TC4 titanium alloy and 5083 aluminum alloy with different groove shapes were joined by laser-MIG hybrid welding–brazing using ER4043 filler wire. The effects of groove shape on the weld formation, intermetallic compounds and tensile property of the Ti/Al butt joints were investigated. The welds without obvious defects could be obtained with grooves of I-shape and V-shape on Ti side, while welds quality with grooves of V-shape on Al side and V-shape on both sides were slightly worse. The interfacial intermetallic compounds (IMCs) on the brazing interface were homogeneous in the joints with groove of V-shape on Ti side, and V-shape on both sides, which had similar thickness and were both composed of TiAl₃. Unlike the IMCs mainly composed of TiAl₃ at the I-shape groove interface, TiAl₃, TiAl, and Ti₃Al constituted the IMCs at the V-shape on Al side interface. The average tensile strength of Ti/Al joints with groove of I-shape was the highest at 238 MPa, and was lowest at 140 MPa with groove of V-shape on Al side. The tensile samples mainly fractured at IMCs interface and the fractured surfaces all exhibited mixed brittle–ductile fracture mode. Based on the above research results, I-shape groove was recommended for laser-arc hybrid welding–brazing of 4 mm thick Ti/Al dissimilar butt joints. Full article

Stainless steel core plates (SSCPs) show great potential for modular construction due to their superiority of excellent mechanical properties, light weight, and low cost over traditional concrete and honeycomb structures. During the brazing process of SSCP joints which connect the skin panel and core tubes, it is difficult to keep an even heat flow of inert gas in the vast furnace, which can lead to partially missing solder defects in brazing joints. Pulsed eddy current imaging (PECI) has demonstrated feasibility for detecting missing solder defects, but various factors including lift-off variation and image blurring can deteriorate the quality of C-scan images, resulting in inaccurate evaluation of the actual state of the brazed joints. In this study, a differential pulsed eddy current testing (PECT) probe is designed to reduce the lift-off noise of PECT signals, and a mask-based image segmentation and thinning method is proposed to eliminate the blurring effect of C-scan images. The structure of the designed probe was optimized based on finite element simulation and the positive peak of the PECT signal was selected as the signal feature. Experiments with the aid of a scanning device are then carried out to image the interrogated regions of the SSCP specimen. The peak values of the signals were collected in a matrix to generate images of the scanned brazing joints. Results show that lift-off noise is significantly reduced by using the differential probe. Image blurring caused by the convolution effect of the probe’s point spread function with the imaging object was eliminated using a mask-based image segmentation and thinning method. The restored C-scan images enhance the sharpness of the profiles of the brazing joints and the opening in the images accurately reflect the missing solder of the brazed joints. Full article

This study proposes a method to enhance the airtightness of the joint between the ZrO₂ and Crofer alloy using coating technology. With the aid of vacuum sputtering technology, a titanium–copper alloy layer with a thickness between 1.5 μm and 6 μm was first deposited on the surface of ZrO₂ and Crofer, respectively. The chemical composition of the deposited reaction layer was 70.2 Cu and 29.8 Ti in at%. Then, using silver as the base material in the reactive air brazing (RAB) process, we explore the use of this material design to improve the microstructure and reaction mechanism of the joint surface between ceramics and metal, compare the effects of different pretreatment thicknesses on the microstructure, and evaluate its effectiveness through air tightness tests. The results show that a coating of Cu-Ti alloy on the ZrO₂ substrate can significantly improve bonding between the Ag filler and ZrO₂. The Cu-Ti metallization layer on the ZrO₂ substrate is beneficial to the RAB. After the brazing process, the coated Cu-Ti layers form suitable reaction interfaces between the filler, the metal, the filler, and the ceramic. In terms of coating layer thickness, the optimized 3 μm coated Cu-Ti alloy layer is achieved from the experiment. Melting and dissolving the Cu-Ti coated layer into the ZrO₂ substrate results in a defect-free interface between the Ag-rich braze and the ZrO₂. The air tightness test result shows no leakage under 2 psig at room temperature for 28 h. The pressure condition can still be maintained even under high-temperature conditions of 600 °C for 24 h. Full article

