Infrared imaging has gained considerable attention across diverse fields, including security, surveillance, and environmental monitoring. The need to minimize size, weight, power, and cost (SWaP-C) poses challenges for conventional optical systems like refractive lenses. Metalenses with subwavelength surface patterns have emerged as promising solutions to address these limitations. This review provides a comprehensive analysis of all-dielectric metalenses for long-wavelength infrared (LWIR) imaging applications, a critical spectral region for human detection and analytical applications (such as gas analysis). We examine the limitations of conventional infrared (IR) lens materials and highlight the performance advantages of LWIR metalenses. Key design principles, including chromatic and achromatic lens configurations, are discussed alongside their imaging performance. Additionally, we review advanced functionalities such as polarization control, multifocal capabilities, zoom, and reconfigurability. Theoretical performance limits and trade-offs are analyzed to provide insights into design optimization. We identify future challenges related to advanced design methods and fabrication techniques. LWIR metalenses can be expected to overcome the shortcomings of conventional LWIR lenses owing to meta-optics technologies, to achieve SWaP-C and advanced functionalities that cannot be achieved by conventional LWIR lenses. This review will guide researchers in academia and industry to develop LWIR metalenses to advance IR imaging technologies. Full article

Metalenses, as ultrathin planar optical devices based on metasurfaces, have attracted significant research interest in recent years due to their compact structure and versatile light manipulation, showing great potential to replace traditional lenses in specific applications. This review focuses on the fundamental principles of geometric and propagation phases of metalenses, introducing their applications in achromatic aberration correction, and emphasizing their advantages and limitations. We further discuss the application of multilayer metalenses in zoom optical systems and summarize methods such as topology optimization and inverse design to enhance the efficiency of metalenses. Special attention is given to comparing broadband and discrete achromatic correction, highlighting their respective working principles, design challenges, and practical implications. Additionally, recent advances in using deep learning for image-side aberration correction are briefly discussed. Finally, we highlight various practical applications of metalenses and discuss future research directions. Full article

Conventional metalenses struggle with chromatic aberration and narrow field of view (FOV), making it challenging to meet the dispersion requirements for large apertures and compensate off-axis aberrations for wide FOV. Here, we demonstrate a hybrid metalens module consisting of five refractive plastic lenses and a polarization-insensitive metalens to achieve broadband achromatic imaging within 400–700 nm and a wide FOV up to 100°. The system exhibits negligible variation in focal length (~1.2%) across the visible range (460–656 nm) and consistently achieves modulation transfer function (MTF) values > 0.2 at 167 lp/mm across all wavelengths and incident angles. We also demonstrate integrated lens modules that capture high-quality images from distances ranging between 0.5 and 4 m without post-processing, showcasing its potential for compact, wide-angle optical systems. Full article

The increasing resolution requirements of imaging optical systems must be satisfied by expanding the aperture of the optical system according to Rayleigh’s criterion, and larger apertures of conventional refractive/reflective optics place a greater demand on manufacturing and transportation. Diffractive optics are applied to imaging optics to achieve lightweight design, but the image quality suffers due to their strong negative properties. Therefore, a wide-band imaging system based on the Schupmann achromatic model is proposed in this paper to solve the above problem, and the achromatic performance of the system is guaranteed by the Schupmann achromatic model. The aperture of the relay lens is reduced, since using harmonic diffractive optics as the primary lens results in a much more compact focus compared to the diffractive optics in the same wavelength band. This allows for the lightweight design of the optical system. An 80 mm aperture diffractive optical system covering the 400–900 nm band was designed and fabricated to verify the above theory. The actual resolution of the optical system was 76.196 lp/mm, and the achromatic task was accomplished. The design and experimentation of the wide-band achromatic imaging optical system confirms that the proposed theory is correct, and lays the foundation for the further application of large aperture diffractive telescopes. Full article

