Search Results (26)

With the increasingly complex space environment, the operational safety of spacecraft faces severe challenges, creating an urgent need to develop efficient and reliable space target detection and identification technologies. Traditional optical detection equipment faces significant challenges in space target detection and identification due to the low signal-to-noise ratio of space targets. To address the limited field of view (FOV) of traditional spectrometers, this paper proposes an improved wide-FOV infrared slitless spectrometer system based on the Dyson spectrometer. The system consists of three main components: a front telescope system, a spectral dispersion system, and a relay lens system. The front telescope system adopts a Ritchey–Chrétien structure and incorporates a correction lens group to enhance imaging quality. To overcome the practical challenges of conventional Dyson spectrometers—such as the high difficulty and cost in manufacturing and aligning concave gratings—an improved Dyson spectrometer based on a planar blazed grating is designed. A collimating lens group is incorporated to reduce spectral line curvature and chromatic aberration while ensuring a linear spectral dispersion relationship, achieving “spectrum-value unification” in the system. Additionally, a secondary imaging relay lens system is designed to ensure 100% cold stop matching efficiency, thereby minimizing stray light interference. Through optimization and ray tracing using optical design software, the final system achieves a field of view of 0.69° × 0.55°, a spectral resolution of 8.41 nm/pixel, spectral line curvature and chromatic aberration both below 10 µm, and a nearly linear spectral dispersion relationship, realizing spectrum-value unification to facilitate target identification. This infrared slitless spectrometer can stably acquire the spectral characteristics of space targets without requiring high-precision theodolites, providing a novel technical solution for the identification of dynamic space targets. It holds broad application prospects in space surveillance and related fields. Full article

High diffraction efficiency optical transmission gratings with quasi-sinusoidal and saw-tooth surface relief profiles were fabricated in Bi₁₂GeO₂₀, Er: LiNbO₃ and Er: Fe: LiNbO₃ crystals by ion beam implantation. The gratings were directly written by nitrogen ion microbeams at energies of 5 MeV and 10.5 MeV. The finest grating constant was 4 μm. Grating constants for the majority of the gratings were 16 μm. The highest amplitudes of the gratings reached 1600 nm. The highest first-order diffraction efficiency obtained in a sinusoidal grating was 25%, close to the theoretical maximum of 33%. The highest first-order diffraction efficiency of a blazed grating was also 25%, without Littrow optimization. Such gratings can be incorporated into integrated optical biosensors. Full article

In this paper, we demonstrate a blazed phase grating to achieve tunable beam steering and propose a novel algorithm to reduce the stripe noise in wrapped phase. To control the diffraction angle to steer light to the desired direction, an electrically tunable transmission-type beam deflector based on liquid crystals is introduced, and electric fields are applied to the patterned indium tin oxide electrodes to change its phase retardation. Two different 2π phase-wrapping methods are applied to obtain various diffraction angles within the minimum cell-gap, and the method of equal interval of phase achieves a worthwhile diffraction efficiency compared to the methods based on equal interval of diffraction angle. The proposed method is able to completely eliminate the stripe noise in all steering angles that helps to improve the diffraction efficiency. Full article

Blazed gratings are periodic surface structures of great interest for applications such as friction control, light trapping, and spectrometry. While different laser processing methods have been explored to produce these elements, they have not yet surpassed conventional surface manufacturing techniques, often based on lithography processes or mechanical ruling. This work introduces a new approach based on the combination of ultrashort pulses and triangular beam shaping, which enables the generation of asymmetrical grooves in a single step. The main advantage of this strategy is that by simply changing the laser processing direction we can induce a significant modification in the ratio of asymmetry between the sidewall angles of the machined channels. The paper includes a comprehensive study, which has been supported by statistical tools, of the effect of this and other experimental parameters on the morphology of grooves machined on stainless steel. As a result, we achieved a wide range of geometries, with asymmetry ratios spanning from 1 to 5 and channel depths between 3 and 15 µm. Furthermore, we demonstrate the validity of the approach through the successful manufacture of blazed gratings of various slopes. The results reflect the versatility and cost-efficiency of the proposed fabrication strategy, and thus its potential to streamline the production of sawtooth gratings and other devices that are based on asymmetrical features. Full article

