite the widespread use of yield-pseudoplastic fluids in various industries, a knowledge gap was identified for analyzing the shear distribution within the double coaxial mixers containing pseudoplastic fluids possessing yield stress. This study examined the effect of four coaxial mixing configurations, including down-pumping and co-rotating, up-pumping and co-rotating modes, down-pumping and counter-rotating, and up-pumping and up-pumping and up-pumping and counter-rotating modes, on the local shear rate distribution. In this regard, computational fluid dynamics (CFD) was employed for the evaluation of the local shear distribution within the coaxial bioreactor. Full article

To prepare lightweight, wideband, strong absorption and low-cost microwave absorbing materials, carbon black/polylactic acid (CB/PLA) composite filaments were prepared using a high-energy mixer and twin-screw extruder. Coaxial ring test pieces were printed by fused filament fabrication (FFF) technology with polylactic acid as the matrix and carbon black as the absorbent. The crystal texture and micromorphology of the composites were observed by XRD and SEM. The electromagnetic parameters were measured at 2–18 GHz using a vector network analyzer. The influence of CB content on the absorbing performance of the composites was studied, and the loss mechanism was explained. The results show that when the CB content (refers to PLA) is 25%, the composite has suitable impedance matching, conduction loss, and polarization loss, resulting in the best microwave absorption performance. The minimum reflection loss reached −45.47 dB at 13.68 GHz, and the corresponding effective absorption bandwidth was 5.36 GHz (10.72–16.08 GHz) with a matching thickness of 2.1 mm. At the same time, the density of the composite was only 1.19 g/cm³. This work sheds light on the development of lightweight and high-efficiency microwave absorption materials (MAMs) in a simple and low-cost manner. Full article

The synthesis of nanoparticles in microchannels promises the advantages of small size, uniform shape and narrow size distribution. However, only with insights into the mixing processes can the most suitable designs and operating conditions be systematically determined. Coaxial lamination mixers (CLM) built by 2-photon polymerization can operate long-term stable nanoparticle precipitation without fouling issues. Contact of the organic phase with the microchannel walls is prevented while mixing with the aqueous phase is intensified. A coaxial nozzle allows 3D hydrodynamic focusing followed by a sequence of stretch-and-fold units. By means of a digital twin based on computational fluid dynamics (CFD) and numerical evaluation of mixing progression, the influences of operation conditions are now studied in detail. As a measure for homogenization, the mixing index ($\mathrm{MI}$) was extracted as a function of microchannel position for different operating parameters such as the total flow rate and the share of solvent flow. As an exemplary result, behind a third stretch-and-fold unit, practically perfect mixing ($\mathrm{MI}>0.9)$ is predicted at total flow rates between 50 µL/min and 400 µL/min and up to 20% solvent flow share. Based on $\mathrm{MI}$ values, the mixing time, which is decisive for the size and dispersity of the nanoparticles, can be determined. Under the conditions considered, it ranges from 5 ms to 54 ms. A good correlation between the predicted mixing time and nanoparticle properties, as experimentally observed in earlier work, could be confirmed. The digital twin combining CFD with the $\mathrm{MI}$ methodology can in the future be used to adjust the design of a CLM or other micromixers to the desired total flow rates and flow rate ratios and to provide valuable predictions for the mixing time and even the properties of nanoparticles produced by microfluidic antisolvent precipitation. Full article

We present a robust, low-cost fabrication method for implementation in multilayer soft photolithography to create a PDMS microfluidic chip with features possessing multiple height levels. This fabrication method requires neither a cleanroom facility nor an expensive UV exposure machine. The central part of the method stays on the alignment of numerous PDMS slabs on a wafer-scale instead of applying an alignment for a photomask positioned right above a prior exposure layer using a sophisticated mask aligner. We used a manual XYZR stage attached to a vacuum tweezer to manipulate the top PDMS slab. The bottom PDMS slab sat on a rotational stage to conveniently align with the top part. The movement of the two slabs was observed by a monocular scope with a coaxial light source. As an illustration of the potential of this system for fast and low-cost multilayer microfluidic device production, we demonstrate the microfabrication of a 3D microfluidic chaotic mixer. A discussion on another alternative method for the fabrication of multiple height levels is also presented, namely the micromilling approach. Full article

