Search Results (25)

This study investigates the influence of chromatic dispersion on the performance of Brillouin optical time-domain analysis (BOTDA) sensors, particularly under high-pump-power conditions, where nonlinear effects become significant. By incorporating dispersion terms into the coupled amplitude equations of stimulated Brillouin scattering (SBS), we theoretically analyzed the dispersion-induced pulse broadening effect and its impact on the Brillouin gain spectrum (BGS). Numerical simulations revealed that dispersion leads to a moderate broadening of pump pulses, resulting in slight changes to BGS characteristics, including increased peak power and reduced linewidth. To explore the interplay between dispersion and nonlinearity, we built a gain-based BOTDA experimental system and tested two types of fibers, namely standard single-mode fiber (SMF) with anomalous dispersion and dispersion-compensating fiber (DCF) with normal dispersion. Experimental results show that SMF is more prone to modulation instability (MI), which significantly degrades the signal-to-noise ratio (SNR) of the BGS. In contrast, DCF effectively suppresses MI and provides a more stable Brillouin signal. Despite SMF exhibiting narrower BGS linewidths, DCF achieves a higher SNR, aligning with theoretical predictions. These findings highlight the importance of fiber dispersion properties in BOTDA design and suggest that using normally dispersive fibers like DCF can improve sensing performance in long-range, high-power applications. Full article

Conventional metalenses struggle with chromatic aberration and narrow field of view (FOV), making it challenging to meet the dispersion requirements for large apertures and compensate off-axis aberrations for wide FOV. Here, we demonstrate a hybrid metalens module consisting of five refractive plastic lenses and a polarization-insensitive metalens to achieve broadband achromatic imaging within 400–700 nm and a wide FOV up to 100°. The system exhibits negligible variation in focal length (~1.2%) across the visible range (460–656 nm) and consistently achieves modulation transfer function (MTF) values > 0.2 at 167 lp/mm across all wavelengths and incident angles. We also demonstrate integrated lens modules that capture high-quality images from distances ranging between 0.5 and 4 m without post-processing, showcasing its potential for compact, wide-angle optical systems. Full article

To address chromatic dispersion (CD) and nonlinear impairments in coherent optical four-level pulse amplitude modulation (PAM4) systems, we propose a magnitude-assisted decision feedback equalizer (MA-DFE). The proposed scheme utilizes signal amplitude information to construct the error function, which is robust to carrier phase noise. Therefore, no additional carrier phase recovery operation is required during digital signal processing (DSP). Under conditions without CD pre-compensation, MA-DFE achieves 80 Gb/s single-wavelength transmission over a 25 km standard single-mode fiber (SSMF) in the C-band. When considering a bit error rate (BER) of 1 × 10⁻² for the soft decision threshold, the link budget achieves 27 dB. In addition, we incorporate the phase into the error function, proposing the phase-assisted decision feedback equalizer (PA-DFE). PA-DFE is also unaffected by carrier phase noise and demonstrates better performance than MA-DFE when equalizing the more severe signal impairments caused by SOA gain saturation. Ultimately, we achieve a link budget of 29 dB using PA-DFE. Full article

We employed a double-layer coupled diffractive optical element, based on metasurfaces and diffraction gratings, which exhibits wavefront modulation and chromatic dispersion compensation. Utilizing this double-layer coupled diffractive optical element in the optical information transmission process of a diffractive waveguide allows for the transmission of color image information using a single-layer waveguide structure. Our results demonstrate that, under the conditions of a field of view of 47° × 47°, an entrance pupil size of 2.9 × 2.9 mm², and an exit pupil extension size of 8.9 mm, the uniformity of the brightness for each monochromatic field reached 85%, while the uniformity of color transmission efficiency exceeded 95%. Full article