High-quality convex colloidal photonic crystals can be grown on the tip of an optical fiber by self-assembly using the hanging drop method. They are convex-shaped, produce the diffraction of reflecting light with high efficiency (blazing colors), and have a high curvature. The convex colloidal crystals are easily detachable and, as free-standing objects, they are mechanically robust, allowing their manipulation and use as convex reflective diffraction devices in imaging spectrometers. Currently, the same characteristics are obtained by using gratings-based structures. The optical fiber/colloidal crystal interface is disordered; thus, no light diffraction can be registered. The ordering at this interface was highly increased by forming a polystyrene spacer on the optical fiber tip, which served as a self-assembly substrate for silica colloid, as a mechanical bond between the fiber and the crystal, and as a filler reservoir for an inverse-opal synthesis. The silica opal-like grown on the optical fiber tip can be transformed into a high-quality polystyrene (blazing colors) inverse-opal by using the polystyrene spacer as a filler. We found that the colloidal crystal axisymmetric self-assembles onto the optical fiber tip only if a maximum volume of the colloid drop is settled on a flat end of the polystyrene spacer. Full article

Diffractive optical elements (DOEs) fundamentally provide the possibility to simultaneously utilize multiple orders for different imaging functions within a system. However, to take advantage of this property, it is necessary to tailor the assignment of specific wavelengths or wavelength ranges with high diffraction efficiency to specific diffraction orders. To achieve this wavelength-selective assignment to different orders, simple diffractive profile shapes are not suitable; instead, multilayer DOEs are required. In this study, we conducted theoretical, scalar investigations on the diffraction efficiency of triple-layer double-relief DOEs for the purpose of tailored wavelength selectivity. Specific materials such as nanocomposites, layer materials, and high-refractive-index liquids with strong dispersion were included, in addition to inorganic glasses, to enable wide design freedom for wavelength selectivity across multiple orders. To simultaneously account for both positive and negative orders, specific material combinations featuring intersecting or touching dispersion curves were utilized. For various material combinations, we calculated significantly different efficiency profiles for multiple orders by varying the relief depths. Further, we discuss the possibility of fine-tuning the efficiency profiles by using high-index liquids as an intermediate layer between two solid profiles, whose dispersion properties can be varied continuously or at least in small steps. Full article

Smith–Purcell radiation (SPR) can be generated nondestructively, providing valuable applications in light sources and beam monitors. Coherent SPR is expected to enable single-shot measurements of very short bunch lengths on the fs scale. Since the reconstruction of the longitudinal bunch shape from the coherent SPR is based on the reliable SPR spectrum, a more detailed understanding of the properties of the radiation is important in this context. Employing a 100 fs ultrashort electron bunch at the t-ACTS test accelerator, the spectrum, angular distribution, and polarization of the produced coherent SPR were measured in the terahertz frequency region and compared with a model calculation. In addition to the widely known surface current model evaluation, the effect of the geometrical shading effect on induced currents on metal surfaces was evaluated using 3D numerical calculations. The obtained SPR characteristics are also presented. In the evaluation of the grating with a shallow blaze angle, it was found that the shading effect has a non-negligible effect on the generated SPR intensity; the measured angular distribution and polarization results were in good agreement with this result. Full article

The secondary-phase grating-based tomographic microscopy system, which is widely used in the biological and life sciences, can observe all the sample multilayer image information simultaneously because it has multifocal points. However, chromatic aberration exists in the grating diffraction, which seriously affects the observation of the image. To correct the chromatic aberration of the tomographic microscope system, this paper proposes a system that adopts blazed gratings and angle-variable reflectors as chromatic aberration correction devices according to the principle of dispersion compensation and Fourier phase-shift theory. A reflector-separated light dispersion-compensated 3D microscopy system is presented to achieve chromatic aberration correction while solving the problem of multilayer image overlap. The theoretical verification and optical design of the system were completed using ZEMAX software. The results show that the proposed system reduced the chromatic aberration of ordinary tomographic microscopy systems by more than 90%, retaining more wavelengths of light information. In addition, the system had a relatively wide range in the color difference compensation element installation position, reducing the difficulty of dispersion compensation element installation. Overall, the results indicate that the proposed system is effective in reducing chromatic aberration in grating diffraction. Full article