The Sweatt model has been extensively used to design optical systems containing diffractive optical elements (DOEs) because it captures the dispersive characteristics of DOEs. We introduce a new dispersive Sweatt model (DSM) that can describe meta-atom (MA) dispersion, which has material and geometric contributions in addition to diffraction. It uses a wavelength-dependent scalar coefficient to modify the diffractive dispersion and describe the dispersion of a given MA basis. This provides a robust framework to design systems containing metasurface (MS) elements while including their unique dispersive properties in the design optimization. Importantly, the DSM is based on ray optics and enables the design of MS-containing systems using conventional optical design software such as Zemax and Code V. We use the DSM to demonstrate the design of a hybrid refractive/MS achromatic doublet for the midwave infrared (MWIR) band. The design example includes multiple wavelengths and field angles during optimization and demonstrates excellent agreement between the DSM and real hybrid lens performance modeled using wave optics. We discuss the limits of the DSM and present a simple model to predict performance limits due to phase mismatch at Fresnel zone boundaries. Full article

Temporal vision is a vital aspect of human perception, encompassing the ability to detect changes in light and motion over time. Optical scattering, or straylight, influences temporal visual acuity and the critical flicker fusion (CFF) threshold, with potential implications for cognitive visual processing. This study investigates how scattering affects CFF using an Arduino-based psychophysical device and electroencephalogram (EEG) recordings to analyze brain activity during CFF tasks under scattering-induced effects. A cohort of 30 participants was tested under conditions of induced scattering to determine its effect on temporal vision. Findings indicate a significant enhancement in temporal resolution under scattering conditions, suggesting that scattering may modulate the temporal aspects of visual perception, potentially by altering neural activity at the temporal and frontal brain lobes. A compensation mechanism is proposed to explain neural adaptations to scattering based on reduced electrical activity in the visual cortex and increased wave oscillations in the temporal lobe. Finally, the combination of the Arduino-based flicker visual stimulator and EEG revealed the excitatory/inhibitory stimulation capabilities of the high-frequency beta oscillation based on the alternation of an achromatic and a chromatic stimulus displayed in the CFF. Full article

The refractive index of the lenses used in optical designs varies with wavelength, causing light rays to fail when focusing on a single plane. This phenomenon is known as chromatic aberration (CA), chromatic distortion, or color fringing, among other terms. Images affected by CA display colored halos and experience a loss of resolution. Fully achromatic systems can be achieved through complex and costly lens designs and/or computationally when digital sensors capture the image. In this work, we propose using the wavefront coding (WFC) technique with a trefoil-shaped phase modulation plate in the optical system to effectively increase the resolution of images affected by longitudinal chromatic aberration (LCA), significantly simplifying the optical design and reducing costs. Experimental results with three LEDs simulating RGB images verify that WFC with trefoil phase plates effectively corrects longitudinal chromatic aberration. Transverse chromatic aberration (TCA) is corrected computationally. Furthermore, we demonstrate that the optical system maintains depth of focus (DoF) for color images. Full article

In recent years, there has been intense development of digital diagnostic tests for vision. All of these tests must be validated for clinical use. The current study enrolled 51 healthy individuals (age 19–72 years) in which achromatic contrast sensitivity function (CSF) in near vision was measured with the printed Vistech VCTS test (Stereo Optical Co., Inc., Chicago, IL, USA) and the Optopad-CSF (developed by our research group to be used on an iPad). Likewise, chromatic CSF was evaluated with a digital test. Statistically significant differences between tests were only found for the two higher spatial frequencies evaluated (p = 0.012 and <0.001, respectively). The mean achromatic index of contrast sensitivity (ICS) was 0.02 ± 1.07 and −0.76 ± 1.63 for the Vistech VCTS and Optopad tests, respectively (p < 0.001). The ranges of agreement between tests were 0.55, 0.76, 0.78, and 0.69 log units for the spatial frequencies of 1.5, 3, 6, and 12 cpd, respectively. The mean chromatic ICS values were −20.56 ± 0.96 and −0.16 ± 0.99 for the CSF-T and CSF-D plates, respectively (p < 0.001). Furthermore, better achromatic, red–green, and blue–yellow CSF values were found in the youngest groups. The digital test allows the fast measurement of near-achromatic and chromatic CSF using a colorimetrically calibrated iPad, but the achromatic measures cannot be used interchangeably with those obtained with a conventional printed test. Full article