We numerically demonstrate the dispersion map configured by random-based residual dispersion per span (RDPS) applied into the mid-span spectral inversion (MSSI) system to mitigate the impact of chromatic dispersion and the fiber nonlinearity in wavelength division multiplexed (WDM) signals. The dispersion map proposed was a scheme in which the RDPS of all optical fiber spans in the front section of the midway optical phase conjugator (OPC) are randomly selected, and the arrangement order of the RDPS in the rear section is inverted from that of the front section. Numerical simulations were performed by evaluating the compensation of the distorted 960 Gb/s WDM signal as a function of the variation of the DCF length and the SMF length, which are involved in determining RDPS. It was confirmed that the compensation effect of the proposed dispersion maps has improved compared to the conventional dispersion map since the dispersion maps examined in this paper have antipodal symmetry around the midway OPC. In particular, it was confirmed that the method of randomly determining the RDPSs by varying the DCF length slightly improved system performance compared to the variation of SMF lengths. We also found that the feature of the RDPS random distribution patterns can achieve excellent compensation for the distorted WDM signal through 50 iterations. Full article

We propose a novel approach to mitigate the limitations of high-speed Passive Optical Networks (PONs) by introducing an all-optical processor. This solution addresses the escalating demand for higher data rates and improved performance in future access networks. The all-optical processor leverages optical signal processing to enhance system efficiency and reduce power consumption compared to traditional electrical methods. Specifically, we explore the processor’s dual functionality in performing all-optical equalization and chromatic dispersion compensation. Our research includes a comprehensive analysis of the processor’s design, operational principles, and system validation through extensive simulation studies, demonstrating significant improvements in signal quality and overall network performance. The results indicate that the all-optical processor not only relaxes the DSP and power requirements but also outperforms the more sophisticated digital counterpart methods. Full article

A digital subcarrier multiplexing (DSCM) system has been proposed as a possible solution for large capacity and long-distance coherent optical transmissions due to its high tolerances for chromatic dispersion (CD), equalization-enhanced phase noise (EEPN) and fiber nonlinearity. In a DSCM receiver, for subcarrier-demultiplex to occur properly, frequency offset estimation (FOE) must be implemented before demultiplexing. It is beneficial to decrease complexity and EEPN by compensating CD on each subcarrier. Therefore, a high CD tolerance is indispensable for the FOE algorithm in a DSCM receiver. However, the mainstream blind FOE algorithms for single-carrier systems, such as the 4th power fast Fourier transform algorithm, could not work for DSCM systems. To deal with this challenge, a pilot tone-based FOE algorithm with high CD tolerance is proposed and verified using simulations and offline experiments. The final estimation accuracy of about 10 MHz of the proposed two-stage FOE is achieved at low computational complexity. Simulations and offline experiments show that DSCM systems with the proposed algorithm have a 0.5~1 dB Q-factor improvement over Nyquist single-carrier systems. Full article

The nonlinear Kerr effect and chromatic dispersion are the fundamental causes of optical signal degradation in single-mode fiber (SMF) and erbium-doped fiber-amplification (EDFA)-based wavelength division multiplexing (WDM) transmission. Dispersion management combined with a midway optical phase conjugator among the technologies for compensating for such optical signal distortion is known to not be limited by the modulation format and multiplexing technology. Optimization of the dispersion map can partially alleviate the capacity and maximum transmission distance limitations of the SMF and EDFA system. In this paper, we propose various types of symmetric dispersion maps in which the position of zero-crossing place of the cumulative dispersion is not constant, and analyze the effect of each dispersion map configuration on 40 Gb/s × 24-channel WDM signal distortion compensation. When designed with the residual dispersion per span (RDPS) around 400 ps/nm, it is confirmed that most of the proposed dispersion maps are more effective in compensating the distorted WDM signal than conventional dispersion map. In particular, we confirm that, among the proposed dispersion maps, the dispersion map in which the RDPS is designed uniformly for all fiber spans can increase the power margin of WDM channel and expand the range of the total residual dispersion in the dispersion-managed link. Full article

