A superconducting transition-edge sensor (TES) as a microcalorimeter detects incoming photons by measuring heat converted from photon energy. With high resolving power and low noise levels, a TES is sensitive to single photons and able to count photons within a wide spectral band from X-ray to near-infrared. We have developed a TES detector aiming at soft X-ray spectroscopy applications. In this work, the performance of this detector is characterized. It is shown that the energy resolution of this detector is about 1.8 eV for 1.5 keV photons. The good resolution is also kept in visible range, enabling photon-number resolving for 405 nm photons. Full article

X-ray nanotomography is a powerful tool for the characterization of nanoscale materials and structures, but it is difficult to implement due to the competing requirements of X-ray flux and spot size. Due to this constraint, state-of-the-art nanotomography is predominantly performed at large synchrotron facilities. We present a laboratory-scale nanotomography instrument that achieves nanoscale spatial resolution while addressing the limitations of conventional tomography tools. The instrument combines the electron beam of a scanning electron microscope (SEM) with the precise, broadband X-ray detection of a superconducting transition-edge sensor (TES) microcalorimeter. The electron beam generates a highly focused X-ray spot on a metal target held micrometers away from the sample of interest, while the TES spectrometer isolates target photons with a high signal-to-noise ratio. This combination of a focused X-ray spot, energy-resolved X-ray detection, and unique system geometry enables nanoscale, element-specific X-ray imaging in a compact footprint. The proof of concept for this approach to X-ray nanotomography is demonstrated by imaging 160 nm features in three dimensions in six layers of a Cu-SiO₂ integrated circuit, and a path toward finer resolution and enhanced imaging capabilities is discussed. Full article

The X-ray Integral Field Unit (X-IFU) is one of the two focal plane detectors of Athena, a large-class high energy astrophysics space mission approved by ESA in the Cosmic Vision 2015–2025 Science Program. The X-IFU consists of a large array of transition edge sensor micro-calorimeters that operate at ~100 mK inside a sophisticated cryostat. To prevent molecular contamination and to minimize photon shot noise on the sensitive X-IFU cryogenic detector array, a set of thermal filters (THFs) operating at different temperatures are needed. Since contamination already occurs below 300 K, the outer and more exposed THF must be kept at a higher temperature. To meet the low energy effective area requirements, the THFs are to be made of a thin polyimide film (45 nm) coated in aluminum (30 nm) and supported by a metallic mesh. Due to the small thickness and the low thermal conductance of the material, the membranes are prone to developing a radial temperature gradient due to radiative coupling with the environment. Considering the fragility of the membrane and the high reflectivity in IR energy domain, temperature measurements are difficult. In this work, a parametric numerical study is performed to retrieve the radial temperature profile of the larger and outer THF of the Athena X-IFU using a Finite Element Model approach. The effects on the radial temperature profile of different design parameters and boundary conditions are considered: (i) the mesh design and material, (ii) the plating material, (iii) the addition of a thick Y-cross applied over the mesh, (iv) an active heating heat flux injected on the center and (v) a Joule heating of the mesh. The outcomes of this study have guided the choice of the baseline strategy for the heating of the Athena X-IFU THFs, fulfilling the stringent thermal specifications of the instrument. Full article

We, the QUARTET Collaboration, propose an experiment to measure the nuclear charge radii of light elements with up to 20 times higher accuracy. These are essential both for understanding nuclear physics at low energies, and for experimental and theoretical applications in simple atomic systems. Such comparisons advance the understanding of bound-state quantum electrodynamics and are useful for searching for new physics beyond the Standard Model. The energy levels of muonic atoms are highly susceptible to nuclear structure, especially to the mean square charge radius. The radii of the lightest nuclei (with the atomic number, $Z=1,2$) have been determined with high accuracy using laser spectroscopy in muonic atoms, while those of medium mass and above were determined using X-ray spectroscopy with semiconductor detectors. In this communication, we present a new experiment, aiming to obtain precision measurements of the radii of light nuclei $3\le Z\le 10$ using single-photon energy measurements with cryogenic microcalorimeters; a quantum-sensing technology capable of high efficiency with outstanding resolution for low-energy X-rays. Full article

