Drilling long horizontal wells in naturally cracked/fractured unconventional shale gas/oil formations presents a huge challenge to the energy industry because of wellbore clogging complications that cause pipe sticking problems. This work proposes to use smooth catenary well trajectories to reduce drilling friction to mitigate these problems. A mathematical model was developed in this study for designing well trajectory profiles with a smooth transition from the kick-out point (KOP) to the catenary section. This model consists of closed-form equations for the radius of curvature and inclination angle in the catenary section. Using the radius of curvature at the top point of the catenary section to design the arc section below the KOP eliminates the trial-and-error procedure required for achieving the smooth transition between the two sections. The result of a field case study with Tuscaloosa Marine Shale (TMS) data shows that the drilling drag (hook load) can be reduced by 15% to 30% with the use of smooth catenary well trajectories to replace the conventional arc-type well trajectories. Model-calculated reduction in the hook load drops linearly with the horizontal borehole friction coefficient (clog indicator). The reduction increases non-linearly from 15% to 30% with drill collar weight increasing from 20 lb/ft to 92 lb/ft. Full article

The Tuscaloosa Marine Shale (TMS) is a versatile Late Cretaceous shale formation present in central and SE Louisiana and SW Mississippi, which drew attention because of the various roles played within the Tuscaloosa Group. In this paper, it is debated whether the Tuscaloosa Marine Shale can act as a source, reservoir, or seal all throughout the shale play or only in certain areas. Well log and core data from Adams County, Mississippi, are compared to data from East Feliciana Parish in Louisiana. Conclusions were drawn based on the results of well log analysis, X-ray Diffraction (XRD), porosity–permeability measurements, programmed pyrolysis, and fracture analysis. It was shown that the Tuscaloosa Marine Shale interval in SE Louisiana consists of important amounts of calcite, exhibits multiple natural fractures, has porosity values as high as 9.3%, and shows a TOC content of up to 2.8 wt%. On the other hand, samples from a well at the Cranfield field, MS, are characterized by considerably lower TOC values of around 0.88 wt%, porosities between 0.33% and 4%, and no serious fracturing. The formation demonstrates better reservoir and source potential in SE Louisiana and reliable CO₂ sealing capacity in SW Mississippi. The analysis presented in this paper represents a holistic approach to the characterization of shale formations, is applicable to other plays around the world, and can be used as an integral part of CO₂ sequestration or hydraulic fracturing programs. Full article

In this technical note, a geostatistical model was applied to explore the spatial distribution of source rock data in terms of total organic carbon weight concentration. The median polish kriging method was used to approximate the “row and column effect” in the generated array data, in order for the ordinary kriging methodology to be applied by means of the residuals. Moreover, the sequential Gaussian simulation was employed to quantify the uncertainty of the estimates. The modified Box–Cox technique was applied to normalize the residuals and a cross-validation analysis was performed to evaluate the efficiency of the method. A map of the spatial distribution of total organic carbon weight concentration was constructed along with the 5% and 95% confidence intervals. This work encourages the use of the median polish kriging method for similar applications. Full article

Shale formations are attractive prospects due to their potential in oil and gas production. Some of the largest shale formations in the mainland US, such as the Tuscaloosa Marine Shale (TMS), have reserves estimated to be around 7 billion barrels. Despite their huge potential, shale formations present major concerns for drilling operators. These prospects have unique challenges because of all their alteration and incompatibility issues with drilling and completion fluids. Most shale formations undergo numerous chemical and physical alterations, making their interaction with the drilling and completion fluid systems very complex to understand. In this study, a high-pressure, high-temperature (HPHT) drilling simulator was used to mimic real time drilling operations to investigate the performance of inhibitive drilling fluid systems in two major shale formations (Eagle Ford Shale and Tuscaloosa Marine Shale). A series of drilling experiments using the drilling simulator and clay swelling tests were conducted to evaluate the drilling performance of the KCl drilling fluid and cesium formate brine systems and their effectiveness in minimizing drilling concerns. Cylindrical cores were used to mimic vertical wellbores. It was found that the inhibitive muds systems (KCl and cesium formate) provided improved drilling performance compared to conventional fluid systems. Among the inhibitive systems, the cesium formate brine showed the best drilling performances due to its low swelling rate and improved drilling performance. Full article

Fracture conductivity decline is a concern in the Tuscaloosa Marine Shale (TMS) wells due to the high content of clay in the shale. An analytical well productivity model was developed in this study considering the pressure-dependent conductivity of hydraulic fractures. The log-log diagnostic approach was used to identify the boundary-dominated flow regime rather than the linear flow regime. Case studies of seven TMS wells indicated that the proposed model allows approximation of the field data with good accuracy. Production data analyses with the model revealed that the pressure-dependent fracture conductivity in the TMS in the Mississippi section declines following a logarithmic mode, with dimensionless coefficient χ varying between 0.116 and 0.130. The pressure-dependent decline of fracture conductivity in the transient flow period is more significant than that in the boundary-dominated flow period. Full article
