Prestressed concrete structures, designed to enhance the compressive strength of concrete through internal pretension, are increasingly susceptible to serviceability issues caused by rising live loads, material degradation, and environmental impacts. Strengthening or retrofitting offers a practical and cost-effective alternative to full replacement. This study investigated the flexural strengthening of prestressed concrete T-beams in the negative moment region using near-surface mounted (NSM) carbon-fiber-reinforced polymer (CFRP) rods. Validation against experimental results from the literature demonstrated high accuracy, with an average numerical-to-experimental ultimate load ratio of 0.97 for reinforced concrete T-beams strengthened with NSM-CFRP rods, a negligible difference of 0.49% for prestressed concrete I-beams, and a minimal error of 1.30% for prestressed concrete slabs strengthened with CFRP laminates. Parametric studies examined the effects of CFRP rod embedment depths and initial prestressing levels. In certain cases, achieving the minimum embedment depth is not feasible due to design or construction constraints. The results showed that fully embedded CFRP rods increased the ultimate load by up to 14.02% for low prestressing levels and 16.36% for high levels, while half-embedded rods provided comparable improvements of 11.20% and 15.76%, respectively. These findings confirm the effectiveness of NSM-CFRP systems and highlight the potential of partial embedment as a practical solution in design-constrained scenarios. Full article

Large-tow carbon fiber-reinforced polymer composites (CFRP) have great application potential in civil engineering due to their low price, but their basic mechanical properties are still unclear. The tensile properties of large-tow CFRP rods and plates were investigated in this study. First, the tensile properties of unidirectional CFRP rods and plates were studied, and the test results of the relevant mechanical properties were statistically analyzed. The tensile strength of the CFRP rod and plate are 2005.97 MPa and 2069.48 MPa. Second, the surface of the test specimens after failure was observed using a scanning electron microscope to analyze the type of failure and damage evolution process. Finally, the probabilistic characteristics of the mechanical properties were analyzed using normal, lognormal, and Weibull distributions for parameter fitting. Quasi-optimality tests were performed, and a probability distribution model was proposed for the mechanical properties of large-tow CFRP rods and plates. Full article

Carbon fiber-reinforced polymer (CFRP) composite materials are widely used in engineering applications, but their production generates a significant amount of waste. This paper aims to explore the potential of incorporating mechanically recycled aerospace prepreg waste in thermoplastic composite materials to reduce the environmental impact of composite material production and promote the use of recycled materials. The composite material developed in this study incorporates a bio−based thermoplastic polymer, polyamide 11 (PA11), as the matrix material and recycled aerospace prepreg waste quasi-one-dimensionally arranged as reinforcement. Mechanical, thermal, and thermomechanical characterizations were performed through tensile, flexural, and impact tests, as well as differential scanning calorimetry (DSC) and dynamic mechanical analysis (DMA). Compared to previous studies that used a different recycled CFRP in the shape of rods, the results show that the recycled prepregs are a suitable reinforcement, enhancing the reinforcement-matrix adhesion and leading to higher mechanical properties. The tensile results were evaluated by SEM, and the impact tests were evaluated by CT scans. The results demonstrate the potential of incorporating recycled aerospace prepreg waste in thermoplastic composite materials to produce high-performance and sustainable components in the aerospace and automotive industries. Full article

Carbon fiber-reinforced polymer (CFRP) composites have been widely used in civil engineering structures due to their excellent mechanical and durability properties. The harsh service environment of civil engineering leads to significant degradation of the thermal and mechanical performances of CFRP, which then reduces its service reliability, service safety, and life. Research on the durability of CFRP is urgently needed to understand the long-term performance degradation mechanism. In the present study, the hygrothermal aging behavior of CFRP rods was investigated experimentally through immersion in distilled water for 360 days. The water absorption and diffusion behavior, the evolution rules of short beam shear strength (SBSS), and dynamic thermal mechanical properties were obtained to investigate the hygrothermal resistance of CFRP rods. The research results show that the water absorption behavior conforms to Fick’s model. The ingression of water molecules leads to a significant decrease in SBSS and glass transition temperature (Tg). This is attributed to the plasticization effect of the resin matrix and interfacial debonding. Furthermore, the Arrhenius equation was used to predict the long-term life of SBSS in the actual service environment based on the time–temperature equivalence theory, obtaining a stable strength retention of SBSS of 72.78%, which was meaningful to provide a design guideline for the long-term durability of CFRP rods. Full article