A single microwave absorbent and simple coating structure cannot meet the increasing requirements for broadband and strong absorption. Three-dimensional printing is an effective way to prepare multi-component complex structure metamaterial absorbers, and the key is to prepare raw materials with excellent absorption properties, suitable for 3D printing. In this paper, CB-CIP/PLA composite filament was prepared via a high-energy mixer and twin-screw extruder by compounding the dielectric loss material carbon black (CB) and the magnetic loss material carbonyl iron powder (CIP) with polylactic acid (PLA) as the matrix. The coaxial ring test piece was printed by FDM technology, and the microstructure of the composites was observed and analyzed by SEM. Meanwhile, the electromagnetic parameters of the composites were examined by a vector network analyzer, mainly studying the influence of the CB and CIP content and thickness on the microwave absorbing properties of the composite material. The results show that when the CB content is 20% and the CIP content is 30%, the CB-CIP/PLA composite has excellent microwave absorption and broad bandwidth. When the matching thickness is 1.6 mm, the minimum reflection loss (RL) reaches −51.10 dB; when the thickness is 1.7 mm, the effective absorption bandwidth (RL < −10 dB) is 5.04 GHz (12.96–18 GHz), nearly covering the whole Ku band. This work provides an efficient formulation and process to prepare an absorbing composite filament for FDM. Full article

Coaxial mixers have shown a uniform energy dissipation rate throughout the mixing tank and a high mass transfer rate. However, to the best of our knowledge no investigation has been conducted on the scale-up of aerated coaxial mixers. In this study, the gas hold-up profile, energy dissipation rate profile, power consumption, and mixing hydrodynamics were explored to keep the mass transfer of the large-scale mixer the same as its small-scale counterpart. The effects of the impeller type, impeller speed, pumping direction, and aeration rate on the reliability of the proposed scale-up technique were explored through electrical resistance tomography, a simplified dynamic pressure method, and computational fluid dynamics. Full article

The development of effective gas-liquid mixing systems in mechanically agitated vessels is typically evaluated in terms of the degree of bubbles dispersion. For instance, adequate gas distribution reduces the formation of oxygen-deficient regions and ensures suitable metabolic pathways in bioreactors. In this regard, the gas holdup is a direct measurement of the process performance because the bubbles’ characteristics determines the gas volume fraction inside the vessel. The accurate estimation of this parameter using empirical correlations provides a better insight and a rapid prediction of the mixing process characteristics, which is crucial for designing stirred tanks. However, a challenge in obtaining empirical correlations is related to the experimental ranges of geometrical and process system conditions. In fact, the existing gas holdup correlations have not considered gas dispersion in yield pseudoplastic fluids using a coaxial mixer that comprises concentric shafts rotating independently. As an opportunity in mixing process system design, this study aims to develop empirical gas holdup correlations for an aerated anchor-PBT coaxial mixing system containing a xanthan gum solution, which behaves as a yield stress fluid. The electrical resistance tomography technique was employed to measure the gas holdup based on the conductivity variation throughout the vessel. A central composite design of experiments was conducted to account for the effect of central impeller speed, anchor speed, and gas flow rate on the mixing performance. The results demonstrated a non-monotonic effect of the central impeller speed on the gas holdup, which indicates a variation in the flow regime. Furthermore, the results showed that the gas holdup was increased by decreasing the anchor speed or increasing the aeration rate applied to the system. The developed correlations were statistically assessed and a good agreement with the experimental data was verified, which enabled us to accurately estimate the gas holdup within the range of operating variables investigated. Full article

Electroporation is a simple but effective and sustainable food processing way of treating cell membranes with an electric field. It is employed in a variety of ways in the food industry, ranging from shelf-life extension to green extraction. Despite its wide range of applications, electroporators are out of reach for many labs due to their high development costs, and different electroporators have been tailored to specific applications. The designing sequence of an electroporator that takes the geometry of a treatment chamber and its electrical resistance into account for the design of a pulse generator has not been addressed in published literature. To meet this demand, this study presents a straightforward way to develop a simple, affordable, and portable electroporator for liquid food pasteurisation. The proposed electroporator comprises a coaxial treatment chamber with static mixers and a high-voltage Marx bank based on insulated-gate bipolar transistors (IGBTs). The generator has a 4.5 kV output voltage and a peak current rating of 1 kA; however, the modular design allows for a wide range of voltage and current ratings. Treated orange juice using thermal pasteurisation (65 °C, 30 min) was also used for comparison. The performance of the electroporator was studied using chemical and microbial tests. A significant log reduction (5.4 CFU·mL⁻¹) was observed in both the PEF-treated samples with sieves. Additionally, the treated juice visual and chemical color analysis showed that the PEF-treated sample extended the shelf-life after 9 days of storage at 4 °C. This research also examines the energy conversion in these two processing steps. This study assists in developing further electroporators for other food applications with different treatment chambers without compromising the product’s quality. Full article