A novel AgCuTi brazing foil with a unique microstructure was developed, which could achieve strong vacuum brazing of Ti6Al4V (TC4) and sapphire. The brazing foil was composed of Ag solid solution (Ag(s,s)), Cu solid solution (Cu(s,s)), and layered Ti-rich phases, and had a low liquidus temperature of 790 °C and a narrow melting range of 16 °C, facilitating the defect-free joining of TC4 and sapphire. The sapphire/TC4 joint fabricated by using this novel AgCuTi brazing foil exhibited an outstanding average shear strength of up to 132.2 MPa, which was the highest value ever reported. The sapphire/TC4 joint had a characteristic structure, featuring a brazing seam reinforced by TiCu particles and a thin Ti₃(Cu,Al)₃O reaction layer of about 1.3 μm. The fracture mechanism of the sapphire/TC4 joint was revealed. The crack originated at the brazing seam with TiCu particles, then propagated through the Ti₃(Cu,Al)₃O reaction layer, detached the reaction layer from the sapphire, and finally penetrated into the sapphire. This study offers valuable insights into the design of active brazing alloys and reliable metal–ceramic bonding. Full article

In heat pumps and refrigeration systems, copper parts play a crucial role. Since heat pumps for space and water heating work under high pressure and are susceptible to vibrations, it is crucial to perfectly weld the copper pipes and heat exchangers to avoid system failures and prevent the leakage of the circulating refrigerants, which are harmful to the environment. The welding of the copper pipes is usually performed by the brazing process in a furnace. The components are subjected to a period of approximately 50 min inside a continuously open oven, varying the temperature from 710 °C to 830 °C. The oven inlets and outlets are protected by nitrogen curtains to guarantee a suitable internal environment and prevent the contamination of the gas inside the oven. This work analyses which welding methods are most suitable for welding copper, the best joint shape, process time, brazing specimens of a copper alloy, tightness tests, and mechanical properties and composition of the welding samples. From the tests carried out, the appearance of small and large defects is reduced by using a 1 mm thick external ring of filler material and a brazing temperature of 820 °C. Full article

We proposed a novel detection method for identifying joint defects in the brazing process between copper tubes and stainless steel using a convolutional neural network (CNN) model. The brazing joints were created using high-frequency induction heating equipment, and infrared thermal imaging cameras were employed to capture the thermal data generated during the jointing process. The experiments involved 15.88 mm diameter copper tubes commonly used in plate heat exchangers, stainless-steel tubes, and filler metal containing 20% Ag. The thermal data were obtained with a resolution of 80 × 80 pixels per frame, resulting in 4796 normal joint data and 5437 defective joint data collected over 100 high-frequency induction-heating brazing experiments. A total of 10,233 thermal imaging data were categorized into 6548 training data, 1638 validation data, and 2047 test data for the development of the predictive model. We designed CNN models with varying hyperparameters, specifically the number of kernel filters and nodes, to evaluate their impact on detection performance. A comparative analysis revealed that a CNN model structure, exhibiting 98.53% accuracy and 99.82% recall on test data, was the most effective. The selected CNN-based defect prediction model demonstrated the potential of using CNN models to discern joint defects in tube configurations that are challenging to identify visually. This study opens avenues for applying CNN-based models for detecting imperfections in complex tube structures. Full article

The International Thermonuclear Experiment Reactor (ITER) Thermal shield (TS) serves as a cryogenic heat exchanger to maintain the thermal stability of the ITER superconducting magnet coil, which is critical to the control of the plasma during the operation of the ITER device. The TS is composed of long-length 316L stainless steel (SS) and copper as brazed joints. In this case, a feasible fabrication design for the CCS TS is presented, accomplished by three kinds of joining processes (vacuum brazing, friction stir weld, and TIG weld). In the reliable fabrication design, the brazing quality of the as-brazed long-distance 316L SS and copper joints plays a critical role in the thermal conductivity performance of the ITER thermal shield. Therefore, a high-quality vacuum brazing process of long-length SS/Cu joints applied in a low-temperature superconductor magnet system was first studied. The macro metallography analysis demonstrates the braze ratio of the samples is 100%, and no crack or defect is observed in the samples. The microstructural characterization reveals the brazing seams are composed of silver-based Ag-rich eutectic. The micro-shear test indicates that the shear strength of the 316L tube and copper joint is 205 MPa, with the fracture position located on the copper side; this zone will be the most vulnerable zone of the joints. In addition, the SEM results illustrated that the shear fracture morphology displayed a ductile fracture feature. The test results demonstrated that the highly precise depth drilling employed in this paper ensured a good control of the brazing clearance, resulting in a 100% braze ratio for the long-length SS/Cu joints. Therefore, it can be concluded that the brazing process can be applied in the ITER TS for the good thermal conductivity performance of long-length SS/Cu-brazing joints. Full article

