Search Results (31)

Theoretical U-values, which measure thermal transmittance, can be calculated based on the thermal parameters of an opaque element’s layers. However, practical measurements are essential to validate these theoretical values. The heat flux meter (HFM) method, is a widely accepted standard for such measurements. Despite its prevalence, the HFM method faces challenges, including wall surface roughness, ensuring proper contact between measurement devices and surfaces, and weather-related fluctuations. This study introduces a prototype system that employs a modified temperature-based method (TBM) to address these challenges. The paper provides a detailed comparison of thermal transmittance measurements obtained using both the modified TBM and the HFM method. The results showed U-value differences between the two methods. Additionally, these experimental findings were compared with theoretical calculations, highlighting the efficacy and potential of the modified TBM as an alternative approach for accurate U-value determination. Full article

Improving the energy efficiency of buildings is an important element of the effort to address global warming. The thermal performance of building envelopes is the most important thermal and physical property affecting energy performance. Therefore, identifying the thermal performance of a building envelope is essential to applying effective energy-saving measures. The U-value is a quantitative indicator of the thermal performance of the building envelope quantitatively. Methods for determining the U-value are largely classified into passive methods, which use building information without measurement campaigns, and active methods, which conduct in situ measurements. This paper reviews and evaluates the most commonly used methods and experimental results of previous studies to determine the actual U-value of a building envelope. Accordingly, this paper focuses solely on field measurement studies, excluding laboratory measurements. Comparing the existing methods used to determine the U-value can help researchers choose appropriate field measurement methods and future research directions. Full article

In recent decades, the issue of building energy usage has become increasingly significant, and U-values for building envelopes have been key parameters in predicting building energy consumption. This study comprehensively reviews the U-values (thermal transmittances) of building envelopes made from conventional and bio-based materials. First, it introduces existing studies related to the theoretical and measured U-values for four types of building envelopes: concrete, brick, timber, and straw bale envelopes. Compared with concrete and brick envelopes, timber and straw bale envelopes have lower U-values. The differences between the measured and theoretical U-values of timber and straw bale envelopes are minor. The theoretical U-values of concrete and brick envelopes ranged from 0.12 to 2.09 W/m²K, and the measured U-values of concrete and brick envelopes ranged from 0.14 to 5.45 W/m²K. The theoretical U-values of timber and straw bale envelopes ranged from 0.092 to 1.10 W/m²K, and the measured U-values of timber and straw bale envelopes ranged from 0.04 to 1.30 W/m²K. Second, this paper analyses the environmental factors influencing U-values, including temperature, relative humidity, and solar radiation. Third, the relationship between U-values and building energy consumption is also analysed. Finally, the theoretical and measured U-values of different envelopes are compared. Three research findings in U-values for building envelopes are summarised: (1) the relationship between environmental factors and U-values needs to be studied in detail; (2) the gaps between theoretical and measured U-values are significant, especially for concrete and brick envelopes; (3) the accuracy of both theoretical and the measured U-values needs to be verified. Full article

In the context of remodeling old buildings, enhancing insulation performance in the exterior skin necessitates an accurate assessment of a wall’s thermal performance. The conventional method for determining the thermal transmittance (U-value) of a wall is the heat flow meter (HFM) as outlined in the ISO 9869-1. However, this measurement is susceptible to errors influenced by indoor and outdoor environmental conditions and the wall’s material composition. This study evaluates the U-value of an internally insulated wall, specifically constructed for this purpose, utilizing both the average and dynamic methodologies of an HFM. Furthermore, it introduces a novel estimation method: the extended average method (EXAM). The effectiveness of this proposed method is ascertained by comparing the accuracy and convergence of the U-value estimations with those derived from existing methodologies. Additionally, the study explores the limitations of the HFM by analyzing the heat flow traversing the interior of a wall. The findings revealed that the EXAM method enhanced the precision of U-value estimation in all scenarios. Particularly, in walls with superior insulation, the HFM tended to underestimate the heat flow observed indoors, leading to negative errors. The EXAM method, incorporating considerations of both insulation and structural materials, offers an accurate in situ measurement of the U-value relative to the HFM. Full article