This work presents a novel method for the non-invasive, in-line monitoring of mixing processes in microchannels using the Raman photometric technique. The measuring set-up distinguishes itself from other works in this field by utilizing recent state-of-the-art customized photon multiplier (CPM) detectors, bypassing the use of a spectrometer. This addresses the limiting factor of integration times by achieving measuring rates of 10 ms. The method was validated using the ternary system of toluene–water–acetone. The optical measuring system consists of two functional units: the coaxial Raman probe optimized for excitation at a laser wavelength of 532 nm and the photometric detector centered around the CPMs. The spot size of the focused laser is a defining factor of the spatial resolution of the set-up. The depth of focus is measured at approx. 85 µm with a spot size of approx. 45 µm, while still maintaining a relatively high numerical aperture of 0.42, the latter of which is also critical for coaxial detection of inelastically scattered photons. The working distance in this set-up is 20 mm. The microchannel is a T-junction mixer with a square cross section of 500 by 500 µm, a hydraulic diameter of 500 µm and 70 mm channel length. The extraction of acetone from toluene into water is tracked at an initial concentration of 25% as a function of flow rate and accordingly residence time. The investigated flow rates ranged from 0.1 mL/min to 0.006 mL/min. The residence times from the T-junction to the measuring point varies from 1.5 to 25 s. At 0.006 mL/min a constant acetone concentration of approx. 12.6% was measured, indicating that the mixing process reached the equilibrium of the system at approx. 12.5%. For prototype benchmarking, comparative measurements were carried out with a commercially available Raman spectrometer (RXN1, Kaiser Optical Systems, Ann Arbor, MI, USA). Count rates of the spectrophotometer surpassed those of the spectrometer by at least one order of magnitude at identical target concentrations and optical power output. The experimental data demonstrate the suitability and potential of the new measuring system to detect locally and time-resolved concentration profiles in moving fluids while avoiding external influence. Full article

Determining the exact rheological properties of cementitious materials in fundamental units is a crucial step in concrete science. It is undisputed that before measuring rheological properties in concrete rheometers, it is necessary to pre-shear the fresh mortar or concrete. Due to the migration of the coarse particles into areas with lower shear stress, however, segregation takes place. An experimental set-up was developed to determine the effects on the measured values of the concrete rheometer ICAR. This allows the active homogenization (pre-shearing) of the material before each change of speed. In the tests higher raw values (macroscopic data) could be measured. This clearly influences the calculated rheological Bingham parameters and modified Bingham parameters for a self-compacting concrete (SCC) with a maximum grain size of 16 mm. Therefore, the homogeneity of the material, a main hypothesis of rheological measurements, does not seem to be fulfilled with the coaxial rheometer used. The process of the indispensable pre-shearing therefore requires more attention in the future so that measurement errors can be minimized. Especially in numerical simulation, suitable rheological models and the realistic determination of parameters are crucial. Since the shear-induced particle migration is largely dependent on the maximum grain size, an ultra-high performance concrete (UHPC) with a maximum particle size of only 0.5 mm was also investigated in the laboratory mixer KNIELE KKM-RT. The integrated rheometer enables also the active homogenization of the fresh concrete during pre-shearing but without the danger of over-mixing, as it is the case for the experimental ICAR setup. This article proves that relevant differences can also be identified for such a material. Full article

Observations of surface deformation are essential for understanding a wide range of geophysical problems, including earthquakes, volcanoes, landslides, and glaciers. Current geodetic technologies, such as global positioning system (GPS), interferometric synthetic aperture radar (InSAR), borehole and laser strainmeters, are costly and limited in their temporal or spatial resolutions. Here we present a new type of strainmeters based on the coaxial cable Bragg grating (CCBG) sensing technology that provides cost-effective strain measurements. Two CCBGs are introduced into the geodetic strainmeter: one serves as a sensor to measure the strain applied on it, and the other acts as a reference to detect environmental noises. By integrating the sensor and reference signals in a mixer, the environmental noises are minimized and a lower mixed frequency is obtained. The lower mixed frequency allows for measurements to be taken with a portable spectrum analyzer, rather than an expensive spectrum analyzer or a vector network analyzer (VNA). Analysis of laboratory experiments shows that the strain can be measured by the CCBG sensor, and the portable spectrum analyzer can make measurements with the accuracy similar to the expensive spectrum analyzer, whose relative error to the spectrum analyzer R3272 is less than ±0.4%. The outputs of the geodetic strainmeter show a linear relationship with the strains that the CCBG sensor experienced. The measured sensitivity of the geodetic strainmeter is about −0.082 kHz/με; it can cover a large dynamic measuring range up to 2%, and its nonlinear errors can be less than 5.3%. Full article