We report on a new experimental approach for the Doppler correction of X-rays emitted by heavy ions, using novel metallic magnetic calorimeter detectors which uniquely combine a high spectral resolution with a broad bandwidth acceptance. The measurement was carried out at the electron cooler of CRYRING@ESR at GSI, Darmstadt, Germany. The X-ray emission associated with the radiative recombination of cooler electrons and stored hydrogen-like uranium ions was investigated using two novel microcalorimeter detectors positioned under 0${}^{\circ }$ and 180${}^{\circ }$ with respect to the ion beam axis. This new experimental setup allowed the investigation of the region of the N, M → L transitions in helium-like uranium with a spectral resolution unmatched by previous studies using conventional semiconductor X-ray detectors. When assuming that the rest-frame energy of at least a few of the recorded transitions is well-known from theory or experiments, a precise measurement of the Doppler shifted line positions in the laboratory system can be used to determine the ion beam velocity using only spectral information. The spectral resolution achievable with microcalorimeter detectors should, for the first time, allow intrinsic Doppler correction to be performed for the precision X-ray spectroscopy of stored heavy ions. A comparison with data from a previous experiment at the ESR electron cooler, as well as the conventional method of conducting Doppler correction using electron cooler parameters, will be discussed. Full article

With metallic-magnetic calorimeters (MMCs), promising detectors for high-precision X-ray spectrometry in atomic and fundamental physics experiments are available. In this work, we present a pilot experiment based on a maXs-30 type MMC-spectrometer for recording X-rays emitted in collisions of lithium-like uranium ions with a molecular nitrogen gas jet in the internal target of the ESR storage ring of the GSI. Sample spectra have been measured, and a multitude of X-ray transitions have been unambiguously identified. As a first test and for comparison with data recorded at an EBIT, the 2s Lamb shift in lithium-like uranium was estimated. Full article

In this report, we compare two filter algorithms for extracting timing information using novel metallic magnetic calorimeter detectors, applied to the precision X-ray spectroscopy of highly charged ions in a storage ring. Accurate timing information is crucial when exploiting coincidence conditions for background suppression to obtain clean spectra. For X-rays emitted by charge-changing interactions between ions and a target, this is a well-established technique when relying on conventional semiconductor detectors that offer a good temporal resolution. However, until recently, such a coincidence scheme had never been realized with metallic magnetic calorimeters, which typically feature much longer signal rise times. In this report, we present optimized timing filter algorithms for this type of detector. Their application to experimental data recently obtained at the electron cooler of CRYRING@ESR at GSI, Darmstadt is discussed. Full article

The low-energy heavy ion storage ring CRYRING was transported from Stockholm to Darmstadt, modernized and reconfigured, and recommissioned as CRYRING@ESR. The machine is now in operation with all installations in service and is available as a user facility for experiments proposed through the SPARC collaboration. During the 2020–2022 period, we brought a number of experimental installations into service and used them to measure first data: the ultra-cold electron cooler for merged-beam electron–ion collisions, the gas jet target for atomic collisions, a next-generation microcalorimeter-based X-ray spectroscopy setup, and others. Ions can be injected either in low charge states from a local ion source through a 300 keV/u RFQ linac, or in high charge states from the GSI accelerator chain through ESR. This allows for very broad access to ions across the entire periodic table. CRYRING@ESR is able to de- or accelerate ions and cool and store beams of isotopically pure species in a desired charge state. While the analysis is still largely ongoing, the first experimental data already show that the machine reached its expected performance level, and our high expectations regarding achievable resolution in spectroscopy experiments have been fulfilled. With access to new classes of ions available through ESR injection and a new generation of experimental instrumentation, CRYRING@ESR is a unique facility for experiments with heavy, highly charged ions. Here, we will review our present setup and machine performance, discuss the data from our first commissioning experiments and briefly preview the upcoming new installations for the coming years. Full article

Galaxy groups host the majority of matter and more than half of all the galaxies in the Universe. Their hot (${10}^7$ K), X-ray emitting intra-group medium (IGrM) reveals emission lines typical of many elements synthesized by stars and supernovae. Because their gravitational potentials are shallower than those of rich galaxy clusters, groups are ideal targets for studying, through X-ray observations , feedback effects, which leave important marks on their gas and metal contents. Here, we review the history and present status of the chemical abundances in the IGrM probed by X-ray spectroscopy. We discuss the limitations of our current knowledge, in particular due to uncertainties in the modeling of the Fe-L shell by plasma codes, and coverage of the volume beyond the central region. We further summarize the constraints on the abundance pattern at the group mass scale and the insight it provides to the history of chemical enrichment. Parallel to the observational efforts, we review the progress made by both cosmological hydrodynamical simulations and controlled high-resolution 3D simulations to reproduce the radial distribution of metals in the IGrM, the dependence on system mass from group to cluster scales, and the role of AGN and SN feedback in producing the observed phenomenology. Finally, we highlight future prospects in this field, where progress will be driven both by a much richer sample of X-ray emitting groups identified with eROSITA, and by a revolution in the study of X-ray spectra expected from micro-calorimeters onboard XRISM and ATHENA. Full article

