Search Results (34)

Photonic crystals, which are important functional materials, are formed by the periodic arrangement of materials with different dielectric constants that have photonic bandgaps and localization properties. Their preparation methods are primarily physical and chemical. Physical methods include mechanical drilling, layer-by-layer stacking, and precision processing. Chemical methods primarily involve colloidal self-assembly methods. Various colloidal crystal self-assembly methods have been reported, each with its own advantages and disadvantages. Photonic crystals have important applications in many fields, such as optical communications, information technology, energy, biomedicine, and sensors, including high-performance optical fiber fabrication, photonic chip development, and solar cell efficiency enhancement. This paper reviews the latest progress in the preparation of photonic crystals using physical and self-assembly methods. Currently, the preparation and application of photonic crystals have made significant achievements; however, there are still challenges in terms of preparation accuracy, efficiency, cost, and application integration technology. With the future development of science and technology, breakthroughs are expected in novel structural development, preparation process optimization, and cross-field integration, which will continue to promote the progress of photonic crystals and social development. Full article

Breath is one of the most important physiological features of human life. In particular, it is significant to monitor the physical characteristics of breath, such as breath frequency and tidal volume. Breath sensors play an important role in the field of human health monitoring. However, an electronic breath sensor is not stable or even safe when the patient is in a Magnetic Resonance Imaging (MRI) system or during any oncology treatment that requires radiation and other high electric/magnetic fields. Fiber-optic-based sensors have attracted a considerable amount of attention from researchers since they are immune to electromagnetic interference. Here, we propose and demonstrate a fiber-optic-based relative-humidity (RH)-sensing strategy by depositing Ti₃C₂T_x nanosheets onto an etched single-mode fiber (ESMF). The humidity sensor function is realized by modulating the transmitted light in the ESMF using the excellent hydrophilic properties of Ti₃C₂T_x. Experiments show that the coated Ti₃C₂T_x nanosheets can effectively modulate the transmitted light in the ESMF in the relative humidity range of 30~80% RH. The sensor’s fast response time of 0.176 s and recovery time of 0.521 s allow it to be suitable for real-time human breath monitoring. The effective recognition of different breath rhythms, including fast, normal, deep, and strong breathing patterns, has been realized. This work demonstrates an all-optical Ti₃C₂T_x-based sensing platform that combines Ti₃C₂T_x with an optical fiber for humidity sensing for the first time, which has great promise for breath monitoring and presents novel options for gas-monitoring applications in the biomedical and chemical fields. Full article

Structural coloration has become a fascinating field of research, inspiring scientists and engineers to explore the vibrant colors observed in nature and develop bio-inspired photonic structures for various applications. Cellulose-based materials derived from plant fibers offer a promising platform for mimicking natural photonic structures. Their abundance, renewability, and versatility in form and structure make them ideal for engineering specific optical properties. Self-assembly techniques enable the creation of ordered, periodic structures at the nanoscale by manipulating the interactions between cellulose fibers through chemical modification or physical manipulation. Alternatively, additive manufacturing techniques like 3D printing and nanoimprint lithography can directly fabricate desired structures. By em-ulating natural photonic structures, cellulose-based materials hold immense potential for applications such as colorimetric sensors, optoelectronic devices, camouflage, and decorative materials. However, further research is needed to fully com-prehend and control their optical properties, as well as develop cost-effective and scalable manufacturing processes. This article presents a comprehensive review of the fundaments behind natural structural colors exhibited by living organisms and their bio-inspired artificial counterparts. Emphasis is placed on understanding the underlying mechanisms, strategies for tunability, and potential applications of these photonic nanostructures, with special focus on the utilization of cellulose nanocrystals (CNCs) for fabricating photonic materials with visible structural color. The challenges and future prospects of these materials are also discussed, highlighting the potential for advancements to unlock the full potential of cellulose-based materials with structural color. Full article