In this study, the variation of fatigue stiffness, fatigue life, and residual strength, as well as the macroscopic damage initiation, expansion, and fracture of CFRP (carbon fiber reinforced polymer) rods in bending-anchored CFRP cable, were investigated experimentally to verify the anchoring performance of the bending anchoring system and evaluate the additional shear effect caused by bending anchoring. Additionally, the acoustic emission technique was used to monitor the progression of critical microscopic damage to CFRP rods in a bending anchoring system, which is closely related to the compression-shear fracture of CFRP rods within the anchor. The experimental results indicate that after the fatigue cycles of two million, the residual strength retention rate of CFRP rod was as high as 95.1% and 76.7% under the stress amplitudes of 500 MPa and 600 MPa, indicating good fatigue resistance. Moreover, the bending-anchored CFRP cable could withstand 2 million cycles of fatigue loading with a maximum stress of 0.4 σ_ult and an amplitude of 500 MPa without obvious fatigue damage. Moreover, under more severe fatigue-loading conditions, it can be found that fiber splitting in CFRP rods in the free section of cable and compression-shear fracture of CFRP rods are the predominant macroscopic damage modes, and the spatial distribution of macroscopic fatigue damage of CFRP rods reveals that the additional shear effect has become the determining factor in the fatigue resistance of the cable. This study demonstrates the good fatigue-bearing capacity of CFRP cable with a bending anchoring system, and the findings can be used for the optimization of the bending anchoring system to further enhance its fatigue resistance, which further promotes the application and development of CFRP cable and bending anchoring system in bridge structures. Full article

This paper intends to deepen the topic of damage detection based on non-destructive tests (NDT) for the assessment of the dynamic behavior of RC beams damaged and strengthened both with near-surface mounted (NSM) Carbon and GlassFRP rods. The NSM strengthening with fiber-reinforced polymer (FRP) rods of damaged reinforced concrete (RC) beams is a viable alternative to the traditional strengthening with externally bonded (EB) FRP strips or sheets. In this paper, static tests were foreseen on RC beams to create cracking, and successively, the RC beams strengthened with NSM CFRP and GFRP rods were still investigated using free vibration tests at different loading levels until failure. The purpose of this research is to compare the response of two different types of strengthening of damaged RC beams based on the strength of CFRP and GFRP rods until failure modes. At different steps of loading, the behavior of beams under experimental vibrations has been monitored by frequency response function (FRF) diagrams. Finally, a discussion of the results is presented. Full article

The rising amount of carbon fiber reinforced polymer (CFRP) composite waste requires new processes for reintroducing waste into the production cycle. In the present research, the objective is the design and study of a reuse process for carbon fibers and CFRP by mechanical recycling consisting of length and width reduction, obtaining rods and reintegrating them as fillers into a polymeric matrix. Preliminary studies are carried out with continuous and discontinuous unidirectional fibers of various lengths. The processing conditions are then optimized, including the length of the reinforcement, the need for a plasma surface treatment and/or for resin post-curing. The resin is thermally characterized by differential scanning calorimetry (DSC), while the composites are mechanically characterized by tensile strength tests, completed by a factorial design. In addition, the composites tested are observed by scanning electron microscopy (SEM) to study the fracture mechanics. Optimal processing conditions have been found to reduce the reinforcement length to 40 mm while maintaining the mechanical properties of continuous reinforcement. Furthermore, the post-curing of the epoxy resin used as matrix is required, but a low-pressure plasma treatment (LPPT) is not recommended on the reinforcement. Full article

Modern fiber-reinforced polymer (FRP)-reinforced concrete structures are excepted to achieve superior mechanical performances and long service lives, even in harsh service environments. Hybrid FRP material could potentially meet this goal with its relatively high strength-to-cost ratio. This paper presents an experimental study on the compressive behavior of concrete cylinders confined by a novel hybrid fiber-reinforced polymer (HFRP) spiral. Nine types, forming a total of 27 confined or non-confined concrete cylinders, were subjected to an axial compressive-loading test. Concrete cylinders confined either with different spiral types or different spiral spacings were comparatively studied in the experiment. The results showed that the compressive failure modes and the stress–strain relationships of the HFRP-spiral-confined cylinders were similar to those of basalt-fiber-reinforced polymer (BFRP)-spiral-confined cylinders. The actual fracture strain of the HFRP spiral (tested as a single rod) was larger than that of the corresponding carbon-fiber-reinforced polymer (CFRP) bar, indicating the advantageous composite effect of the HFRP spiral. The maximum strain of the HFRP spiral reached over 70% of its ultimate strain in the cylinders compared to the BFRP spiral, which only reached 50%. Most of the existing models overestimated the ultimate stress and strain of the HFRP-spiral-confined cylinders. Wu’s model was proved to be the most accurate model, yet proper modification was required for predicting the peak strain of the HFRP-confined cylinders. Full article