The numerical aperture of the spectrometer is crucial for weak signal detection. The transmission lens-based configuration has more optimization variations, and the grating can work approximately in the Littrow condition; thus, it is easier to acquire high numerical aperture (NA). However, designing a large aperture focusing lens remains challenging, and thus, ultra-high NA spectrometers are still difficult to acquire. In this paper, we propose a method of setting image plane tilt ahead directly when designing the large aperture focusing lens to simplify the high NA spectrometer design. By analyzing the accurate demands of the focusing lens, it can be concluded that a focusing lens with image plane tilt has much weaker demand for achromatism, and other monochromatic aberration can also be reduced, which is helpful to increase the NA. An NA0.5 fiber optic spectrometer design is given to demonstrate the proposed method. The design results show that the NA can achieve 0.5 using four lenses of two materials, and the MTF is higher than 0.5 when the spectral dispersion length is 12.5 mm and the pixel size is 25 μm, and thus, the spectral resolution can achieve 6.5 nm when the spectral sampling ratio is 2:1. The proposed method can provide reference for applications when appropriate materials are limited and high sensitivity is necessary. Full article

Lenses have been a cornerstone of optical systems for centuries; however, they are inherently limited by the laws of physics, particularly in terms of size and weight. Because of their characteristic light weight, small size, and subwavelength modulation, metalenses have the potential to miniaturize and integrate imaging systems. However, metalenses still face the problem that chromatic aberration affects the clarity and accuracy of images. A high-quality image system based on the end-to-end joint optimization of a neural network and an achromatic metalens is demonstrated in this paper. In the multi-scale encoder–decoder network, both the phase characteristics of the metalens and the hyperparameters of the neural network are optimized to obtain high-resolution images. The average peak-signal-to-noise ratio (PSNR) and average structure similarity (SSIM) of the recovered images reach 28.53 and 0.83. This method enables full-color and high-performance imaging in the visible band. Our approach holds promise for a wide range of applications, including medical imaging, remote sensing, and consumer electronics. Full article

Dispersion control is a critical aspect in nano-optical systems. Moreover, chromatic aberration significantly impacts image quality. Despite metasurfaces being a novel approach to tackle chromatic aberration in diffractive lenses, numerous challenges hinder their practical implementation due to the complexity of 3D fabrication techniques and high manufacturing costs. In contrast, ultra-thin graphene oxide lenses are simpler and less expensive to manufacture. The optical performance of graphene oxide lenses, such as high focusing efficiency, large depth of field, wide bandwidth, and zooming capability, depends on the design of the positional arrangement of reduced graphene oxide regions. In this study, we utilized the self-constructed datasets to train machine learning models based on the structure of the graphene oxide lens and combined it with intelligent optimization algorithms. This approach facilitated the design of the graphene oxide achromatic lens in multi-wavelengths with high-performance. Experimental results substantiate that the designed ultra-thin graphene oxide lens, with a thickness of ~200 nm, effectively controls dispersion across multiple incident wavelengths (450, 550, and 650 nm) and achieves super resolution with consistent intensity at the focal point. Our graphene oxide lens holds the potential for integration into micro-optical systems that demand dispersion control, providing broad applications in optical imaging, optical communication, the biomedical field, and beyond. Full article

A four-polarisation camera was used to map the absorbance of olivine micro-grains before and after high-temperature annealing (HTA). It is shown that HTA of olivine xenoliths at above 1200 $°$C in O₂ flow makes them magnetised. Different modes of operation of the polariscope with polarisation control before and after the sample in transmission and reflection modes were used. The reflection type was assembled for non-transparent samples of olivine after HTA. The sample for optical observation in transmission was placed on an achromatic, plastic, quarter-wavelength waveplate as a sample holder. Inspection of the sample’s birefringence (retardance), as well as absorbance, was undertaken. The best fit for the transmitted intensity or transmittance T (hence, absorbance $A=-{log}_{10}T$) is obtainable using a simple best fit with only three orientations (from the four orientations measured by the camera). When the intensity of transmitted light at one of the orientations is very low due to a cross-polarised condition (polariser–analyser arrangement), the three-point fit can be used. The three-point fit in transmission and reflection modes was validated for $T\left(\theta \right)=Amp\times cos(2\theta -2{\theta }_{shift})+offset$, where the amplitude $Amp$, offset $offset$, and orientation azimuth ${\theta }_{shift}$ were extracted for each pixel via the best fit. Full article

