This paper presents a model of the bending behavior of a bi-layer cantilever composed of titanium nickelide and a magnetoactive elastomer embedded with magnetically hard particles. The cantilever is initially subjected to an external magnetic field in its high-temperature state, followed by cooling to a low-temperature state before the magnetic field is removed. This sequence results in residual bending deformation. Basic relations describing the material behavior of titanium nickelide and the magnetoactive elastomer are presented. A variational formulation for the problem under consideration is written down. The problem is solved numerically using the finite element method. The influence of the applied magnetic field magnitude and the thickness of the titanium nickelide layer on the cantilever deflection magnitude is studied. The dependence of the residual cantilever deflection on the applied magnetic field is obtained. The possibility of this structure as a controllable gripping element for applications in robotics and micro-manipulation is demonstrated. Full article

This work presents a dynamic modeling approach for analyzing the behavior of a bi-material cantilever actuator structure, consisting of a strip of filter paper bonded to a strip of tape. The actuator’s response is induced by a mismatch strain generated upon wetting, leading to the bending of the cantilever. The study delves into a comprehensive exploration of the dynamic deflection characteristics of the bilayer structure. It untangles the intricate connections among the saturation, modulus, hygro-expansion strain, and deflection, while uniquely addressing the challenges stemming from fluid–structure coupling. To solve the coupled fluid–solid differential equations, a combined numerical method is employed. This involves the application of the Highly Simplified Marker and Cell (HSMAC) technique for fluid flow analysis and the Finite Difference Method (FDM) for response deflection computation. In terms of the capillary flow model, the Computational Fluid Dynamics (CFD) simulations closely align with the classical Washburn relationship, depicting the wetted front’s evolution over time. Furthermore, the numerical findings demonstrate that heightened saturation levels trigger an increase in hygro-expansion strain, consequently leading to a rapid rise in response deflection until a static equilibrium is achieved. This phenomenon underscores the pivotal interplay among saturation, hygro-expansion strain, and deflection within the system. Additionally, the actuator’s response sensitivity to material characteristics is highlighted. As the mismatch strain evolving from paper hygro-expansion diminishes, a corresponding reduction in the axial strain causes a decrease in response deflection. The dynamic parameter demonstrates that the deflection response of the bilayer actuator diminishes as dynamic pressure decreases, reaching a minimal level beyond which further changes are negligible. This intricate correlation underscores the device’s responsiveness to specific material traits, offering prospects for precise behavior tuning. The dependence of paper modulus on saturation levels is revealed to significantly influence bilayer actuator deflection. With higher saturation content, the modulus decreases, resulting in amplified deflection. Finally, strong concordance is observed among the present fluidically coupled model, the static model, and empirical data—a testament to the accuracy of the numerical formulation and results presented in this study. Full article

In this paper, the behavior of the Bi-Material Cantilever (B-MaC) response deflection upon fluidic loading was experimentally studied and modeled for bilayer strips. A B-MaC consists of a strip of paper adhered to a strip of tape. When fluid is introduced, the paper expands while the tape does not, which causes the structure to bend due to strain mismatch, similar to the thermal loading of bi-metal thermostats. The main novelty of the paper-based bilayer cantilevers is the mechanical properties of two different types of material layers, a top layer of sensing paper and a bottom layer of actuating tape, to create a structure that can respond to moisture changes. When the sensing layer absorbs moisture, it causes the bilayer cantilever to bend or curl due to the differential swelling between the two layers. The portion of the paper strip that gets wet forms an arc, and as the fluid advances and fully wets the B-MaC, the entire B-MaC assumes the shape of the initial arc. This study showed that paper with higher hygroscopic expansion forms an arc with a smaller radius of curvature, whereas thicker tape with a higher Young’s modulus forms an arc with a larger radius of curvature. The results showed that the theoretical modeling could accurately predict the behavior of the bilayer strips. The significance of paper-based bilayer cantilevers lies in their potential applications in various fields, such as biomedicine, and environmental monitoring. In summary, the novelty and significance of paper-based bilayer cantilevers lie in their unique combination of sensing and actuating capabilities using a low-cost and environmentally friendly material. Full article

