Search Results (11)

This work presents an in-depth investigation of the early stages of abnormal grain growth (AGG) in a friction-stir-welded (FSWed) 2519-T820 aluminium alloy. Microstructural evolutions, which occurred during the heating stage of a solution heat treatment (SHT), were studied. It was found that the welded materials underwent a complex sequence of precipitation phenomena, which eventually led to AGG. The evolution of precipitates was found to be heavily dependent on the FSW temperature condition. In a weld produced with a low-heat input, a significant portion of the precipitates were retained in the stir zone after FSW and then underwent coarsening and a subsequent dissolution during the annealing that followed. This led to a reduction in precipitation-pinning forces and thus promoted rapid grain coarsening. In a weld produced with a high-heat input, the initial precipitates were completely dissolved during the FSW, owing to the higher temperature, and then partially re-precipitated during the heating stage of the post-weld heat treatment. Due to the fine-grain structure of the stir zone, re-precipitation typically occurred at grain boundaries, thus promoting significant thermal stability. However, at temperatures approaching the SHT temperature, the new precipitates coarsened and then dissolved, resulting in AGG. Full article

A new cellular automaton (CA) model of abnormal grain growth (AGG) that considers anisotropic grain boundary energies was developed in this paper. The anisotropic grain boundary energy was expressed based on two types of grains, which correspond to two components of different crystallographic orientation in textured materials. The CA model was established by assigning different grain boundary energies and grain-growth-driven mechanisms to four types of grain boundaries formed by two types of grains. The grain boundaries formed by different kinds of grains adopted the lowest energy principle, while the grain boundaries formed by the same kind of grains adopted the curvature-driven mechanism. The morphology calculated by the CA model shows the characteristics of AGG. Then, the Johnson–Mehl–Avrami (JMA) model was fitted to predict the growth kinetics. By analyzing the fitting results, the JMA model is capable of predicting the growth kinetics of AGG. The Avrami exponent p decreases from about 1.5 to 1 with the initial number of Type II grains increasing. The investigation of the Hillert model and grain size distribution further indicates that the microstructure evolution is consistent with AGG. Therefore, the analysis of morphology and kinetics indicates that AGG can be fairly well-simulated by the present CA model. Full article

In this study, the microstructural evolution and the interaction between the clad and the core alloys that occurs during the brazing process of two-layer Al sheets with equiaxed grains were examined. The study was carried out using optical microscopy (OM), scanning electron microscopy (SEM), transmission electron microscopy (TEM), electron backscatter diffraction (EBSD) and glow discharge optical emission spectrometry (GDOES). The effects of microstructure on the brazing performances of two-layer sheets were clarified. Although the grains were fine and equiaxed before brazing, three typical microstructural evolutions happened during brazing, corresponding to three kinds of interactions between the clad and core alloys of the aluminum brazing sheets. In the alloys, which had either relatively uniform grain growth or no grain growth, the interaction between the clad alloy and the core alloy was weak; accordingly, they showed a smooth surface, an even microstructure, faint element mutual diffusion, and eventually good brazeability. Meanwhile, in the alloy with obvious abnormal grain growth (AGG), strain-induced liquid-film migration (SILFM) occurred when the energy was too low to cause strain-induced boundary migration (SIBM). This led to rough and uneven surface morphology, significant mutual diffusion, and surface segregation of elements; eventually, this produced the worst brazeability. Full article