The separation of oxygen from air by means of inorganic ceramic membranes requires gas-tight ceramic–metal joints that enable reliable permeation operation in the oxygen partial pressure gradient at 850 °C. Reactive air brazing is a promising method to solve this challenge. However, reactive air brazed BSCF membranes suffer from a significant strength degradation that is caused by unhindered diffusion from the metal component during aging. In this study, we investigated how diffusion layers applied on the austenitic steel AISI 314 influence the bending strength of BSCF-Ag3CuO-AISI314 joints after aging. Three different approaches were compared as diffusion barriers: (1) aluminizing via pack cementation, (2) spray coating with NiCoCrAlReY, and (3) spray coating with NiCoCrAlReY and an additional 7YSZ top layer. Coated steel components were brazed to bending bars and aged for 1000 h at 850 °C in air prior to four-point bending and subsequent macroscopic as well microscopic analyses. In particular, coating with NiCoCrAlReY showed low-defect microstructures. The characteristic joint strength was raised from 17 MPa to 35 MPa after 1000 h aging at 850 °C. In addition, the dominant delamination fracture between the steel and the mixed oxide layer, observed in the reference series with uncoated steel, could be replaced by mixed and ceramic fractures of higher strength. The effect of residual joint stresses on the crack formation and path is analyzed and discussed. Chromium poisoning could no longer be detected in the BSCF, and interdiffusion through the braze was effectively reduced. Since the strength degradation of reactive air brazed joints is mainly caused by the metallic joining partner, the findings on the effect of the diffusion barriers in BSCF joints might be transferred to numerous other joining systems. Full article

SiC-particulate-reinforced aluminum matrix composites (SiCp/Al MMCs) are widely used in the aerospace field due to their high specific stiffness and strength, low thermal expansion coefficient, and good radiation resistance. In the process of application and promotion, there is a connection problem between the aluminum matrix composites and electronic glass. In this work, the lead-free SiO₂-B₂O₃-Na₂O glass filler was used to seal 65 vol.% SiCp/ZL102 composites and DM305 electronic glass in an atmospheric environment. The effects of the sealing temperature on the properties of the joints were studied by scanning electron microscopy (SEM) and energy dispersive X-ray spectroscopy (EDS). Additionally, the causes of defects and the fracture mechanisms of the joints were analyzed. The results showed that the glass filler and base material were connected through a dual mechanism of an Al, Na, Si, and O element diffusion reaction and a mechanical occlusion. At a sealing temperature of 540 °C and a holding time of 30 min, the joint interface was dense and crack-free. Meanwhile, the average shear strength reached 13.0 MPa, and the leakage rate of air tightness was 1 × 10⁻⁹ Pa·m³/s. The brittle fracture features were revealed by the step-like morphology of the fracture, which originated from the brazing seam and propagated into the pore. The crack gradually propagated into the base material on both sides as the fracture area expanded, ultimately resulting in a fracture. Full article

In this work, SiC ceramics were successfully brazed at 900 °C using a composite brazing filler, and the effects of holding time and LiAlSiO₄ addition on the interfacial microstructure and mechanical properties of the joints were systematically investigated. The results showed that the brazed joints were devoid of obvious defects, and the joint structure was mainly composed of SiC/Ti₅Si₃/TiC + TiCu₂ + TiO₂ + LAS + LiAlSi₂O₆ + Cu (s, s) + Ag (s, s)/Ti₅Si₃/TiC/SiC. When the brazing temperature was 900 °C for 10 min and the LiAlSiO₄ addition was 1 wt%, the SiC brazed joints reached a maximum shear strength of 106.47 MPa, which was 4.7 times higher than that of the joints without LiAlSiO₄ addition under the same conditions. According to theoretical calculations, the addition of LAS can successfully reduce residual stresses in SiC brazed joints and enhance the joint strength. Full article