This paper presents a simple method for the in situ determination of Young’s moduli of surface-micromachined bilayer thin films. The test structure consists of a cantilever, a bottom drive electrode located near the anchor, and a bottom contact electrode placed below the free end of the cantilever. The cantilever is driven by applying a voltage sweep between the cantilever and the drive electrode, and bends due to the electrostatic force. A novel theoretical model is derived to relate Young’s modulus with the applied voltage and structure dimensions. The theoretical model is validated by finite element simulation. Test structures for Au/polysilicon thin films are fabricated by the PolyMUMPsand tested with the current–voltage measurement system. The measured Young modulus of polysilicon ranges from 152.344 GPa to 154.752 GPa, and the measured Young modulus of Au ranges from 71.794 GPa to 74.880 GPa. Compared with existing extraction methods, the proposed method is featured with simple operation, good repeatability, relatively high precision, and low requirements for equipment. It can be used alongside the application of a process control monitor (PCM) in surface-micromachining process lines. Full article

The cyclic stress evolution induced by repeated volume variation causes mechanical degradation and damage to electrodes, resulting in reduced performance and lifetime of LIBs. To probe the electro-chemo-mechanical coupled degradation, we conducted in situ measurements of Young’s modulus and stress evolution of commercial used graphite electrodes during multiple cycles. A bilayer graphite electrode cantilever is cycled galvanostatically in a custom cell, while the bending deformation of the bilayer electrode is captured by a CCD optical system. Combined with a mechanical model, Li-concentration-dependent elastic modulus and stress are derived from the curvature of the cantilever electrode. The results show that modulus, stress and strain all increase with the lithium concentration, and the stress transforms from compression to tension in the thickness direction. During multiple cycles, the modulus decreases with an increase in the cycle number at the same concentration. The maximum stress/strain of each cycle is maintained at almost same level, exhibiting a threshold that results from the co-interaction of concentration and damage. These findings provide basic information for modeling the degradation of LIBs. Full article

Precise prediction of mechanical behavior of thin films at the nanoscale requires techniques that consider size effects and fabrication-related issues. Here, we propose a test methodology to estimate the Young’s modulus of nanometer-thick films using micromachined bilayer cantilevers. The bilayer cantilevers which comprise a well-known reference layer and a tested film deflect due to the relief of the residual stresses generated during the fabrication process. The mechanical relationship between the measured residual stresses and the corresponding deflections was used to characterize the tested film. Residual stresses and deflections were related using analytical and finite element models that consider intrinsic stress gradients and the use of adherence layers. The proposed methodology was applied to low pressure chemical vapor deposited silicon nitride tested films with thicknesses ranging from 46 nm to 288 nm. The estimated Young’s modulus values varying between 213.9 GPa and 288.3 GPa were consistent with nanoindentation and alternative residual stress-driven techniques. In addition, the dependence of the results on the thickness and the intrinsic stress gradient of the materials was confirmed. The proposed methodology is simple and can be used to characterize diverse materials deposited under different fabrication conditions. Full article

We used a spray-coating process to cover silicon microcantilevers with ca. 33 wt% [Fe(Htrz)₂(trz)](BF₄)@P(VDF₇₀-TrFE₃₀) nanocomposite thin films of 1500 nm thickness. The bilayer cantilevers were then used to investigate the thermomechanical properties of the composites through a combined static and dynamic flexural analysis. The out-of-plane flexural resonance frequencies were used to assess the Young’s modulus of the spray-coated films (3.2 GPa). Then, the quasi-static flexural bending data allowed us to extract the actuation strain (1.3%) and an actuation stress (7.7 MPa) associated with the spin transition in the composite. Full article

High-sensitivity and simple, low-cost readout are desirable features for sensors independent of the application area. Micro-cantilever sensors use the deflection induced by the analyte presence to achieve high-sensitivity but possess complex electronic readouts. Current holographic sensors probe the analyte presence by measuring changes in their optical properties, have a simpler low-cost readout, but their sensitivity can be further improved. Here, the two working principles were combined to obtain a new hybrid sensor with enhanced sensitivity. The diffractive element, a holographically patterned thin photopolymer layer, was placed on a polymer (polydimethylsiloxane) layer forming a bi-layer macro-cantilever. The different responses of the layers to analyte presence lead to cantilever deflection. The sensitivity and detection limits were evaluated by measuring the variation in cantilever deflection and diffraction efficiency with relative humidity. It was observed that the sensitivity is tunable by controlling the spatial frequency of the photopolymer gratings and the cantilever thickness. The sensor deflection was also visible to the naked eye, making it a simple, user-friendly device. The hybrid sensor diffraction efficiency response to the target analyte had an increased sensitivity (10-fold when compared with the cantilever or holographic modes operating independently), requiring a minimum upturn in the readout complexity. Full article