Many studies have sought to overcome the two main limitations of the average method of ISO 9869-1—its long test duration and low accuracy. These studies reported that the reliability of the results is dependent on the temperature differences. This consensus was based on the results of studies that measured a few cases with specific temperature differences, and the convergence criteria utilized for the representative thermal transmittance (U-value) were rarely examined. This study analyzed the influence of the average temperature difference and test duration on the convergence characteristics and accuracy of U-value estimation using the average method. Data from a north-facing exterior wall with a theoretical U-value of 0.145 W/m²·K were measured between June 2022 and May 2023. The influences of different measurement conditions were analyzed for cases divided based on four measurement periods and 11 average air temperature differences. The findings show that an accurate U-value can be obtained from 7 days’ worth of measurement data with an average temperature difference of 10 °C or higher and that the improvement in accuracy is minimal under stricter conditions. To achieve a convergence probability of over 90% for temperature differences of 10 °C or greater, the second and third criteria required measurement periods of 7 and 15 days respectively. Full article

The world is emphasizing the need for building design that considers energy performance to deal with climate problems. South Korea has constantly been tightening the design standards for saving building energy but with a focus on thermal performance and equipment systems. Accordingly, this study conducted an energy simulation experiment on office buildings with different window-to-wall ratios (WWRs) to propose a smart glazing plan to improve energy performance. An energy simulation experiment was performed on office buildings with varying WWRs to hierarchically analyze the influence of building window performance elements, including the heat transmission coefficient (U-value), visible light transmittance (VLT), and solar heat gain coefficient (SHGC), on building energy performance. The analysis showed that SHGC had the most significant impact on the heating and cooling load, by 22.13%, with the influences of the variables being 12.4% for the U-value, 4.78% for VLT, and 82.83% for SHGC. The results showed that the solar heat gain coefficient (SHGC) had the greatest impact on energy performance among window performance elements, and the effect increased significantly in certain WWRs. Moreover, to improve the energy performance of buildings with higher WWRs, it is essential to reflect the optimum composition of the U-value and SHGC on the window plan. This study’s findings propose measures to supplement existing window plans focusing on thermal performance. Furthermore, these results hold academic value in providing concrete grounds for that. Full article

The thermal properties of a building envelope are key indicators of the energy performance of the building. Therefore, methods are needed to determine quantities like the thermal transmittance (U-value) or heat capacitance in a fast, reliable way and with as little impact on the use of the building as possible. In this paper a technique is proposed that relies on a simplified electrical analogical model of building envelope components which can cover their dynamic thermal behavior. The parameters of this model are optimized to produce the best fit between simulated and measured outside surface temperatures. As the temperatures can be measured remotely with an infrared camera this approach requires significantly less installation effort and intrusion in the building than other methods. At the same time, a single measurement provides data for a large range of locations on a facade or a roof. The paper describes the method and a first experimental implementation of it. The experiment indicates that this method has the potential to produce results which have an accuracy that is comparable to standardized reference methods. Full article

Different standard methods for the assessment of the thermal performance of the building envelope are used: analogy with coeval building, theoretical method, heat flow meter measurement, simple hot box, infrared thermography, and thermometric method. Review papers on these methods, applied in situ and in laboratory, have been published, focusing on theory, equipment, metrological performance, test conditions and data acquisition, data analysis, benefits, and limitations. However, steps forward have been done and not been deepened in previous works: in fact, the representative points method and the weighted area method have been proposed, too, whilst artificial intelligence and data-driven methods have begun to prove the reliability also in the U-value prevision using available datasets. Considering this context, this work aims at updating the literature background considering exclusively in situ methods. The work starts from bibliometric and scientometric analysis not previously conducted: this helped to group the methods and to sketch the innovations and the future perspectives. Indeed, from the bibliometric and scientometric literature analysis what emerged was (i) the richness of the background on this topic, especially in the recent years, (ii) two macro-groups (methods with and without measurements), and (iii) the importance of paper keywords (otherwise, interesting papers are eluded by the output of simple database queries). The method study that followed aims at providing (i) a broader view of the thermal transmittance (U-value) assessment procedures, including the utmost recent applications, proposal, and outlooks in this field, (ii) the understanding on the fundamental theories of the techniques, (iii) practical advice for building-envelope assessment, focusing on the advantages and limitations useful for professionals and researchers involved in the energy audit, conservation, or refurbishment of building stock, (iv) the identification of the interconnection between the techniques that often rely on one another, and (v) final remarks and future perspective of the procedures, which embrace the use of artificial intelligence (AI). From the topic analysis, as a result, it emerged that this is an open field for future research, especially with the implementation of AI, which requires good datasets and trials on the models’ architectures, in terms of input layer, number of hidden layer and neurons, and percentage of data to be employed for model training and testing. Full article