In this paper, laser welding Ni to Al using pulsed wave (PW) and continuous wave (CW) lasers was investigated. Weld quality and strength were evaluated in terms of cross-section examination, intermetallic compounds formation, microhardness, shear test and 90-degree peel test. The results show that deep penetration welding Ni to Al causes high melting pool temperature and severe material mixing, which could result in dominant AlNi₃ and AlNi intermetallics (IMCs) in the weld. These IMCs could significantly increase the hardness of the welding zone, but could also lead to the formation of defects, as well as reducing the ability to withstand the shear force and peel force applied to the weld. In comparison, using process optimization to maintain a shallow penetration or form a weld-braze joint, low melting pool temperature and minimum material mixing can be achieved. Hence, low-hardness Al₃Ni IMCs are prevalent in the weld. This helps generate a defect-free dissimilar weld joint to withstand higher shear force and peel force. The findings show promising applications, such as the battery management system of electric vehicles, in which joining a Ni adaptor to an Al bus bar is required. Full article

Si₃N₄ ceramics with a microscale rice leaf structure (MRLS) and titanium alloy were connected via brazing, and the influence of the surface microstructure on the ceramic connection was analyzed. MRLS fabrication is an efficient and high-degree-of-freedom method that can be used to change a material’s surface morphology and wettability. The MRLS was obtained at a laser power of 110 W, with line spacings of 100 and 50 μm. The laser-treated surface included nanoparticles and micro particles, exhibiting a coral-like structure after agglomeration. When the MRLS was used to braze the titanium alloy, no defects were observed at the brazing interface, and the formation was excellent. Throughout the brazed joint, the MRLS remained intact and formed a strong metallurgical bond with the brazing filler metal. A finite element analysis was performed to study the cross-sectional morphology after joint fracture; from the load-time curve, it was found that the MRLS on the surface not only helped improve the mechanical occlusion and brazing area at the interface, but also helped generate compressive stress on the Si₃N₄ side. Crack propagation was hindered, thereby increasing the joint strength. Full article

Stainless steel core panel is a novel structure for fast modular building, but its brazing foils are susceptible to defects due to the difficulty of precisely controlling the brazing process. An automated, nondestructive testing technique is highly desirable for quick inspection of the brazing defects buried in the stainless-steel core panel. In this paper, pulsed eddy current testing (PECT) was employed to inspect local incomplete brazing defects. Finite element simulation and experiment verification were conducted to investigate the feasibility and effectiveness of the proposed method. The peak value of the PECT signal was found to be sensitive to the presence of the defect. With the aid of an industrial robotic arm, line and two-dimensional scans were performed of the PECT probe above the panel specimen. The prefabricated incomplete brazing foil was successfully imaged as a notched ring, whose opening coincides with the physical length of the missing brazing. The proposed method shows potential to serve as an effective tool for in-line or off-line automated nondestructive testing of the brazing defects in stainless steel core panels. Full article

Alumina-based ceramic hip endoprosthesis heads have excellent tribological properties, such as low wear rates. However, stress peaks can occur at the point of contact with the prosthesis stem, increasing the probability of fracture. This risk should be minimized, especially for younger and active patients. Metal elevations at the stem taper after revision surgery without removal of a well-fixed stem are also known to increase the risk of fracture. A solution that also eliminates the need for an adapter sleeve could be a fixed titanium insert in the ceramic ball head, which would be suitable as a damping element to reduce the occurrence of stress peaks. A viable method for producing such a permanent titanium–ceramic joint is brazing. Therefore, a brazing method was developed for coaxial samples, and two modifications were made to the ceramic surface to braze a joint that could withstand high cyclic loading. This cyclic loading was applied in multiple amplitude tests in a self-developed test setup, followed by fractographic studies. Computed tomography and microstructural analyses—such as energy dispersive X-ray spectroscopy—were also used to characterize the process–structure–property relationships. It was found that the cyclic loading capacity can be significantly increased by modification of the surface structure of the ceramic. Full article

Automobile laser brazing remains a complex process whose results are affected by several process variables that may result in nonacceptable welds. A multisensory customized inspection system is proposed, with two distinct non-destructive techniques: the potential drop method and eddy current testing. New probes were designed, simulated, produced, and experimentally validated in automobile’s laser-brazed weld beads with artificially introduced defects. The numerical simulations allowed the development of a new four-point probe configuration in a non-conventional orthogonal shape demonstrating a superior performance in both simulation and experimental validation. The dedicated inspection system allowed the detection of porosities, cracks, and lack of bonding defects, demonstrating the redundancy and complementarity these two techniques provide. Full article
