Based on the characteristics and distribution patterns of collapsed holes in cast-in-place bored pile foundations in the typical coastal area of Guangdong Petrochemical Company, the deformation and collapse behavior of pile walls in the project zone were systematically monitored and measured using a specialized pore diameter detection system for cast-in-place bored pile quality assessment. A collapse rate parameter is proposed and established as an evaluation index for pile wall stability and collapse. Using the basic principles of Quantification Theory I and considering the collapse characteristics of pile walls in a cast-in-place bored pile project in Guangdong, the influencing factors and mechanisms of pile wall collapse are comprehensively analyzed and evaluated. A quantitative theoretical evaluation model for the influencing factors of pile wall collapse is then established. Focusing on the construction technology of cast-in-place bored piles, the proposed quantitative theoretical evaluation model is applied to quantitatively analyze and assess the factors contributing to pile wall collapse in the project area. The relationships between pile wall collapse rate in the Guangdong Petrochemical Company cast-in-place bored pile project and influencing factors such as stratum structure, soil properties, sand layer thickness, drilling depth, and drilling methods are systematically determined. The primary collapse factors and secondary influencing factors in the pile wall collapse of the cast-in-place bored pile engineering zone are identified, providing a theoretical basis for determining optimal prevention and control measures against pile wall collapse during the drilling process of cast-in-place bored piles. Full article

Real-time monitoring of the pile foundation pouring status is the key to ensuring the quality and reliability of cast-in-place bored pile foundation structures. In response to the technical challenge of difficult real-time monitoring and accurate evaluation of pile top morphology during concrete pouring, this paper proposes a method for detecting the cast-in-place bored pile top surface based on full waveform inversion. Firstly, a coupling equation between concrete sound waves and viscoelastic waves inside the borehole is constructed, forming a full waveform inversion method that considers multiple parameters of the complex environment inside the borehole. Subsequently, a pile top flatness factor that simultaneously considers the elevation and undulation characteristics of the pile top is constructed to achieve a comprehensive evaluation of the elevation between the center position and the center peripheral position of the bored pile top. Finally, the feasibility and accuracy of the proposed method are verified through indoor experiments. The results indicate that the detection method proposed in this article can not only accurately reflect the actual elevation of the pile top, ensuring the accuracy of the measurement data, but also achieve a comprehensive evaluation of the quality of the pile top considering the differences in the center and edge positions of the pile top, which can provide a new analysis method for quality control of bored piles. Full article

The screw piles used in permafrost regions represent a new type of pile, and their vertical bearing characteristics play a crucial role in ensuring the normal operation of engineering buildings. This study establishes a numerical calculation model to simulate the interaction between screw piles and soil in permafrost regions and verifies the numerical simulation results through model tests. The bearing mechanism of screw piles in permafrost areas is studied and compared with common, bored, cast-in-place piles widely used. Finally, a method for estimating the bearing capacity of screw piles in permafrost regions is proposed. The research indicates that approximately 90% of the bearing capacity of screw piles in permafrost regions is derived from the mechanical interaction between the concrete pile’s side and the permafrost soil. The shear strength of the permafrost is the primary determinant of the pile foundation’s bearing capacity, while the seasonally active layer has a minimal impact on its bearing capacity, resulting in a stable year-round performance. In permafrost regions, the equivalent friction resistance of screw piles is significantly greater than that of the conventional cast-in-place piles. When the pile reaches its ultimate bearing capacity, the plastic zone on the pile’s side becomes connected, and shear failure occurs in the surrounding soil. The design value of the bearing capacity of a single pile can be effectively estimated in engineering practice by improving the formula of the code for calculating the vertical bearing capacity. Full article

In order to address the issue of hole collapse, which frequently arises when boring piles are being constructed in intricate marine strata, this paper discusses the influence of the slurry ratio on the slurry performance as well as the mechanism of slurry wall protection. It performs this by means of theoretical analysis, laboratory ratio testing, engineering analogies, numerical simulation, and field testing. Our findings demonstrate that adding sodium polyacrylate and sodium carboxymethyl cellulose can enhance mud’s viscosity, contribute to flocculation, and improve the connection between mud and soil layers. Refering similar engineering cases, three optimization schemes are proposed for achieving a mud ratio that offers wall protection in complex marine strata. Furthermore, the particle flow model of slurry viscous fluid is established. The collapse of holes in the sand layer is reflected in the uneven radial displacement of hole walls and the invasion of mud particles. Increasing the viscosity of mud gradually transforms the uneven radial deformation of pore walls in the sand layer into a uniform radial deformation, whereas increasing the proportion of mud significantly decreases the radial displacement of hole walls. Additionally, when the mud pressure in the hole is 300 kPa and 600 kPa, the wall protection effect is better, and there is no particle penetration by substances such as sand. It is found that a high mud pressure can promote the diffusion of mud particles into the sand layer, while low mud pressure cannot balance the pressure on deep soil. The results of the field tests show that the ratio of water–clay–bentonite–CMC-Na–sodium carbonate = 700:110:90:1.5:0.5 used (where the mass percentage of each material is 77.8% water, 12.2% clay, 10% bentonite, 0.16% CMC-Na, and 0.05% sodium carbonate) can effectively prevent hole collapse and reduce the thickness of the sand layer at the bottom of the hole by 50%. Full article

