This article derives approximate formulations for Rayleigh waves on a coated orthorhombic elastic half-space with a prescribed vertical load acting as an elastic Winkler foundation. In addition, perfect continuity conditions are imposed between the coating layer and the substrate, while suitable decaying conditions are slated along the infinite depth of the half-space. The effect of the thin layer is modeled using appropriate effective boundary conditions within the long-wave limit. By applying the Radon transform and using the perturbation method, the derived model successfully captures the physical characteristics of elastic surface waves in coated half-spaces. The model consists of a pesudo-static elliptic equation decaying over the interior of the half-space and a singularly perturbed hyperbolic equation with a pseudo-differential operator. The pseudo-differential equation gives the approximate dispersion of surface waves on the coated half-space structure and is analyzed numerically at the end. Full article

Semiconductor chips on a substrate have a wide range of applications in electronic devices. However, environmental temperature changes may cause mechanical buckling of the chips, resulting in an urgent demand to develop analytical models to study this issue with high efficiency and accuracy such that safety designs can be sought. In this paper, the thermal buckling of chips on a substrate is considered as that of plates on a Winkler elastic foundation and is studied by the symplectic superposition method (SSM) within the symplectic space-based Hamiltonian system. The solution procedure starts by converting the original problem into two subproblems, which are solved by using the separation of variables and the symplectic eigenvector expansion. Through the equivalence between the original problem and the superposition of subproblems, the final analytical thermal buckling solutions are obtained. The SSM does not require any assumptions of solution forms, which is a distinctive advantage compared with traditional analytical methods. Comprehensive numerical results by the SSM for both buckling temperatures and mode shapes are presented and are well validated through comparison with those using the finite element method. With the solutions obtained, the effects of the moduli of elastic foundations and geometric parameters on critical buckling temperatures and buckling mode shapes are investigated. Full article

The design and manufacturing technology of interference-absorbing short-wave filters based on a layered composition of Si–SiO on a sapphire substrate of various shapes was developed. A transition layer of SiO was applied to the surface of the substrate, alternating with layers of Si–SiO with an odd number of quarter-wave layers of materials with high (Si) and low refractive indices (SiO), and the application of an outer layer of SiO as an appropriate control of the materials’ thickness. The optical properties of the infrared light filter were studied. It was established that the created design of the light filter provides the minimum light transmission in the visible region of the spectrum from 0.38 to 0.78 µm and the maximum in the near infrared region from 1.25 to 5 µm and has stable optical indicators. A method for studying the stress–strain state and strength of a multilayer coating of a light filter under the action of a local arbitrarily oriented load was developed. For simplicity in the analysis and for obtaining results in the analytical form, the one-dimensional model of the configuration “multilayer covering—firm substrate” constructed earlier by authors was used. From a mechanical point of view, the upper protective layer of the multilayer coating was modeled by a flexible plate, and the inner operational composite N-layer was subjected to Winkler’s hypothesis about the proportionality of stresses and elastic displacements. Full article

This paper proposes a novel nanobar–substrate medium model for static and free vibration analyses of single-walled carbon nanotube (SWCNT) systems embedded in the elastic substrate medium. The modified strain-gradient elasticity theory is utilized to account for the material small-scale effect, while the Gurtin–Murdoch surface theory is employed to represent the surface energy effect. The Winkler foundation model is assigned to consider the interactive mechanism between the nanobar and its surrounding substrate medium. Hamilton’s principle is used to consistently derive the system governing equation, initial conditions, and classical as well as non-classical boundary conditions. Two numerical simulations are employed to demonstrate the essence of the material small-scale effect, the surface energy effect, and the surrounding substrate medium on static and free vibration responses of single-walled carbon nanotube (SWCNT)–substrate medium systems. The simulation results show that the material small-scale effect, the surface energy effect, and the interaction between the substrate and the structure led to a system-stiffness enhancement both in static and free vibration analyses. Full article

