Point cloud-based BIM reconstruction is an effective approach to enabling the digital documentation of existing buildings. However, current methods often demand substantial time and expertise for the manual measurement of building dimensions and the drafting of BIMs. This paper proposes an automated approach to BIM modeling of the external surfaces of existing buildings, aiming to streamline the labor-intensive and time-consuming processes of manual measurement and drafting. Initially, multi-angle images of the building are captured using drones, and the building’s point cloud is reconstructed using 3D reconstruction software. Next, a multi-plane segmentation technique based on the RANSAC algorithm is applied, facilitating the efficient extraction of key features of exterior walls and planar roofs. The orthophotos of the building façades are generated by projecting wall point clouds onto a 2D plane. A lightweight convolutional encoder–decoder model is utilized for the semantic segmentation of windows and doors on the façade, enabling the precise extraction of window and door features and the automated generation of AutoCAD elevation drawings. Finally, the extracted features and segmented data are integrated to generate the BIM. The case study results demonstrate that the proposed method exhibits a stable error distribution, with model accuracy exceeding architectural industry requirements, successfully achieving reliable BIM reconstruction. However, this method currently faces limitations in dealing with buildings with complex curved walls and irregular roof structures or dense vegetation obstacles. Full article

The extraction of UAV building point cloud contour points is the basis for the expression of a three-dimensional lightweight building outline. Previous unmanned aerial vehicle (UAV) building point cloud contour extraction methods have mainly focused on the expression of the roof contour, but did not extract the wall contour. In view of this, an algorithm based on the geometric features of the neighborhood points of the region-growing clustering fusion surface is proposed to extract the boundary points of the UAV building point cloud. Firstly, the region growth plane is fused to obtain a more accurate segmentation plane. Then, the neighboring points are projected onto the neighborhood plane and a vector between the object point and neighborhood point is constructed. Finally, the azimuth of each vector is calculated, and the boundary points of each segmented plane are extracted according to the difference in adjacent azimuths. Experiment results show that the best boundary points can be extracted when the number of adjacent points is 24 and the difference in adjacent azimuths is 120. The proposed method is superior to other methods in the contour extraction of UAV buildings point clouds. Moreover, it can extract not only the building roof contour points, but also the wall contour points, including the window contour points. Full article

In urban point cloud scenarios, due to the diversity of different feature types, it becomes a primary challenge to effectively obtain point clouds of building categories from urban point clouds. Therefore, this paper proposes the Enhanced Local Feature Aggregation Semantic Segmentation Network (ELFA-RandLA-Net) based on RandLA-Net, which enables ELFA-RandLA-Net to perceive local details more efficiently by learning geometric and semantic features of urban feature point clouds to achieve end-to-end building category point cloud acquisition. Then, after extracting a single building using clustering, this paper utilizes the RANSAC algorithm to segment the single building point cloud into planes and automatically identifies the roof point cloud planes according to the point cloud cloth simulation filtering principle. Finally, to solve the problem of building roof reconstruction failure due to the lack of roof vertical plane data, we introduce the roof vertical plane inference method to ensure the accuracy of roof topology reconstruction. The experiments on semantic segmentation and building reconstruction of Dublin data show that the IoU value of semantic segmentation of buildings for the ELFA-RandLA-Net network is improved by 9.11% compared to RandLA-Net. Meanwhile, the proposed building reconstruction method outperforms the classical PolyFit method. Full article

Developments in UAV sensors and platforms in recent decades have stimulated an upsurge in its application for 3D mapping. The relatively low-cost nature of UAVs combined with the use of revolutionary photogrammetric algorithms, such as dense image matching, has made it a strong competitor to aerial lidar mapping. However, in the context of 3D city mapping, further 3D modeling is required to generate 3D city models which is often performed manually using, e.g., photogrammetric stereoplotting. The aim of the paper was to try to implement an algorithmic approach to building point cloud segmentation, from which an automated workflow for the generation of roof planes will also be presented. 3D models of buildings are then created using the roofs’ planes as a base, therefore satisfying the requirements for a Level of Detail (LoD) 2 in the CityGML paradigm. Consequently, the paper attempts to create an automated workflow starting from UAV-derived point clouds to LoD 2-compatible 3D model. Results show that the rule-based segmentation approach presented in this paper works well with the additional advantage of instance segmentation and automatic semantic attribute annotation, while the 3D modeling algorithm performs well for low to medium complexity roofs. The proposed workflow can therefore be implemented for simple roofs with a relatively low number of planar surfaces. Furthermore, the automated approach to the 3D modeling process also helps to maintain the geometric requirements of CityGML such as 3D polygon coplanarity vis-à-vis manual stereoplotting. Full article

The article is an original insight into interdisciplinary challenges of shaping innovative unconventional complex free form buildings roofed with multi-segment shell structures arranged with using novel parametric regular networks. The roof structures are made up of nominally plane thin-walled folded steel sheets transformed elastically and rationally into spatial shapes. A method is presented for creating such symmetric structures based on the regular spatial polyhedral networks created as a result of a composition of many complete reference tetrahedrons by their common flat sides and straight side edges arranged regularly and symmetrically in the three-dimensional Euclidean space. The use of the regularity and symmetry in the process of shaping different forms of (a) single tetrahedral meshes and whole consistent polyhedral structures, (b) individual plane walls and complex elevations, (c) single transformed folds, entire corrugated shell roofs, and their structures allow a creative search for attractive rational parametric solutions using a few author’s parametric algorithms and their implementation as built-in commands of the AutoCAD visual editor or applications of the Rhino/Grasshopper program. Full article