The secondary-phase grating-based tomographic microscopy system, which is widely used in the biological and life sciences, can observe all the sample multilayer image information simultaneously because it has multifocal points. However, chromatic aberration exists in the grating diffraction, which seriously affects the observation of the image. To correct the chromatic aberration of the tomographic microscope system, this paper proposes a system that adopts blazed gratings and angle-variable reflectors as chromatic aberration correction devices according to the principle of dispersion compensation and Fourier phase-shift theory. A reflector-separated light dispersion-compensated 3D microscopy system is presented to achieve chromatic aberration correction while solving the problem of multilayer image overlap. The theoretical verification and optical design of the system were completed using ZEMAX software. The results show that the proposed system reduced the chromatic aberration of ordinary tomographic microscopy systems by more than 90%, retaining more wavelengths of light information. In addition, the system had a relatively wide range in the color difference compensation element installation position, reducing the difficulty of dispersion compensation element installation. Overall, the results indicate that the proposed system is effective in reducing chromatic aberration in grating diffraction. Full article

We report on synchronized dual-wavelength (1.07 μm and 1.24 μm) pulsed lasing driven by a quasi-synchronous primary pumping (at 0.98 μm) of an Yb-doped fiber laser, which incorporates also a P₂O₅-doped fiber as an intracavity Raman converter. The original method developed for such lasing does not require saturable absorbers (or optical modulators) and dispersion management. We demonstrated that the mechanism of the quasi-synchronous pumping enables the aforesaid stationary lasing in spite of significant differential group delay (DGD) inevitably acquired by light pulses with such different wavelengths during an intracavity round trip due to large normal chromatic dispersion. This DGD can be actively compensated at every round trip by the forced “acceleration” of the pulses at 1.07 μm in the Yb-doped active fiber due to the overrated frequency of the quasi-synchronous pumping at 0.98 μm. This mechanism is related to the particular pulse amplification dynamics in a such gain-modulated active fiber. The demonstrated approach to synchronized dual-wavelength pulsed lasing in a single-cavity fiber laser features remarkable simplicity and reliability. Our proof-of-concept setup enabled the stable two-wavelength generation of regular trains of nanosecond pulses with energy up to 34 nJ at equal repetition rates. Full article

Faster-than-Nyquist (FTN) coherent optical transmission technology is considered to be an outstanding solution to achieve higher spectral efficiency (SE), larger capacity, and greater achievable transmission by using advanced modulation formats in concert with highly efficient digital signal processing (DSP) to estimate and compensate various impairments. However, severe inter-symbol interference (ISI) caused by tight FTN pulse shaping will lead to intractable chromatic dispersion (CD) estimation problems, as existing conventional methods are completely ineffective or exhibit unaffordable computational complexity (CC). In this paper, we propose a low-complexity and highly robust scheme that could realize accurate and reliable CD estimation (CDE) based on a designed training sequence (TS) in the first stage and an optimized fractional Fourier transform (FrFT) in the second stage. The training sequence with the designed structure helps us to estimate CD roughly but reliably, and it further facilitates the FrFT in the second stage to achieve accurate CDE within a narrowed searching range; it thereby results in very low CC. Comprehensive simulation results of triple-carrier 64-GBaud FTN dual-polarization 16-ary quadrature amplitude modulation (DP-16QAM) systems demonstrate that, with only overall 3% computational complexity compared with conventional blind CDE methods, the proposed scheme exhibits a CDE accuracy better than 65 ps/nm even under an acceleration factor as low as 0.85. In addition, 60-GBaud FTN DP quadrature phase shift keying (DP-QPSK)/16QAM transmission experiments are carried out, and the results show that the CDE error is less than 70 ps/nm. The advantages of the proposed scheme make it a preferable candidate for CDE in practical FTN coherent optical systems. Full article

