Wave overtopping occurring in offshore wind renewable energy structures such as tension leg platforms (TLPs) or semi-submersible platforms is a phenomenon that is worth studying and preventing in order to extend the remaining useful life of the corresponding facilities. The behaviour of this phenomenon has been extensively reported for linear coastal defences like seawalls. However, no referenced study has treated the case of cylindrical structures typical of these applications to a similar extent. The aim of the present study is to define an empirical expression that portrays the relative overtopping rate over a vertical cylinder including a variety of bull-nose type mitigation structures to reduce the overtopping rate in the same fashion as for the linear structures characteristic of shoreline defences. Hydrodynamic interaction was studied by means of an experimentally validated numerical model applied to a non-impulsive regular wave regime and the results were compared with the case of a plain cylinder to evaluate the expected improvement in the overtopping performance. Four different types of parapets were added to the crest of the base cylinder, with different parapet height and horizontal extension, to see the influence of the geometry on the mitigation efficiency. Computational results confirmed the effectivity of the proposed solution in the overtopping reduction, though the singularity of each parapet geometry did not lead to an outstanding difference between the analysed options. Consequently, the resulting overtopping decrease in all the proposed geometries could be modelled by a unique specific Weibull-type function of the relative freeboard, which governed the phenomenon, showing a net reduction in comparison with the cylinder without the geometric modifications. In addition, the relationship between the reduced relative overtopping rate and the mean flow thickness over the vertical cylinder crest was studied as an alternative methodology to assess the potential damage caused by overtopping in real structures without complex volumetric measurements. The collection of computational results was fitted to a useful function, allowing for the definition of the overtopping discharge once the mean flow thickness was known. Full article

Free-form surface parts are widely used in industries, and they consist of intricate 3D surfaces such as molds, impellers, and turbine blades that possess complex geometrical contours and demand high precision. Proper tool orientation is crucial for ensuring the efficiency and accuracy of five-axis computer numerical control (CNC) machining. Multi-scale methods have received much attention and have been widely used in various fields. They have been proven to be instrumental and can obtain fruitful outcomes. Ongoing research on multi-scale tool orientation generation methods, which aim to acquire tool orientations that satisfy both macro- and micro-scale requirements, is significantly important for improving the machining quality of workpiece surfaces. This paper proposes a multi-scale tool orientation generation method that considers both the machining strip width and roughness scales. This method also ensures a smooth tool orientation and avoids interference in the machining process. First, the correlation between the tool orientation and rotational axis is analyzed, and feasible area calculation and tool orientation adjustment methods are introduced. Then, the paper introduces the calculation method for machining strip widths on the macro-scale and the roughness calculation method on the micro-scale. Besides, tool orientation adjustment methods for both scales are proposed. Next, a multi-scale tool orientation generation method is developed to generate tool orientations that meet the macro- and micro-scale requirements. Finally, to verify the effectiveness of the proposed multi-scale tool orientation generation method, it is applied to the machining of a free-form surface. Experimental verification results have shown that the tool orientation generated by the proposed method can obtain the expected machining strip width and roughness, meeting both macro- and micro-scale requirements. Therefore, this method has significant potential for engineering applications. Full article

During the bull-nose end milling operations of thin-walled structures, chatter usually occurs and adversely affects cutter performance, finished surface quality, and production efficiency. To accurately predict chatter stability, a suitable dynamic model with effective system parameters is required. In this article, a three-degree-of-freedom (3-DOF) dynamic model is developed to analyze the milling stability of the thin-walled cylinders, in which the dynamics of the bull-nose end mill along the x-axis and y-axis directions and the dynamic of the workpiece along the z-axis direction are taken into account. Then, the cutter-workpiece engagement (CWE) is extracted by employing a slice-intersection-based approach. And the layered cutting force coefficients are identified by considering the influences of varying cutter diameters on the cutting speed. Thereafter, the semi-discretization method (SDM) is adopted to compute the stability lobe diagram (SLD). In the end, a group of milling tests are carried out on a thin-walled cylinder to validate the accuracy and reliability of the proposed model, and the results show that the model predictions agree well with the experimental data. Full article