The Double C Block (DCB) is an innovative composite Concrete Masonry Unit (CMU) developed to offer enhanced thermal performance over standard hollow core blocks (HCBs). The DCB features an original design consisting of a polyurethane (PUR) foam inserted between two concrete c-shaped layers, thus acting as the insulating layer and the binding agent of the two concrete elements simultaneously. The purpose of this research is to describe the results obtained when assessing the thermal transmittance (U_DCB and U_HCB) of these blocks using three different methodologies: theoretical steady-state U-value calculations, numerical simulation using a Finite Element Method (FEM), and in situ monitoring of the U-value by means of the Heat Flow method (HFM). The results obtained show that the three methodologies corroborated each other within their inherent limitations. The DCB showed a performance gap of 52.1% between the predicted FEM simulation (U_DCB was 0.71 W/(m²K)) and the values measured via HFM, which converged at 1.47 W/(m²K). Similarly, a gap of 19.9% was observed when assessing the HCB. The theoretical value via FEM of U_HCB was 1.93 W/(m²K) and the measured one converged at 2.41 W/(m²K). Notwithstanding this, the DCB showed superior thermal performance over the traditional block thanks to a lower U-value, and it complies with the Maltese building energy code. Further improvements are envisaged. Full article

Some of the major challenges of the twenty-first century include the continued increase in energy consumption and environmental pollution. One approach to overcoming these challenges is to increase the use of waste materials and environmentally friendly manufacturing methods. The high energy consumption in the building sector contributes significantly to global climatic changes. Here, by using date palm surface fibers, a high-performance green insulation material was developed via a simple technique that did not rely on any toxic ingredients. Polyvinyl alcohol (PVA) was used as a binding agent. Four insulation samples were made, each with a different density within the range of 203 to 254 kg/m³. Thermal conductivity and thermal diffusivity values for these four green insulators were 0.038–0.051 $\mathrm{W}/\left(\mathrm{m}·\mathrm{K}\right)$ and 0.137–0.147 mm²/s, respectively. Thermal transmittance (U-value) of the four insulation composites was between 3.8–5.1 $\mathrm{W}/{\mathrm{m}}^2·\mathrm{K}$, which was in good comparison to other insulators of similar thickness. Thermogravimetric analysis (TGA) showed that insulating sample have excellent thermal stability, with an initial degradation temperature of 282 °C, at which just 6% of its original weight is lost. Activation energy ($E_a$) analysis revealed the fire-retardancy and weakened combustion characteristics for the prepared insulation composite. According to differential scanning calorimetry (DSC) measurements, the insulating sample has a melting point of 225 °C, which is extremely close to the melting point of the binder. The fiber-based insulating material’s composition was confirmed by using Fourier transform infrared spectroscopy (FTIR). The ultimate tensile range of the insulation material is 6.9–10 MPa, being a reasonable range. Our study’s findings suggest that developing insulation materials from date palm waste is a promising technique for developing green and low-cost alternatives to petroleum-based high-cost and toxic insulating materials. These insulation composites can be installed in building envelopes during construction. Full article

In developed countries, a large part of the building stock in 2050 will consist of currently existing buildings. Consequently, in order to achieve the objectives in terms of energy efficiency in the building sector we must consider not only new infrastructures but also the old ones. A reduction in energy consumption for climate control of between 50 and 90% can be achieved by rehabilitation and the implementation of different energy efficiency measures. Currently, these measures to reduce energy consumption and associated CO₂ emissions can be modelled using computer tools. However, high precision and detail of thermal behaviour models through simulations can mean a great computational cost for companies, which results in a blockage of servers and workers. In this paper, the Response Surface Methodology (RSM) is presented as an innovative methodology for the simplification of models for calculation of the energy savings associated with thermal comfort improvement in buildings. A single-family house model, located in three different climates, is presented as a case study in order to validate the proposed methodology. Different scenarios were simulated, addressing heating and cooling temperature set points and external wall insulation represented by the transmittance (U-value). Results obtained from energy simulation using Design Builder were contrasted against those estimated from the simplified model extracted from the RSM analysis. The results revealed a deviation lower than 3% when comparing both methods. Therefore, the simplified mathematical prediction models are demonstrated to be suitable for the study of the energy performance of buildings, saving computational time, costs and associated human resources. Full article