Photonic sensing devices have become increasingly important in various fields such as agriculture, medicine, biochemical sensing, and manufacturing. They are highly sensitive and can classify minor changes in the physical and chemical properties of the ambient medium with high precision. This makes them practical in applications where accurate measurements are critical, such as medical diagnostics and environmental monitoring. In this review paper, recent advances in different types of photonic sensors are discussed, which include photonic crystal-based sensors, surface plasmon resonance-based sensors, optical fiber-based sensors, optical waveguide-based sensors, and wearable sensors. These highly fascinating sensing devices play a crucial role in countless applications and have several advantages over traditional sensors. As technology continues to advance, we can expect photonic sensors to become even more precise, versatile, and reliable. Full article

In recent decades, the Surface Plasmon Resonance (SPR) phenomenon has been utilized as an underlying technique in a broad range of application fields. Herein, a new measuring strategy which harnesses the SPR technique in a way that is different from the classical methodology was explored by taking advantage of the characteristics of multimode waveguides, such as plastic optical fibers (POFs) or hetero-core fibers. The sensor systems based on this innovative sensing approach were designed, fabricated, and investigated to assess their ability to measure various physical features, such as magnetic field, temperature, force, and volume, and to realize chemical sensors. In more detail, a sensitive patch of fiber was used in series with a multimodal waveguide where the SPR took place, to alter the mode profile of the light at the input of the waveguide itself. In fact, when the changes of the physical feature of interest acted on the sensitive patch, a variation of the incident angles of the light launched in the multimodal waveguide occurred, and, as a consequence, a shift in resonance wavelength took place. The proposed approach permitted the separation of the measurand interaction zone and the SPR zone. This meant that the SPR zone could be realized only with a buffer layer and a metallic film, thus optimizing the total thickness of the layers for the best sensitivity, regardless of the measurand type. The proposed review aims to summarize the capabilities of this innovative sensing approach to realize several types of sensors for different application fields, showing the high performances obtained by exploiting a simple production process and an easy experimental setup. Full article

Optical fiber sensors based on tapered optical fiber (TOF) structure have attracted a considerable amount of attention from researchers due to the advantages of simple fabrication, high stability, and diverse structures, and have great potential for applications in many fields such as physics, chemistry, and biology. Compared with conventional optical fibers, TOF with their unique structural characteristics significantly improves the sensitivity and response speed of fiber-optic sensors and broadens the application range. This review presents an overview of the latest research status and characteristics of fiber-optic sensors and TOF sensors. Then, the working principle of TOF sensors, fabrication schemes of TOF structures, novel TOF structures in recent years, and the growing emerging application areas are described. Finally, the development trends and challenges of TOF sensors are prospected. The objective of this review is to convey novel perspectives and strategies for the performance optimization and design of TOF sensors based on fiber-optic sensing technologies. Full article

Graphene-based materials have been increasingly incorporated to optical fiber plasmonic sensors due to the peculiar physical and chemical properties of these materials (hardness and flexibility, high electrical and thermal conductivity, and very good adsorption for many substances, etc.). In this paper, we theoretically and experimentally showed how the addition of graphene oxide (GO) to optical fiber refractometers permits the development of surface plasmon resonance (SPR) sensors with very good characteristics. We used doubly deposited uniform-waist tapered optical fibers (DLUWTs) as supporting structures because of their already proven good performance. The presence of GO as an effective third layer is useful to tune the wavelength of the resonances. In addition, the sensitivity was improved. We depict the procedures for the production of the devices and characterize the GO+DLUWTs produced in this way. We also showed how the experimental results are in agreement with the theoretical predictions and used these to estimate the thickness of deposited GO. Finally, we compared the performance of our sensors with other ones that have been recently reported, showing that our results are among the best reported. Using GO as the medium in contact with the analyte, in addition to the good overall performance of devices, permit consideration of this option as an interesting possibility for the future development of SPR-based fiber sensors. Full article