To make the mid-infrared (MIR) dispersive spectrograph a practical tool in industrial food processing lines, we designed a dispersive spectrograph system with an uncooled microbolometer focal plane array (FPA) detector for MIR spectral acquisition. To precisely regulate the angle of a rotatable grating to acquire the MIR spectrum, the spectral resolution and spatial resolution of the system were rigorously controlled to improve system performance. In the reflectance operation mode of the MIR dispersive spectrograph, the uncooled microbolometer FPA detector offered a maximum spectral resolution of 12 nm for the MIR, when a 300 grooves/mm blazed grating was used. Utilizing an optical parametric oscillator (OPO) pulse laser source, the wavelengths of the first-order diffraction were validated, and the system’s spectral resolution limit was determined. As a line-scanning source, a Globar broadband source was installed, and the USAF 1951 Resolution Calculator was used to establish the spatial resolution of the imaging spectrograph. Using NI LabView, the logical operational technique for controlling the MIR dispersive spectrograph was encoded into system firmware. The GUI and test results are thoroughly described. Full article

The optical system of an imaging spectrometer working on a geostationary earth orbit (GEO) covering a full optical spectrum of 0.3–12.5 μm is analyzed and designed. It enables a ground coverage of 400 × 400 km by internal scanning and achieves a high spatial resolution of 25 m. The full spectrum is divided into five sub-bands, and each band adopts four spectrometers to splice in the field of view to achieve the ultra-long slit required by the wide swath. The total length of the slit is up to 241.3 mm. This paper focuses on compact spectrometers with long slits that can meet the splicing requirements and points out that low spectral distortions, low stray light, high signal-to-noise ratio, and uniform spectral response are necessary for high-fidelity performance. The Offner and Wynne–Offner high-fidelity spectrometers based on convex blazed gratings are designed, and prototypes of each band are developed as well. The properties of long slits and convex blazed gratings are presented. The maximum length of a single slit is 61.44 mm. The groove density of gratings for five bands ranges from 8.8 lp/mm to 312.1 lp/mm, and the peak efficiency is up to 86.4%. The alignment and test of the spectrometers are introduced. Results show that the developed spectrometers have high fidelity and fulfill all requirements. Full article

Echelle grating provides high spectral resolving power and diffraction efficiency in a broadband wavelength range by the Littrow mode. The spectrometer with the cross-dispersed echelle scheme has seen remarkable growth in recent decades. Rather than the conventional approach with common blazed grating, the cross-dispersed echelle scheme achieves the two-dimensional spatial distribution of the spectrum by one exposure without scanning in the broadband spectral range. It is the fastest and most sensitive spectroscopic technology as of now, and it has been extensively applied in commercial and astronomical spectrometers. In this review, we first highlight the characteristics of the echelle and then present the optical layout, detection approach, and method of calibration. Finally, we discuss the state-of-the-art implementations and applications of commercial and astronomical instruments. Full article

Convex blazed gratings, which can effectively broaden the spectral range and improve spectral resolution, have gradually evolved into a crucial optical component for lightweight and compact imaging spectroscopy instruments. Their design, processing, and testing involve multidisciplinary interdisciplinary scientific issues, and they continue to be a major area of research in imaging optics applications. This paper summarizes the effects of various grating groove shapes and structural parameters on the spectral range and diffraction efficiency of convex blazed gratings, after providing a brief introduction to the typical functions and applications of convex blazed gratings. Firstly, the latest progress in typical processing methods for convex blazed gratings is reviewed. It focuses on the current fabrication processes and reviews their capabilities in creating convex blazed gratings from three main types of technologies, namely ultra-precision machining, high-energy density beam processing, and chemically assisted fabrication processes. Secondly, the adaptability of the manufacturing process for convex blazed gratings on different scales is summarized, analyzing the adaptation of current procedures to various grating fabrication scales and their bottlenecks. Finally, the characterization methods and future feasible characterization methods for convex blazed gratings are reviewed. The development trend of efficient and precise preparation of convex blazed gratings is pointed out. Full article