T-cell antigen recognition is accompanied by extensive morphological rearrangements of the contact zone between the T-cell and the antigen-presenting cell (APC). This process involves binding of the T-cell receptor (TCR) complex to antigenic peptides presented via MHC on the APC surface, the interaction of costimulatory and adhesion proteins, remodeling of the actin cytoskeleton, and the initiation of downstream signaling processes such as the release of intracellular calcium. However, multiparametric time-resolved analysis of these processes is hampered by the difficulty in recording the different readout modalities at high quality in parallel. In this study, we present a platform for simultaneous quantification of TCR distribution via total internal reflection fluorescence microscopy, of intracellular calcium levels, and of T-cell-exerted forces via atomic force microscopy (AFM). In our method, AFM cantilevers were used to bring single T-cells into contact with the activating surface. We designed the platform specifically to enable the study of T-cell triggering via functionalized fluid-supported lipid bilayers, which represent a widely accepted model system to stimulate T-cells in an antigen-specific manner. In this paper, we showcase the possibilities of this platform using primary transgenic T-cells triggered specifically via their cognate antigen presented by MHCII. Full article

Various multilayered thin films are extensively used as the basic component of some micro-electro-mechanical systems, requiring an efficient measurement method for material parameters, such as Young’s modulus, residual stress, etc. This paper developed a novel measurement method to extract the Young’s moduli and residual stresses for individual layers in multilayered thin films, based on the first resonance frequency measurements of both cantilever beams and doubly-clamped beams. The fabrication process of the test structure, the corresponding modeling and the material parameter extraction process are introduced. To verify this method, the test structures with gold/polysilicon bilayer beams are fabricated and tested. The obtained Young’s moduli of polysilicon films are from 151.38 GPa to 154.93 GPa, and the obtained Young’s moduli of gold films are from 70.72 GPa to 75.34 GPa. The obtained residual stresses of polysilicon films are from −14.86 MPa to −13.11 MPa (compressive stress), and the obtained residual stresses of gold films are from 16.27 to 23.95 MPa (tensile stress). The extracted parameters are within the reasonable ranges, compared with the available results or the results obtained by other test methods. Full article

The dynamic properties of inkjet-printed Ag thin films on flexible substrates were measured using flexural wave propagation. The Ag nanoparticle suspension was inkjet-printed on polyimide (PI), silicon wafer, and glass. The effects of flexible substrates on the dynamic properties of the films were investigated. Beam-shaped Ag-printed substrates were fabricated by pico-second laser pulse cutting. The wave approach was presented to analyze the vibrations of the thin film on the substrates. The Young’s modulus and loss factor of the Ag thin films with the substrates were represented by the combined bending stiffness of the bilayer beam. The vibration response of the base-excited cantilever was measured using an accelerometer and laser Doppler vibrometer (LDV). Vibration transfers were analyzed to obtain dynamic characteristics of the Ag-printed bilayer beam. The substrate affects the reduction of the Ag thin film thickness during the sintering process and surface roughness of the film. The proposed method based on the wave approach allows measurement of the dynamic properties regardless of the ratio of the modulus between the thin film and substrate. Full article

We derived an analytical expression for a resonant-mode based bi-layered cantilever with distributed mass load. The behavior of mode of vibration, nodal position, frequency shift, as well as sensitivity under different mass load distributions was theoretically studied. The theoretical results suggested that asymmetric mass load distribution leads to the shift of nodes as well as the sensitive regions of a resonant-mode based cantilever. n − 1 local maximal sensitivities and n − 1 local minimal sensitivities are observed when the cantilever vibrates in the nth-order resonance. The maximal sensitivity is found at the first local maximal sensitivity and the behavior of mass load length as a function of the maximal sensitivity follows the rule of an exponent decaying function. The sensitivity increases as the load mass increases for the same mass load distribution, but the corresponding slopes are different. Full article