The current generation is witnessing a huge interest in optical waveguides due to their salient features: they are of low cost, immune to electromagnetic interference, easy to multiplex, have a compact size, etc. These features of optical fibers make them a useful tool for various sensing applications including in medicine, automotives, biotechnology, food quality control, aerospace, physical and chemical monitoring. Among all the reported applications, optical waveguides have been widely exploited to measure the physical and chemical variations in the surrounding environment. Optical fiber-based temperature sensors have played a crucial role in this decade to detect high fever and tackle COVID-19-like pandemics. Recognizing the major developments in the field of optical fibers, this article provides recent progress in temperature sensors utilizing several sensing configurations including conventional fiber, photonic crystal fiber, and Bragg grating fibers. Additionally, this article also highlights the advantages, limitations, and future possibilities in this area. Full article

Cholesteric liquid crystals (CLCs) can be applied to various physical and chemical sensors because their alignment structures are changed by external stimuli. Here, we propose a CLC device fabricated by vertically forming the helical axis of the CLC between the cross-sections of two optical fiber ferrules. An optical fiber temperature sensor was successfully implemented using the proposed optical fiber ferrule-based CLC device. A wideband wavelength-swept laser with a center wavelength of 1073 nm and scanning range of 220 nm was used as a light source to measure the variations in the reflection spectrum band according to the temperature change in the CLC cell. The wavelength variation of the reflection spectrum band according to the temperature applied to the CLC cell was reversible and changed linearly with a change in the temperature, and the long-wavelength edge variation rate according to the temperature change was −5.0 nm/°C. Additionally, as the temperature applied to the CLC cell increased, the reflection spectrum bandwidth gradually decreased; the reflection spectrum bandwidth varied at a rate of −1.89 nm/°C. The variations in the refractive indices with temperature were calculated from the band wavelengths of the reflection spectrum. The pitch at each temperature was calculated based on the refractive indices and it gradually decreased as the temperature increased. Full article

An inline optical fiber sensor is proposed to monitor in real time the evaporation process of ethanol–water binary mixtures. The sensor presents two interferometers, a cladding modal interferometer (CMI) and a Mach–Zehnder interferometer (MZI). The CMI is used to acquire the variations in the external medium refractive index, presenting a maximum sensitivity of 387 nm/RIU, and to attain the variation in the sample concentration profile, while the MZI monitors temperature fluctuations. For comparison purposes, an image analysis is also conducted to obtain the droplet profile. The sensor proposed in this work is a promising alternative in applications where a rigorous measurement of volatile organic compound concentrations is required, and in the study of chemical and physical properties related to the evaporation process. Full article

In this paper, we review the characteristics of critical wavelength (CWL)-existed fiber-optic Mach–Zehnder interferometers (MZIs), including special few-mode fibers and microfibers, and their sensing applications in physical, chemical, and marine fields. Owing to the existence of CWL in the transmission spectra, the in-line MZIs show some specific characteristics. The closer the peak/dip wavelength to the CWL, the larger the wavelength shift or the related sensitivity when the interferometer is under testing. Meanwhile, CWL shifts monotonically with the variations in measurands, such as temperature (in the air or seawater), axial strain, water pressure, surrounding refractive index, etc., when they are applied to the sensing fibers. These characteristics of the CWL-existed in-line MZIs make them appealing solutions for fabricating various interferometric sensors, with the advantages of large measurement range, high sensitivity, multiparameter sensing, etc. Theoretical and experimental studies on the properties of the CWL-existed in-line MZIs are reviewed and discussed in this paper. Full article

Optical fiber sensors based on an interferometer structure play a significant role in monitoring physical, chemical, and biological parameters in natural environments. However, sensors with high-sensitivity measurement still present their own challenges. This paper deduces and summarizes the methods of sensitivity enhancement in interferometer based fiber optical sensors, including the derivation of the sensing principles, key characteristics, and recently-reported applications.The modal coupling interferometer is taken as an example to derive the five terms related to the sensitivity: (1) the wavelength-dependent difference of phase between two modes/arms $\partial {\varphi }_d/\partial \lambda$, (2) the sensor length $L_{w,A}$, (3) refractive index difference between two modes/arms $\mathsf{\Delta }{n}_{eff,A}$, (4) sensing parameter dependent length change $\alpha$, and (5) sensing parameter dependent refractive index change $\gamma$. The research papers in the literature that modulate these terms to enhance the sensing sensitivity are reviewed in the paper. Full article