In this work, based on the diffraction principle of reflective blazed grating, the structure size of the convex spherical blazed grating unit is determined, the machining accuracy of the convex spherical blazed grating is formulated, the effects of tool nose radius and Poisson burr on the diffraction efficiency of the convex spherical blazed grating are analyzed, and the performances of cutting convex gratings with microcrystalline aluminum RSA6061 and RSA6061+ chemically plated NiP for two workpiece materials are compared. A convex spherical blazed grating with a radius of curvature R = 41.104 mm, substrate diameter 14 mm, grating density 53.97 line/mm, and blaze angle of roughly 3.8° is turned by a four-axis ultra-precision machining system by adjustment of the cutting tool, workpiece material, and cutting parameters, as well as modification of the layouts of the blazed grating on the convex sphere. The results of the testing of convex spherical blazed grating elements in both layouts show that the size error of the grating period is close for both layouts, the size error of grating height is smaller in the equal-along-arc layout, the blaze angle error in the equal-along-projection layout is only 0.74%, and the average roughness of the blazed surface is less than 5 nm to meet the processing quality requirements of the reflective convex spherical blazed grating. The greater the blaze angle accuracy of the blazed grating, the higher its diffraction efficiency, so the grating element with an equal-along-projection layout has a higher diffraction efficiency than the grating element with an equal-along-arc layout. RSA6061+ chemically plated NiP material is superior to RSA6061 material in Poisson burr height and blazed surface roughness, which is more suitable for Offner-type imaging spectrometers in the spectral range 0.95–2.5 μm (SWIR). Full article

Blazed gratings are the critical dispersion elements in spectral analysis instruments, whose performance depends on structural parameters and topography of the grating groove. In this paper, high diffraction efficiency silicon-blazed grating working at 800–2500 nm has been designed and fabricated. By diffraction theory analysis and simulation optimization based on the accurate boundary integral equation method, the blaze angle and grating constant are determined to be 8.8° and 4 μm, respectively. The diffraction efficiency is greater than 33.23% in the spectral range of 800–2500 nm and reach the maximum value of 85.62% at the blaze wavelength of 1180 nm. The effect of platform and fillet on diffraction efficiency is analyzed, and the formation rule and elimination method of the platform are studied. The blazed gratings are fabricated by anisotropic wet etching process using tilted (111) silicon substrate. The platform is minished by controlling etching time and oxidation sharpening process. The fillet radius of the fabricated grating is 50 nm, the blaze angle is 7.4°, and the surface roughness is 0.477 nm. Finally, the blazed grating is integrated in scanning micromirror to form scanning grating micromirror by MEMS fabrication technology, which can realize both optical splitting and scanning. The testing results show that the scanning grating micromirror has high diffraction efficiency in the spectral range of 810–2500 nm for the potential near-infrared spectrometer application. Full article

We propose to achieve multichannel information transmission in free space by means of variously polarized beams. The interaction of vortex beams of various orders with the main polarization states is theoretically analyzed. The passage of beams with different polarization states through multi-order diffractive optical elements (DOEs) is simulated numerically. Using the simulation results, tables of code correspondence of diffraction order numbers to the presence of phase vortices in the analyzed beams are constructed, which allow one to determine diffraction orders that carry information about various polarization states. The performed experiment made it possible to study the recognition of the first order cylindrical polarization state formed by a Q-plate converter using a phase DOE. In the experiment, these elements were built into a commercial fiber-optic communication system operating at the near-IR frequencies. After detecting the beam polarization state, beams of the required diffraction orders are efficiently coupled into optical fiber using an additional phase element. The developed optical detection system also provides channel suppression of homogeneously polarized components, which are supposed to be used for transmission of other channels. Full article