Surface topography is closely related to fatigue strength and mating accuracy of workpieces. The profile method is widely adopted to evaluate surface topography. In the present study, a 2D profile simulation model of five-axis CNC machining with a bull-nose cutter is proposed to predict the surface topography of a machined workpiece. To this end, a simplified scallop model is established by analyzing the geometry and motion of the bull-nose cutter. Then, the principles of the 2D profile simulation model for plane and free-form surfaces are described to provide the basis for building 2D profile simulation models. After that, 2D profiles are obtained directly from CL data, tool parameters, and workpiece design models, and an algorithm is proposed to obtain 2D profiles. Finally, the proposed algorithm is verified by different machining experiments on plane and free-form surfaces. The results show that the simulation and measurement results are in good agreement. The proposed simulation model for five-axis CNC machining with a bull-nose cutter can be effectively applied to simulate 2D profiles of plane and free-form surfaces. The present study is expected to provide a reference for optimizing process parameters. Full article

The productivity during the machining of thin-floor components is limited due to unstable vibrations, which lead to poor surface quality and part rejection at the last stage of the manufacturing process. In this article, a semi-active magnetorheological damper device is designed in order to suppress chatter conditions during the milling operations of thin-floor components. To validate the performance of the magnetorheological (MR) damper device, a 1 degree of freedom experimental setup was designed to mimic the machining of thin-floor components and then, the stability boundaries were computed using the Enhance Multistage Homotopy Perturbation Method (EMHPM) together with a novel cutting force model in which the bull-nose end mill is discretized in disks. It was found that the predicted EMHPM stability lobes of the cantilever beam closely follow experimental data. The end of the paper shows that the usage of the MR damper device modifies the stability boundaries with a productivity increase by a factor of at least 3. Full article

The influence of parapets on crown walls of mound breakwaters on wave forces has not been extensively analyzed in the literature. In this study, numerical experiments were carried out using the open-source platform OpenFOAM^® to evaluate the influence of nine crown wall geometries with and without parapets. The OpenFOAM^® model was validated with laboratory experiments. Dimensionless horizontal forces and overturning moments due to horizontal forces increase when there is a parapet. Dimensionless up-lift forces provide similar results, regardless of the existence of a parapet. Crown walls with parapets increase the horizontal wave forces and overturning moments due to horizontal wave forces by a factor of two. Full article

In finishing processes, the quality of aluminum parts is mostly influenced by static and dynamic phenomena. Different solutions have been studied toward a stable milling process attainment. However, the improvements obtained with the tuning of process parameters are limited by the system stiffness and external dampers devices interfere with the machining process. To deal with this challenge, this work analyzes the suitability of elastomer layers as passive damping elements directly located under the part to be machined. Thus, exploiting the sealing properties of nitrile butadiene rubber (NBR), a suitable flexible vacuum fixture is developed, enabling a proper implementation in the manufacturing process. Two different compounds are characterized under axial compression and under finishing operations. The compression tests present the effect of the feed rate and the strain accumulative effect in the fixture compressive behavior. Despite the higher strain variability of the softer rubber, different milling process parameters, such as the tool feed rate, can lead to a similar compressive behavior of the fixture regardless the elastomer hardness. On the other hand, the characterization of these flexible fixtures is completed over AA2024 floor milling of rigid parts and compared with the use of a rigid part clamping. These results show that, as the cutting speed and the feed rate increases, due to the strain evolution of the rubber, the part quality obtained tend to equalize between the flexible and the rigid clamping of the workpiece. Due to the versatility of the NBR for clamping different part geometries without new fixture redesigns, this leads to a competitive advantage of these flexible solutions against the classic rigid vacuum fixtures. Finally, a model to predict the grooving forces with a bull-nose end mill regardless of the stiffness of the part support is proposed and validated for the working range. Full article

Background literature on the influence of parapets on the overtopping of mound breakwaters is limited. In this study, numerical tests were conducted using computational fluid dynamics (CFD) to analyze the influence of nine crown wall geometries (seven with parapets). The CFD model was implemented in OpenFOAM^® and successfully validated with laboratory tests. A new estimator of the dimensionless mean wave-overtopping discharges (logQ) on structures with parapets is proposed. The new estimator depends on the estimation of logQ of the same structure without a parapet. The effects on wave overtopping of the parapet angle (ε_p), parapet width (w_p), and parapet height (h_p) were analyzed. Low values of ε_p and w_p/h_p ≈ 1 produced the highest parapet effectiveness to reduce the mean wave-overtopping discharges. Full article