In situ measurements are highly desirable in many microfluidic applications because they enable real-time, local monitoring of physical and chemical parameters, providing valuable insight into microscopic events and processes that occur in microfluidic devices. Unfortunately, the manufacturing of microfluidic devices with integrated sensors can be time-consuming, expensive, and “know-how” demanding. In this article, we describe an easy-to-implement method developed to integrate various “off-the-shelf” fiber optic sensors within microfluidic devices. To demonstrate this, we used commercial pH and pressure sensors (“pH SensorPlugs” and “FOP-MIV”, respectively), which were “reversibly” attached to a glass microfluidic device using custom 3D-printed connectors. The microfluidic device, which serves here as a demonstrator, incorporates a uniform porous structure and was manufactured using a picosecond pulsed laser. The sensors were attached to the inlet and outlet channels of the microfluidic pattern to perform simple experiments, the aim of which was to evaluate the performance of both the connectors and the sensors in a practical microfluidic environment. The bespoke connectors ensured robust and watertight connection, allowing the sensors to be safely disconnected if necessary, without damaging the microfluidic device. The pH SensorPlugs were tested with a pH 7.01 buffer solution. They measured the correct pH values with an accuracy of ±0.05 pH once sufficient contact between the injected fluid and the measuring element (optode) was established. In turn, the FOP-MIV sensors were used to measure local pressure in the inlet and outlet channels during injection and the steady flow of deionized water at different rates. These sensors were calibrated up to 140 mbar and provided pressure measurements with an uncertainty that was less than ±1.5 mbar. Readouts at a rate of 4 Hz allowed us to observe dynamic pressure changes in the device during the displacement of air by water. In the case of steady flow of water, the pressure difference between the two measuring points increased linearly with increasing flow rate, complying with Darcy’s law for incompressible fluids. These data can be used to determine the permeability of the porous structure within the device. Full article

Optical chemosensors with surface plasmon resonance (SPR) transduction are widely employed, even in complex environments, such as those outside the laboratory. In this context, not only the chemical nature but also the physical form of the receptor layer is particularly relevant. Synthetic receptors as molecularly imprinted polymers (MIPs) are well suited. This is demonstrated here in the case of an SPR sensor platform based on a multimode plastic optical fiber, which is very promising for on site application due to the low dimensions and low cost. A specific MIP was used as the receptor, with high affinity for the substance to be determined, 2-furaldehyde, in water. Here, a medium of high refractive index, i.e., vegetable oil, was considered because of the high interest for its determination in industrial diagnostics. The effects of the MIP layer thickness and the washing extent on the quality of the analytical signal were investigated. Better spectra were generated at the thinner MIP layer, while a lower detection limit is reached with extended washing. Full article

The use of advanced sensing devices for concrete and reinforced concrete structures (RCS) is considered a rational approach for the assessment of repair options and scheduling of inspection and maintenance strategies. The immediate benefits are cost reduction and a reliable prevention of unpredictable events. The use of optical fiber sensors (OFS) for such purposes has increased considerably in the last few years due to their intrinsic advantages. In most of the OFS, the chemical transducer consists of immobilized chemical reagents placed in the sensing region of the optical sensor by direct deposition or by encapsulation in a polymeric matrix. The choice of the support matrix impacts directly on the performance of the OFS. In the last two decades, the development of OFS functionalized with organic–inorganic hybrid (OIH) sol–gel membranes have been reported. Sol–gel route is considered a simple method that offers several advantages when compared to traditional synthesis processes, allowing to obtain versatile materials with unique chemical and physical properties, and is particularly valuable in the design of OIH materials. This review will provide an update of the current state-of-the-art of the OFS based on OIH sol-gel materials for concrete and RCS since 2016 until mid-2021. The main achievements in the synthesis of OIH membranes for deposition on OFS will be discussed. The challenges and future directions in this field will also be considered, as well as the main limitations of OFS for RCS monitoring. Full article