It is well-known that on-site measurements are suitable for verifying the actual thermal performance of buildings. Performance assessed in situ, under actual thermal conditions, can substantially vary from the theoretical values. Therefore, experimental measurements are essential for better comprehending the thermal behavior of building components, by applying measurement systems and methods suitable to acquire data related to temperatures, heat flows and air speeds both related to the internal and external environments. These data can then be processed to compute performance indicators, such as the well-known thermal transmittance (U-value). This review aims at focusing on two experimental techniques: the widely used and standardized heat flow meter (HFM) method and the quite new thermometric (THM) method. Several scientific papers were analyzed to provide an overview on the latest advances related to these techniques, thus providing a focused critical review. This paper aims to be a valuable resource for academics and practitioners as it covers basic theory, in situ measurement equipment and criteria for sensor installation, errors, and new data post-processing methods. Full article

Hollow concrete masonry blocks made of low strength self-compacting concrete with recycled crushed brick and ground polystyrene as an aggregate (RBC-EP blocks), and their expected structural role as masonry infill in steel frames, has been confirmed in previous research studies, thus the extensive investigation of thermal properties is presented in this paper to fully approve their potential application in practice. The Heat Flow and Temperature Based Method was used to conduct in-situ measurements of the wall thermal transmittance (U-value). The experimental U-values of the wall without insulation varied from 1.363 to 1.782 W/m²·K, and the theoretical value was calculated to be 2.01 W/m²·K. Thermal conductivity of the material used for making RBC-EP blocks was measured in a laboratory by using a heat flow meter instrument. To better understand the thermal performance characteristics of a wall constructed from RBC-EP blocks, a comparison with standard materials currently used and found on the market was performed. Walls constructed from RBC-EP blocks show an improvement of building technology and environmentally based enhancement of concrete blocks, since they use recycled materials. They can replace standard lightweight concrete blocks due to their desired mechanical properties, as well as the better thermal performance properties compared to commonly used materials for building walls. Full article

Three-dimensional-printed concrete (3DPC), which is also termed as digital fabrication of concrete, offers potential development towards a sustainable built environment. This novel technique clearly reveals its development towards construction application with various global achievements, including structures such as bridges, houses, office buildings, and emergency shelters. However, despite the enormous efforts of academia and industry in the recent past, the application of the 3DPC method is still challenging, as existing knowledge about its performance is limited. The construction industry and building sectors have a significant share of the total energy consumed globally, and building thermal efficiency has become one of the main driving forces within the industry. Hence, it is important to study the thermal energy performance of the structures developed using the innovative 3DPC technique. Thermal characterization of walls is fundamental for the assessment of the energy performance, and thermal insulation plays an important role in performance enhancements. Therefore, in this study, different wall configurations were examined, and the conclusions were drawn based on their relative energy performance. The thermal performance of 32 different 3DPC wall configurations with and without cavity insulation were traced using validated finite element models by measuring the thermal transmittance value (U-value). Our study found that the considered 3DPC cavity walls had a low energy performance, as the U-values did not satisfy the standard regulations. Thus, their performance was improved with cavity insulation. The simulation resulted in a minimum thermal transmittance value of 0.34 W/m²·K. Additionally, a suitable equation was proposed to find the U-values of 100 mm-thick cavity wall panels with different configurations. Furthermore, this study highlights the importance of analytical and experimental solutions as an outline for further research Full article

Windows, which have a U-value that is governed by an insulating glass unit (IGU) U-value, must be a building’s only enclosure element, which has no design value concept. The declared U-value, which is calculated or measured with 0 °C of external ambient temperature, is used instead of the design value. For most of a building’s elements, its thermal transmittance with a decrease in the external temperature diminishes a little, i.e., improves. However, for modern window IGUs with Low-E coatings, it is the opposite: the thermal transmittance with a lowering external temperature increases. Therefore, for calculating the peak power for the heating of buildings it is necessary to pay attention to this phenomenon and, therefore, it would be wise to introduce the concept of design U-value for windows, recalculation rules, or affix their declared U-values. This is especially the case in modern times with the prevailing architectural tendencies for enlargement of transparent building elements. For IGUs with Low-E coatings and inert gas fillers, the thermal transmittance depends on the temperature difference between warm and cold environments. When the external temperature is −30 °C instead of 0 °C, the thermal transmittance of the IGU can increase by up to 35%. This study presents the thermal properties of windows’ IGUs depending on the changes in outdoor temperatures by using guarded a hot box climate chamber and presents the proposed simplified methodology for determining the thermal properties of windows’ glass units. The accuracy of the composed simplified methods, comparing the calculated thermal transmittances of IGUs with those measured in the “hot box”, were up to 1.25%. Full article