This paper presents an alternative approach to formulating a rational bar-elastic substrate model with inclusion of small-scale and surface-energy effects. The thermodynamics-based strain gradient model is utilized to account for the small-scale effect (nonlocality) of the bar-bulk material while the Gurtin–Murdoch surface theory is adopted to capture the surface-energy effect. To consider the bar-surrounding substrate interactive mechanism, the Winkler foundation model is called for. The governing differential compatibility equation as well as the consistent end-boundary compatibility conditions are revealed using the virtual force principle and form the core of the model formulation. Within the framework of the virtual force principle, the axial force field serves as the fundamental solution to the governing differential compatibility equation. The problem of a nanowire embedded in an elastic substrate medium is employed as a numerical example to show the accuracy of the proposed bar-elastic substrate model and advantage over its counterpart displacement model. The influences of material nonlocality on both global and local responses are thoroughly discussed in this example. Full article

This article presents the effect of taking into account the subgrade coefficient on static work of a pontoon with an internal partition, made in one stage and treated computationally as a monolithic closed rectangular tank. An exemplary pontoon is a single, ready-made shipping element that can be used as a float for a building. By assembling several floats together, the structure can form a floating platform. Due to the increasingly violent weather phenomena and the necessity to ensure safe habitation for people in countries at risk of inundation or flooding, amphibious construction could provide new solutions. This article presents calculations for a real pontoon made in one stage for the purpose of conducting research. Since it is a closed structure without any joint or contact, it can be concluded that it is impossible for water to get inside. However, in order to exclude the possibility of the pontoon filling with water, its interior was filled with Styrofoam. For static calculations, the variational approach to the finite difference method was used, assuming the condition for the minimum energy of elastic deflection during bending, taking into account the cooperation of the tank walls with the Styrofoam filling treated as a Winkler elastic substrate and assuming that Poisson’s ratio ν = 0. Based on the results, charts were made illustrating the change in bending moments at the characteristic points of the analysed tank depending on acting loads. The calculations included hydrostatic loads on the upper plate and ice floe pressure as well as buoyancy, stability and metacentric height of the pontoon. The aim of the study is to show a finished product—a single-piece pontoon that can be a prefabricated element designed for use as a float for “houses on water”. Full article

The paper presents the effect of considering the substrate under the floor—insulation in the form of closed-cell polyurethane spray foam, which is used for insulating surfaces particularly exposed to mechanical impact. The layer of thermal insulation was made by spraying, which prevents the occurrence of thermal bridges due to tight filling of the insulated space. It seems extremely important to adopt the appropriate material characteristics of an insulating layer. The basic thermophysical properties of polyurethane foam justifying its choice as an insulation material were the values of its thermal conductivity coefficient (0.022 W/(mK)) and density (36 kg/m³). However, what was the most important for the calculations provided in the work was to determine the stiffness of the foam subgrade so as to assess its impact on the floor load capacity. The paper includes calculations for a floor slab characterized by a static diagram, with all edges free (unfixed), loaded in strips circumferentially. The reinforced concrete slab was 6 × 6 m long, 0.25 m thick, and made of C20/25 concrete resting on an elastic substrate. Calculations were made for two variants taking into consideration two values of subgrade stiffness. The first variant concerned the subgrade stiffness for sprayed polyurethane foam insulation. On the basis of laboratory tests in situ made according to the standard procedure, its average value was assumed as K = 32,000 kN/m³. The second, comparative, computational variant included the subgrade stiffness equal to K = 50,000 kN/m³. A variation approach to the finite difference method was used for static calculations, adopting the condition for the minimum energy of elastic deformation while undergoing bending that was accumulated in the slab resting on a Winkler elastic substrate. Static calculations resulted in obtaining the values of deflections at each point of the discretization grid adopted for the slab. The obtained results have proved the necessity of calculating the floor as a layer element. For the reference substrate with the subgrade stiffness K = 50,000 kN/m³ that was adopted in the work, the value of the bending moment was 17% lower than when taking into account that there was thermal insulation under the floor slab, causing an increase in the deflection of the slab and an increase in its bending moment. If a design does not include the actual subgrade stiffness of the layer under the floor slab, it results in an understatement of the values of the bending moments on the basis of which the slab reinforcement is designed. Adherence of insufficient concrete slab reinforcement may cause subsequent damage to floor slabs. Full article
