Accurate quantification of spatial distances between fluorescent signals in multi-channel 3D microscopy is essential for understanding genomic organization and gene regulation. However, chromatic aberration introduces systematic spatial offsets between channels that significantly bias distance measurements, particularly at short genomic distances. We present FISH-Dist, an automated computational pipeline for quantitative distance measurements in 3D fluorescence in situ hybridization (FISH) experiments acquired on standard confocal microscopes. Our method combines deep learning-based spot segmentation, 3D Gaussian fitting for sub-pixel localization, and two complementary chromatic aberration correction approaches: affine (ACC) and linear (LCC). We validated the pipeline by measuring the lengths of DNA origami nanorulers and systematically evaluated FISH probe design parameters, including probe spacing, density, and target sequence length. FISH-Dist achieves sub-pixel accuracy in signal detection and substantially reduces inter-channel distance measurement errors. This enables a reproducible quantification of spatial relationships in 3D FISH datasets. Unlike existing tools optimized for long-range chromosomal interactions or requiring super-resolution microscopy, FISH-Dist specifically addresses the technical challenges of standard confocal imaging at short genomic distances, where chromatic aberration has a proportionally greater impact on measurement accuracy. Full article

A hybrid strategy is proposed to meet the challenge of obtaining the profile of micro gear teeth with a small modulus. Firstly, the contact probe segmentally obtained the falling flank profiles with an auxiliary lifting mechanism to avoid interference when it climbs on the rising slope. Then, the noncontact chromatic confocal displacement sensor efficiently acquired the gear peak positions to carry out the two-point error separation with the gear peak positions from the probe measurement. Finally, actual experiments were carried out to obtain the profile of a harmonic drive flexspline. Compared with the commercial ultraprecise profiler, the proposed method provides measurement results with a deviation of less than 20 μm. In conclusion, the hybrid strategy is feasible and accurate for drawing the micro gear teeth profile without any collision between the measuring probes and the measured workpiece. Full article

This paper presents an intentional investigation of the effect of the object tilt angle on the tracking local minimum method (TL method), which is the one for detecting the measurement target position of the object optical axis, in a chromatic confocal probe employing a differential dual-fiber-detector optical system with a mode-locked femtosecond laser as the light source. The effect of the object tilt angle on dual-detector confocal probes, and even chromatic confocal probes, has not been investigated in detail so far, although the effect of object tilt angle on scanning confocal probes has been studied. At first, to examine the influence of the object tilt angle on the TL method, a theoretical model is established, and numerical simulations are performed based on the established theoretical equation. Then, the effect of aberrations in confocal optics on the confocal response curve is investigated in experiments. Finally, investigations on the effect of the object tilt angle on the TL method are demonstrated in experiments. Full article

This paper presents an off-axis differential method for the improvement of a femtosecond laser differential chromatic confocal probe having a dual-detector configuration. In the proposed off-axis differential method employing a pair of single-mode fiber detectors, a major modification is made to the conventional differential setup in such a way that the fiber detector in the reference detector is located at the focal plane of a collecting lens but with a certain amount of off-axis detector shift, while the fiber detector in the measurement detector is located on the rear focal plane without the off-axis detector shift; this setup is different from the conventional one where the difference between the two confocal detectors is provided by giving a defocus to one of the fiber detectors. The newly proposed off-axis differential method enables the differential chromatic confocal setup to obtain the normalized chromatic confocal output with a better signal-to-noise ratio and approaches a Z-directional measurement range of approximately 46 μm, as well as a measurement resolution of 20 nm, while simplifying the optical alignments in the differential chromatic confocal setup, as well as the signal processing through eliminating the complicated arithmetic operations in the determination of the peak wavelength. Numerical calculations based on a theoretical equation and experiments are carried out to verify the feasibility of the proposed off-axis differential method for the differential chromatic confocal probe with a mode-locked femtosecond laser source. Full article