The state-of-the-art technology of X-ray microcalorimeters based on superconducting transition-edge sensors (TESs), for applications in astrophysics and particle physics, is reviewed. We will show the advance in understanding the detector physics and describe the recent breakthroughs in the TES design that are opening the way towards the fabrication and the read-out of very large arrays of pixels with unprecedented energy resolution. The most challenging low temperature instruments for space- and ground-base experiments will be described. Full article

Detectors are a key feature of the contemporary scientific approach to cultural heritage (CH), both for diagnostics and conservation. INFN-CHNet is the network of the Italian National Institute of Nuclear Physics that develops and applies new instrumentation for the study of CH. This process results in both optimized traditional state-of-the-art and highly innovative detection setups for spectrometric techniques. Examples of the former are X-rays, gamma-rays, visible-light and particles spectrometers tailored for CH applications, with optimized performances, reliability, weight, transportability, cost, absorbed power, and complementarity with other techniques. Regarding the latter, examples are ARDESIA, the array of detectors at the DAΦNE-Light facility, the MAXRS detection setup at the Riken-RAL muon beamline and the imaging facilities at the LENA Laboratory. Paths for next-generation instruments have been suggested, as in the case of the X-ray Superconductive Detectors and X-ray Microcalorimeter Spectrometers, allowing astonishing improvement in energy resolution. Many issues in CH can now be addressed thanks to scientific techniques exploiting the existing detectors, while many others are still to be addressed and require the development of new approaches and detectors. Full article

X-ray spectroscopy of highly charged heavy ions is an important tool for the investigation of many topics in atomic physics. Such highly charged ions, in particular hydrogen-like uranium, are investigated at heavy ion storage rings, where high charge states can be produced in large quantities, stored for long times and cooled to low momentum spread of the ion beam. One prominent example is the determination of the 1s Lamb Shift in hydrogen-like heavy ions, which has been investigated at the Experimental Storage Ring (ESR) at the GSI Helmholtz Centre for Heavy Ion Research. Due to the large electron binding energies, the energies of the corresponding photon transitions are located in the X-ray regime. To determine the transition energies with high accuracy, highly resolving X-ray spectrometers are needed. One concept of such spectrometers is the concept of microcalorimeters, which, in contrast to semiconductor detectors, uses the detection of heat rather than charge to detect energy. Such detectors have been developed and successfully applied in experiments at the ESR. For experiments at the Facility for Antiproton and Ion Research (FAIR), the Stored Particles and Atoms Collaboration (SPARC) pursues the development of new microcalorimeter concepts and larger detector arrays. Next to fundamental investigations on quantum electrodynamics such as the 1s Lamb Shift or electron–electron interactions in two- and three-electron systems, X-ray spectroscopy may be extended towards nuclear physics investigations like the determination of nuclear charge radii. Full article

This paper presents a study on the carbonation reaction heat and products of tricalcium silicate (C₃S) paste exposed to carbon dioxide (CO₂) for rapid curing. Reaction heat was measured using a retrofitted micro-calorimeter. The highest heat flow of a C₃S paste subject to carbonation curing was 200 times higher than that by hydration, and the cumulative heat released by carbonation was three times higher. The compressive strength of a C₃S paste carbonated for 2 h and 24 h was 27.5 MPa and 62.9 MPa, respectively. The 24-h carbonation strength had exceeded the hydration strength at 28 days. The CO₂ uptake of a C₃S paste carbonated for 2 h and 24 h was 17% and 26%, respectively. The X-ray diffraction (XRD), transmission electron microscope coupled with energy dispersive spectrometer (TEM-EDS), and ²⁹Si magic angle spinning–nuclear magnetic resonance (²⁹Si MAS-NMR) results showed that the products of a carbonated C₃S paste were amorphous silica (SiO₂) and calcite crystal. There was no trace of calcium silicate hydrate (C–S–H) or other polymorphs of calcium carbonate (CaCO₃) detected. Full article