The selection of grouting methods and parameters significantly affects the improvement in the pile-bearing capacity of cast-in-place bored piles. This study proposes a comprehensive set of test methods for constructing model piles, performing grouting at the pile tip and pile side. A series of single-pile grouting and static load tests were conducted using these test methods. The results reveal that pile-side grouting is more effective in controlling pile settlement compared to tip grouting. Furthermore, tip-side-combined grouting exhibits superior reinforcement effects compared to the other two grouting methods. After grouting, a grout bubble is formed at the outlet, consisting of a compact diffusion zone internally and a split diffusion zone externally. Additionally, a vertical diffusion of grout occurs along the pile body, establishing a lateral friction resistance enhancement region. Within this region, the lateral friction resistance of the pile shows a negative correlation with the distance from the grouting outlet. The test results emphasize the significance of grouting volume and its impact on the bearing capacity, settlement control, lateral friction resistance, and grout bubble size in grouted piles, while the influence of variation in grouting pressure in a small range on bearing characteristics is not significantly apparent. Full article

In order to ensure the safety and stability of the existing old masonry structure houses in the process of dewatering and excavation of the super deep foundation pit of the subway, the support form of a water stop curtain combined with bored cast-in-place piles and internal support is adopted, and the rotary jet grouting piles are constructed around the houses, and sleeve valve pipes are embedded, and the soil and house foundation are grouted and strengthened. The deformation of the building foundation is analyzed by the finite element method. The results show that the deformation of adjacent buildings is mainly uniform at the initial stage of foundation pit dewatering and excavation. With the increase of foundation pit dewatering and excavation depth, the deformation of adjacent buildings shows significant differential characteristics, and the maximum displacement of buildings is settlement deformation. The field monitoring data show that the actual deformation trend and value range of the building structure are basically consistent with the finite element calculation results, and no new damage is found in the building structure during the construction process. Effective foundation pit support method and soil layer reinforcement method can effectively reduce the impact of foundation pit on the deformation of adjacent buildings. Full article

An analytical conversion method was developed for the self-balanced test results of monopile bearing capacity in layered soils to realize the better applicability of the self-balanced test theory for the bearing capacity test of foundation piles. To the additional settlement of the lower pile bottom brought on by the negative friction of the upper pile soil during the loading process in layered soils, the interaction effect between the upper piles and lower piles is first taken into account. To accurately convert the results of the self-balanced test pile into the traditional static load test curve form and solve the ultimate bearing capacity, the displacements and internal forces at micro-segment piles in each layer of soil were obtained using the finite difference method. Then, for verification, conventional static test piles and indoor model tests were conducted in a multi-layered ground foundation. The outcome demonstrates that the simplified conversion method’s bearing capacity of the test pile is greater than that of the traditional static pressure test, the analytical conversion method’s Q-s curve is relatively similar to the results of the conventional static load test, and the accuracy of the analytical conversion results is increased by about 9.3 percent. At the same time, the analytical conversion method was applied to the self-balanced test project of bored cast-in-place piles in Wutong Garden, Laibin, Guangxi, China, and the accurate bearing capacity and internal force deformation characteristics were obtained. The accuracy of the calculation result is improved by 12% compared with that of the simple conversion calculation result. Therefore, it can be widely promoted and applied in self-balanced pile bearing capacity test projects. Full article

In order to study the deformation of a bored pile during concrete curing, it is necessary to monitor the strain of the pile. In this paper, Brillouin optical time domain reflectometer (BOTDR) technology is used to monitor the pile strain during concrete curing, and reliable monitoring data are obtained. These data provide a basis for the study of pile deformation and pile–soil interaction during curing of bored cast-in-place piles. Compared with the traditional point strain sensor, the distributed fiber optic sensor is simple in layout and highly accurate; it can fully reflect the strain changes of the pile; the experiment also shows the advantages of distributed fiber optic sensing technology over the traditional point monitoring method. Full article