Over the last two decades, considerable attention has been devoted to the strengthening of sub-standard flat-slab constructions. With the evolution of composite materials and an increasing emphasis on the economical and sustainable use of natural fibers, many researchers have utilized them in the strengthening of flat flabs mitigating punching failures. This study aims at investigating and comparing the behavior of flat slabs strengthened with post-installed composite and natural reinforcements. An experimental program was devised consisting of eight flat-slab specimens. One specimen was tested in as-built condition to provide a reference. The remaining specimens were strengthened with Carbon Fiber-Reinforced Polymer (CFRP), Aramid Fiber-Reinforced Polymer (AFRP), and sisal rods. The pattern of post-installed rods was varied as single line, double line, and star shapes around the column. The results indicated that the single-line pattern could only enhance the maximum sustained load by up to 6% compared to that of the reference specimen. On the contrary, double line and star shape configurations resulted in a substantial increase in the maximum sustained load. An analytical assessment of ACI 318-19 provisions resulted in an over-estimation of the shear strengths of CFRP- and AFRP-strengthened slabs. Furthermore, the same provisions led to lower yields than experimental shear strengths for sisal-strengthened slabs. Full article

This study aims to develop a prestressed concrete steel (PC) strand with an embedded optical Fiber Bragg Grating (FBG) sensor, which has been developed by the Korea Institute of Civil Engineering and Building Technology since 2013. This new strand is manufactured by replacing the steel core of the normal PC strand with a carbon-fiber-reinforced polymer (CFRP) rod with excellent tensile strength and durability. Because this new strand is manufactured using the pultrusion method, which is a composite material manufacturing process, with an optical fiber sensor embedded in the inner center of the CFRP Rod, it ensures full composite action as well as proper function of the sensor. In this study, a creep test for maintaining a constant load and a relaxation test for maintaining a constant displacement were performed on the proposed sensor-type PC strand. Each of the two tests was conducted for more than 1000 h, and the long-term performance verification of the sensor-type PC strand was only completed by comparing the performance with that of a normal PC strand. The test specimens were fabricated by applying an optical fiber sensor-embedded PC strand, which had undergone long-term performance verification tests, to a reinforced concrete beam. Depending on whether grout was injected in the duct, the specimens were classified into composite and non-composite specimens. A hydraulic jack was used to prestress the fabricated beam specimens, and the long-term change in the prestress force was observed for more than 1600 days using the embedded optical fiber sensor. The experimental results were compared with the analytical results to determine the long-term prestress loss obtained through finite-element analysis based on various international standards. Full article

Significant strengthening of concrete structures can be obtained when using adhesively-bonded carbon fiber-reinforced polymer (CFRP) systems. Challenges related to such strengthening methods are; however, the brittle concrete delamination failure, reduced warning, and the consequent inefficient use of the CFRP. A novel ductile near-surface mounted reinforcement (NSMR) CFRP strengthening system with a high CFRP utilization is introduced in this paper. It is hypothesized that the tailored ductile enclosure wedge (EW) end anchors, in combination with low E-modulus and high elongation adhesive, can provide significant strengthening and ductility control. Five concrete T-beams were strengthened using the novel system with a CFRP rod activation stress of approximately 980 MPa. The beam responses were compared to identical epoxy-bonded NSMR strengthened and un-strengthened beams. The linear elastic response was identical to the epoxy-bonded NSMR strengthened beam. In addition, the average deflection and yielding regimes were improved by 220% and 300% (average values), respectively, with an ultimate capacity comparable to the epoxy-bonded NSMR strengthened beam. Reproducible and predictable strengthening effect seems obtainable, where a good correlation between the results and applied theory was reached. The brittle failure modes were prevented, where concrete compression failure and frontal overload anchor failure were experienced when failure was initiated. Full article

The reinforcement of structural elements subjected to bending with carbon fiber reinforced polymers (CFRP) located on the underside of the element to be reinforced (known as near surface mounted or NSM) is an effective technique that provides environmentally sustainable solutions in the field of civil engineering. Introducing preloads on the reinforcing elements allows us to maximize the high performance of CFRPs, besides recovering deformations. A new technique to perform the pre-stressing of CFRP bars in NSM configuration is described in this paper. The technique introduces the preload on the rods after they have been placed in the grooves, and with a system that acts and reacts against the beam itself. We also present the results of a testing campaign conducted to determine the effectiveness of said technique. Breakage of the control beams (without reinforcement) was ductile, while breakage of reinforced beams was explosive. Pre-stressing the reinforcing elements allowed us to increase the bearing capacity of the beams 170% compared to the control beams, also resulting in an increase in the rigidity of the reinforced elements and a decreased cracking of the beam. The results however are only slightly better than those of a conventional CFRP NSM reinforcement, due to the appearance of cavities in the groove where the adhesive didn’t manage to penetrate. Full article

This paper presents an elastic shear stress distribution theoretical model at the carbon fiber-reinforced polymer (CFRP)-adhesive interface of a single-rod and a multi-rod straight-pipe bonding anchor. A comparison between theoretical and finite element analysis results reveals that the accuracy of the theory can be used to guide the preliminary design of CFRP rod bonding anchors. The mechanical performance of the inner cone bonding anchor for multi-rods are evaluated within different coefficients of friction and inner inclined angles. Numerical results indicate that the straight-parabolic inner cone bonding anchor has a significant effect on reducing the shear force at the loading end. Full article