The weakness of the dispersion-managed link, which is combined with optical phase conjugation to compensate for optical signal distortion caused by chromatic dispersion and the nonlinear Kerr effect of the standard single mode fiber is, its limited structural flexibility. We propose a dispersion map that can simultaneously compensate for the distorted wavelength division multiplexed signal while increasing the configurational flexibility. Each residual dispersion per span (RDPS) in the former half of the proposed link is randomly determined, and in the latter half, the arrangement order of RDPS is the same as or inverted in the former half. We confirm that the dispersion maps in which the RDPS distribution pattern in the latter half is opposite to the arrangement order in the former half are more effective in compensation, and the compensation effect is better than in the dispersion map of the conventional scheme. The notable result of this study is that the flexibility can be increased by randomly arranging RDPS in the former half, and compensation improvement can be achieved by inversing the order of RDPS arrangement of the former half in the latter half, which makes the dispersion profile of each half link roughly symmetric with respect to the midway optical phase conjugator. Full article

The current work addresses cubic–quartic solitons to compensate for the low count of the chromatic dispersion that is one of the major hindrances of soliton transmission through optical fibers. Thus, the present paper handles the cubic–quartic version of the perturbed Fokas–Lenells equation that governs soliton communications across trans-oceanic and trans-continental distances. The model is also considered with the power-law form of nonlinear refractive index that is a sequel to the previously reported result. This is a tremendous advancement to the previously known result that was only with the Kerr-law form of nonlinear refractive index. The present paper mainly contributes by generalizing the Kerr law of nonlinearity to the power law of nonlinearity. The prior results therefore fall back as a special case to the results of this paper. The semi-inverse variational principle yields a bright 1-soliton solution that is imperative for the telecommunication engineers to carry out experimental investigation before the rubber meets the road. Hamiltonian perturbation terms are included that come with maximum intensity. The soliton amplitude–width relation is retrievable from a polynomial equation with arbitrary degree. The parameter constraints are also identified for the soliton to exist. Full article

In this paper we present the simulative analysis of a 200 Gbps per wavelength (λ) 8-level pulse amplitude modulation (PAM-8) downstream communication over up to 20 km single mode fiber (SMF) in C-band based on direct detection (DD) achieving at least a 29 dB link power budget in a PON environment. We use chromatic dispersion digital pre-compensation (CD-DPC) and a dual-arm in-phase and quadrature Mach–Zehnder modulator (IQ-MZM) at the optical line termination (OLT) side, while preserving DD in the optical network unit (ONU). Three receiver digital-signal-processing (DSP) options are analyzed and compared: square-root-like technique (SQRT) in combination with a feed forward equalizer (FFE) and a decision feedback equalizer (DFE), the Volterra nonlinear equalizer (VNLE), and the SQRT in combination with the VNLE. The SQRT can be applied in combination with the VNLE to decrease the receiver DSP complexity while maintaining the required system performance. We show that PAM-8 with CD-DPC and the SQRT in combination with the VNLE is a feasible solution for 200 Gbps per λ downstream C-band transmission for PON. Full article

The paper presents a method of selecting an optical channel for transporting the double-sideband radio-frequency-over-fiber (DSB-RFoF) radio signal over the optical fronthaul path, avoiding the dispersion-induced power penalty (DIPP) phenomenon. The presented method complements the possibilities of a short-range optical network working in the flexible dense wavelength division multiplexing (DWDM) format, where chromatic dispersion compensation is not applied. As part of the study, calculations were made that indicate the limitations of the proposed method and allow for the development of an algorithm for effective optical channel selection in the presence of the DIPP phenomenon experienced in the optical link working in the intensity modulation–direct detection (IM-DD) technique. Calculations were made for three types of single-mode optical fibers and for selected microwave radio carriers that are used in current systems or will be used in next-generation wireless communication systems. In order to verify the calculations and theoretical considerations, a computer simulation was performed for two types of optical fibers and for two selected radio carriers. In the modulated radio signal, the cyclic-prefix orthogonal frequency division multiplexing (CP-OFDM) format and the 5G numerology were used. Full article