An intentional investigation on the thermal stability of a mode-locked femtosecond laser chromatic confocal probe, which is a critical issue for the probe to be applied for long-term displacement measurement or surface profile measurement requiring long-time scanning, is carried out. At first, the thermal instability of the first prototype measurement setup is evaluated in experiments where the existence of a considerably large thermal instability is confirmed. Then the possible reasons for the thermal instability of the measurement setup are analyzed quantitatively, such as the thermal instability of the refractive index of the confocal lens and the thermal expansion of mechanical jigs employed in the probe. It is verified that most of the thermal instability of the measurement setup is caused by the thermal expansion of mechanical jigs in the probe. For the improvement of the thermal stability of the probe, it is necessary to employ a low thermal expansion material for the mechanical jigs in the measurement setup and to shorten the optical path length of the laser beam. Based on the analysis result, a second prototype probe is newly designed and constructed. The improved thermal stability of the second prototype probe is verified through theoretical calculations and experiments. Full article

Chromatic confocal technology (CCT) is one of the most promising methods for the contactless and accurate measurement of structure profiles. Based on the principles of chromatic dispersion and confocal theory, a dispersion probe is proposed and optimized with several commercial and cheap refractive index lenses. The probe provides 0.3× magnification and a dispersion range of 400 μm with a commercial LED source with an effective bandwidth of ca. 450–623 nm. Since the noise fluctuation can affect the extraction stability of the focal wavelength, a modification to the centroid peak extraction algorithm is proposed in this paper, where several virtual pixels are interpolated among the real pixels of the spectrometer before thresholding. In addition, a series of experiments were carried out to test the system’s displacement measurement performance. The results clearly show that stability is improved by the modified algorithm, and the calibration repeatability is ±0.3 μm in the full measurement range with a linear stage. The standard deviation at the fixed position has an optimal value of 0.009 μm. The section profile of a Fresnel lens is measured by the CCT system to demonstrate its high feasibility and efficiency. Full article

A method is proposed to expand the Z-directional measurement range of a fiber-based dual-detector chromatic confocal probe with a mode-locked femtosecond laser source. In the dual-detector chromatic confocal probe, the Z-directional displacement of a measurement target is derived from the peak wavelength in the normalized intensity ratio from the two light intensities obtained by the two identical fiber detectors. In this paper, a new method utilizing the main-lobe and side-lobes of axial responses acquired from both the normalized intensity ratio I_a and the invert normalized intensity ratio I_n, which is the inverse of I_a, is proposed to obtain the seamless relationship between the peak wavelength and the Z-directional displacement of a measurement target. Theoretical calculations and experimental investigation are carried out to demonstrate the feasibility of the proposed measurement range expansion method. Full article

Registration is a critical step in multi-sensor dimensional measurement. As the accuracy of registration directly impacts the quality of final results, a reference sphere as a common standard is problematic in high-precision registration. In this paper, a novel method based on a composite standard is proposed to fuse the multiple heterogeneous sensors in high-precision coordinate measuring machines (CMMs), which will void the drawbacks of a reference sphere. The composite standard consists of a cone and cylinder, which share a same central axis. To ensure high precision in the submicron range, or better, the standard is manufactured by an ultra-precision machine. Three features of the composite standard are inspected by three sensors: a video camera (VC), a tactile probe (TP), and a chromatic confocal displacement sensor (CC). All features will concentrate on a common point through which the relation between the three sensors will be obtained. The errors of each measurement were analyzed theoretically, and simulations and real experiments were carried out to verify the composite standard. This study demonstrates that the proposed registration method is stable and that the standard has potential use for the registration of multiple sensors in high-precision dimensional measurement. Full article

For a comprehensive study of Sheet Molding Compound (SMC) surfaces, topographical data obtained by chromatic confocal imaging were submitted systematically for the development of a profile model to understand the formation of cavities on the surface. In order to qualify SMC surfaces and to predict their coatability, a characterization of cavities is applied. To quantify the effect of surface modification treatments, a new parameter (Surface Relative Smooth) is presented, applied and probed. The parameter proposed can be used for any surface modification of any solid material. Full article