The roof plane segmentation is one of the key issues for constructing accurate three-dimensional building models from airborne light detection and ranging (LiDAR) data. Region growing is one of the most widely used methods to detect roof planes. It first selects one point or region as a seed, and then iteratively expands to neighboring points. However, region growing has two problems. The first problem is that it is hard to select the robust seed points. The other problem is that it is difficult to detect the accurate boundaries between two roof planes. In this paper, to solve these two problems, we propose a novel approach to segment the roof planes from airborne LiDAR point clouds using hierarchical clustering and boundary relabeling. For the first problem, we first extract the initial set of robust planar patches via an octree-based method, and then apply the hierarchical clustering method to iteratively merge the adjacent planar patches belonging to the same plane until the merging cost exceeds a predefined threshold. These merged planar patches are regarded as the robust seed patches for the next region growing. The coarse roof planes are generated by adding the non-planar points into the seed patches in sequence using region growing. However, the boundaries of coarse roof planes may be inaccurate. To solve this problem, namely, the second problem, we refine the boundaries between adjacent coarse planes by relabeling the boundary points. At last, we can effectively extract high-quality roof planes with smooth and accurate boundaries from airborne LiDAR data. We conducted our experiments on two datasets captured from Vaihingen and Wuhan using Leica ALS50 and Trimble Harrier 68i, respectively. The experimental results show that our proposed approach outperforms several representative approaches in both visual quality and quantitative metrics. Full article

In Airborne Light Detection and Ranging (LiDAR) data acquisition practice, discrepancies exist between adjacent strips even though careful system calibrations have been performed. A strip adjustment method using planar features acquired by the Minimum Hausdorff Distance (MHD) is proposed to eliminate these discrepancies. First, semi-suppressed fuzzy C-means and restricted region growing algorithms are used to extract buildings. Second, a binary image is generated from the minimum bounding rectangle that covers overlapping regions. Then, connected components labeling algorithm is applied to process the binary image to extract individual buildings. After that, building matching is performed based on MHD. Third, a coarse-to-fine approach is used to segment building roof planes. Then, plane matching is conducted under the constraints of MHD and normal vectors similarity. The last step is the calculation of the parameters based on Euclidean distance minimization between matched planes. Two different types of datasets, one of which was acquired by a dual-channel LiDAR system Trimble AX80, were selected to verify the proposed method. Experimental results show that the corresponding planar features that meet adjustment requirements can be successfully detected without any manual operations or auxiliary data or transformation of raw data, while the discrepancies between strips can be effectively eliminated. Although adjustment results of the proposed method slightly outperform the comparison alternative, the proposed method also has the advantage of processing the adjustment in a more automatic manner than the comparison method. Full article

RANdom SAmple Consensus (RANSAC) is a widely adopted method for LiDAR point cloud segmentation because of its robustness to noise and outliers. However, RANSAC has a tendency to generate false segments consisting of points from several nearly coplanar surfaces. To address this problem, we formulate the weighted RANSAC approach for the purpose of point cloud segmentation. In our proposed solution, the hard threshold voting function which considers both the point-plane distance and the normal vector consistency is transformed into a soft threshold voting function based on two weight functions. To improve weighted RANSAC’s ability to distinguish planes, we designed the weight functions according to the difference in the error distribution between the proper and improper plane hypotheses, based on which an outlier suppression ratio was also defined. Using the ratio, a thorough comparison was conducted between these different weight functions to determine the best performing function. The selected weight function was then compared to the existing weighted RANSAC methods, the original RANSAC, and a representative region growing (RG) method. Experiments with two airborne LiDAR datasets of varying densities show that the various weighted methods can improve the segmentation quality differently, but the dedicated designed weight functions can significantly improve the segmentation accuracy and the topology correctness. Moreover, its robustness is much better when compared to the RG method. Full article

Automatic extraction of building roofs from remote sensing data is important for many applications, including 3D city modeling. This paper proposes a new method for automatic segmentation of raw LIDAR (light detection and ranging) data. Using the ground height from a DEM (digital elevation model), the raw LIDAR points are separated into two groups. The first group contains the ground points that form a “building mask”. The second group contains non-ground points that are clustered using the building mask. A cluster of points usually represents an individual building or tree. During segmentation, the planar roof segments are extracted from each cluster of points and refined using rules, such as the coplanarity of points and their locality. Planes on trees are removed using information, such as area and point height difference. Experimental results on nine areas of six different data sets show that the proposed method can successfully remove vegetation and, so, offers a high success rate for building detection (about 90% correctness and completeness) and roof plane extraction (about 80% correctness and completeness), when LIDAR point density is as low as four points/m2. Thus, the proposed method can be exploited in various applications. Full article

In recent years there has been an increasing demand among home owners for cost effective sustainable energy production such as solar energy to provide heating and electricity. A lot of research has focused on the assessment of the incoming solar radiation on roof planes acquired by, e.g., Airborne Laser Scanning (ALS). However, solar panels can also be mounted on building facades in order to increase renewable energy supply. Due to limited reflections of points from vertical walls, ALS data is not suitable to perform solar potential assessment of vertical building facades. This paper focuses on a new method for automatic solar radiation modeling of facades acquired by Mobile Laser Scanning (MLS) and uses the full 3D information of the point cloud for both the extraction of vertical walls covered by the survey and solar potential analysis. Furthermore, a new method isintroduced determining the interior and exterior face, respectively, of each detected wall in order to calculate its slope and aspect angles that are of crucial importance for solar potential assessment. Shadowing effects of nearby objects are considered by computing the 3D horizon of each point of a facade segment within the 3D point cloud. Full article