The 5083 and 6061(T6) aluminum (Al) alloys are widely used in transportation industries and the development of structural designs because of their high toughness and high corrosion resistance. Friction stir welding (FSW) was performed to produce the dissimilar welded joint of Al5083-Al 6061(T6) under different welding parameters. However, softening behavior occurred in the friction stir welded (FSWed) samples because of grain coarsening or the dissolution of precipitation-hardening phases in the welding zone. Consequently, this research intended to investigate the effect of the post-weld heat treatment (PWHT) method on the mechanical property improvement of the dissimilar FSWed Al5083-Al6061(T6) and governing abnormal grain growth (AGG) through different welding parameters. The results showed PWHT enhanced the mechanical properties of dissimilar joints of Al5083-Al6061(T6). AGG was obtained in the microstructure of PWHTed joints, but appropriate PWHT could recover the dissolved precipitation-hardening particle in the heat-affected zone of the as-welded joint. Further, the tensile strength of the dissimilar joint increased from 181 MPa in the as-welded joint to 270 MPa in the PWHTed joint, showing 93% welding efficacy. Full article

Matrix microstructure and texture controlling is an important way to optimize Goss ({110}<001>) abnormal grain growth (AGG) in high magnetic induction grain-oriented silicon (Hi-B) steel during primary recrystallization. In the present work, a matrix with homogeneous grain size and favorable texture components was obtained through two-stage normalized annealing followed by primary recrystallization. Furthermore, secondary recrystallization was performed for sharp Goss orientation by slow heating and purified annealing. It was found that plenty of island grains, which occurred and disappeared gradually, accompanied the process of AGG. Through analyzing the evolution of microstructure and texture, we realized that the formation of island grains was related to the large-size grains in matrix, and the elimination of that was attributed to the special grain boundaries which satisfied both coincident site lattice (CSL) and high-energy (HE) models. It was essential to control grain size and favorable orientations in matrix comprehensively for the high-efficient abnormal growing of sharp Goss orientation, through which excellent magnetic properties could be obtained simultaneously. Full article

Despite aluminum profiles, magnesium profiles have not been well developed due to the low formability. Furthermore, extruded magnesium profiles show a strong dependence on the mechanical properties, according to the loading direction. This is caused by a strong basal texture, which is directly dependent on the process parameters during the extrusion and the subsequent aging. Thus, the present paper focuses on the analysis of the microstructure and its evolution of extruded magnesium hollow profiles, which were subjected to a series of heat treatments at 475 °C up to one hour. The hollow profiles were extruded through a porthole die, thus, containing longitudinal weld seams. These were formed by material that underwent heavy shearing along the tool surface based on the friction conditions in the porthole die. Three extrusion ratios (ER = 8:1, ER = 16:1, ER = 30:1) were applied, resulting in three different wall thicknesses of the profiles. The microstructure of the profiles was analyzed using light-optical microscopy (LOM) and scanning electron microscopy (SEM) coupled with electron backscatter diffraction (EBSD). The analysis revealed no change of the microstructure of the profiles extruded at the two higher extrusion ratios within the time frame of the heat treatment. In contrast, the microstructure and, thus, the micro-texture of the profile with the lowest extrusion ratio (ER = 8:1) has been affected to a great extent. While only small changes in microstructure in the weld-free area were observed, the initial microstructure in the weld seam was transformed from fine recrystallized grains into a significantly bimodal microstructure mainly due to an abnormal grain growth (AGG). These changes were accompanied by a promotion of the rare-earth (RE) texture component for the weld-free material and a change of the overall texture from RE to a typical non-RE double fiber texture for the weld seam due to the intense AGG within the short-time heat treatments. In addition, the influence of the extrusion ratio on particle size and distribution as well as the character of the microstructure governing the behavior during heat treatments was analyzed and discussed. Full article

In order to overcome constraints related to crack formation during additive processing (laser powder bed fusion, L-BPF) of Fe-Mn-Al-Ni, the potential of high-temperature L-PBF processing was investigated in the present study. The effect of the process parameters on crack formation, grain structure, and phase distribution in the as-built condition, as well as in the course of cyclic heat treatment was examined by microstructural analysis. Optimized processing parameters were applied to fabricate cylindrical samples featuring a crack-free and columnar grained microstructure. In the course of cyclic heat treatment, abnormal grain growth (AGG) sets in, eventually promoting the evolution of a bamboo like microstructure. Testing under tensile load revealed a well-defined stress plateau and reversible strains of up to 4%. Full article