A multispectral infrared zoom optical system design and a single-frame hierarchical guided filtering image enhancement algorithm are proposed to address the technical problems of low contrast, blurred edges, and weak signal strength of single-spectrum infrared imaging of faint targets, which are easily drowned out by noise. The multispectral infrared zoom optical system, based on the theory of complex achromatic and mechanical positive group compensation, can simultaneously acquire multispectral image information for faint targets. The single-frame hierarchical guided filtering image enhancement algorithm, which extracts the background features and detailed features of faint targets in a hierarchical manner and then weights fusion, effectively enhances the target and suppresses the interference of complex background and noise. Solving multi-frame processing increases data storage and real-time challenges. The experimental verification of the optical system design and image enhancement algorithm proposed in this paper separately verified that the experimental enhancement was significant, with the combined use improving Mean Square Error (MSE) by 14.32, Signal-Noise Ratio (SNR) by 11.64, Peak Signal-to-Noise Ratio (PSNR) by 12.78, and Structural Similarity (SSIM) by 14.0% compared to guided filtering. This research lays the theoretical foundation for the research of infrared detection and tracking technology for clusters of faint targets. Full article

(1) Background: Achromatopsia is a rare disease of which the natural course and impact on life are still unknown to this date. We aimed to assess the morphological, functional characteristics, and quality of life in a large sample size of patients with achromatopsia. (2) A total of 94 achromats were included in this retrospective cohort study. Sixty-four were patients of the Department of Ophthalmology, Saarland University Medical Centre in Homburg/Saar, Germany, between 2008 and 2021. Thirty further participants with achromatopsia from the national support group were included using an online questionnaire, which is available under ‘Supplementary data’. Statistical analysis was performed using SPSS Version 25; (3) The 94 patients (37 males (39.4%) and 57 females (60.6%)) showed a mean age of 24.23 ± 18.53 years. Visual acuity was stable (SD ± 0.22 logMAR at 1.0 logMAR) over a time of observation from 2008 to 2021. Edge filter glasses were the most used optical aids, while enlarged reading glasses were the most used low vision aids. (4) Conclusions: Our findings give an insight into describing the natural process and the quality of life of achromatopsia. The results demonstrate that achromatopsia is a predominantly stationary disease. The individual prescription of edge filters and low-vision aids is essential following a personalised fitting. Full article

Microdrills are specific cutting tools widely used to drill microholes and microvias. For certain microdrill manufacturers, a conventional sampling inspection procedure is still manually operated for carrying out the destructive and visual measurements of two essential cross-sectional geometric parameters (CSGPs), called the cross-sectional web thickness (CSWT) and the cross-sectional outer diameter (CSOD), of their straight (ST) and undercut (UC) type microdrill products. In order to comprehensively automate the conventional sampling inspection procedure, a destructive and visual measuring system improved from an existing vision-aided automation system, for both the hardware and the automated measuring process (AMP), is presented in this paper. The major improvement of the hardware is characterized by a machine vision module consisting of several conventional machine vision components in combination with an innovative and lower cost optical subset formed by a set of plano-concave achromatic (PCA) lenses and a reflection mirror, so that the essential functions of visually positioning the drilltip and visually measuring the CSGPs can both be achieved via the use of merely one machine vision module. The major improvement of the AMP is characterized by the establishment of specific image processing operations for an auto-focusing (AF) sub-process based on two-dimensional discrete Fourier transform (2D-DFT), for a web thickness measuring (WTM) sub-process based on an iterative least-square (LS) circle-fitting approach, and for an outer diameter measuring (ODM) sub-process based on integrated applications of an iterative LS circle-fitting approach and an LS line-fitting-based group-dividing approach, respectively. Experiments for measuring the CSGPs of microdrill samples were conducted to evaluate the actual effectiveness of the developed system. It showed that the developed system could achieve good repeatability and accuracy for the measurements of the CSWTs and CSODs of both ST and UC type microdrills. Therefore, the developed system could effectively and comprehensively automate the conventional sampling inspection procedure. Full article