Friction stir welding (FSW) is an alternative method to join aluminum (Al) alloys in a solid-state condition. However, the coarsening or dissolution of precipitation hardening phases in the welding zone causes strength reduction or softening behavior in the welded area of age-hardened Al alloys. Therefore, this research aimed to improve the mechanical properties of an FSW Al–Mg–Si alloy via post-weld heat treatment (PWHT) and the possibility of controlling the abnormal grain growth (AGG) using different welding parameters. FSW was performed with different rotational and travel speeds, and T6 heat treatment was carried out on the FSW samples as the PWHT. The results showed a decrease in the strength of the FSW samples compared with that of the base material (BM) due to the dissolution of precipitation hardening particles in the heat-affected zone. However, the emergence of AGG in the microstructure after the T6-PWHT was identified as the potential event in the microstructure of the PWHT samples. It is found that the AGG of the microstructure in similar joints of Al6061(T6) was governed by the welding parameters. The results proved that PWHT was able to increase the tensile properties of the welded samples to values comparable to that of Al6061(T6)-BM. The increased mechanical properties of the FSW joints were attributed to a proper PWHT that resulted in a homogeneous distribution of the precipitation hardening phases in the welding zones. Full article

Secondary recrystallization Goss texture was efficiently achieved in rolled, binary Fe₈₁Ga₁₉ alloy sheets without the traditional dependence on inhibitors and the surface energy effect. The development of abnormal grain growth (AGG) of Goss grains was analyzed by quasi-situ electron backscatter diffraction (EBSD). The special primary recrystallization texture with strong {112}–{111}<110> and weak Goss texture provides the inherent pinning effect for normal grain growth by a large number of low angle grain boundaries (<15°) and very high angle grain boundaries (>45°) according to the calculation of misorientation angle distribution. The evolution of grain orientation and grain boundary characteristic indicates that the higher fraction of high energy grain boundaries (20–45°) around primary Goss grains supplies a relative advantage in grain boundary mobility from 950 °C to 1000 °C. The secondary recrystallization in binary Fe₈₁Ga₁₉ alloy is realized in terms of the controllable grain boundary mobility difference between Goss and matrix grains, coupled with the orientation and misorientation angle distribution of adjacent matrix grains. Full article

The occurrence of abnormal grain growth (AGG) of austenite during annealing is a serious problem in steels with carbide and/or nitride particles, which should be avoided from a viewpoint of mechanical properties. The effects of cold deformation prior to annealing on the occurrence of AGG have been investigated. It was found that the temperature range of the occurrence of AGG is shifted toward a low temperature region by cold deformation, and that the shift increases with the increase of the reduction ratio. The lowered AGG occurrence temperature is attributed to the fine and near-equilibrium AlN particles that are precipitated in the cold-deformed steel, which is readily dissolved during annealing. In contrast, coarse and non-equilibrium AlN particles precipitated in the undeformed steel, which is resistant to dissolution during annealing. Full article

Grain boundary engineering (GBE) is a thermomechanical processing technique used to control the distribution, arrangement, and identity of grain boundary networks, thereby improving their mechanical properties. In both GBE and non-GBE metals, the phenomena of abnormal grain growth (AGG) and its contributing factors is still a subject of much interest and research. In a previous study, GBE was performed on minimally strained (ε < 10%), commercially pure Nickel-200 via cyclic annealing, wherein unique onset temperature and induced strain pairings were identified for the emergence of AGG. In this study, crystallographic segmentation of grain orientations from said experiments are leveraged in tandem with image processing to quantify growth rates for abnormal grains within the minimally strained regime. Advances in growth rates are shown to vary directly with initial strain content but inversely with initiating AGG onset temperature. A numeric estimator for advancement rates associated with AGG is also derived and presented. Full article
